Taurus TT-SB 200 User manual

AFTER SALES SUPPORT
TEL:[phone]
EMAIL: [email protected]
250W
BAND SAW
INSTRUCTION MANUAL
MODEL NUMBER TT-SB 200
N26704

After Sales Support TEL: [phone] EMAIL: [email protected]om
2
Band Saw
What your 1year warranty means
Great care has gone into the manufacture of this product and it should therefore provide you with years of good service
when used properly. In the event of product failure within its intended use over the course of the rst 1year after the date of
purchase we will remedy the problem as quickly as possible once it has been brought to our attention. In the unlikely event of
such an occurrence, or if you require any information about the product, please contact us via our after sales support services,
details of which can be found in this manual and on the product itself.
Welcome Section
Congratulations on choosing to buy a TAURUS® product.
All products brought to you by TAURUS® are manufactured to the highest standards of performance and safety, and,
as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Table of Contents
1. General Safety Rules Pg. 7
2. Special Safety Rules Pg. 8
3. Layout Pg. 10
4. Items Supplied Pg. 10
5. Proper use Pg. 10
6. Technical data Pg. 11
7. Before putting the machine into operation Pg. 11
8. Assembly Pg. 11
9. Control elements Pg. 13
10. Operation Pg. 13
11. Transport Pg. 14
12. Maintenance Pg. 14
13. Ordering spare parts Pg. 14
14. Disposal and recycling Pg. 14

1
2 3
9
13
12
24
12
13
19 20
26
18
6
17
11
10
8
15
3
2
21
25
22
57
1
4
4
14
2
16
23
3
After Sales Support TEL: [phone] EMAIL: [email protected]om

After Sales Support TEL: [phone] EMAIL: [email protected]om
4
4 5
8 9
7
6
27
17
34
37
35 36
37
30
28
27
26
26
33
31
49
28
40

5
After Sales Support TEL: [phone] EMAIL: [email protected]om
12
10 11
14 15
13
38 38
15
15
29
11
26
11
d
41
42
f
3

After Sales Support TEL: [phone] EMAIL: [email protected]om
6
18
16 17
20 21
19
26
g
29
28
28
11
11
24
26
h
15 15
15
21
24
17
29
28

After Sales Support TEL: [phone] EMAIL: [email protected]om
71. General Safety Rules
WARNING! Read all instructions Failure to follow all
instructions listed below may result in electric shock, re and/
or serious injury. The term“power tool’ in all of the warnings
listed below refers to your mains-operated (corded) power
tool or battery-operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
1. Work area
a.
Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
b.
Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
c.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tools plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tool. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b.
Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a.
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious
personal injury.
b. Use safety equipment. Always wear eye protection.
Safety equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the
o-position before plugging in. Carrying power tools
with your nger on the switch or plugging in power tools that
have the switch on invites accidents.
d.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
rotating part of the power tool may result in personal injury.
e.
Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool in
unexpected situations.
f.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can
reduce dust-related hazards.
4. Power tool use and care
a.
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn
it on and o. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c.
Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e.
Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may aect the power
tools operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly
maintained power tools.
f.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
g. Use the power tool, accessories and tool bits etc.
in accordance with these instructions and in the
manner intended for the particular type of power tool,
taking into account the working conditions and the
work to be performed. Use of the power tool for
operations dierent from those intended could result in a
hazardous situation.
5. Service
a.
Have your power tool serviced by a qualied repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
6. Recommendation
a.
We recommend that the tool always be supplied via a residual
current device with a rated residual current of 30 mA or less.

After Sales Support TEL: [phone] EMAIL: [email protected]om
8
2. Special Safety Rules
Important: Whenever you use electric tools it is imperative
to take basic safety precautions in order to reduce the risk
of re, electric shock and personal injury. Essential safety
precautions include:
1. Keep your work area tidy!
- An untidy work area invites accidents.
2. Check the working conditions!
- Do not expose electric tools to rain.
- Never use electric tools in damp or wet locations.
- Make sure there is good lighting.
- Do not use electric tools near ammable liquids or gases.
3. Guard against electric shock!
- Avoid body contact with earthed components.
4.
Keep other persons away!
-
Do not allow other persons, particularly children, to touch
the tool or cable. Keep all persons out of your work area.
5.
Store tools in a safe place!
-When tools are not in use they should be stored in a dry,
locked room out of children’s reach.
6.
Do not overload your tools!
- Tools work better and safer when used within their
quoted capacity range.
7. Use the right tool!
-
Never use tools or attachments with insucient power for
the job in hand.
-
Never use tools on jobs for which they were not intended.
For example, do not use a hand-held circular saw to cut
down trees or lop o branches.
8.
Wear suitable work clothes!
-
Do not wear loose clothing or jewellery as they may get
caught in moving parts.
-
Non-slip shoes are recommended when working outdoors.
- Wear a hair net if you have long hair.
9.
Use personal safety equipment!
- Wear safety goggles.
- Use a dust mask when working on dusty jobs
10.
Connect up a vacuum extraction system!
-
If there are provisions for connecting up a vacuum
extraction system, make sure that such a system is tted
and in use.
11.
Do not mis-use the cable!
-
Do not carry the tool by its cable or pull on the cable to
remove the plug from the socket-outlet.
Protect the cable from heat, oil and sharp edges.
12.
Secure your workpiece!
-
Use clamps or a vice to hold the workpiece securely.
This is safer than using your hand and will enable you to
operate the machine with both hands.
13.
Avoid abnormal working postures!
-
Make sure you stand squarely and keep your balance at
all times.
14. Look after your tools!
-
Keep your tools sharp and clean for better and safer
performance.
-
Follow the instructions for maintenance work and for
changing any attachments.
- Check the plug and cable regularly and, if damaged, have
them replaced by an authorized specialist.
- Check the extension cable regularly and replace it if
damaged.
- Keep handles dry and free from oil and grease.
15. Always pull out the power plug:
-
When the tool is not being used, before carrying out any
maintenance work and when changing attachments such
as blades, bits and cutters of any kind.
16.
Remove adjusting keys and wrenches!
-
Make sure that all keys and adjusting wrenches are
removed from the tool before switching it on.
17. Avoid unintentional starting!
-
Make sure that the switch is in OFF position when
inserting the power plug.
18. When using an extension cable outdoors:
-
Check that it is approved for outdoor duty and is marked
accordingly.
19.
Be alert at all times!
- Watch what you are doing. Use common sense. Do not
operate the tool if your mind is not on your work.
20.
Check the tool for damage!
- Each time before re-using the tool, carefully check that
the guards or any slightly damaged parts are working as
intended.
- Check that the moving parts are in good working order,
that they do not jam, and that no parts are damaged.
-Make sure that all parts are tted correctly and that all
other operating conditions are properly fullled.
-Unless otherwise stated in the operating instructions,
damaged guards and parts have to be repaired or
replaced by an authorised service center.
- Have damaged switches replaced by a customer service
workshop.
-Never use any tool if its switch can not be turned o and on.
21. IMPORTANT!
The use of any accessory or attachment other than
those recommended may involve a risk of injury for you
personally.
22.
Have repairs carried out only by a qualied electrician!
-
This electric tool complies with the pertinent safety
regulations. Repairs are to be carried out only by a
qualied electrician using original replacement parts or
the user may suer an accident.

After Sales Support TEL: [phone] EMAIL: [email protected]om
923.
Wear safety gloves whenever you carry out any
maintenance work on the blade!
24. In the case of mitre cuts when the table is tilted, the guide
must be positioned on the lower part of the table.
25.
When cutting round wood, use a device to stop the
workpiece from twisting.
26.
When cutting boards in upright position, use a device to
prevent kick-back.
27. A dust extraction system designed for an air velocity of
20 m/s should be connected in order to comply with
woodworking dust emission values and to ensure reliable
operation.
28.
Give these safety regulations to all persons who work on
the machine.
29. Do not use this saw to cut re wood.
30.
The machine is equipped with a safety switch to prevent it
being switched on again accidentally after a power failure.
31. Before you use the machine for the rst time, check that
the voltage marked on the rating plate is the same as your
mains voltage.
32. If you use a cable reel, the complete cable has to be pulled
o the reel.
33.
Persons working on the machine should not be distracted.
34.
Note the direction of rotation of the motor and blade.
35. Never dismantle the machine’s safety devices or put them
out of operation.
36.
Never cut workpieces which are too small to hold securely
in your hand.
37.
Never remove loose splinters, chips or jammed pieces of
wood when the saw blade is running.
38.
It is imperative to observe the accident prevention
regulations in force in your area as well as all other
generally recognised rules of safety.
39.
Note the information published by your professional
associations.
40. Position the blade guard so it is approx. 3 mm above the
material you want to saw.
41. Important! Support long workpieces (e.g. with a roller
table) to prevent them sagging at the end of a cut.
42.
Make sure the blade guard is in its lower position when
the saw is being transported.
43.
Safety guards are not to be used to move or mis-use the
machine.
44.
Blades that are misshapen or damaged in anyway must
not be used.
45.
If the table insert is worn, replace it.
46.
Never operate the machine if either the door protecting
the blade or the detachable safety device are open.
47.
Ensure that the choice of blade and the selected speed
are suitable for the material to be cut.
48.
Do not begin cleaning the blade until it has come to a
complete stand still.
49. In the case of straight sawing against the parallel stop, a
push stick must be used.
50.
The bandsaw blade guard should be in its lowest position
close to the bench during transport.
51.
For mitre cuts when the table is tilted, the parallel stop
must be positioned on the lower part of the table.
52. When cutting round timber, use a suitable holding device
to prevent the workpiece turning.
53.
Never use guards to lift or transport items.
54.
Ensure that the bandsaw blade guards are used and
correctly adjusted.
55. Keep your hands a safety distance away from the
bandsaw blade. Use a push stick for narrow cuts.
Caution
Read the operating instructions to reduce the
risk of injury.
Wear ear-mus.
The impact of noise can cause damage to
hearing.
Wear a breathing mask.
Dust which is injurious to health can be
generated when working on wood and other
materials. Never use the device to work on any
materials containing asbestos!
Wear safety goggles.
Sparks generated during working or splinters,
chips and dust emitted by the de-vice can cause
loss of sight.
Pull the power plug before beginning any
repair, cleaning or maintenance work!

After Sales Support TEL: [phone] EMAIL: [email protected]om
10
3. Layout (Figures 1/2)
1. ON/OFF switch
2. Power cord
3. Rubber tires
4. Web panel
5. Machine foot
6. Extractor socket
7. Lower blade pulley
8. Upper blade pulley
9. Tightening screw
10. Blade guard
11. Upper blade guide
12. Side cover
13. Hood closure
14. Retaining screw for upper blade pulley
15. Saw table
16. Dial scale for tilt angle
17. Plastic table insert
18. Fixing handles for saw table
19. Setting handle for blade guide
20. Fixing handle for blade guide
21. Clip for parallel stop
22. Setting screw for upper blade pulley
23. Motor
24. Parallel stop
25. Machine frame
26. Blade
4. Items Supplied
- 1 x Bandsaw
-
1 x Saw table
-
1 x Push stick
-
1 x Parallel stop
-
1 x Instruction Manual
-
1 x Quick Start Guide
- 1 x Warranty Card
- 1 x Warranty Sticker
-
Open the packaging and take our the equipment
with care.
-
Remove the packaging material and any packaging
and/or transportation braces (if available).
- Check to see if all items are supplied.
-
Inspect the equipment and accessories for the
transport damage.
-
If possible, please keep the packaging until the end
of the guarantee period.
Important!
The equipment and packaging material are not toys. Do
not let children play with plastic bags, foils or small parts.
There is a danger of swallowing or suocating! Do not let
children play with plastic bags, foils or small parts. There
is a danger of swallowing or suocating.
5. Proper use
The bandsaw is designed to perform longitudinal and cross
cuts on timber or wood-type materials. To cut round materials
you must use suitable holding devices. The machine is to be
used only for its prescribed purpose.
Any use beyond that mentioned is considered to be a case
of misuse. The user/operator and not the manufacturer shall
be liable for any damage or injury resulting from such cases
of misuse. The machine is to be operated only with suitable
sawblades. To use the machine properly you must also
observe the safety regulations, the assembly instructions and
the operating instructions to be found in this manual.
All persons who use and service the machine have to be
acquainted with this manual and must be informed about the
machine’s potential hazards. It is also imperative to observe
the accident prevention regulations in force in your area.
The same applies for the general rules of occupational health
and safety.
The manufacturer shall not be liable for any changes made to
the machine nor for any damage resulting from such changes.
Even when the machine is used as prescribed it is still
impossible to eliminate certain residual risk factors. The
following hazards may a rise in connection with the machine’s
construction and design:
• Damagetohearingifear-musarenotusedasnecessary
• Harmfulemissionsofwooddustwhenusedinclosedrooms.
• Contactwiththebladeintheuncoveredcuttingzone.
• Injuries(cuts)whenchangingtheblade.Injuryfrom
catapulted workpieces or parts of workpieces.
• Crushedngers.
• Kickback.
• Tiltingoftheworkpieceduetoinadequatesupport.
• Touchingtheblade.
• Catapultingofpiecesoftimberandworkpieces.
Please note that our equipment has not been designed
for use in commercial, trade or industrial applications. Our
warranty will be voided if the machine is used in commercial,
trade or industrial businesses or for equivalent purposes.

After Sales Support TEL: [phone] EMAIL: [email protected]om
11 6. Technical data
Voltage:_______________________________ 230 V ~ 50Hz
Power: _____________________ S1 180 W S2 15 min 250 W
Ideal speed no: ___________________________ 1400 min-1
Blade length:______________________________ 1400 mm
Max blade width: _____________________________ 8 mm
Blade speed: _____________________________900 m/min
Cutting height: __________________________80 mm / 90˚
__________________________________45 mm / 45˚
Throat:____________________________________ 200 mm
Table size: ____________________________ 300 x 300 mm
Tilting range table: __________________________ 0˚ to 45˚
Workpiece size:________________________ 400 x 400 mm
Weight: ____________________________________13.2 kg
Noise emission values
Sound and vibration values were measured inaccordance
with EN 61029.
Cutting
LpA sound pressure level 82.3 dB(A)
KpA uncertainty 3dB
LWA sound power level 92.8 dB(A)
KWA uncertainty 3dB
Load factor:
A load factor of S2 15 min (intermittent periodic duty) means
that you may operate the motor continuously at its nominal
power level (250 W) for no longer than the time stipulated
on the specications label (15minutes ON period). If you fail
to observe this time limit the motor will overheat. During
the OFF period the motor will cool again to its starting
temperature.
Wear ear-mus.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a minimum.
• Only use appliances which are in perfect working order.
• Service and clean the appliance regularly.
• Adaptyourworkingstyletosuittheappliance.
• Donotoverloadtheappliance.
• Havetheapplianceservicedwhenevernecessary.
• Switchtheapplianceowhenitisnotinuse.
Residual risks
Even if you use this electric power tool in accordance with
instructions, certain residual risks cannot be ruled out.
The following hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust mask is used.
2. Damage to hearing if no suitable ear protection isused.
7. Before putting the machine
into operation
• Makesurethemachinestandssecurely,i.e.boltittoa
workbench or solid base. There are two holes for this
purpose in the machine foot.
• Thesawtablemustbemountedcorrectly.
• Allcoversandsafetydeviceshavetobeproperlytted
before the machine is switched on.
• Itmustbepossibleforthebladetorunfreely.
• Whenworkingwithwoodthathasbeenprocessedbefore,
watch out for foreign bodies such as nails or screws etc.
• BeforeyouactuatetheOn/Oswitch,makesurethat
the saw blade is correctly tted and that the machine’s
moving parts run smoothly.
• Beforeyouconnectthemachinetothepowersupply,
make sure the data on the rating plate is the same as that
for your mains.
8. Assembly
Caution! Pull out the power plug before carrying out any
maintenance, resetting or assembly work on the bandsaw!
8.1. Mounting the saw table (Fig. 1 - 5)
• Removethewebpanel(4).
• Placethesawtable(15)onthemachinehousing(25)from
the right and fasten with 3 xing screws (27). Make sure
that the blade (26) is positioned exactly in the center of
the saw table.
• Re-insertthewebpanel(4).
• Inserttheplastictableinsert(17)intothetablefrom
above. Do this in such a way that a through-going slot is
the result.
• Todismantlethesawtable,proceedinreverseorder.
8.2. Tensioning the blade (Fig. 1/6)
• CAUTION!Remove the tension from the blade if the
bandsaw is not going to be used for some time. Be sure to
re-tension the blade before you start the machine.
• Turnthetighteningscrew(9)fortensioningtheblade(26)
in a clockwise direction. The correct blade tension can
be checked by applying pressure to the side of the blade
with your nger, somewhere in the middle between the
two blade pulleys (7 + 8). You should only beable to bend
the blade (26) very slightly (approx.1-2 mm).
•IMPORTANT! The blade may break if the tension is too
high. BEWARE OF INJURY! If the tension is too low, the
powered blade pulley (7) will spin while the blade does
not move.
8.3 Adjusting the blade (Fig. 1/2)
• CAUTION!The blade tension has to be set correctly
before you can adjust the blade.
• Undothefasteners(13)andopenthesidecover(12).

After Sales Support TEL: [phone] EMAIL: [email protected]om
12
• Slowlyturntheupperbladepulley(8)clockwisebyhand.
The blade (26) should run in the middle of the pulley. If
it does not, you will have to adjust the tilt of the upper
blade pulley (8).
• Iftheblade(26)tendstoruntothebackoftheblade
pulley (8), i.e. towards the machine frame(25), turn the
setting screw (22) anti-clockwise while turning the blade
pulley (8) by hand until the blade (26) runs in the middle.
• Iftheblade(26)tendstoruntothefrontedgeof
the blade pulley (8), turn the setting screw (22) in a
clockwise direction.
• Aftersettingtheupperbladepulley(8)youneedtocheck
the blade (26) position on the lower blade pulley (7). The
blade (26) should run in the middle of the blade pulley (7),
as above. If it does not, you will have to adjust the tilt of
the upper blade pulley (8) again.
• Turntheupperbladepulleyseveraltimesuntilthe
adjustment to the upper blade pulley (8) has an eect on
the blade position of the lower blade pulley (7).
• Afteranyadjustmentshavebeencarriedout,theside
covers (12) must be closed again and re-secured with
the fasteners (13).
8.4. Setting the blade guide (Fig. 7 - 10)
Whenever you change the blade you must re-set both the
support bearings (30 + 31) and the guide pins (28 + 29).
• Undothefasteners(13)andopenthesidecover(12).
8.4.1. Upper support bearing (30)
• Undothescrew(33).
• Movethesupportbearing(30)sothatitisnolonger
touching the blade (26). There should be a maximum gap
of 0.5 mm.
• Re-tightenthescrew(33).
8.4.2. Adjusting the lower support bearing (31)
• Dismantlethesawtable(15).
• Swingthebladeguard(34)away.
• Adjustinthesamewaythattheuppersupportbearing
was adjusted.The blade (26) is only supported by the
support bearings (30 + 31) during cutting. When idle the
blade should not touch the ball bearing.
8.4.3. Adjusting the upper guide pins (28)
• UndotheAllenscrew(35)
• Movethemount(36)oftheguidepins(28)sothatthere
is a gap of approx. 1 mm between the front edge of the
guide pins (28) and the gullet of the blade in front.
• Re-tightentheAllenscrew(35).
• CAUTION! The blade will be rendered useless if the teeth
touch the guide pins while the blade is running.
• UndotheAllenscrews(37).
• Movetheguidepins(28)towardsthebladesothatthere
is a gap of approx. 0.5 mm between the guide pins (28)
and the blade (26). The blade must not jam.
• Re-tightentheAllenscrews(37).
• Turntheupperbladepulley(8)severaltimesina
clockwise direction.
• Checkthesettingoftheguidepins(28)againandre-
adjust if necessary.
8.4.4. Adjusting the lower guide pins (29)
• Dismantlethesawtable(15).
• Undothescrew(40).
• Movethemount(49)oftheguidepins(29)sothatthere
is a gap of approx. 1 mm between the front edge of the
guide pins (29) and the gullet of the blade in front.
• Re-tightenthescrew(40).
• CAUTION! The blade will be rendered useless if the teeth
touch the guide pins while the blade is running.
• UndotheAllenscrews(38).
• Movetheguidepins(29)towardsthebladesothatthere
is a gap of approx. 0.5 mm between the guide pins (29)
and the blade (26). The blade must not jam.
• Re-tightentheAllenscrews(38).
• Turnthelowerbladepulley(7)severaltimesina
clockwise direction. Check the setting of the guide pins
(29) again and re-adjust if necessary.
CAUTION! When the adjustments have been nished, the
blade guard (34) must be closed again.
8.5. Adjusting the upper blade guide (Fig.11/Item 11)
• Undothexinghandle(Fig.2/Item20).
• Turnthesettingwheel(Fig.2/Item19)tolowertheblade
guide (Fig.11/Item 11) as close as possible to the work
piece to be cut. The gap should be approx. 2-3 mm.
• Re-tightenthexinghandle(Fig.2/Item20).
• Checkthesettingbeforeeachcutandre-adjustif
necessary.
8.6. Adjusting the machine table (Fig.12/Item 15) to 90°
• Movetheupperbladeguide(Fig.12/Item11)
to the top.
• Undothexinghandles(Fig.2/Item8).
• Settheangle(Fig.12/Item11)betweentheblade
(Fig.12/Item 26) and the table (Fig.12/Item 15).
• Turnthesettingwheel(Fig.12/Item19)totiltthesaw
table (Fig.12/Item 15) until it is at an angle of exactly 90°
to the blade (Fig.12/Item 26).
• Re-tightenthexinghandle(Fig.2/Item18).
• Undothenut(Fig.13/Item42).
• AdjusttheAllenscrew(Fig.13/Item41)untilthereis
contact with the machine frame.
• Re-tightenthenut(Fig.13/Item42)tofastentheAllen
screw (Fig.13/Item 41).

After Sales Support TEL: [phone] EMAIL: [email protected]om
13 8.7. Blade selection
The blade supplied with the bandsaw is designed for all-
purpose use. When you select a blade you should have regard
to the following criteria:
• Useanarrowbladetocuttighterradiusthanyoucanwith
a wider blade.
• Widebladesareusedtosawstraightcuts.Thisis
particularly important in cutting wood because the blade
has a tendency to follow the grain of the wood and there
by deviate easily from the cutting line.
• Finelytoothedbladesprovidesmoothercutsbutare
slower than coarse blades.
Important: Never use warped or lacerated blades!
8.8. Changing the blade (Fig.14)
• Movethebladeguide(Fig.1/Item11)intoaposition
approximately half way between the saw table
(Fig.1/Item 15) and the machine housing (Fig.2/Item 25).
• Undothefasteners(Fig.1/Item13)andopentheside
cover (Fig. 1/Item 12).
• Removethewebpanel(Fig.3/Item4).
• Turnthetighteningscrew(Fig.1/Item9)anti-clockwiseto
remove the tension from the blade (Fig.2/Item 26).
• Removetheblade(Fig.2/Item26)fromthebladepulleys
(Fig.1/Item 7 & 8) and take out through the slot in the table
(Fig.1/Item 15).
• Fitthenewblade(Fig.2/Item26),alignedcentrallyonthe
blade pulleys (Fig.1/Item 7 & 8).
• Theteethoftheblade(Fig.2/Item26)mustpoint
downwards in the direction of the table.
• Tensiontheblade(Fig.2/Item26)(see8.2)
• Closethesidecover(Fig.1/Item12)again.
• Mountthewebpanel(Fig.3/Item4)again.
8.9. Changing the rubber tires on the blade pulleys
After a certain time the rubber tires (Fig.15/Item 3) on the
blade pulleys (Fig.1/Item7 & 8) will get worn by the sharp teeth
of the blades and must be replaced.
• Openthesidecover(Fig.1/Item12).
• Removetheblade(Fig.2/Item26)(see8.7).
• Lifttheedgeofthetire(Fig.15/Item3)withasmall
screwdriver (Fig.15/Item f) and remove from the upper
blade pulley (Fig.1/Item 8).
• Repeatforthelowerbladepulley(Fig.1/Item7).
• Fitthenewtire(Fig.15/Item3),replacetheblade
(Fig.2/Item 26) and close the side cover (Fig.1/Item12).
8.10. Changing the table insert (Fig.16)
To prevent increased likelihood of injury the table insert
(Fig.16/Item 17) should be changed whenever it is worn
or damaged.
• Detachthetable(Fig.1/Item15)(see8.1).
• Liftouttheworntableinsert(Fig.16/Item17).
• Fitthereplacementtableinsertbyfollowingtheabove
in reverse.
8.11. Extractor sockets
The bandsaw is equipped with extractor sockets (Fig.1/Item 6)
for extracting sawdust and chips.
9. Control elements
9.1. On/O switch (Fig.17)
• Toturnthemachineon,pressthegreenbutton“l”(g).
• Toturnthemachineoagain,presstheredbutton“0“(h).
• Yourbandsawhasaswitchwithundervoltagerelease.
After a power failure you must re-activate the switch.
9.2. Parallel stop (Fig.18)
• Pushtheclip(21)ontheparallelstop(24)upwards.
• Movetheparallelstop(24)alongthetable(15),from
either the right or left of the blade (26), and position
as required.
• Pushtheclip(21)downtoxtheparallelstop(24).Ifthe
clip (21) does not give enough hold, turn it clockwise
several times until the parallel stop is securely xed.
• Youmustalwaysensurethattheparallelstop(24)is
positioned parallel to the blade (26).
10. Operation
Caution! After every new adjustment we recommend to make
a trial cut in order to check the new settings.
• Forallcuttingoperationsitisimportanttopositiontheblade
guide (Fig.1/Item 11) as close as possible to the workpiece
(see 8.5).
• Alwaysguidetheworkpiecewithbothhands,holding
it at on the table (Fig.1/Item 15) in order to prevent the
blade (Fig.2/Item 26) from jamming.
• Feedtheworkpieceatauniformspeedthatenablesthe
blade to cut through the material without diculty and
without blocking.
• Alwaysusetheparallelstop(Fig.2/Item26)onallcutsfor
which they are intended.
• Alwaysaimatmakingacompletecutinonepassrather
than in a stop-and-go operation requiring the workpiece
to be withdrawn. If you have to withdraw the workpiece,
switch o the bandsaw rst and wait for the blade (Fig.2/
Item 26) to stop before freeing the workpiece.
• Theworkpiecemustalwaysbeguidedbythelongerside
during cutting.
Important! When handling narrower workpieces, it is
essential to use a push stick.The push stick (Fig.20/Item 28)
must always be kept close at hand at the hook (Fig.20/Item 29)
provided for that purpose on the side of the saw.

After Sales Support TEL: [phone] EMAIL: [email protected]om
14
10.1. Longitudinal cuts (Fig.20)
Longitudinal cutting is when you use the saw to cut along the
grain of the wood.
• Placetheparallelstop(Fig.20/Item24)totheleftofthe
blade (Fig.2/Item 26), as far as possible, for the width
required.
• Lowerthebladeguide(Fig.20/Item11)downtothe
workpiece (see 8.5).
• Switchonthesaw.
• Presstheedgeoftheworkpiecewithyourrighthandto
hold it securely against the parallel stop (Fig.20/Item 24)
and at on the table (Fig.20/Item 15).
• Guidetheworkpiecealongtheparallelstop
(Fig.20/Item 24) and through the blade (Fig.2/Item 26)
at a uniform speed.
• Important: Long workpieces must be secured against
falling o at the end of the cut (e.g. with a roller stand etc.)
10.2. Angular cuts (Fig.19)
To enable you to perform angular cuts parallel to the blade
(Fig.19/Item 26) , the table (Fig.19/Item 15) can be tilted
forwards between 0° - 45°.
• Undothexinghandles(Fig.2/Item18).
• Tiltthesawtable(Fig.19/Item15)forwardsuntilthe
required angle value is set on the dial scale (Fig.2/Item 16).
• Re-tightenthexinghandles(Fig.2/Item18).
• Important: When the table (Fig.19/Item 15) is tilted, place
the parallel stop (Fig.19/ Item 24) to the right of the blade
(Fig.19/Item 26) looking in the direction in which you are
working, on the side pointing downwards (provided the
workpiece is wide enough in order to stop the workpiece
from slipping o).
• Carryoutthecutasdescribedin10.1.
10.3. Freehanded cuts (Figure 21)
One of the most outstanding features of a bandsaw is the ease
with which it allows you to make curved cuts and radius.
• Lowerthebladeguide(Fig.21/Item11)totheworkpiece
(see 8.5).
• Switchonthesaw.
• Holdtheworkpiecesecurelyonthetable(Fig.21/Item15)
and guide slowly through the blade (Fig.2/Item 26).
• Freehandedcutsshouldbemadeatlowfeedspeedso
that you can guide the blade (Fig.2/Item 26) along the
required line.
• Itoftenpaystorstcutosurpluscurvesandcornersup
to about 6 mm from the cutting line.
• Inthecaseofcurveswhicharetootightforthebladeto
cut correctly, it can help to make a series of close-lying
cuts at right angles to the curved line. When you saw the
radius the material will simply drop o.
11. Transport
To transport the bandsaw, hold the supporting foot
(Fig.1/Item 5) with one hand and the frame (Fig.2/Item 25)
with the other hand. Important! Never use guards to lift or
transport the equipment.
12. Maintenance
• Caution! Pull out the power plug rst.
• Removedustanddirtregularlyfromthebandsaw.
Cleaning is best carried out with a ne brush or a cloth.
• Donotusecausticcleaningagentsforcleaningplastic.
13. Ordering spare parts
Contact our After Sales Support on 1300 922 271 and quote
the following data when ordering spare parts:
• Typeofmachine
• Articlenumberofthemachine
• Identicationnumberofthemachine
• Sparepartnumberofthepartrequired
14. Disposal and recycling
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material and
can therefore be reused or can be returned to the raw
material system.
The unit and its accessories are made of various types of
material, such as metal and plastic. Defective components
must be disposed of as special waste. Ask your local council.
