TCL RAY-DANZ TS9030 User manual

TS9030
RAY·DANZ 3.1 Atmos Sound Bar with
Wireless Subwoofer
User manual

1
Contents
1 Before you begin 3
2 Welcome 4
What’s in the box 4
Overview of the Sound Bar main unit 6
Overview of the wireless subwoofer 8
Remove the Sound Bar back cover 9
Set up your Sound Bar system 9
3 Connect, install and pair 14
Connect to your TV 14
Optional: Connect your Blu-ray player 16
Connect your Sound Bar to power supply 17
Install/replace the remote control batteries 18
Pair your wireless subwoofer to the Sound Bar 19
4 Optional connections 21
Connect with the supplied optical cable 21
Connect with the audio cable 23
Pair the Sound Bar with your Bluetooth device 24

2
5 Use your Sound Bar system 26
Operate your Sound Bar with the top panel 26
Sound Bar LED display 26
Listen to music from your Bluetooth device 28
Use the USB device for music playback 29
6 Specications 30
7 Notice 31
Declaration of conformity 31
Disposal of your old product and battery 31
8 Trademarks 33
9 FAQ 35

3
1 Before you begin
•Carefully read and observe all safety instructions in the safety
leaet
•This soundbar is intended for indoor use only. In case it
accidentally gets in contact with small amounts of water,
unplug immediately and use a dry cloth to remove the
water.
•Unplug the soundbar if it is not used for long periods of
time or during lightning storms.
•Make sure the soundbar is installed on a solid surface
or solidly wall-mounted below your TV for the best
experience.
•Only use AAA 1.5V non-rechargeable batteries for the
remote control.
•In case any of the cables are visibly damaged or pinched,
unplug the soundbar and replace the cable.
•Be careful not to sharply bend the HDMI and optical cable
as they may affect the performance.
•Protect your hearing by adjusting to a proper volume.
Predened and customizable sound settings are available
for your listening comfort.

4
2 Welcome
Congratulations on the purchase of your new TCL Sound
Bar! After it is set up and connected, you can experience a
superb sound quality and state-of-the-art design to best t
your home entertainment system. You are recommended
to read through this user manual which helps you set up,
connect and operate the product easily and properly.
Let’s get started.
What’s in the box
Sound Bar main unit with
wireless subwoofer
Remote control
Wireless subwoofer
HDMI cable

5
Optical cable
AC power cord x 2
AAA battery x 2
Wall mount bracket x 2
Wall screw x 2
Wall anchor x 2
Wall mounting screw x 2
Wall mount template
Quick start guide
Safety
instructions
Safety leaet
QSG

6
Overview of the Sound Bar main unit
HELLO
HELLO
1 2 3 54
6
7
8 9 11 1210
1
Press to turn the Sound Bar main unit on or off.
2
Press to switch the audio source among
AUX/Bluetooth/Optical/HDMI in/HDMI ARC/USB
modes.
3
Press to select the Bluetooth source. Press and hold to
enter pairing mode.
4 -
Press to decrease the volume level.

7
5 +
Press to increase the volume level.
6 LED display
It indicates the Sound Bar status (e.g. volume level,
sound bar status).
7 AC input power connector
8 USB Type A connector (only for music playback)
9 Optical input connector
10 AUX input connector
11 HDMI OUT (ARC) connector
12 HDMI IN connector

8
Overview of the wireless subwoofer
LED
1
2
3
1 AC input power connector
2 Amber LED indicator
• ashes slowly when the subwoofer is in standby
mode.
• ashes slowly when pairing is in progress.
• remains on solidly when pairing is successful.
3 PAIR
Press to activate pairing with the Sound Bar main unit.
Note
•The subwoofer is already paired at the factory. Manual
pairing is needed only in case of troubleshooting.

9
Remove the Sound Bar back cover
Remove the back cover of your Sound Bar before
connecting cables.
Set up your Sound Bar system
Notes
•Make sure you read all the safety information before you
mount the Sound Bar main unit on the wall. (see ‘Before
you begin’ on page 3).
•Make sure you use screws provided or specied by the
authorized manufacturer.
•TCL Corporation bears no responsibility for accidents or
damage caused by improper wall mounting and screws
installation or insufcient wall strength, etc.
•Additional tools (not supplied) are required for
installation.

10
Place your Sound Bar and subwoofer
You are recommended to place the Sound Bar main unit on the top
of the table and right below the center of your TV. The distance
between the subwoofer and the Sound Bar main unit should
be less than 3 meters.
< 3m
TV
Wall mount your Sound Bar main unit
1 Place the supplied wall mount template on the wall.
Make sure the wall mount template is at least 5cm
below the center of the TV.
2 Use a level to make sure the Sound Bar is positioned
accurately.
3 Use the tape to stick the wall mount template rmly on
the wall.
4 Mark on the wall using each marking on the template
through the mounting holes.
5 Take away the wall mount template.
6 Drill a screw hole at each marking on the wall.

11
> 5cm
TV
TV
1
3
2
5
6
4
950mm
7 Insert the supplied wall anchors into 2 screw holes on
the wall.
8 Insert the supplied wall bracket screws through the wall
brackets into the wall anchors.
9 Fix and tighten the screws on the wall.
7 8 9
10
1050 mm / 41.3"

12
10
Insert the supplied wall mounting screws into the screw
holes in the back of the Sound Bar main unit.
7 8 9
10
1050 mm
11
Hang the Sound Bar main unit on the wall mount
brackets.
11

13
Notes
•Check the installation location before you mount the
Sound Bar on the wall.
•You may consider to connect the cables rst before
mounting the Sound Bar on the wall.

14
3 Connect, install and
pair
After you have xed the position of the Sound Bar main unit,
you can start connecting it to your TV, installing the remote
control and pair it with the Sound Bar main unit.
Connect to your TV
Note
•Make sure your TV or device supports the HDMI ARC
feature. For information, check the user manual of your
TV or device.

15
Connect one end of the supplied HDMI cable to the HDMI
input connector on your Sound Bar main unit and another
end to the HDMI ARC output connector of your TV or
device.

16
Optional: Connect your Blu-ray player
For ease of use, you are advised to connect a Blu-ray player
to the TV and enjoy the Sound Bar through HDMI-ARC.
However, in order to enjoy Dolby TrueHD based Atmos
content that not all TVs may support through HDMI-ARC,
you can optionally connect your Blu-ray player directly to
the Sound Bar using the HDMI-in port.
Note
The Sound Bar willl pass on the video signal to the TV. If it
is not successful, turn on the Sound Bar and try again.

17
Connect your Sound Bar to power
supply
1 Make sure that you have completed all other
connections before connecting the Sound Bar to power
supply.
2 Make sure the power supply voltage complies with your
country’s safety standards (see ‘Specications’ on page
30).
3 Connect one end of a supplied AC power cord to the
AC input connector on your Sound Bar main unit and
another end to the power socket on the wall.

18
Install/replace the remote control
batteries
Warnings
•Replace only with same or equivalent types of batteries.
Performance may be affected when using NiMH
rechargable batteries.
1 Open the battery compartment, remove the old batteries
if necessary.
2 Place two new AAA batteries into the battery
compartment with the correct polarity (+/-).
3 Close the battery compartment.
1 2 3
Setup is complete. Your Sound Bar is ready to use. For
more information about how to access different connection
options on your Sound Bar, see the following chapter.

19
Pair your wireless subwoofer to the
Sound Bar
When the wireless subwoofer is connected, you can enjoy
powerful deep bass sounds and a truly immersive audio
experience.
Auto pairing
Make sure both the Sound Bar and wireless subwoofer are
connected to the power supply and are turned on.
 The Sound Bar will pair with the subwoofer
automatically.
 The amber LED will ash when pairing is in progress.
 The amber LED will remain on solidly when pairing is
successful.
Note
• Do not press PAIR at the back of the wireless
subwoofer during auto pairing.
• If auto pairing is not successful, you can pair the
subwoofer with the Sound Bar manually.
