Cadenceberge CAD-HV-HCA19 User manual

U S E R M A N U A L
4K HDMI to USB Capture
Model : CAD-HV-HCA19

Enjoy the vivid world!
INTRODUCTION
1.Introduction
4K HDMI to USB Video Capture Dongle,it is easy to carry, have a superior performance,superior
compatibility,simple installation. The video capture can capture both HDMI video and HDMI audio, sending
audio and video signals to computers and smart phones for preview and storage. Suitable for high definition
acquisition, teaching recording, medical imaging, etc.
2. Features
1. The capture resolution up to 1080P/30Hz, input resolution up to 4K/30Hz
2. Support capture format MJPEG
3. Support 8/10/12bit deep color;
4. Conform to USB Video and UVC standard;
5. Conform to USB Audio UAC standard;
6. Support Windows、Linux and MacOS;
7. Support most thrid-party player software compatible with UVC and UAC protocol such as VLC、OBS 、
Amcap, etc;
8. No need external power supply, compact and portable.
3. Specification
Connection:
Input interface
1 HDMI interface
Output interface
USB2.0, 40MB/s throughput MAX
HDMI input
4K/30,25, 24; 1080P/60, 59.94, 50, 30, 29.97, 25, 24, 23.98,
1080i 50/60, 720P 50/60, 480P, 576P,1280x1024, 1280x960,
1024x768, 800x600, 640x480

HDMI audio input
1 LPCM audio signal
Standards:
HDMI input formats
It meets the HDMI 1.4 standard, and supports 225 MHZ 4K/30Hz
12bit deep color
Output Formats
Preview resolution
1920x1080
Frame rate 30fps
Video Sampling Rate
HDMI: 165MHz
Audio and video capture
It meets the standards of UVC (USB video class) and UAC(USB
audio class)
Output color space
YUV, RGB
Others
Operating system support
Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS
Software compatibility
Adobe Flash Media Live Encoder (Windows, OS X)
Real Producer Plus (Windows)
VLC (Windows, OS X, Linux)
QuickTime Broadcaster (OS X)
QuickTime Player (OS X)and etc.
OBS
PotPlayer
Upgrade
The firmware can be upgraded
Size
75X41X12mm
Power consumption
<= 2.5W
Working Temperature
0-70 deg C
Storage Temperature
-20-120 deg C
Storage Humidity
5%-90%
4.Package
1. HDMI to USB video capture----------------------------------- 1 unit
2. USB cable --------------------------------------------------------- 1 unit
3. User manual----------------------------------------------------------- 1 unit
5.Computer system requirements:
System: Windows® 10 / Windows 8.1 / Windows 7 (SP1) /Linux/MacOs x 10.9 above
PC: Intel® Core™ i5-3440 3.20 GHz + NVIDIA® GeForce® GTX 630or above
Notebook: Intel Core i7-4810MQ + NVIDIA GeForce GTX 7350QM or above
RAM:4 GB RAM
Graphics card compatible with DirectX10
6. Connection and Operation
1: Connect the UHD signal source to the HDMI input of the video capture with one HDMI cable.
2: Connect the computer to the usb port of the video capture with usb cable.
3: Operation steps for USB video capture(OBS): Open the software→Choose sources of
“Video capture Device”→Set the size of image→Choose “Studio Mode”(double window)
→Choose “Start Recording”.
