TechLogix Networx TL-DA14-F2 User manual

User Manual
TL-DA14-F2
1x4 HDMI splitter with EDID management and
downscaling
All Rights Reserved
Version: TL-DA14-F2_191025

TL-DA14-F2 User Manual
www.tlnetworx.com
Preface
Read this user manual carefully before using this product. Pictures shown in this manual
are for reference only; the actual product may vary.
This manual is only for operation instruction only and not for any maintenance or repair.
Trademarks
Product model and logo are trademarked. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

TL-DA14-F2 User Manual
www.tlnetworx.com
SAFETY PRECAUTIONS
To i n s ure p ro p e r o pe r at i o n, please read all instructions carefully before using the device.
Save this manual for further reference.
l
Unpack the equipment carefully and save the original box and packing material for
possible future shipment
l
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
l
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
l
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
l
Refer all servicing to qualified service personnel.
l
To p reve n t f i re or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
l
Do not remove the housing of the device, as opening or removing housing may
expose you to dangerous voltage or other hazards.
l
Install the device in a place with adequate ventilation to avoid damage caused by
overheating.
l
Keep the device away from liquids.
l
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the device immediately.
l
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
l
Unplug the power cord when left unused for a long period of time.
l
If disposing of the unit, do not burn or mix with general household waste. The device
must be disposed of per local regulations for electronic recycling.

www.tlnetworx.com
TL-DA14-F2 User Manual
Table of Contents
1.
Introduction
................................................................................................................. 5
1.1
Introduction to the TL-DA14-F2
......................................................................... 5
1.2
Features
.............................................................................................................. 5
1.3
Package Contents
............................................................................................... 5
2.
Panel Description
......................................................................................................... 6
2.1
Front Panel
......................................................................................................... 6
2.2 Rear Panel ......................................................................................................... 6
3.
System Connection
...................................................................................................... 7
4. Mode Selection ........................................................................................................... 7
5. Firmware Update Procedure ....................................................................................... 9
6.
Specifications
............................................................................................................. 10
7.
Panel Drawing
........................................................................................................... 12
8.
Tro ubl eshoot in g & Mainte na nce
................................................................................ 13
9.
After-sales Service
..................................................................................................... 14

www.tlnetworx.com
TL-DA14-F2 User Manual
1. Introduction
1.1
Introduction to the TL-DA14-F2
The TL-DA14-F2 is an 18Gbps HDMI splitter with four simultaneous outputs.
Compatible with HDMI 2.0a & HDCP 2.2/1.4 sources and devices, the TL-DA14-HD2
supports video resolutions up to 8k30 (4:2:0 8bit).
The TL-DA14-F2 will support 4k video with HDR1, xvYCC, x.v.Color, and Deep Color.
The TL-DA14-F2 can downscale video2 on each output individually to match the
connected display’s highest compatible resolution. This feature is required when mixing
4k and 1080p displays in the same installation. Advanced EDID management puts
you in control of what resolution the source will output.
Notes:
1: HDR content can pass through the TL-DA14-F2 but cannot be processed to properly
for 1080p displays.
2: Certain video conversions are not supported:
• 4k60 4:2:2 to 1080p
• Frame rate conversion
• 4k60 4:2:2 to 4k60 4:2:0
1.2
Features
• Advanced EDID management
• Automatic downscaling per output
• Supports HDMI 2.0, 4Kx2K@60Hz 4:4:4
• HDCP 2.2 compliant
• 18Gbps video bandwidth
•
1.3
Package Contents
Ø
1 x TL-DA14-F2
Ø
1 x Power Adapter (DC 5V)
Ø
1 x User Manual Card

www.tlnetworx.com
TL-DA14-F2 User Manual
2. Panel Description
2.1
Front Panel
No.
Name
Description
1
EDID
Mode
4 DIP switches for selection of EDID mode
2
Firmware
Mini-USB connection for firmware updates only
3
Power
Indicator
Power LED Indicator
4
Signal
Indicator
Indicates signal link on HDMI input (lit when both source and display
are connected)
5
Output
Indicator
(1~4)
Indicates signal link on HDMI outputs
2.2 Rear Panel
No.
Name
Description
A
EDID
Mode
4 DIP switches for selection of EDID mode
B~E
Firmware
Mini-USB connection for firmware updates only
F
Power
Indicator
Power LED Indicator
***Pictures shown in this manual are only for reference.

www.tlnetworx.com
TL-DA14-F2 User Manual
3. System Connection
1. Using quality HDMI cables, connect an HDMI source (such as Blu-ray, games
console, satellite/cable TV, media server etc.) to HDMI In of the TL-DA14-F2.
2. Connect the HDMI outputs to HDMI sinks (TVs, projectors, etc).
3. Connect the included 5V power supply to the TL-DA14-F2.
4. Check that the Power, Signal, and Output lights are illuminated to indicate
successful connection.
5. Booyah!
4. Mode Selection
The TL-DA14-F2 has [4] 2-position DIP switches labelled “EDID” on the front panel.
These switches are used to select the EDID* and operating modes. The switches are
labelled 1~4 from left to right, and the switch should be in the down position to be
considered ‘ON’. After changing the switch positions, please power cycle the TL-
DA14-F2 for the new settings to take effect.
*EDID – Extended Display Identification Data is metadata that is passed from the
display to the source in order to ‘request’ compatible video and audio formats from the
source. Since the TL-DA14-F2 may be connecting different types of display, some
manual manipulation may be required in order to successfully reproduce audio and
video at all displays.
Continued on next page…

www.tlnetworx.com
TL-DA14-F2 User Manual
Tabl e 4-1 – EDID selection
DIP Switch Position
Description
Pin 2
Pin 3
Pin 4
Off [↑]
Off [↑]
Off [↑]
Ultra HD(8K4K@30)1(4K2K@60) – 8/10/12bit 3D HDR video &
7.1ch audio
On [↓]
Off [↑]
Off [↑]
Ultra HD(4K2K@60) – 8/10/12bit 3D HDR video & 2ch audio
Off [↑]
On [↓]
Off [↑]
Ultra HD(4K2K@30)(4K2K@60 420) – 8bit 3D HDR video &
7.1ch audio
On [↓]
On [↓]
Off [↑]
Ultra HD(4K2K@30)(4K2K@60 420) – 8bit 3D HDR video & 2ch
audio
Off [↑]
Off [↑]
On [↓]
Full-HD(1080p@60) – 12bit 3D video & 7.1ch audio
On [↓]
Off [↑]
On [↓]
Full HD(1080p@60) – 8bit 2D video & 2ch audio
Off [↑]
On [↓]
On [↓]
Learning EDID from Output 1
On [↓]
On [↓]
On [↓]
Auto EDID analysis learning mode2
1: Only supports 8k4k@30Hz 4:2:0 8bits
2: Automatic EDID learning will detect all the connected displays and analyze all the
contents of the EDID. The maximal resolution supported will be the reference EDID for the HDMI
source.
Tabl e 4-2 – Operating mode selection
DIP Switch Position
Description
Pin 1
Off [↑]
Working mode (Normal)
On [↓]
Firmware Update mode

www.tlnetworx.com
TL-DA14-F2 User Manual
5. Firmware Update Procedure
If a firmware update is required for any reason, the process can be completed by
connecting a PC to the Mini-USB port on the front panel of the TL-DA14-F2. Please use
the following procedure to successfully complete the update:
1. Save the firmware file (.bin) and the Firmware Update software in the
same folder on your PC.
2. Power on the TL-DA14-F2, connect it to your PC using a Mini-USB cable.
Please be sure to use a cable that includes the data lines, and not a
‘charging’ cable.
3. Set the ‘Pin 1’ DIP switch to On [↓] (Firmware update mode).
4. Open the Firmware Update software and the TL-DA14-F2 will start the
update process automatically.
5. After the update process is done, the software will show a ‘Success”
message and then close automatically.
6. Set the ‘Pin 1’ DIP switch to Off [↑] (Working mode).

www.tlnetworx.com
TL-DA14-F2 User Manual
6. Specifications
I/O Connections
HDMI Input
One HDMI type A receptacle
HDMI Outputs
Four HDMI type A receptacle
DC 5V Power
One micro USB Type B port
Supported Video and Audio
Resolutions
480i, 480p, 576i, 576p, 720p, 1080i, 1080p,
1080p, 4Kx2K (60Hz 4:2:0 10bit, 60Hz 4:4:4 8bit),
8kx4k (30Hz 4:2:0 8bit)
Video Compliance
HDMI 2.0a, HDCP 2.2
Bandwidth
Single-link 600MHz (18 Gbps)
Embedded Audio Compatibility
DTS-HD Master Audio, Dolby TrueHD, Dolby
Digital, DTS, DVD-Audio, LPCM, SACD, MPCM
Maximum Passive HDMI
Distance
10 m (33 ft)
Input DDC Signal
5.0 volts p-p (TTL)
Input Video Signal
0.5 ~ 1.0 volts p-p
Chassis and Environmental
Enclosure
Painted steel
Dimensions (W x H x D)
136mm x 62mm x 20 mm (5.3 in x 2.4 in x 0.8 in)
Dimensions (W x H x D)
(Package)
264mm x 170mm x 77mm (10.4 in x 6.7 in x 3 in)
Weight
0.23 Kg (8.1 oz)
Weight
(Shipping)
0.77 Kg (1.7 lbs)

www.tlnetworx.com
TL-DA14-F2 User Manual
Operating Temperature
(Environment)
0° ~ 40° C (+32° ~ +104° F)
Operating Humidity
(Environment)
20% ~ 90% Non-condensing
Storage Temperature
(Environment)
-20° ~ 60° C (-4° ~ +140° F)
Storage Humidity (Environment)
20% ~ 90% Non-condensing
Power, ESD, Regulatory
Maximum Power Consumption
10W
Power Supply
5V at 2A DC
Regulatory
CE, FCC
Other
Standard Warranty
3 Year
Indicators
1 Power, 1 Input status, 4 Output connection status
Firmware Update
Via Mini-USB (Front Panel)
Included Items
User Manual Card, Power adaptor

www.tlnetworx.com
TL-DA14-F2 User Manual
7. Panel Drawing

13
www.tlnetworx.com
TL-DA14-F2 User Manual
8. Troubleshooting & Maintenance
l No image on display:
l Ensure that the display device has been set to the correct input.
l Ensure that the HDMI cables used for both the source/transmitter and the
receiver/display are properly connected and are working. Test the HDMI cables
directly from a source to display and ensure their operation.
l Test with 1080p mode. Set the EDID switches to [Pin2, Pin3, Pin4=↓-↑-↓] and
power-cycle the TL-DA14-F2. The only requirement for video to show will be
that the display must support Full HD (1920x1080@60hz)
l Test with Learning Mode. Set the EDID switches to [Pin2, Pin3, Pin4=↑-↓-↓]
and power-cycle the TL-DA14-F2. This will learn the EDID from Output 1. Be
sure to connect the display with the lowest resolution to Output 1.
If your problem persists after following the above troubleshooting steps, please contact
your authorized reseller or TechLogix technical support.

www.tlnetworx.com
TL-DA14-F2 User Manual
9. After-sales Service
1)
Product Limited Warranty: We warrant that our products will be free from defects in
materials and workmanship for three years.
2)
Warranty coverage may be voided when:
l
The warranty period has expired
l
The factory applied serial number has been altered or removed from the product
l
There is damage, deterioration or malfunction caused by:
l
Atypical wear and tear
l
Use of supplies or parts not meeting the specifications
l
No certificate or invoice as the proof of warranty
l
Damage caused by force majeure
l
Non-authorized service
3)
Te c h n i c a l S u p p o r t : When contacting TechLogix support, please have the following
information available:
l
Product part number
l
Installation and sale date
l
Detailed failure information
