TrendGeek®* User Manual
Bluetooth Gamepad TG-126
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the
essential requirements of the standards referred to the Directive RED
2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/
(in bar at the bottom “Konformitätserklärung”). Before using the device the
first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: [e-mail]
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product * Share your experience and opinion on one of the
well-known internet portals.
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany

Features
Bluetooth 3.0
Bluetooth range up to 10m
30 days standby time (full charged)
10 hours continuous play
Connection with computer via Bluetooth or Micro-USB cable
Connection with PS3 game console via Micro-USB cable
NOTE: If your computer do not have built-in Bluetooth, you need a
Bluetooth-Dongle to connect the device with the computer.
Product overview
1
LT(L2)-Button
9
Start-Button
2
LB-Button
10
Right Stick/R3-Button
3
LED-Indicator lights
11
RT-Button
4
Power/Pairing-Button
12
RB-Button
5
Directional-Buttons
13
Y-Button
6
Micro-USB port
14
B-Button
7
Left Stick/L3-Button
15
A-Button
8
Select-Button
16
X-Button

Specifications
Bluetooth
Version 3.0
BT transmitting range
2.4GHz
BT max. radiated output
power
1mW
Bluetooth range
Up to 10 Meters
Compatibility
Win7, Win8, Win10
Connection
Micro-USB / Bluetooth / Bluetooth-Dongle
(not included)
Weight / Dimensions
206g / (L)17.5 x (W)13.6 x (H)6.6cm
Power supply
Built in rechargeable 380mAh Lithium-
Polymer battery
Charging time
~1-2 hours
Battery-Standby
30 days (full charged)
Playing time
Up to 10 hours continuous play
Package contents
TrendGeek TG-126, Micro-USB cable,
User manual
Charging and Sleep function
Please connect the device via Micro-
USB to a USB interface of your
computer. The device is now charging.
The four LED-Indicator light flash
simultaneously. The lights turn off
when the charging is completed.
When the battery status is low, the
LED-Indicator lights flash rapidly.
The device turns into sleep mode, if it
is not used within 5 Minutes. Press the
Power/Pairing-Button for two seconds
to turn the device on again.

Connect with PS3 Game console by Micro-USB cable
Press the Start-
Button on the
device and connect
it to the console´s
USB port via the
USB cable. The
LED-Indicator light
shines.
Connect with Windows Computer by Micro-USB cable
Press the Start-
Button on the
device and connect
it to the computers
USB interface via
the USB cable.
Connect to Computer via Bluetooth
1. Press and hold the Power/Pairing-Button + X-Button for two
seconds until the LED-Indicator light flashes. The device is now
in pairing mode. Note: (If your computer has Bluetooth
function, please go to step 4)
2. Insert a Bluetooth-Dongle (not included) with Bluetooth 3.0 (or
above) version into the USB interface of your computer.
3. After the driver for the Bluetooth-Dongle is installed successfully
the Bluetooth Symbol is displayed in the lower right corner of the
computer Desktop.
4. Move the mouse to the Bluetooth symbol, click the right button
and select «Add device».

5. After selecting «Add device» you can search for TG-126 in the
Bluetooth list and click on it with the left mouse button.
6. Click «next» with the mouse and select «Do not use the code to
match». It will be automatically added after confirmed. The
computer shows that the device is connected. After connection
the LED-Indicator light shines. The device is now ready to use.
Hints
●The device is intended exclusively for private and not for commercial use.
●Only use this device as described in this user manual. ●Do not place any
part of this device in water or any other liquid. ●Do not handle the device
with wet hands. ● When disconnecting the cable, always pull at the plug. Do
not pull on the cable itself. ●Do not let the power cord on the edge of a table
or work surface. ●Prevent it comes into contact with hot surfaces. ●Keep it
away from heat sources to avoid deformation of plastic parts.
Safety instructions
Rebuilding or modifying the product impairs product safety. All
modifications and repairs of the device or accessories must be performed by
the manufacturer or by persons expressly authorized by the manufacturer.
Never open the product by yourself. Never perform repairs by yourself!
Handle the product carefully. It can be damaged by knocks, blows or even
by falling from low height. Keep the product away from damp, moisture and
extreme heat. Never immerse the product in water or other fluids.
Technical specifications are subject to change without notice. Never heat
the battery above 60°C and do not drop or throw it into the fire! Danger of
explosion/fire hazard! Do not short-circuit the battery. Do not subject the
battery to mechanical stress. Avoid dropping, striking, bending, twisting or
cutting the battery. Discontinue the charging process immediately should
the battery become overheated. A battery that becomes overheated or
deformed during the charging process is defective and should no longer be
used. Never drain the battery completely, as this shortens its lifetime. If
the battery must be stored, it is recommended that it be stored at 30% of its
loading volume. Store out of direct sunlight. Ideal storage temperature: 10–
20°C. Keep the product away from little children.
