TARAL 850 User manual

INTRODUCTION
We would like to thank you, our valuable customers, for purchasing this TARAL product.
This instruction manual contains information on the operation, lubrication and maintenance of your tractor. The information contained
is comprehensive and essential, and is designed to assist you, even-if une perienced, in utilizing your Tractor.
If the tractor is sold or transferred to another person, please give this manual to any new owners or operators of the tractor as they
may need the information contained.
If you lose this manual, request a new one from the dealer.
How well your Tractor continues to give satisfactory performance depends greatly upon the manner in which it is operated. It is,
therefore, requested that this manual be read carefully and kept ready for use so that the operation and maintenance services will
properly be carried out in order to keep the tractor in top mechanical condition at all times.
Should any information as to your tractor be required, consult your local dealer or distributor stating the product model and its chassis
and engine serial numbers of the Tractor concerned.
We are sure you will be happy with your Tractor.
NOTE:
The drawings used in this catalogue are for demonstration purposes only and may slightly be different from your tractor.
NOTE:
Keep this tractor instruction manual in a safe and convenient place to avoid any damages or wearing. Read this manual carefully when
you require any information or have concerns about operation and maintenance of your tractor.
NOTE:
E pressions such as LEFT, RIGHT, FRONT or REAR used in this manual should be understood in accordance with following rules:
FRONT means the front grill end while REAR means the lifting arm end of the Tractor. LEFT or RIGHT means the left or right hand side of
the Tractor looking forward from operator's seat.
FRONT
REAR
LEFT
RIGHT

TRACTOR TYPE INFORMATION
Tractor Brand: TARAL
Tractor Type: 800D
Tractor Variant: 850D 4WD SWB ÖR
855D 4WD SWB ÖR
860D 4WD SWB ÖR
856D 4WD SWB ÖR
850G 4WD SWB ÖR
855G 4WD SWB ÖR
860G 4WD SWB ÖR
856G 4WD SWB ÖR
850G 4WD LWB ÖR
855G 4WD LWB ÖR
860G 4WD LWB ÖR
856G 4WD LWB ÖR
850G 4WD LWB AR
855G 4WD LWB AR
860G 4WD LWB AR
856G 4WD LWB AR
Tractor Category: T2
Tractor Trade Name: TARAL 850
TARAL 855
TARAL 860
TARAL 856
TARAL-agrimac 850
TARAL-agrimac 855
TARAL-agrimac 860
TARAL-agrimac 856
Manufacturer of Tractor: TARAL Tarım Makine ve Aletleri
Sanayi A.Ş.
Address: Maltepe Mah. Hastane Yolu Sok.
No:1, 34010, Zeytinburnu,
İstanbul
Telephone: [phone]
Fax: [phone]
[phone]
e-mail: [email protected]
Web site: www.taral.com
ENGINE SERIAL NUMBER:
A: En ine Identification Plate: It is placed on the
cylinder head.
B: En ine Serial Number Barcode: It is placed either
on manifold or cylinder head.
C: En ine Serial Number: It is located at the ri ht
side of the cylinder block, next to injection pump.
TRACTOR IDENTIFICATION PLATE:
It is located at the ri ht side of the tractor tunnel
(service) sheet.
CHASSIS SERIAL NUMBER:
It is placed on transmission case, specifically under
the ri ht side of tractor tunnel (service) sheet.
FRONT AXLE SERIAL NUMBER:
It is placed on the center body of the front axle,
specifically at the front side.

TAKING DELIVERY OF THE
TRACTOR
When your tractor is delivered, ask your dealer to
perform the first operation and provide you
information on instruction and maintenance.
If you have further questions, please contact the
factory.
Make sure all components are installed and in
perfect workin condition before takin the
delivery of the tractor. Make sure all accessories
are provided, the tool box includin all tools is
available and no manual is missin . Two i nition
keys are delivered with the tractor.
Documentation of the tractor:
Instruction Manual
Lo Book
Warranty Card
Service Center List
THE LIFE OF THE TRACTOR
Tractor is desi ned to operate for 10 years.
The life of your tractor may be realized or even
extended by observin the rules and methods
described in this manual, performin scheduled
maintenance before and after warranty period at
authorized maintenance centers and usin ori inal
TARAL spare parts.
WARRANTY
All products manufactured by TARAL and
purchased from authorized dealers and services
are under warranty.
We recommend you to use ori inal TARAL parts
supplied by authorized dealers or services.
Dama es resultin from faulty operation,
insufficient or late maintenance, use of non-
ori inal spare parts or implements not allowed are
not covered under warranty.
NOTE:
The tractor may be operated with several
implements; however, this manual may not ive
information about each possible implement to be
used. Consult your dealer or the factory about the
conformity of such implements which are not
described in this manual, before usin them.
TARAL may not be held liable for the dama es or
unexpected losses that may result from the
incorrect installation, handlin of undescribed or
unapproved implements and/or incorrect
operation of the tractor.
SAFETY
One of the main concerns focused durin the
development and production of the tractor is
operator’s safety. Desi n is composed of several
safety issues.
Despite all these precautions, accidents may still
occur and most of them are caused due to the
safety precautions ne lected.
The best way to prevent accidents is to be aware of
the possible risks and precautions to be taken and
behave accordin ly.
Prior to the operation of the tractor, operator must
be aware and have a throu h understandin of the
safety warnin s and precautions described in this
manual.
All protective elements must be in place and
undama ed, and if dama ed they must be serviced
immediately.
Tractor must not be operated without the operator
is seated. Ensure that all warnin labels is in place
and le ible, and if not, replace the labels.
Operator of the tractor must always be well-rested
and alert and must not be under the influence of
alcohol or dru . Persons who use prescribed
medicines may not use a tractor without the
permission or report by a doctor.

TREATMENT OF A NEW
TRACTOR
All components of your tractor are subject to
strin ent checkin durin assembly in the factory.
However, a new tractor should be carefully
checked over by the operator himself for the first
25—50 hours operation, heavy duty work should
be avoided. If heavy duty work is unavoidable,
drive in a ear one sta e lower than you would
normally use, and run the en ine at lower rpm.
“IMPORTANT”
50 HOURS SERVICE
When the tractor is brand new, after the first 50
hours of runnin , the followin service,
maintenance and checkin should be carried out as
specified below.
1. Replace en ine filter and en ine oil.
2. Replace transmission oil.
3. Replace the oil of front axle.
4. Replace traction oil.
5. Reti hten all bolts and nuts, payin special
attention to those for steerin linka e and
wheel.
6. Check and adjust the fan belt tension.
7. Check the wheels to see if their condition is
ood and tire pressure is correct.
8. Reti hten the cylinder head bolts and adjust
valve clearances.
9. Replace the air cleaner and clean its container.
10. Replace the fuel filter and clean its container.
11. Replace the transmission oil filter and clean its
container.
12. Replace the en ine oil filter and clean its
container.
13. Check the front hub for end-play.
14. Check brake fluid.
15. Check battery char e level.
16. Clean the hydraulic oil filter.
17. Check parkin brake/foot brakes and clutch
pedal free play.
18. Check transmission and en ine link bolts.
This 50-hour Service is an essential procedure for
keepin the tractor in top condition, so it must be
done properly.
