Soundstream T5 Series T5-10 User manual

Woofer & Enclosure
Information

Congratulations on your new Soundstream sub-woofer purchase. We
greatly appreciate your business. This may look like is a run of the mill
cardboard box, but is actually a protective barrier over one of the finest
engineered and assembled subwoofer available.
Harmonic Indulgence… Listen and Feel
series wired T5-10 T5-12 T5-15
Rms Power 800 900 1000
Cutout Dia. 9.000 11.125 14.250
Voice Coil DVC 2 ΩDVC 2 ΩDVC 2 Ω
Fs 35.88 30.47 27.83
Qms 4.633 4.502 5.075
Vas (ft^3) .706 1.266 2.984
Cms (mm/N) .098 .084 .079
Mms (g) 203.7 326.5 429.0
Rms (kg/s) 9.823 13.840 14.290
Xmax (mm) 13.00 14.00 14
Sd (in^2) 58.90 83.70 136.50
Qes .505 .472 .526
Re 3.20 3.20 3.20
Z444
BL (Telsa) 17.07 20.57 21.36
Qts .455 .427 .476
1w/1m SPL 84.47 85.05 87.25
Depth 6.625 7.125 9.125
Soundstream does not provide enclosure dimensions as there are
infinite variables when designing a box, i.e. vehicle, amplifier, music
preferences, etc… For designs tailored to your specific needs, please
contact us at tech-suppor[email protected]
All enclosures should be made of .75” (3/4”) material only. When
possible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the
depth of the enclosure to compensate. All volumes INCLUDE
vent/port and subwoofer displacements. DO NOT change the volume
unless you plan on adding a substantial amount of bracing. For added
performance, applying a coat of fiberglass resin to the interior walls
will greatly improve sealing the enclosure. Adding a thin layer of poly-
fill will improve response by smoothing out reflections within the
enclosure
T5-10 Ported T5-12 Ported T5-15 Ported
Vol. Port FB/F3 Vol. Port FB/F3 Vol. Port FB/F3
Min 1.25 3x9.5 38/33 2.00 4x10 38/32 2.50 4x8 36/32
Opt 1.50 4x18 36/31 2.50 4x8 36/30 3.00 (2)4x19.75 34/30
Max 1.75 4x16.5 34/29 3.00 (2)4x20 34/29 3.50 (2)4x18.5 32/28
54.5512.5059.5351.5075.4851.00
Max
54.5812.0057.5911.0074.512.75
Opt
53.6281.5057.644.7573.565.5
Min
F3QtcVol.F3QtcVol.F3QtcVol.
T5-15 SealedT5-12 SealedT5-10 Sealed
