Tappan TDB210RF Instruction Manual

P30L0080.eps P30C0159.eps P30B0045.eps P30U0024.eps P30M0030.eps P30F0022.eps
P30R0045.eps
Product No. TDB210RFB5 TDB210RFS5
Series 24" Built-in 24" Built-in
Color black white
Owner's Guide English 154648801 154648801
Owner's Guide Spanish 154648803 154648803
Owner's Guide French 154648802 154648802
Service Data Sheet 154441201 154441201
Energy Guide 154678501 154678501
Installation Instructions 154427301 154427301
Market North America North America
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995519120
08/07/17
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
TDB210RF
Copyright ©2008 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995519120 TDB210RF
07/08 2
CONTROL PANEL

TDB210RF Publication No: 5995519120
# Functional Parts 3 07/08
* Non-Illustrated Parts
CONTROL PANEL
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
1 154667301 A - Panel, control, white, w/graphics
1 154667303 - B Panel, control, black, w/graphics
3 # 154437801 A B Timer
3* 154095701 A B Screw, thread rolling, (2), timer
3* 154131204 A B Shield, timer
8 # 154240401 A - Switch, rocker/selector, white
8 # 154240403 - B Switch, rocker/selector, black
8* 5303318719 A B Screw, mtg.
13 154338301 A - Knob, timer, white
13 154338303 - B Knob, timer, black
20 154433001 A B Vent assy, static dry
20* 154436201 A B Screw, dry duct, (3)
* # 154645901 A B Harness, wiring, main
* 154678501 A B Energy guide label

Publication No: 5995519120 TDB210RF
07/08 4
DOOR

TDB210RF Publication No: 5995519120
# Functional Parts 5 07/08
* Non-Illustrated Parts
DOOR
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
1 154430501 A B Spring, door, (2)
1A 154325201 A B Linkage, door spring, (2)
2 154093301 A B Screw, arm assy, (4)
3 154691401 A B Arm Assy, LH
3A 154691301 A B Arm Assy, RH
* 154647101 A B Hinge Pin, arm assy
* 154686401 A B Bearing, hinge pin
5 154079601 A B Nut, arm assy, and handle mtg.
7 154494601 A B Liner, door assy.
9 154574401 A B Dispenser, det/rinse aid, w/o reed
9* 154294701 A B Screw, #7 plas .375, (6), disp. assy.
10 154103702 A B Screw, latch mtg, (2)
12 # 154537301 A - Latch assy, white
12 # 154537303 - B Latch assy, black
20 154359105 A - Door, white
20 154359107 - B Door, black
20* 5304428306 A B Screw, door mtg., (2)
22 154388801 A B Cap, Rinse aid
49 154588201 A B Gasket, door wiper
51 154320301 A B Clamp, drip loop, wire
* 154200601 A B Screw, #10-16 x 3/8

Publication No: 5995519120 TDB210RF
07/08 6
TUB

TDB210RF Publication No: 5995519120
# Functional Parts 7 07/08
* Non-Illustrated Parts
TUB
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
1 # 154730001 A B Tub assy, w/frame parts, white, tower
2 154662601 A B Strike, door
3 # 154561001 A B Gasket, tub
4 154200602 A B Screw, 10-16 x 3/8, hex
5 154333902 A B Roller, tub
6 5303943103 A B Screw, w/washer, (8)
22 154577401 A B Tubing, water inlet
23 5303318539 A B Clamp, tubing, (2)
24 # 154606701 A B Hose, drain
25 # 154209701 A B Float
28 154408701 A B Switch Assy, float
29 # 154290204 A B Thermostat, re-settable
30 154241101 A B Retainer, thermostat
30* 154297701 A B Screw, retainer-thermo
* 5300807270 A B Screw, (2), countertop mtg.
* 154200601 A B Screw, #10-16 x 3/8
* 154685101 A B Gasket, tub, corner, (2)
* 154041001 A B Screw, plask #1, 10-10 x 9/16

Publication No: 5995519120 TDB210RF
07/08 8
MOTOR & PUMP

TDB210RF Publication No: 5995519120
# Functional Parts 9 07/08
* Non-Illustrated Parts
MOTOR & PUMP
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
1 154247601 A B Heater
1* 154106202 A B Nut, heater, (2)
1* 154289801 A B Shield, heater terminal
2 154479601 A B Bracket, heater, (2)
10 154335301 A B Cover, volute
13 154246801 A B Gasket, sump
14 154365903 A B Housing, sump
16 154246502 A B Retainer, sump
24 154567701 A B Spray arm, lower, w/heat shield
24A 154335201 A B Nut, spray arm
40 154348401 A B Clamp, hose, red, push spring, (3)
40 154348502 A B Clamp, red, hose
40* 154380601 A B Clamp, hose, 1.5" open, worm gear, (5)
54 154234401 A B Hose, connector
55 154595901 A B Bracket, motor
55* 5303316032 A B Screw, truss ss, 8 .625, (7)
59 154246901 A B O-ring, rear
59A 154247001 A B O-ring, front
60 # 154640201 A B Drain Pump Assy
60* 154426201 A B Bracket, motor, drain
60* 154581501 A B Screw, drain motor, (3)
63 154252201 A B Base, soil director
64 154332602 A B Filter, soil director
65 154252401 A B Filter, polypro
70 # 154683201 A B Motor & Pump Assy
* 154200601 A B Screw, #10-16 x 3/8

Publication No: 5995519120 TDB210RF
07/08 10
FRAME

TDB210RF Publication No: 5995519120
# Functional Parts 11 07/08
* Non-Illustrated Parts
FRAME
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
3 # 154637401 A B Valve, water
4 154669301 A B Brace, front frame
8 154589401 A - Toeplate, adjustable, white
8 154589403 - B Toeplate, adjustable, black
9 154589501 A - Kickplate Assy, white
9 154589503 - B Kickplate Assy, black
10 154371301 A - Screw, Phillips head, white
10 5300808658 - B Screw, #8A x .375", black
11 154200701 A B Screw, #10-32 x 3/8
11A 154200601 A B Screw, #10-16 x 3/8
15 154571101 A B Leg, leveling, (4)
20 154597001 A B Cover, junction box
* 154041001 A B Screw, plask #1, 10-10 x 9/16
* 154200602 A B Screw, 10-16 x 3/8, hex
* 154409401 A B Screw, #8-18 x .375

Publication No: 5995519120 TDB210RF
07/08 12
RACKS

TDB210RF Publication No: 5995519120
# Functional Parts 13 07/08
* Non-Illustrated Parts
RACKS
Model Index: ATDB210RF (TDB210RFS5)
BTDB210RF (TDB210RFB5)
POS. NO PART NO. DESCRIPTION
1 154331604 A B Rack assy, lower
2 5300808994 A B Basket, silverware
3 154331502 A B Rack assy, upper
4 154522901 A B Wheel & bushing assy, upper rack, (8)
5 5300809927 A B Cap, slide, (4)
6 154597801 A B Slide, rack, upper, (2)
7 154174502 A B Wheel & bracket assy, lower rack
