Figures and illustrations in this User’s Guide are
provided for reference only and may dier from
actual product appearance. Product design and
specications may be changed without notice.
L49C2US L55C2US L65C2US

EN 1
English
Important information and manual
Safety
Ensure that your domestic mains supply voltage matches the voltage
indicated on the identication sticker located at the back of your set.
Where the mains plug, AC inlet or an appliance coupler is used as
disconnect device, it shall remain readily operable.
On certain models, the light indicator is located at the side of the TV
set. The absence of a light indication at the front does not mean that
the TV set is fully disconnected from the mains. To disconnect the TV
set completely, the mains plug must be pulled out.
The TV set’s components are sensitive to heat. The maximum
ambient temperature should not exceed 35º Celsius. Do not cover
the vents at the back or sides of the TV set. Leave sufcient space
around it to allow adequate ventilation. Install the appliance away
from any source of heat (replace, etc.) or appliances creating strong
magnetic or electric elds.
Moisture in rooms where the set is installed should not exceed 75%
humidity. Moving the set from a cold place to a warm one can cause
condensation on the screen (and on some components inside the TV
set). Let the condensation evaporate before switching the TV set on
again.
The or POWER/ button on the TV set or the button on the
remote control can be used to switch it on and put it into standby
mode. If you are not going to be watching the TV for a lengthy
period of time, switch it off completely by removing the plug from
the mains power socket.
During thunderstorms, we recommend that you disconnect the TV
set from the mains and aerial so that it is not affected by electrical
or electromagnetic surges that could damage it. For this reason,
keep the mains and aerial sockets accessible so they can be
disconnected, if necessary.
Unplug the TV set immediately if you notice it giving off a smell of
burning or smoke. You must never, under any circumstances, open
the TV set yourself, as you run the risk of an electric shock in doing
so.
WARNINGS
This appliance is intended for domestic household use only and
should not be used for any other application, such as for non-
domestic use or in a commercial environment.
If the external exible cable or cord of this product is damaged,
it shall be replaced by the manufacturer or his service agent or a
similar qualied person in order to avoid a hazard.
Leave more than 10cm clearance around the television to allow
adequate ventilation. The ventilation should not be impeded by
covering the ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or splashing and
no objects lled with liquids, such as vases shall be placed on the
apparatus.
Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, re or the like.
To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
Never place a television set in an unstable location. A television set
may fall, causing serious personal injury or death. Many injuries,
particularly to children, can be avoided by taking simple precautions
such as:
• Using cabinets or stands recommended by the manufacturer of the
television set.
• Only using furniture that can safely support the television set.
• Ensuring the television set is not overhanging the edge of the
supporting furniture.
• Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture and
the television set to a suitable support.
• Not placing the television set on cloth or other materials that may
be located between the television set and supporting furniture.
• Educating children about the dangers of climbing on furniture to
reach the television set or its controls.
If your existing television set is being retained and relocated, the
same considerations as above should be applied.
Equipment with this symbol is a Class II or double insulated
electrical appliance. It has been designed in such a way that
it does not require a safety connection to electrical earth.
Equipment without this symbol is a Class I electrical
appliance. It shall be connected to a mains socket outlet with
a protective earthing connection.
To prevent the spread of re, keep candles or other open
ames away from this product at all times.
To prevent injury, this apparatus must be securely attached to the
oor/wall in accordance with the installation instructions.
To reduce the risk of RF exposure, the use distance of this apparatus
should be at least 100cm.
TV screen
The TV screen used in this product is made of glass. Therefore, it
can break when the product is dropped or impacted upon by other
objects.
The TV screen is a very high technology product, giving you nely
detailed pictures. Occasionally, a few nonactive pixels may appear
on the screen as a xed point of blue, green or red. This does not
affect the performance of your product.
Care
Use a glass-cleaning product to clean the screen and a soft cloth and
mild detergent to clean the rest of the set.
Important: Using strong detergents, alcohol-based and abrasive
products may damage the screen.
Dust the vents at the back and sides regularly. Using solvents,
abrasive or alcohol-based products could damage the TV set. If an
object or liquid enters the appliance, unplug it immediately and have
it checked by an authorized engineer. Never open the appliance
yourself since this may put you at risk or damage the appliance.
ESD regulation
This apparatus meets ESD performance criteria. In case the
apparatus does not recover in Ethernet connection mode due to
electrostatic discharge, user interference is required.

EN 2
English
Bluetooth function notice
Bluetooth® technology (if available in your TV) uses 2.4GHz
frequency thus close proximity to WiFi access points, routers or
microwave ovens might interfere with Bluetooth audio streaming.
If you face interruptions in audio reception, you should restart your
Bluetooth device to nd frequency with less interferences and if you
continue to face issues you should move closer to TV or increase
space between TV and source of interferences.
Bluetooth declaration ID: D031897
Hanging the TV set on the wall
Warning: This operation requires two people.
To ensure a safe installation, observe the following safety notes:
• Check that the wall can support the weight of the TV set and wall
mount assembly.
• Follow the mounting instructions provided with the wall mount.
For certain models, make sure to screw the hexagonal VESA wall
mounting screw bosses (and screws) provided with the set into
the nuts for the wall mount at the back of your set before your wall
mounting.
• The TV set must be installed on a vertical wall.
• Make sure to use only screws suitable for the material of the wall.
• Make sure that the TV set cables are placed so that there is no
danger of tripping over them.
All other safety instructions about our TV sets are also applicable
here.
Multi product user manual
The features described in this manual are common to most models.
Some features may not be available on your TV and/or your TV
may include features that are not described in this user manual. The
illustrations in this manual may differ from the actual product. Please
refer to the actual product.
Accessing channels
Using the numeric buttons: press the corresponding numeric
buttons on the remote control to access the channels.
Using the P / buttons: press the P / buttons on the
remote control or the corresponding buttons on the TV set to scroll
through the channels.
Using the LIST button: press the LIST button on the remote control
to display the channel list and press ▲/▼/◄/►and OK to select
channels.
Watching connected devices
Press on the remote control to display the source list. Press
▲/▼to select TV or other input sources and press OK to conrm.
You can also press on the remote control to display the
homepage, press ▲/▼to move to the Source area, then press ◄/►
and OK to select the input source.
Adjusting volume
Volume control: press the / buttons on the remote control or
the corresponding buttons on the TV set to increase or decrease the
volume.
Important information and manual
Sound mute: press the button to temporarily mute the sound.
Press this button again or the button to restore the sound.
Accessing Android TV homepage
Allows you to enjoy Internet Applications (Apps) and specially
adapted Internet websites, and perform system settings for your TV.
You can make controlling with the TV remote control.
WARNING:
• Congure the network settings before using Smart TV applications.
• Slow responses and/or interruptions may occur, depending on your
network conditions.
• If you experience a problem using an application, please contact
the content provider.
• According to circumstances of the content provider, an
application’s updates or the application itself may be discontinued.
• Depending on your country's regulations, some applications may
have limited service or not be supported.
• Changes in application content may be made without prior notice
by the service provider.
1. Press on the remote control to display the Android TV
homepage.
2. Press ▲/▼/◄/► and OK to enter the desired Apps, functions or
settings.
3. Press to return to the homepage.
Note: Since the connection with Internet takes time, it’s
recommended that you wait a few minutes to use the
Smart TV feature after activation of TV from standby.
Accessing T-Launcher
Allows you to enjoy Internet Applications (Apps) and videos.
1. Press on the remote control to display T-Launcher.
2. Press ▲/▼/◄/► and OK to enter the desired Apps or videos.
3. Press to return to the launcher.
4. Press again to exit the launcher.
Using TV settings menu
Allows you to adjust TV settings, such as picture and sound.
1. Press on the remote control to display the Settings menu.
2. Press ▲/▼to select the desired item, then press OK/► to enter
the corresponding submenu.
3. In submenus, press ▲/▼to select menu options, then press
OK/► to enter the option list, the adjustment interface, or the
corresponding submenu.
4. Press to return to the previous menu.
5. Press EXIT or to close the menu.
Note: You can also press on the remote control, select
Settings (if available) and press OK to enter the Settings
menu. Some options may not be available for certain
signal sources.
Installing channels
This section describes how to search and store channels
automatically. This may be done in any of the cases below:
- you have skipped the channel installation step in the initial setup;

EN 3
English
- you are prompted that there are no channels in TV mode;
- you want to update your channels.
1. In TV mode, press on the remote control and select
Channel > Channel scan. Press OK/► to enter.
2. The TV installs and arranges channels according to your country.
Press ▲/▼to select Country, and press OK/► to enter. Enter
the default password 1234 or your own password in case you
have changed the password in the System > Lock menu. Press
▲/▼to select your country and press OK to conrm.
3. Press ▲/▼to select Automatic search and press OK/►to
enter.
4. Press ▲/▼to select Tuner mode and press ◄/►to select
Cable, Antenna or Satellite. (Note: Satellite option is available
only in selected models.)
5. Press ▲/▼ to select other options to congure.
6. After conguration is completed, press ▼to select Search and
press OK to start scanning channels.
7. The channel search may take a few minutes. After the automatic
search, channels are arranged in a preset order. If you wish to
hide or move channels, press on the remote control, select
Channel > Channel organizer and press OK/► to enter.
Instant power on
It enables you to turn on your TV in 4 seconds from standby mode.
Note: This function may increase standby power consumption.
1. Press on the remote control, select Settings > Device >
Power > Instant power on and press OK.
2. Press ▲/▼to select On and press OK to conrm.
3. Press to return to the homepage.
> Please refer to Quick Start Guide to access the complete
instructions.
Radio Information
• Bluetooth® transmitter frequency range: 2402 - 2480MHz
• Bluetooth® transmitter power: 2dBm (+/- 5dB)
• 2.4G Wi-Fi transmitter frequency range: 2412 - 2472MHz
• 2.4G Wi-Fi transmitter power: 16dBm (+/- 4dB)
• 5G Wi-Fi transmitter frequency range:
- Band 1: 5180 - 5240MHz
- Band 4: 5745 - 5825MHz
• 5G Wi-Fi transmitter power:
- Band 1: 14dBm (+/- 3dB)
- Band 4: 11dBm (+/- 3dB)
• DVB-T/T2/C tuner frequency range: 45 - 858MHz
• DVB-S/S2 tuner frequency range: 950 - 2150MHz
* In all EU member states, operation of 5180 - 5240MHz is restricted
to indoor use only.
BE BG CZ DK DE EE IE
EL ES FR HR IT CY LV
LT LU HU MT NL AT PL
PT RO SI SK FI SE UK
OSS Notice
This product uses the GPL (Version 2 and 3) and LGPL (version 2.1)
and MPL (version 1.1).
To send inquiries and requests for questions regarding open source,
contact nearest TCL ofce.
This product uses some software programs which are distributed
under the Independent JPEG Group.
This product uses some software programs which are distributed
under the libpng Project.
This product uses some software programs which are distributed
under the Freetype Project.
This product uses some software programs which are distributed
under the zlib Project.
This product uses some software programs (libxml2, curl, expat,
c-areas) which are distributed under the MIT.
This product uses CyberLink for C which is distributed under the
Open Source Project.
This product uses opensl, xerces which is distributed under the
Apach License Project.
GPL software: Linux Kernel, glib, libiconv, gcc libgcc, gcc libstdc++,
u-Boot loader, ffmepg, util-linux-ng, e2fsprogs, wget, iptables
LGPL software: DFB (DirectFB), gstreamer, gst-plugins-base, gst-
plugins-good, gst-plugins-bad, gst-plugins-ugly, gst-ffmpeg, glibc,
wpa_supplicant
BSD software: webp, mng, uriparser
GNU software: dosfstools
[Legal Statement] of TCL - manufacturer of this TV set
Due to the various capabilities of products featuring the SmartTV
- Services, as well as limitations in the available content, certain
features, applications, and services may not be available on all
devices or in all territories. Some features on SmartTV may also
require additional peripheral devices or membership fees that are
sold separately. Please visit our website for more information on
specic device information and content availability. The services and
availability of content through SmartTV are subject to change from
time to time without prior notice.
All content and services accessible through this device belong to
third parties and are protected by copyright, patent, trademark and/
or other intellectual property laws. Such content and services are
provided solely for your personal noncommercial use. You may
not use any content or services in a manner that has not been
authorized by the content owner or service provider. Without limiting
the foregoing, unless expressly authorized by the applicable content
owner or service provider, you may not modify, copy, republish,
upload, post, transmit, translate, sell, create derivative works, exploit,
or distribute in any manner or medium any content or services
displayed through this device.
YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF
THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE
RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND
ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD PARTY
CONTENT AND SERVICES ARE PROVIDED “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. TCL
EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS
Important information and manual

EN 4
English
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and
specications may be changed without notice.
Information for Users on Disposal of Old
Equipment and Batteries
[European Union]
These symbols indicate that the electrical and
electronic equipment and the battery with this symbol
should not be disposed of as general household
waste at their end-of-life. Instead, the products should
be handed over to the applicable collection points for
the recycling of electrical and electronic equipment as
well as batteries for proper treatment, recovery and
recycling in accordance with your national legislation
and the Directive 2012/19/EU, 2006/66/EC and
2008/12/EC.
By disposing of these products correctly, you will help
to conserve natural resources and will help to prevent
potential negative effects on the environment and
human health which could otherwise be caused by
inappropriate waste handling of these products.
For more information about collection points and
recycling of these products, please contact your local
municipal ofce, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
[Business users]
If you wish to dispose of this product, please contact
your supplier and check the terms and conditions of
the purchase contract.
[Other Countries outside the European Union]
These symbols are only valid in the European Union.
If you wish to dispose of these items, please do so
in accordance with applicable national legislation or
other rules in your country for the treatment of old
electrical equipment and batteries.
Notice:
The sign Pb
below the
symbol for
batteries
indicates that
this battery
contains lead.
Products
Battery
Important information and manual
WITH RESPECT TO THE DEVICE AND ANY CONTENT AND
SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT
NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR
PURPOSE, OF ACCURACY, OF QUIET ENJOYMENT, AND
NON-INFRINGEMENT OF THIRD PARTY RIGHTS. TCL DOES
NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS,
LEGALITY, OR COMPLETENESS OF ANY CONTENT OR
SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES
NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES
WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION
OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED
OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING
NEGLIGENCE, SHALL TCL BE LIABLE, WHETHER IN CONTRACT
OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES,
EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN
CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS
A RESULT OF THE USE OF THE DEVICE, OR ANY CONTENT OR
SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Third party services may be changed, suspended, removed,
terminated or interrupted, or access may be disabled at any time,
without notice, and TCL makes no representation or warranty that
any content or service will remain available for any period of time.
Content and services are transmitted by third parties by means of
networks and transmission facilities over which TCL has no control.
Without limiting the generality of this disclaimer, TCL expressly
disclaims any responsibility or liability for any change, interruption,
disabling, removal of or suspension of any content or service made
available through this device. TCL may impose limits on the use of or
access to certain services or content, in any case and without notice
or liability. TCL is neither responsible nor liable for customer service
related to the content and services. Any question or request for
service relating to the content or services should be made directly to
the respective content and service providers.

ТЕЛЕВИЗОР ЦВЕТНОГО ИЗОБРАЖЕНИЯ ЖИДКОКРИСТАЛЛИЧЕСКИЙ
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
L49C2US L55C2US L65C2US

3

4

5

Технические характеристики, функции и комплект поставки могут отличаться от приведенных в настоящей
«Инструкции по эксплуатации» вследствие модернизации телевизоров заводом-изготовителем.
Видеофайлы AVI и MKV могут содержать различные видео и аудио потоки, формат которых
не поддерживается телевизором. В этом случае файл AVI или MKV воспроизводиться не будет.
Система звука
принимаемого сигнала D/K, B/G, I, NICAM
SECAM, PAL
Система цветности
принимаемого сигнала
Источник питания
(CR=>10)
Формат экрана
Формат сигнала
Aspect ratio
N.Weight
Sound Power
Viewing angles
Resolution
Brightness
Screen size
Model
Format of signal
В~, 50 Гц220-240
В~, 50 Гц220-240
L65C2US
65"
400 cd/m2
3840x2160
178°/178°
8 Вт х 2 +4 Вт х 2
24.1 кг
16:9
DVB-T/T2/C/S/S2
L55C2US
55"
400 cd/m2
3840x2160
178°/178°
8 Вт х 2 +4 Вт х 2
18.5 кг
16:9
DVB-T/T2/C/S/S2
L49C2US
49"
400 cd/m2
3840x2160
178°/178°
8 Вт х 2
13.3 кг
16:9
DVB-T/T2/C/S/S2

72-TCMT58-EUMAG
