Technika T75E1200FL-5 Operation manual

Instructions for Use and
Installation
7.5kg Front-Load Washing Machine
T75E1200FL-5

CONTENTS
Safety Instructions
Safety Instructions ......................................................................................................... 2
Installation
Product Description .................................................................................................... 7
Installation ........................................................................................................................ 8
Operation
Quick Start .......................................................................................................................... 11
Before Each Wash ......................................................................................................... 12
Detergent Dispenser ..................................................................................................... 13
Control Panel .................................................................................................................... 15
Program Options ............................................................................................................. 16
Other Functions ............................................................................................................... 18
Programmes...................................................................................................................... 20
Washing ProgrammesTable ..................................................................................... 21
Maintenance
Cleaning and Care ........................................................................................................... 22
Trouble Shooting ............................................................................................................. 25
Technical Specifications .............................................................................................. 26
Testing Methods .............................................................................................................. 27
Warranty .............................................................................................................................. 28

SAFETY INSTRUCTIONS
• Safety Instructions
For your safety, the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
Explanation of the symbols.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injury unless it’s avoided.
Warning!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Caution!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
Note!
Warning!
The electric shock!

SAFETY INSTRUCTIONS
• The new hose-sets supplied with the appliance are to be
used and old hose-sets should not be reused.
• Before any maintenance is performed on the device,
unplug the appliance from the mains.
•Always unplug the machine and turn off the water supply after
use. The max. Inlet water pressure, in pascals. The min. inlet
water pressure, in pascals.
•To ensure your safety, power plug must be inserted into an
earthed three-pole socket. Check carefully and make sure
that your socket is properly and reliably earthed.
• Make sure that the water and electric devices are
connected by a qualified technician in accordance with the
manufacturer’s instructions and local safety regulations.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge unless they are under
supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Animals and children may climb into the machine. Check the
machine before every operation.
• Children should be kept away unless continuously supervised.
Risk to children!

SAFETY INSTRUCTIONS
•Glass door may be very hot during the operation. Keep kids and pets
far away from the machine during the operation.
Risk of explosion!
• Do not wash or dry articles that have been cleaned in, washed in,
soaked in, or dabbed with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents,
kerosene, etc.) this may result in fire or explosion.
•Thoroughly rinse these items by hand before washing.
• This washing machine is for indoor use only.
• It isn’t intended for built-in use.
• The openings must not be obstructed by a carpet.
• Washing machine shall not be installed in bathroom or very wet
rooms with explosive or caustic gases.
• The washing machine with single inlet valve only can be connected
tothe cold water supply. The product with double inlet valves should
be correctly connected to the hot water and cold water supply.
• Plug must be accessible after installation.
Caution!
Installing the product!

SAFETY INSTRUCTIONS
• Remove all packages and transport bolts before using the
appliance. Otherwise, serious damage may result.
Risk of explosion!
• Before washing clothes for the first time, the product shall be
operated one full cycle without the clothes inside.
• Flammable and explosive or toxic solvents are forbidden. Gasoline
and alcohol etc. Shall not used as detergents. Please only select the
detergents suitable for machine washing, especially for the drum.
•Your product is only for home use and is only designed for the textiles
suitable for machine washing.
•Do not climb up and sit on top cover of the machine.
• Do not lean against the machine door.
• Cautions during Handling Machine:
1. Transport bolts shall be reinstalled to the machine by a
specialized person.
2. The accumulated water shall be drained out of the machine.
3. Handle the machine carefully. Never hold each protruded
part on the machine while lifting. Machine door can not be used
as the handle during the conveyance.
4. This appliance is heavy. Transport with care.
• Please do not close the door with excessive forces. If it is found
difficult to close the door, please check if the clothes are put in or
distributed well.
• It is forbidden to wash carpets.
Operating the appliance!

SAFETY INSTRUCTIONS
• Make sure that all pockets are emptied. Sharp and rigid items such as
coin, brooch, nail, screw or stone etc. May cause serious damages to
this machine.
• Please check whether the water inside the drum has been drained
before opening its door. Please do not open the door if there is any
water visible.
• Be careful of burning when the product drains hot washing water.
• Never refill the water by hand during washing.
• After the program is completed, please wait for two minutes to open
the door.
Packaging/Old appliance
Correct Disposal of this product:
This marking indicates that this product should
not be disposed with other household waste.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the product
was purchased. they can take this product for
environmental safe recycling.

•The product line chart is for reference only, please refer to
real product as standards.
Note!
Accessories
Transport
hole plug
Water supply hose
Detergent dispenser
Top cover
Control panel
Power supply cord
Drum
Service filter
Door
Drain hose
Supply hose
cold water
Drain hose
support
Owner’s Manual
Product Description
SAFETY INSTRUCTIONS

INSTALLATION
Installation
Installation area
•Stability is important to prevent the product from
wandering!
•Make sure that the product should not stand on the
power cord.
Warning!
1. Rigid, dry, and level surface
2. Avoid direct sunlight
3. Sufficient ventilation
4. Room temperature is above 0’C
5. Keep far away from the heat resources such as coal or gas
Before installing the machine, the location should be
characterised by:
• Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
• There is a risk of suffocation! Keep all packaging
well away from children.
Warning!
Unpacking the washing machine
Remove transport bolts
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing. Make sure
the small triangle foam is removed with the bottom one together.
If not, lay the unit down with side surface, then remove the small
foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Loosen 4 bolts with spanner and then remove them.
2. Stop the holes with transport hole plugs.
3. Keep the transport bolts properly for future use.
•You must remove the transport bolts from the backside before using the product.
•You’ll need the transport bolts again if you move the product, so make sure
you keep them in a safe place.
Warning!
Please take the following steps to remove the bolts:

Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1. Check if the legs are closely attached to the cabinet. if not, please turn them to their
original positions tighten the nuts.
2. Loosen the lock nut turn the feet until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
INSTALLATION
Leveling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, modify or sever water inlet hose.
•For the model equips hot valve, connect it to hot water tap with hot water supply
hose. Energy consumption will decrease automatically for some program.
Warning!
Warning!
Connect Water Supply Hose
1. Connection between ordinary tap and inlet hose.
2. Connection between screw tap and inlet hose.
Loosen clamp nut and
four bolts
Tighten clamp nut Press slide bushing,
insert inlet hose into
connecting base
Connection finished
Tap with threads and inlet hose Special tap for washing machine

INSTALLATION
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
Drain Hose
• Do not kink or protract the drain hose.
• Position drain hose properly, otherwise damage might result of water leakage.
Warning!
There are two ways to place the end of drain hose:
1. Put it into the water trough. 2. Connect it to the branch drain pipe of
the trough.
Note!
• If the machine has drain hose support, please install it like the following.
• When installing drain hose, fix it properly with a rope.
•If drain hose is too long, do not force it into washing machine as it will cause
abnormal issues.
Warning!

OPERATIONS
Quick Start
Caution!
• Before washing, please make sure it’s installed properly.
• Before washing the first time, the washing machine shall be operated in
one round of the whole procedures without clothes in as follows.
1. Before Washing
Note!
•Detergent only need to be added in “ case I ” after selecting pre-washing
for machines with this function.
2. Washing
Note!
1. If default is selected, step 3 can be skipped.
2. The function button line chart is for reference only, please refer to real
product as standard.
3. After Washing
Buzzer beep or “ End ” on display.

OPERATIONS
Before Each Wash
•The working condition of the washer should be(0-40)’C. if used under 0’C, the inlet
valve and draining system may be damaged. If the machine is placed under condition
of 0’C or less, then it should be transferred to normal ambient temperature to ensure
the water supply hose and drain hose are not frozen before use.
•Please check labels and the explanation of using detergent before wash. Use non-
foaming or less-foaming detergent suitable for machine washing properly.
• When washing single clothes, it may easily cause great eccentricity and give
alarm due to great unbalance. Therefore it is suggested to add one or two more
clothes to be washed together so that draining can be done smoothly.
• Don’t wash clothes that have touched kerosene, gasoline, alcohol or other
flammable materials.
Warning!

OPERATIONS
Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
Caution!
•Detergent only need to be added in “ case I” after selecting pre-washing for
machines with this function.

OPERATIONS
Option
Pre Wash
The Prewash function can get an extra wash before main wash, it is
suitable for washing the dust rises to surface of the clothes; You need to
put into detergent the Case ( I ) when selected.
Speed Wash
Delay
Extra Rinse
The laundry will undergo an extra rinse cycle.
The function can decrease the washing time.
Set the Delay function:
Cancel the Delay function:
Press the [Delay] button until the display be 0H. It should be pressed
before starting the program. If the program already started, should press
the [On/O] button to reset the program.
1. Select a program
2. Press the Delay button to choose the time (the delaying time is 0-24 H).
3. Press [Start/Pause] to commence the delay operation.
Caution!
• If there is any break in the power supply while the machine is operating
a special memory stores the selected program and when the power is
restarted, press the [ On/Off ] button the program will continue.

OPERATIONS

OPERATIONS
Other functions
My Cycle
Remembers the frequently used programmes.
Press [Spin]([Speed Wash]/[Temp.]) 3sec. to remember the running
program. The default is cotton.
Extra Rinse
Press the button to regulate the temperature.
Speed Wash
Press the button to change the spin speed.
Caution!
•When the lights of spin speed (600, 800, 1000, 1200, 1400) are o means
the spin speed is 0.

OPERATIONS
Mute the buzzer
Reload
Child Lock
Caution!
•After Muting the buzzer function, the sounds will not be activated any more.
This operation can be executed during the washing progress. When
the drum is still rolling and there is large amount of water with high
temperature in the drum. The state is unsafe and the door cannot be
opened forcefully. To press [Start/Pause] for 3 sec. to reload, and start the
clothes adding in the midway function. Please follow the steps as below:
To avoid mis operation by children.
1. Wait until the drum stops rotating.
2. The door lock is unlocked.
3. Close the door when the clothes are reloaded and press the
[Start/Pause] button.
Caution!
• Don’t use the Reload function when the water level is over the edge of
the inner tub or the temperature is high.

OPERATIONS
Caution!
• Press the two button 3 sec. also to be released the function.
• The “Child Lock” will lock all the buttons except [On/O].
• Cut o the power supply, the kid’s protection is to released.
•The child lock will remain eective when the power is resumed for some models.
Programs
Note!
• Reference to your product to select the programs.
Programs are available according to the laundry type.
