Service Manual
TOP NEXT
AD0102032C2
Compact Disc Player
●SL-EH570
Traverse Deck: RAE0152Z Mechanism series
Colour
(S)..........Silver Type
Area
(E)..........Europe.
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0000000000.htm (1 of 2) [25.4.2003 20:50:06]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0000000000.htm
© 2001 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
•@
TOP NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0000000000.htm (2 of 2) [25.4.2003 20:50:06]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0100000000x.htm
1 Note
TOP PREVIOUS NEXT
Refer to the service manual for Model No. SA-EH570 (Order No. AD0102030C2) for information on
Accessories and Packaging.
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0100000000x.htm [25.4.2003 20:50:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0200000000x.htm
2 Handling Precautions for Traverse
Deck
TOP PREVIOUS NEXT
The laser diode in the traverse deck (optical pickup) may break down due to potential difference caused
by static electricity of clothes or human body.
So be careful of electrostatic breakdown during repair of the traverse deck (optical pickup).
2.1 Handling of traverse deck (optical pickup)
2.2 Grounding for electrostatic breakdown prevention
2.2.1 Human body grounding
2.2.2 Work table grounding
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0200000000x.htm [25.4.2003 20:50:58]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0201000000.htm
2.1 Handling of traverse deck (optical
pickup)
TOP PREVIOUS NEXT
1. Do not subject the traverse deck (optical pickup) to static electricity as it is extremely sensitive to
electrical shock.
2. To protect the laser diode against electrostatic breakdown, short the flexible board (FFC board)
with a clip or similar object. Refer to Fig. 2-1.
3. Take care not to apply excessive stress to the flexible board (FFC board).
4. Do not turn the variable resistor (laser power adjustment). It has already been adjusted. Refer to
Fig. 2-1.
Fig. 2-1.
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0201000000.htm (1 of 2) [25.4.2003 20:51:15]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202000000.htm
2.2 Grounding for electrostatic
breakdown prevention
TOP PREVIOUS NEXT
2.2.1 Human body grounding
2.2.2 Work table grounding
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202000000.htm [25.4.2003 20:51:36]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202010000.htm
2.2.1 Human body grounding
TOP PREVIOUS NEXT
Use the anti-static wrist strap to discharge the static electricity from your body. Refer to Fig. 2-2.
Fig. 2-2.
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202010000.htm [25.4.2003 20:51:53]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202020000.htm
2.2.2 Work table grounding
TOP PREVIOUS NEXT
Put a conductive material (sheet) or steel sheet on the area where the traverse deck (optical pickup) is
placed, and ground the sheet. Refer to Fig. 2-3.
Fig. 2-3.
Caution:
The static electricity of your clothes will not be grounded through the wrist strap.
So take care not to let your clothes touch the traverse deck (optical pickup).
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0202020000.htm [25.4.2003 20:52:10]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0300000000x.htm
3 Precaution of Laser Diode
TOP PREVIOUS NEXT
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0300000000x.htm [25.4.2003 20:52:28]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0400000000x.htm
4 Location of Controls
TOP PREVIOUS NEXT
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0400000000x.htm [25.4.2003 20:52:47]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0500000000x.htm
5 Operation Checks and Component
Replacement/ Procedures
TOP PREVIOUS NEXT
●This section describes procedures for checking the operation of the major printed circuit boards
and replacing the main components.
●For reassembly after operation checks or replacement, reverse the respective procedures. Special
reassembly procedures are described only when required.
/
5.1 Checking for the main P.C.B.
5.2 Checking for the CD servo P.C.B.
5.3 Replacement for the traverse deck ass’y
5.4 Replacement for the belt, loading motor ass’y and loading switch
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0500000000x.htm [25.4.2003 20:53:43]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0501000000.htm
5.1 Checking for the main P.C.B.
TOP PREVIOUS NEXT
●Check the main P.C.B. as shown above.
/
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0501000000.htm [25.4.2003 20:54:02]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0502000000.htm
5.2 Checking for the CD servo P.C.B.
TOP PREVIOUS NEXT
●Follow the (Step 1) - (Step 3) of item 5.1.
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0502000000.htm (1 of 2) [25.4.2003 20:54:21]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0502000000.htm
●Check the CD servo P.C.B. as shown below.
•@
TOP PREVIOUS NEXT
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0502000000.htm (2 of 2) [25.4.2003 20:54:21]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
5.3 Replacement for the traverse deck
ass’y
TOP PREVIOUS NEXT
●Follow the (Step 1) - (Step 3) of item 5.1.
●Follow the (Step 1) - (Step 5) of item 5.2.
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm (1 of 6) [25.4.2003 20:54:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm (2 of 6) [25.4.2003 20:54:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm (3 of 6) [25.4.2003 20:54:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm (4 of 6) [25.4.2003 20:54:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm (5 of 6) [25.4.2003 20:54:39]

file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0503000000.htm
•@
TOP PREVIOUS NEXT
