TC Electronic DBMAX-V 2.90 User manual

DBMAX - V 2.90
DIGITAL BROADCAST MAXIMIZER
English
USER’S MANUAL

a
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8 Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Unplug this apparatus during lightning storms or
when unused for long periods of time.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13 Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has
been dropped.
• This equipment should be installed near the socket
outlet and disconnection of the device should be easily
accessible.
• To completely disconnect from AC mains, disconnect
the power supply cord from the AC receptable.
• The mains plug of the power supply shall remain
readily operable.
• Do not install in a confined space.
• Do not open the unit - risk of electric shock inside.
Caution:
You are cautioned that any change or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Service
• There are no user-serviceable parts inside.
• All service must be performed by qualified personnel.
Warning!
• To reduce the risk of fire or electrical shock, do not
expose this equipment to dripping or splashing and
ensure that no objects filled with liquids, such as vases,
are placed on the equipment.
• This apparatus must be earthed.
• Use a three wire grounding type line cord like the one
supplied with the product.
• Be advised that different operating voltages require the
use of different types of line cord and attachment plugs.
• Check the voltage in your area and use the
correct type. See table below:
Voltage Line plug according to standard
110-125V UL817 and CSA C22.2 no 42.
220-230V CEE 7 page VII, SR section
107-2-D1/IEC 83 page C4.
240V BS 1363 of 1984.
Specification for 13A fused
plugs and switched and
unswitched socket outlets.
The lightning flash with an arrowhead symbol
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated "dan-
gerous voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the product.
IMPORTANT SAFETY INSTRUCTIONS

b
Certificate Of Conformity
TC Electronic A/S, Sindalsvej 34, 8240
Risskov, Denmark, hereby declares on own
responsibility that following products:
DBMAX - Digital Broadcast Maximizer
- that is covered by this certificate and
marked with CE-label conforms with
following standards:
EN 60065 Safety requirements for mains
(IEC 60065) operated electronic and
related apparatus for household
and similar general use
EN 55103-1 Product family standard for
audio,video, audio-visual and
entertainment lighting control
apparatus for professional
use. Part 1: Emission.
EN 55103-2 Product family standard for
audio, video, audio-visual and
entertainment lighting control
apparatus for professional
use. Part 2: Immunity.
With reference to regulations in following
directives:
73/23/EEC, 89/336/EEC
Issued in Risskov, February 1th 1998
Anders Fauerskov
Managing Director
EMC / EMI.
This equipment has been tested and found to comply with
the limits for a Class B Digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection
against harmful interference in residential installations. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on. The user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
For the customers in Canada:
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
IMPORTANT SAFETY INSTRUCTIONS

3
TABLE OF CONTENTS
INTRODUCTION
Table of Contents . . . . . . . . . . . . . . . . . . 3
Quick Start Guide . . . . . . . . . . . . . . . . . . 4
Introduction . . . . . . . . . . . . . . . . . . . . . . . 5
Front Panel . . . . . . . . . . . . . . . . . . . . . . . 6
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 8
Signal flow diagram . . . . . . . . . . . . . . . . . 9
DBMAX setup . . . . . . . . . . . . . . . . . . . . 10
BASIC OPERATION
Reference Levels . . . . . . . . . . . . . . . . . 12
Reference Levels Illustration . . . . . . . . . 14
Recall. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Store - Delete and Preset Names . . . . . 16
MAIN PAGE
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inserts
AGC . . . . . . . . . . . . . . . . . . . . . . . . . 22
Parametric EQ . . . . . . . . . . . . . . . . . 22
90 deg. mono. . . . . . . . . . . . . . . . . . 22
Dynamic Equalizer. . . . . . . . . . . . . . 24
Stereo Enhance . . . . . . . . . . . . . . . . 24
Normalizer . . . . . . . . . . . . . . . . . . . . 26
MS Decoding . . . . . . . . . . . . . . . . . . 26
MS Encoding . . . . . . . . . . . . . . . . . . 26
Expander . . . . . . . . . . . . . . . . . . . . . . . 28
Compressor . . . . . . . . . . . . . . . . . . . . . 30
Limiter. . . . . . . . . . . . . . . . . . . . . . . . . . 34
Inserts - Post Dynamic
Transmission Limiter . . . . . . . . . . . . 36
Production Limiter . . . . . . . . . . . . . . 36
Output
Dither . . . . . . . . . . . . . . . . . . . . . . . . 38
Fade. . . . . . . . . . . . . . . . . . . . . . . . . 38
TC Electronic, Sindalsvej 34, DK-8240 Risskov - [email protected] English version Rev 2.05 - SW - V 2.90
Prod. No: 606054123
Tools
Flow . . . . . . . . . . . . . . . . . . . . . . . . . 40
Surround Meter . . . . . . . . . . . . . . . . 40
Peak-Hold Meter . . . . . . . . . . . . . . . 41
Phase Meter . . . . . . . . . . . . . . . . . . 41
Digital I/O . . . . . . . . . . . . . . . . . . . . . 42
Calibration Tone. . . . . . . . . . . . . . . . 42
Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Reset page . . . . . . . . . . . . . . . . . . . . . . 46
The WIZARD . . . . . . . . . . . . . . . . . . . . . 47
APPENDIX
Trouble Shooting . . . . . . . . . . . . . . . . . . 48
Self test . . . . . . . . . . . . . . . . . . . . . . . . . 49
Technical specifications . . . . . . . . . . . . 50
Tutorial. . . . . . . . . . . . . . . . . . . . . . . . . . 51
Glossary . . . . . . . . . . . . . . . . . . . . . . . . 53
Soldering instructions . . . . . . . . . . . . . . 54
Preset list. . . . . . . . . . . . . . . . . . . . . . . . 56
FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Optional Master Fader. . . . . . . . . . . . . . 59

1 Connect analog and/or digital I/O and power to the unit.
The DBMAX will adapt to the power being used in your
area without you having to select a voltage.
2 Turn on the POWER switch at the rear, and press the
POWER key on the front.
3 On LCD IN page 1, select analog, S/PDIF or AES/EBU
Input.
4 Press the REF. LEVELS key and set your I/O
level conditions:
4.1 If you use analog Inputs or Outputs, adjust the analog level
required for digital full scale by selecting a proper value for
the In Level parameter. When a correct In Level is selected,
the red LEDs on the INPUT meter should never light up,
and indication should be in the -18 to -6dB range.
4.2 Your normal operating level, typically the level at which you
would want a calibration tone, may be set as Reference
Level. In a broadcast environment, the Reference Level
would normally be set 18-20dB below your In Level. If you
only want to relate to digital full scale, turn the Reference
Level all the way up.
4.3 The Abs.Peak Output setting determines the maximum
instant peak Output level from the DBMAX. If you work
against digital peak meters or in transmission, the setting
should be spot on. If you work in an environment depending
on analog PPM meters, this setting should be 3-4 dB above
the maximum level allowed with the meter. If you work
against VU meters, the setting should be 12-20dB above the
0VU level.
5. Press the WIZARD key and select the type of limiting/
compression you want by using the PARAMETER keys
and the ADJUST wheel.
QUICK START
6. Press the OK key. Play some program material and leave
the Wizard working while you are playing a soft part and a
loud part of the type of signal the DBMAX will be
processing. 10 seconds of each will do.
7. Press the OK key again, and the DBMAX has loaded a
best fit parameter setting for your application and source
material.
8. If required, go to the COM block in the MAIN PAGE, and
adjust the More/Less setting to suit your taste. Turning the
control to Less makes the unit behave as a Limiter.
Turning the control to More makes the unit behave like a
maximizer.
9. No more overs. Enjoy!
We recommend you read the entire manual before using the DBMAX, but if you’re anxious to get started we suggest
you take the following steps in the described sequence.
4

5
INTRODUCTION
Useful features for Production
Level settings for a number of Radio and TV stations
5-band parametric EQ insert
Stereo Enhancer insert
90º mono insert
MS Decoding insert
MS Encoding insert
Dynamic EQ and De-esser insert
Production Final Limiter providing PPM attack response
Production Final Limiter providing adjustable Soft-Clip
Dedicated presets for Film and Post Pro Mastering
Dedicated presets for Production Recording
Dedicated presets for CD Mastering
Useful features for Continuity and Transmission
Final TX Limiter providing Emphasis compensated HF limiting
Final TX Limiter providing adjustable Soft-Clip
RS485 remote control
90º mono insert
AGC insert
Stereo Enhancer insert
5-band parametric EQ insert
Dynamic EQ and De-esser insert
Dedicated presets for Continuity Limiting
Dedicated presets for Continuity AGC (1-5 bands)
Dedicated presets for gentle Transmission processing
Dedicated presets for aggressive Transmission processing
General features in the DBMAX version 2.02
Versatile multi-band Compressor/Limiter/Expander with switchable architecture between 1 and 5 bands
Minimum distortion algorithms utilizing 24 and 48 bit processing
New Less/More for control of multi-band compression
Processing at any Sample Rate between 32 and 48kHz
Relay bypass of analog I/O on power-down
Unlock detection of digital Input
Audio bandwidth to 24kHz, or variable lo-pass filtered for FM transmission
24 bit resolution AD and DA converters and built in optional Sample Rate converter
Congratulations on the purchase of your new DBMAX.
We hope that you will have as much pleasure using it as we had making it.
The DBMAX V2.02 is the result of hard work by TC Electronic’s skilled developers, based upon the experience of some of the best
qualified transmission engineers in the business. The DBMAX V2.02 is TC Electronic’s second generation of broadcast compressors.
Stuffed with all the necessary tools, a strong collection of presets as well as a selection of predefined Level setups, the DBMAX could be a
difficult unit to operate. But nicely wrapped in TC’s award winning highly intuitive design, you will soon be ready to operate it.
We invite you to have your Input/Output and reference level specifications included in later software releases. Other DBMAX owners will
then very easily comply with your specifications when delivering program material to your station or production house.
For suggestions please contact TC Electronic at: [e-mail]
Please keep informed on the latest updates either via our internet site at www.tcelectronic.com
or contact TC Electronic directly.

6
FRONT PANEL
INPUT PPM GAIN REDUCTION
METERS
High - Indicating
the max gain
reduction in the two
high freq.bands.
Mid - Indicating the
max gain reduction
in the mid freq.
bands.
Low - Indicating the
max gain reduction
in the two lower
bands.
LIMIT
LEDS
EXPANDER
ACTIVE
INDICATORS
INDICATORS
OVERLOAD LED
Lights up if internal overload
occurs.
INPUT SAMPLE RATE
INDICATOR
48000 Hz
44100 Hz
32000 Hz
MIDI IN LED
MIDI or RS485 receive
indicator.
CARD LED
Indicates presence of a valid
memory card.
ACTIVITY LED
Indicates when a calculation is
performed.
EDITED LED
Indicates that the preset has
been edited.
PC CARD SLOT
Presets may be copied
to/from a standard
PCMCIA/PC-CARD
memory card.
ELECTRONIC POWER
SWITCH
»Easy touch«
Keep pressed for more than
2 seconds to turn device off.
OUTPUT PPM
High resolution meters.
DEFINED OVERLOAD
User defined overload LED.
CLIP LED
Indicates that Output
is clipped.

7
FUNCTIONS SECTION
MAIN PAGE
This key allows you to edit
the entire signal flow, from
Input to Output.
REF. LEVELS
All I/O levels are set here.
TOOLS
This key gives you access to
a lot of useful tools for opti-
mizing your material.
UTILITY
Security, Timing calculations,
Memory management and
others.
PROGRAM SECTION
RECALL
Recall presets.
STORE
Store and name presets.
WIZARD
The Wizard guides you
thru some of the hard work
of finding the correct set-
tings of essential
parameters.
BYPASS
Bypass the signal
processing.
CONTROL SECTION
OK
Confirm operations
and switch individual blocks on/off.
HELP & LOCK
Get help on selected display by
pressing the HELP key.
Press and hold to activate/deactivate
Front Panel Lock function.
BLOCK < >
Select which block to edit on the Main
page.
MENU up/down
Vertically oriented menu selector.
PARAMETER < >
Moves horizontally for selection of
parameter to be modified.
BAND < >
Select between the five bands on the
Com/Lim/Exp pages.
On the EQ page, the BAND keys select
which of the five EQ filters are displayed and
ready for modification.
ADJUST wheel
Sets parameter values and
preset numbers.
FRONT PANEL

8
IN
PIN2+/PIN3- PIN2+/PIN3-
LEFTLEFT
DI
RIGHTRIGHT
DO
DI
DO
S/PDIF
BALANCED OUTPUTS
BALANCED INPUTS DIGITAL AUDIO
AES/EBU
2
13
RS485 GPI
IN
SYNC
SERIAL NO.
TYPE: V002-B
MADE IN DENMARK
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
AVI S:
RISQUE DE CHOC ELECTRIQUE-NE PAS
THIS CLASS B DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS AND
COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION SUBJECT TO CONDITIONS STATED IN THE MANUAL.
OUVRIR.
100-240V 50-60Hz 20W~AC
R
NRTL/C
UL1419
EN 60065
PROFESSIONAL
AUDIO
EQUIPMENT
REAR PANEL
Main
Power
Switch
Balanced
XLR
Inputs
Balanced
XLR
Outputs
Serial No. Word
Clock
Input
AES/EBU
digital
In/Out
S/PDIF
digital
In/Out
RS485
In
Thru
Out
EXTERNAL
CONTROL
Pedal/Fader
Input
NOTES:
To comply with international regulations, we have also added a rear panel POWER switch.
You don’t need to use the POWER switch on the rear panel. Use the front panel POWER switch instead.
Pin 2 is »hot« on all XLR’s (IEC and AES standards). For soldering instructions please refer to page 55.
If you are connecting the DBMAX to unbalanced equipment, you must tie pins 1 and 3 together in the cable
ends away from the DBMAX.
NOTE!
Pins 1 and 3 on the DIN connectors serve as RS485 connection. Therefore, if you are connecting the unit to
other equipment that use these pins, please make sure to use 3-wire standard MIDI type cable (not a five
wire MIDI-PLUS type).
If you want to use the Pedal Input, make sure it is a momentary type.
Power
Input

ANALOG
INPUTS
[balanced]
DBMAX
Trim Input
Internal 44.1kHz
Internal 48kHz
Ext. DI
Clock
Ext. Sync
In Level
Out Fine L/R
Trim Output
ANALOG
OUTPUTS
[balanced]
A/D
INPUT PPM OUTPUT PPM
Defined Overload
Left
Left Left
Right
Bypass
Fader
Right
Right
Input
Selector
Digital Output
[AES]
Digital Input
[AES] AES/EBU
S/PDIF
Digital Output
[S/PDIF]
Digital Input
[S/PDIF]
EXP COMP LIM
Dither
D/A
Ins 4
Ins 1 Ins 2 Ins 3
Digital In Gain
Digital Out Gain
SRC
9
SIGNAL FLOW

10
DBMAX SETUP
The DBMAX is carefully designed to optimize or limit the overall level and enhance the energy in your material.
The use of the five band Compressor, Limiter and Expander makes the dynamics section of the DBMAX very flexible, while
maintaining the fidelity of the original material. The dynamics section, in combination with a Normalizer, AGC, EQ, De-esser
etc. makes the DBMAX a very powerful tool for optimizing the current signal.
Because the DBMAX can be used in different applications, we propose a few different setups.
Radio Production & Transmission applications
DAB production or FM Production suite
The two applications for the DBMAX in this configuration are:
1. The DBMAX can be inserted pre master, to optimize the production.
2. The DBMAX can be inserted post master to emulate the signal processing in transmission.
Transmission
The two applications for the DBMAX in a transmission situation:
1. Digital Broadcast: DBMAX optimizing, limiting and equalizing the signal for digital Audio Broadcast.
2. FM broadcast: DBMAX optimizing, limiting and equalizing the signal in proportion to the current pre-emphasis.

11
TV Production & Transmission applications
Surround Production Suite
The two applications for the DBMAX in this configuration are:
1. The DBMAX can be inserted pre master, to optimize the production.
Note: Adjusting the L/R balance can cause serious changes to the surround encoded signal.
2. The DBMAX can be inserted post master to emulate the signal processing in transmission.
TV continuity/Transmission
The two applications for the DBMAX in a transmission situation are:
1. Digital Sound: DBMAX optimizing, limiting and equalizing the signal for NICAM (or other systems) using the
wordclock as ext. sync.
2. FM Sound: DBMAX optimizing, limiting and equalizing the signal in proportion to the current pre-emphasis,
generating mono (0º or 90º).
DBMAX SETUP

12
REFERENCE LEVELS
The Reference level settings are the heart of the
DBMAX. If these parameters are not set properly, the
DBMAX may not perform correctly. So please take the
time to go through these level settings and make sure
they are set correctly.
The DBMAX is prepared to match several different predefined
Reference Level setups. These setups could be considered as
“level presets”. In addition to these presets you can store four
setups of your own.
Basic operation
- Use the MENU keys to select parameter.
- Use the ADJUST wheel to change value.
Setup
Load Setup
- Select “Load Setup” by pressing the grey OK key, and
scroll through the list using the MENU keys.
- Select an environment/application resembling your own,
and press OK.
Save Setup
It is possible to store four different custom user setups.
- Place the cursor next to ”Save Setup” using the MENU keys.
- Press OK and use the MENU keys to select the location where
you want to store the setup.
- Confirm with OK to store the preset with the same name or
change the name before storing.
To change the name before storing:
- Use the PARAMETER keys to select letter-position and the
ADJUST wheel to select letter.
- When you have the desired name in the display, press OK to
store the setup with the new name.
All parameters in Ref. Levels will be saved.
Operating Levels
General advice
If you use analog Inputs or Outputs, first adjust the analog levels
In Level setting to define the analog level for digital full scale (FS).
The Ref. Levels setting should be adjusted for
nominal signal level, which is both expressed in dBFS (digital) and
dBu (analog). The Abs. Peak max setting should be adjusted for
maximum instant peak permitted Output level.

13
REFERENCE LEVELS
Ref. Level
With Reference level you can set the reference point of the
Compressor to eg. +4dBu. All Thresholds, except the Limiter
Thresholds, are relative to this parameter.
The Reference level parameter is adjustable in dBu and dBFS.
Abs. Peak max
Sets the hardclip point of the DBMAX. Absolute peak means that
notching occurs above this level digitally.
Absolute Peak Max. is adjustable in dBu and dBFS.
Analog Levels
In Level 0dBFS
Sets the dBu level you want to equal to 0dBFS (Full Scale), i.e.
setting this parameter to +18dBu, means that when you are
sending +18 dBu out of your desk, the DBMAX will be showing
0dBFS.
It is very important that you set this parameter correctly as all
other dBu levels are relative to it.
Trim Input
This parameter trims the level of the analog Input for digital full
scale (FS). Correct trimming optimizes the 24 bit AD converters
performance in conjunction with the trimming of the Output
parameters.
Trim Output
Trims the analog Output level. This parameter may be trimmed
in 1dB steps.
Digital Levels
Input Gain
Sets the digital Input level. Use this if you need to trim a source
to a new level. A typical situation could be trimming down the
digital Output of a CD-player.
All trims may be stored using the Save setup command.
Output Gain
Sets the digital Output level.
Define Overload LED
Overload
This parameter allows you to custom-define the DEFINE LED.
The Overload level can be set anywhere between -30 dBFS
and 0 dBFS.
The Overload parameter is adjustable in dBu and dBFS.
Integration
To simulate different types of meters, the defined overload can
work in proportion to an integration time. Digital meters have an
integration time of 0ms where analog meters typically have an
integration time of 10ms.
The Integration time can be set to 0 ms, 1 ms, and 10 ms.
Front Panel Output Meters
Ref
You can set the Output meters to refer to digital Full Scale
(dBFS), which is the default, or Clip which means that the meters
are referring to “Absolute Peak” as 0 dB. When set to Clip you
will take full advantage from the Output meter.
Peak Hold
Set the desired Peak-Hold time with this parameter.
Choose between Off, 1, 2, 5, or 10 seconds.
Clip LED def.
You are able to define when you want the CLIP LEDs to be
activated. Choose the number of consecutive samples to be at
0dbFS before the CLIP LEDs are activated.
Bypass Definition
Att.
When bypassing the DBMAX in this mode the signal will not
exceed the Abs. peak max level set in the Ref. Levels - I/O
Levels menu.
1:1
Use this setting if you want to bypass the signal but apply Dither
and delay.
Thru
Use the Thru setting to bypass the entire signal bit by bit.

14
REFERENCE LEVELS
IN I1 I2 I3 I4EXP COM LIM OUT
Analog In
Digital In
Analog Out
Digital Out
OPERATING LEVELS:
____________________________
Ref. Level : 0dBu
(dBFS) : -18dB
Abs. Peak max : +9dBu
(dBFS) : -9dB
____________________________
ANALOG LEVELS :
In level 0dBFS : +18dBu
Trim Input : 0dB
Trim Output : 0dB
Out Fine L : 0.0dB
Out Fine R : 0.0dB
DIGITAL LEVELS:
Input Gain : 0dB
Output Gain : 0dB

15
Factory
Presets
The DBMAX contains two different preset banks and a card
bank if you use a PCMCIA card.
The RAM bank can hold up to 128 presets.
The RAM preset bank is located after the ROM bank.
The card bank is located after the RAM bank.
Scroll through the ROM presets to enter the RAM bank.
Scroll through the RAM bank to access the CARD bank.
For fast RAM/ROM access use the BLOCK keys
to switch between the banks.
Note: When previewing the RAM bank you will not see the empty
RAM spaces.
Factory/User Presets
RECALL
Select which blocks to load from
the new preset
Preset name
Preset number
Press the RECALL key to enter the Recall page.
To recall/activate a preset:
- Use the ADJUST wheel to scroll through the presets. Until you
confirm your choice you are previewing the presets. At this
stage the OK LED will be blinking.
- When you find the desired preset press OK to recall/confirm.
Recall conditions
It is possible to set up a couple of conditions for the preset that
you are about to recall. Use the MENU keys to step through the
filters.
Recall
This function enables you to make a partial recall where you
recall segments from a new preset and implement them in the
currently recalled preset.
- Use the MENU keys to place the cursor at the Recall line.
- Use the ADJUST wheel to select which parts from the new
preset you wish to implement in the current recalled preset.
Your Recall options are:
All - To recall an entire new preset.
INS 1-3 - To recall all insert settings in Insert 1-3.
XP-COM-LIM - To recall all settings in the Expander,
Compressor and Limiter
I4 - To recall all insert settings in the post
dynamics Insert 4
Category
This filter enables you to select presets by category.
Select “All” or a specific category and you will now only be
previewing presets from the current category.
Select Preset Category
65 ROM
PRESETS
Your own
Presets
128 RAM
PRESETS
Your own
Card Presets
128 CARD
PRESETS
Bank indication
Read only/On air indication

16
STORE - DELETE & PRESET NAMES
Store
Storing a preset with the same name
- Press the STORE key.
- Place the cursor next to the “Name” line (see illustration).
- Select a location for your new preset using the ADJUST wheel (You can store your preset in the RAM bank or the Card bank).
- Press OK and the preset is stored with the same name at the selected location.
Storing a preset with a new name
- Press STORE and place the cursor at the “Name Edit” line using the MENU keys.
- Type the new preset name. Use the PARAMETER keys to select letter position and the ADJUST wheel to select letter.
- Press OK and the preset is stored with the new name at the selected location.
Flags
When storing a preset, you may give it two flags:
ON-AIR :Use the ON-AIR flag for easy identification and
sorting of presets.
READ ONLY :Important presets may be marked with the
READ ONLY for protection. A preset with this
flag cannot be overwritten by another preset.
A pop-up display will tell you that the preset is
write protected.
Note: The READ ONLY flags may be disregarded if you
wish to replace the entire RAM bank from the Utility page.
Deleting a Preset
To delete a preset in the internal RAM bank or PCMCIA card:
- Press STORE.
- Use the MENU keys to move to the top line,
and use the ADJUST wheel to select DELETE.
- Use the MENU keys to move down one line, and choose the
preset you wish to delete by using the ADJUST wheel.
- Press OK.
Overwriting or Deleting
Protected Presets
- Press STORE.
- In the top line use the PARAMETER keys and the ADJUST
wheel to remove the READ ONLY flag.
- Make selections regarding Overwrite, Delete, Location, new
Flags and Title as described above.
- Press OK to store or delete.
Using a Memory Card
If you wish to use a memory card, simply insert the card in the
DBMAX. The DBMAX will now autodetect your card and the
Store and Recall facilities will be attached to the memory card.
If the format of the memory card is not correct, the DBMAX will
detect this immediately.
Card types
Type 1 PCMCIA cards with a minimum of 64KB SRAM and a
maximum of 2 MB.
Mode selection
Name line
Name Edit line
Bank selection
Flag information for
preset protection

17
STORE
What is stored where ?
Global Parameters
Global parameters describe your general working environment:
Inputs used, System delay, Settings for Transmission or
Production etc. Global parameters are not affected by setup or
preset recalls. The parameters include:
- Input and Output Blocks on the Main Page:
Delay, Formats, HP and LP Filters, Rate Conversion, Dither
and Output Fader.
- Parameters in the Utility Page:
Display Angle, RS485, Security, General Purpose Input.
- Parameters in the Tools digital Out Page.
- User Data, Name and Phone and Keyboard lock.
Setup Parameters
Setup parameters describe the interface and Reference Levels in
your environment. Setup parameters are not affected by preset
recalls.
If you need to deliver the same program to different Output level
conditions, you may keep your preset and load a different setup.
Preset parameters may change with every preset and when the
Wizard is invoked.

INPUT I 1
18
MAIN PAGE Input
I 3I 2 EXPANDER COMPRESSOR LIMITER OUTPUTI 4
Input page 1
Input page 2
Black box indicates
selected block
Page select
Input type
selector
Sample Rate
converter on/off
Clock
select
Master Input delay
in milliseconds
Lo Cut adjust Hi Cut adjust Reference level selection
Choose whether the setup
should follow preset changes
or not.
Master Input Delay
in frames pr. second
Process both channels (normal)
or only Left or Right
Delay on/off
switch
