Tdrforce Ds-800s/2p User manual

DS-800S/2P

Jewelry Steam Cleaner

Operating Instruction

www.tdrpump.com

Technical Specification

Model: DS-800S/2P

Outer Dimension: 8.26 x12 x13.77in

Voltage: 110V/50-60Hz

Power：1200W

Steam Pressure: 2-5 bar

Volume: Boiler 2L

Material：Superior SUS 304

Highest Temperature in Steam Outlet: 135℃

Packing List

A. DS-800S/2P Steam Cleaner 1PC

B. Power Line 1PC

C. Breaker 1PC

D. Funnel 1PC

E. Pedal Switch 1PC

F. Activity Spray Gun 1PC

G. Fixed Nozzle 1PC

H. Water Inlet Pipe 1PC

I. Filter Head 1PC

J. Operating Instruction 1PC

www.tdrpump.com

Notice

1.Check whether the power voltage is the same as the voltage of the cleaner prior to

use.

2.Use clear water or mineral water and don’t use impure water as to avoid blocking

pipe.

3.Don’t put the hand directly under the nozzle port during use so as to avoid scalding.

4.Keep the external surface of the cleaner clean and dry. Don’t move the cleaner to

avoid the damage while using.

5.Check the water level of the external water source before starting the machine.

6.If the machine sounds beating after starting, please press the safety valve to clear.

Principle of Steam Cleaning

-Steam cleaning is to inject clear water into steam heating pressure boiler, then the

water is heated to steam in a complete sealing status. In the heating process, the

pressure in the boiler will gradually increase. When the pressure in the boiler reaches

over 3.5 bar, the steam cleaner enters into working state, the temperature of the

spraying saturated steam reaches over 135℃, use the high temperature and high

pressure of saturated steam to remove the attachments such as oil stain, sewage from

the surface of the parts and vaporize them away. At the same time, it can also clean

small gaps and holes, peel off and remove oil stains and residues to achieve

requirements for high efficiency, water saving, clean and dry.

www.tdrpump.com

Application

-Cleaning of high quality is the premise for quality assurance of electroplate on the

jewelry surface. DS series steam cleaner is especially suitable for cleaning all kinds of

ornaments with complicated design. Ornaments cleaned by steam will better

guarantee the adhesion and brightness of electroplate when plated.

-DS series steam cleaner can generate steam of high pressure to ensure the touch

between the steam and each angle of inlaid products. Steam cleaning can quickly

reach every part of the inlaid structure, so as to remove stains from each dead space

and instantly restore all kinds of jewels to their beauty and luster.

-DS series steam cleaner use steam as cleaning medium instead of water to ensure the

effect of environmental cleaning. It has the function of high pressure and high

temperature cleaning which is not included in usual cleaning, and can quickly peel off

the polishing wax that remains on the surface and dead space of the ornaments.

Operating Method

1. Plug in the power socket, turn on the main power switch on the machine back. The

power button indicator lamp blinks, the pressure window show “ -”, the cleaner is in

standby state.

2. Touch the power button once, if the steam boiler water level is not full of water, and

the pressure is “0”, then the automatic water adding program will be started, and the

water adding will stop after the full water alarm, the start is complete.

3. When the steam cleaner is started, the power button and steam pressure adjustment

button indicator light keep on, pressure window show the set pressure value; when the

pressure not arrive the set pressure value, the heating indicator show the red light,

www.tdrpump.com

when the pressure arrived the set pressure value, the heating indicator show the green

light.

4. When the boiler water level is full of water, the full water indicator “F” lights up

and alarms 1 sec.

5. When the machine is short of water during use, the heating automatically stops, the

shortage water indicator “L” lights up and alarms; at the same time start the automatic

water procedure. While the boiler is still under high pressure, it should be released by

gently stepping on the pedal switch. When the boiler pressure displays “0”, the pump

will be started, the heating function restarted after the full water.

6. There are four kinds of steam pressure adjustable from 2 - 5 bar.

7. Touch the power button again in the boot state to shut down and enter the standby

state, but the steam solenoid valve can work normally in the standby state. After

turning off the main power switch at the back of machine, the exhaust fan will

continue to exhaust and cool down for a while. When the internal temperature of the

machine drops, the exhaust fan will automatically stop.

www.tdrpump.com

Trouble Shooting

TYPE OF DEFECT CAUSE SOLUTION

No steam comes out from

the nozzle.

-Water line or the nozzle

is blocked.

-Blocked heating tube.

-Use pure distilled water

as the water supply. Use a

needle to unclog the

nozzle.

-Replace the boiler. Use

pure distilled water as the

water supply.

The outlet steam pressure

is unstable.

- Insufficient water

supply.

-With leakage in water

line or in the seal and

connections , air is in.

- The nozzle is worn.

-The input voltage is

unstable.

-Ensure adequate water

supply.

-Repair or replace the

broken parts.

-Replace the nozzle.

-Work at the rated voltage

as the instruction manual.

Spray water beads. -Below operating

temperature.

-Steam condensed in the

hose.

- The nozzle is too far

away from the item and

the steam condenses.

-Turn on with the max

pressure (digital

displaying “5”). Wait for

the heating light to go off

and operate.

-Step the pedal to drain

out the condensed water

- The nozzle should be as

close to the item as

possible while using.

The light indicates lack

of water, but the machine

does not pump water.

-The pressure in the

boiler is too high.

-The water pump is

damaged.

-Press the pedal to release

the pressure.

-Replace the accessories.

www.tdrpump.com

Machine buzzing when

turned on.

-The steam in the boiler

has condensed without

releasing pressure, which

leads to negative pressure

and buzzing in the

machine.

-Press the safety valve on

the top or step on the

pedal to release negative

pressure.

www.tdrpump.com

Warranty Card

Customer contact, please keep it properly.

Dear customer:

Thank you for choosing products of TDRFORCE. In order to provide you with more satisfactory

service and better protect your rights, please read this regulation carefully and keep the warranty

card properly.

Regulations:

1.For any quality issue of TDRFORCE product within 180 days after sale, we offer no-hassel

return service for our customers;

2.Please contact our Amazon online customer service or sales04@tdrshine.com before return;

3.Valid evidence of purchase will be essential such as order ID or warranty card;

4.Valid evidence showing product problems shall be provided in the contact such as videos, photos

or detailed descriptions.

5.Warranty card shall be filled out and attached with the return product.

Please notice:

The following situations are not applicable to our no-hassel return policy.

1. Product damage caused by installation or use not in accordance with the instruction manual;

2. Product beyond 180 days after sale;

3. Product return with no reason;

4. Product damage caused by self-disassembly or sabotage;

5. Product damage caused by force majeure such as earthquakes, fires, etc.

Buyer’s Name:

Tele:

E-mail:

Order ID:

Return Address:

Product Problem Description:

www.tdrpump.com
