TCA PR56TC10-BK User manual

56" Pro Series
Top Tool Chest
and Bottom
Roller Cabinet
Chest Models:
PR56TC10-BK
PR56TC10-BL
Cabinet Models:
PR56RC11-BK
PR56RC11-BL
INSTRUCTION MANUAL
www.tcatoolstorage.com

BEFORE YOU START
SAFETY GUIDELINES
THIS MANUAL CONTAINS INFORMATION THAT RELATES TO PROTECTING PERSONAL SAFETY
AND PREVENTING EQUIPMENT PROBLEMS. IT IS VERY IMPORTANT TO READ THIS MANUAL CAREFULLY
AND UNDERSTAND IT THOROUGHLY BEFORE USING THE TOOL CHEST AND CABINET.
DO NOT attempt to lift the chest using chains, ropes
or other lifting devices if two persons cannot lift
the chest by the side handles. Use a forklift placed
under the bottom of the chest if this situation
occurs. The side handles may fail, which may
cause personal injury or damage to the product.
DO NOT stand on this product. You may
fall which may cause personal injury.
WEAR SAFETY GLASSES when removing
or repositioning the slides.
When moving this product, do not pull it. Push
the product to prevent personal injury.
USE THE BRAKES when not moving this product.
This will prevent the product from rolling, which
may cause personal injury or product damage.
DO NOT open more than one drawer at a time.
The product may become unstable and tip, which
may cause personal injury or product damage.
DO NOT mount this product on a truck bed
or any other moving object. This may cause
personal injury or product damage.
Secure this product properly before
moving it with a forklift.
DO NOT tow with power equipment.
The product could tip, which may cause
personal injury or product damage.
DO NOT alter this product in any manner. For
example, do not weld external lock bars or
attach electrical equipment. This may cause
product damage or personal injury.
Keep this product on level surfaces. The
product may become unstable and tip if stored
or moved on an uneven surface, which may
cause personal injury or product damage.
Close the cover and lock the drawers before moving
this product. The drawers could come open and
make the product unstable and tip, which may
cause personal injury or product damage.
When the cover is opened, be sure the cover
stop is in the locked position. This will prevent
accidental closure and personal injury.
BE CAREFUL when closing the cover.
Remove hands before the cover closes
completely to prevent personal injury.
The maximum weight for each drawer should
be no more than 100 kg (220 lbs).
When locking a chest, close the drawers before
closing the cover for lock bars to work properly.
IMPORTANT: Do not attach or mount this product
to a vehicle. Mounting this product to any
vehicle in any manner will void warranty.

PARTS LIST
2
3
6
9
10
8
7
4
12
5
1
Ref. No. Description Part No. Qty. Replacement keys may be ordered using the code that
appears on the face of the lock.
Give this information for spare parts: part number and
quantity.
Not all parts are available under warranty. Those parts
not available may be purchased.
1 Gas Struts 303159 2
2 Connectors 200837 2
3 M6x12 Hex Bolts 321051 2
4 M6×16 Hexagon Socket Head Cap Screws 320111 12
5 Chest Handles 100504 2
6 Slide Sets 300277–
300278
10
7 Drawer Liners 551520 5
8 Drawer Liners 551519 5
9 Lock (001–010) 304197 1
10 Till Liner 551518 1
11 Lid Handle 301649 1
The keys are taped
to the top storage area
of the chest.

PARTS LIST
1
2
4
5
6
8
9
11
10
3
7
12
Ref. No. Description Part No. Qty. Replacement keys may be ordered using the code that
appears on the face of the lock.
Give this information for spare parts: part number and
quantity.
Not all parts are available under warranty. Those parts
not available may be purchased.
1 M6×16 Hexagon Socket Head Cap Screws 320111 12
2 Cabinet Handles 113082 2
3 Slide Sets 300277–
300278
16
4 Swivel Casters with Brakes 302074 4
5 Washers 324000 24
6Spring Washers 324005 24
7 M8x25 Hex Bolts 321047 24
8 Drawer Liners 551520 5
9 Drawer Liners 551519 5
10 Swivel Casters without Brakes 302184 2
11 Lock (001–010) 304197 4
12 Drawer Liner 551521 1
The keys are taped
to the top drawer
of the cabinet.

ASSEMBLY
HANDLE INSTALLATION
NOTE: Assemble the handle first to make it easier
to move the tool cabinet.
Simply position the handle over the holes and attach
with the M6×16 hexagon socket head cap screws
provided. Tighten securely.
CASTER INSTALLATION
NOTE: You may require the assistance of another person
to complete this step.
Carefully lay cabinet on its back with a soft mat
underneath for protection. Position the swivel casters
on the bottom of the cabinet. Insert the M8x25 hex bolts
through washers and spring washers, then through
the casters and into the bottom of the cabinet. Tighten
securely.
Return the cabinet to the upright position.
CHEST AND CABINET CONNECTION
NOTE: You may require the assistance of another person
to complete this step.
Remove the worktop from the cabinet top, if necessary.
Place the chest on the cabinet. Attach the connectors
to the chest, making sure that the hook head snaps in
the square hole on the back of the chest. Fasten the
connector to the cabinet with the provided screws.

OPERATION
RAISE AND RELEASE DRAWER FRONTS
These units are equipped with the raise and release
drawer fronts. To open, lift up on the drawer front while
pulling towards you. To close, shut the drawer firmly until
the latch engages.
If the drawer does not stay closed, the hook may be bent,
or it may be rubbing against the drawer slides. To fix
this problem, lightly bend the hook until the drawer will
engage in the slide. Lift
REMOVING DRAWERS
To remove a drawer, pull the drawer out so it’s almost
fully extended. Push up on the black release lever on one
side, while pulling down on the black release lever on
the other side. While holding the levers in the positions
as instructed above, pull the drawer outward until it is
released from the drawer slide.
REPLACING DRAWERS
Extend the drawer slides from the tool chest or cabinet.
Insert the brackets on each side of the drawer into the
slots in the slides, being careful that they are properly
positioned. Once properly inserted, completely close the
drawer to set the slides in their proper positions.
Push up (one side)
Push down (other side)

MAINTENANCE AND WARRANTY
MAINTENANCE
For casters, use high quality bearing
grease once a year.
Lubricate the slides twice a year with a
spray lubricate or light duty oil.
Periodically clean the drawer fronts, drawer trims
and other surfaces with mild detergent and water.
Grease and oil can be removed with
most standard cleaning fluids.
3-YEAR LIMITED WARRANTY
The manufacturer warrants this product to the original
user against defective material or workmanship for
a period of three years from the purchase date.
The manufacturer reserves the right to determine
whether the part or parts failed because of
defective material, workmanship or other causes.
Also, failures caused by accidents, alterations
or misuse are not covered by this warranty.
The manufacturer, at his discretion, will repair or replace
products covered under this warranty free of charge.
Repairs or replacements of products covered under this
warranty are warranted from the original warranty date.
The manufacturer or his authorised service
representative must perform all warranty repairs.
Any repair warranty is limited to the original user
and may not be transferred to subsequent users.
This warranty is in lieu of all other warranties,
expressed or implied, including warranties of
merchantability and the fitness for a particular purpose.
Some jurisdictions do not allow the exclusion or
limitations of incidental or consequential damages,
so the above limitations may not apply to you.

FORM #: TCA5610/5611-0814
