Tayama TG-863XL User manual

Model：TG-863XL
1
Please read all instruction carefully
and keep it for future reference.

○This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision
Keep the appliance and its cord out of reach of children less than 8 years.
○Appliances are not intended to be operated by means of an external timer or separate remote-control
system.
○If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
○The connector must be removed before the appliance is cleaned and that the appliance inlet must be
dried before the appliance is used again.
○The temperature of accessible surfaces may be high when the appliance is operating.
○Please check the device and the electrical wire timely, and stop using if you find some problems of the
device.
○Never immerse the appliance with heating elementˈthe appliance should be switched off at mains when
not in use.
○Use only one appliance per plug and always use an earthed extension cable, with cross section of at
least 1.0mm2
○Do not touch the appliance (cover or grill plate) when cooking in order to prevent any risk of burning.
○The temperature of the surface will be very high when using, please keep it away from tinder.
○This appliance is only use for cooking.
○Never place your appliance on a fragile surface
○Only the appropriate connector must be used.
○The supply cord should be regularly examined for signs of damage, and if the cord is damaged, the
appliance must not be used.
○The appliance must be supplied through a residual current device (RCD) having a rated residual
operating current not exceeding 30 mA.
○The appliance is to be connected to a socket-outlet having an earthing contact.
○Charcoal or similar combustible fuels must not be used with this appliance.
This appliance is intended to be used in household and similar applications such as:
–staff kitchen areas in shops, offices and other working environments;
–farm houses;
–by clients in hotels, motels and other residential type environments;
–bed and breakfast type environments.
COMPONENT:
SAFETY WARNINGS:
2

INSTRUCTIONS FOR SAFE OPERATIONS
1. Please read this instruction manual carefully before using this product.
2. Be sure to check the electric power cable regularly, in case any damage, it must be repaired by the
manufacturer, the servicing department of the agents or similar technicians.
3. The power cable with thermostat can’t be immersed in water in order to avoid electric shock.
4. Do not use this product on inflammables like cloth curtains, tablecloths, carpet, etc.
5. Do not touch the grill plate when the product is still using or its temperature is still very high.
6. If any malfunction for the thermostat, it must be repaired by the manufacturer, the servicing
department of the agents or similar technicians.
7. Be sure to unplug when clean the surface of the grill plate.
8. The appliance connector must be removed before the appliance is cleaned and make sure the
appliance inlet must be dried before the appliance is used again.
9. Only the connector provided by the manufacturer can be used.
10. Charcoal or similar fuels must not be used with appliance.
1. The baffle can be used to prevent the splashing oil or water.
2. Cooked food can put on the rack to keep thermal retardation.
3. Do not touch the rack and baffle when cooking,in order not to get a burn.
4. Make sure the rack and baffle is in correct fitted before use.
zDrip tray
1. Drip tray must be put in the base, and make sure to put the correct place.
2. Put little water into the drip tray to reduce smog, but don’t let the water spill out or reach the heater.
zOperation of the thermostat
1. Turn the Temperature-Controller button to “off”, and inset it in the plughole.
2. Insert the power plug in the outlet.
zTemperature Setting
1. According to cooking needs, adjust the temperature to the set level and the indicator light will turn on.
2. Instructions for Cooking
2.1 After being powered for 3-4 minutes, the temperature will reach an appropriate level and the
indicator lamp will turn off automatically. Put some proper amount of edible oil on the grill plate,
then cook the food.
2.2 If you want to preserve the heat of food, turn the Temperature-Controller button to heat
preservation. Long-term heat preservation will not keep the food fresh.
2.3 When in operation, you may hear a slight sound, there means the product is in use, this does not
indicate trouble with the product.
2.4 Notice
- Do not use a metal scoop to scratch the surface of grill plate.
-The food that can be cooked on the grill plate includes beefsteak, hamburger, roast meat, etc.
-When the meat, beefsteak or hamburger is grilled on the grill plate, the extra grease will flow into
the drip tray, which will result in healthier and more delicious food.
zAfter Use
Rack and Baffle
Operation
3

1. Turn the Temperature-Controller button to “off”.
2. Do not touch the product, as it is still hot after use.
3. Unplug the power plug from outlet.
zGrill plate
1. Before cleaning the grill plate, be sure to confirm that the grill plate has been cooled enough.
2. Clean the grill plate after each use and be sure to remove the plug to avoid scalding.
3. Use paper towel or a dishcloth to wipe off excess messˈdo not wipe with metal or abrasive material.
zThermostat
1. The thermostat must be cleaned with a dry cloth.
2. The thermostat is not allowed to immerse in water.
3. The electric grill can’t use other types of thermostat.
zHandle and Drip tray
Clean the handle and drip tray after use.
zWarning
1. Be careful during use the appliance, since the surface is very hot.
2. Only use the appropriate thermostat.
3. After use, switch off the thermostat
4. The appliance is not intended by the person (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
5. Children should be supervised to ensure that they do not play with the appliance.
6. The appliances are not intended to operate by means of an external timer or separate remote-control
system.
Cleaning and Maintenance
