GrandTec Grand Magic Guard III User manual

Grand
Magic Guard III
. . . .
Four Port
Video Monitoring
GrandTec USA
2715 Electronic Lane
Dallas, TX 75220
tel: [phone]
fax: [phone]
2005 GrandTec USA. All trademarks are the property of their respective owners.
Visit us on the web
www.GrandTec.com
Grand Magic Guard III is designed for
security monitoring. The device provides
inputs for four different sources and
outputs to a TV and a VGA monitor. The
output can also be recorded to a VCR.
Real time displays each video in full
screen, 1/4 display area at the same time,
or PIP (Picture In picture).
KEY FEATURES
¾Switchable NTSC, PAL video system
modes.
¾Supports Composite VIDEO, S-
VIDEO and VGA Monitor Outputs
¾VGA Modes: 15.75KHz to 31.5KHz
for NTSC, 15.625KHz to 31.25KHz
for PAL.
¾Supports up to 4 composite video
input connections.
¾Can be displayed TV / VGA monitor
security individually or security
system.
¾Quad Processing: real time display of
each video signal on 1/4 display area
at the same time.
Displays are simulated.
