TECHNIMOUNT PRO Series User manual

BRACKET PRO SERIE®71
USER GUIDE
EMS
TM

Return to Table of Contents
2BP71-UG-202207-02 www.technimount.com
Copyright 2022 Technimount E.M.S. Holding Inc. (Technimount), an aliated company of Technologies CGC Inc. All
Rights Reserved. No part of this publicaon may be reproduced, transmied, transcribed, stored in a retrieval system,
or translated into any language in any form or by any means without the wrien permission of Technimount or its
aliate companies.
Trademark Aribuons:
Bracket Pro Serie®, Technimount EMS™ are registered trademarks of Technologies CGC Inc.
IntelliVue™ X3 Monitor is a registered trademark of Philips.
Technimount does not have a commercial relaonship with Philips. Philips does not promote or sell Technimount
products.
In order to ensure connuous improvements to our products and services, we invite you to communicate your
comments to our Customer Service Department at [e-mail].
LEGAL NOTICE
Technologies CGC Inc. or Technimount E.M.S. Holding Inc. or its aliates are not expressly associated with the
markeng, distribuon or sale of Philips products.
COPYRIGHT

www.technimount.com BP71-UG-202207-02 3
Return to Table of Contents
OFFICE ADDRESS
Technimount E.M.S. Holding Inc.
3770 Jean Marchand Street, Suite 100-C
Quebec (QC) G2C 1Y6
Canada
[email protected]
www.technimount.com
T + 1 581.700.6613
TF + 1 888.639.2758
NOTE:
For any issues with your Technimount product, its components, or for any technical quesons during the installaon
or maintenance processes, please send an email to [e-mail].
Please have the serial number of your Technimount product available (as shown in the gure below) when calling
Technimount Technical Support. Include the serial number in all wrien communicaons.
SERIAL NUMBER LOCATION
CONTACT INFORMATION
The serial number
is written under
the bracket
as shown in
this image

4BP71-UG-202207-02 www.technimount.com
TABLE OF CONTENTS
COPYRIGHT ............................................................................................................................................................ 2
Legal Notice ...................................................................................................................................................................2
CONTACT INFORMATION....................................................................................................................................... 3
Symbols and Definitions ...............................................................................................................................................6
Warning/Caution/Note ................................................................................................................................................7
Product Illustration .....................................................................................................................................................8
Bracket Pro Serie 71 ..............................................................................................................................................8
Front View ..........................................................................................................................................................................8
Back View ............................................................................................................................................................................9
INTRODUCTION ................................................................................................................................................... 10
Purpose of the Document ..........................................................................................................................................10
Product Description ...................................................................................................................................................10
Intended Use of the Product .....................................................................................................................................10
Technical Specifications..............................................................................................................................................11
SUMMARY OF SAFETY PRECAUTIONS ................................................................................................................ 12
Warning/Caution/Note ..............................................................................................................................................12
NOTICE ................................................................................................................................................................. 14
INSTALLATION GUIDE .......................................................................................................................................... 15
Removing the Packaging for Installation .................................................................................................................15
Tools Required for Installation.................................................................................................................................15
List of Material ...........................................................................................................................................................15
Installation of the Dock, monitor and Microstream into the Bracket .................................................................16
DOCK .....................................................................................................................................................................16
Monitor ................................................................................................................................................................18
Microstream and Monitor ..................................................................................................................................19
OPERATION GUIDE .............................................................................................................................................. 20
Removing the Philips IntelliVue X3 Monitor and extension from the Bracket .....................................................20
Monitor ................................................................................................................................................................20
Monitor ANd microstream .................................................................................................................................20
MAINTENANCE GUIDE......................................................................................................................................... 22
Cleaning .......................................................................................................................................................................22
Cleaning Process ..................................................................................................................................................22
Cleaning Solutions...............................................................................................................................................23
Removal of Iodine Compounds ...........................................................................................................................23
Preventive Maintenance .............................................................................................................................................23
Inspection Process and Schedule...............................................................................................................................24
Maintenance Program .........................................................................................................................................24
Inspection and Maintenance Record .........................................................................................................................25
Training Record ...........................................................................................................................................................26
Replacement Parts .......................................................................................................................................................27
WARRANTY .......................................................................................................................................................... 28
Warranty Policy ..........................................................................................................................................................28
Limited Responsibility and Warranty .........................................................................................................................28

www.technimount.com BP71-UG-202207-02 5
TABLE OF CONTENTS
International Warranty Clause .................................................................................................................................28
RETURN POLICY ................................................................................................................................................... 29
Return Policy ...............................................................................................................................................................29
Prior to 30 Days ...................................................................................................................................................29
Prior 45 Days ........................................................................................................................................................29
Prior 60 Days ........................................................................................................................................................29
Return Authorization .................................................................................................................................................29
Damaged Merchandise ................................................................................................................................................30
Claim Process ..............................................................................................................................................................30
Required Information ..........................................................................................................................................30
Findings and Conclusion .....................................................................................................................................30
Questions about our Policy .......................................................................................................................................30

Return to Table of Contents
6BP71-UG-202207-02 www.technimount.com
INTRODUCTION
SYMBOLS AND DEFINITIONS
SYMBOL DESCRIPTION
Warning and Cauon, special aenon is required. Consult
accompanying documents
Safe working load symbol and Load balance symbol

www.technimount.com BP71-UG-202207-02 7
Return to Table of Contents
WARNING/CAUTION/NOTE
The word warning, cauon, or note carry special meaning and should be carefully reviewed.
SYMBOL DESCRIPTION
Warning
Alerts the reader about a situaon which, if not avoided, could
result in death or serious injury. It may also describe potenal
serious adverse reacons and safety hazards.
Caution
Alerts the reader of a potenally hazardous situaon, which, if
not avoided, may result in minor or moderate injury to the user
or paent or damage to the equipment or other property. This
includes special care necessary for the safe and eecve use of the
device to avoid damage that may occur as a result of use or misuse.
NOTE Provides special informaon about the product.
INTRODUCTION

Return to Table of Contents
8BP71-UG-202207-02 www.technimount.com
PRODUCT ILLUSTRATION
BRACKET PRO SERIE 71
Front View
INTRODUCTION
Locking Assembly Block
with Black-Anodized Finish
Technimount Molded
Polyurethane Transport Handle
Boom Micro Disc
Adjustment Knob
Front Support Plate with
Black-Anodized Finish

www.technimount.com BP71-UG-202207-02 9
Return to Table of Contents
PRODUCT ILLUSTRATION (CONTINUED)
BRACKET PRO SERIE 71
Back View
INTRODUCTION
Acetal Feet
Red Quick Release
Mechanism
Adjustment Plate
An-Rotaon Micro Disc

Return to Table of Contents
10 BP71-UG-202207-02 www.technimount.com
INTRODUCTION
PURPOSE OF THE DOCUMENT
This user guide is designed to assist you with the installaon, operaon and maintenance of the Technimount Bracket
Pro Serie 71 for the Philips IntelliVue X3 Monitor.
PRODUCT DESCRIPTION
The Bracket Pro Serie 71 is a mounng system for the Philips Intellivue X3 monitor with or without Microstream
Extension. It can be used in dierent applicaons such as on a surface, oor, cot/stretcher and wall. It is designed to
securely support and transport the Philips Intellivue X3 monitor in pre-hospital environments and it can t into any
ground and air ambulance conguraons. When used in emergency vehicles with a cot/ stretcher, the Bracket Pro
Serie 71 can be posioned on Technimount's Micro Base, on a Safety MD-Transporter or on vercal mounng systems.
These soluons provide a higher exibility for dierent EMS/CCT protocols and applicaons. This mounng system is
compable with all of Technimount's products.
INTENDED USE OF THE PRODUCT
The Bracket Pro Serie 71 is a mounng soluon to securely transport the IntelliVue X3 Monitor from Philips during
inter-hospital transfers. It is designed to be installed on the equipment as described in this user guide. The Bracket
Pro Serie 71 is for crew who has received the appropriate training necessary to operate the equipment in the eld
according to its intended use as outlined in this user guide. Please read this user guide thoroughly before using this
equipment. To ensure the safe operaon of this equipment, it is highly recommended to train sta prior to use.

www.technimount.com BP71-UG-202207-02 11
Return to Table of Contents
INTRODUCTION
TECHNICAL SPECIFICATIONS
Product Name Bracket Pro Serie® 71
Product Descripon Bracket for transport of Philips IntelliVue™ X3 for emergency and crical care
transport
Compability of Medical Device* Philips® IntelliVue™ X3 Monitor, with or without IntelliVue Microstream CO2
Extension
Environment of Usage EMS/CCT (Ground) – Hospital/Clinic
Product Secon Material • Main Assembly: Aluminum 6061-T6 and Acetal
• An-Rotaon Micro Disc: Aluminum 6061-T6
• Transport Handle: Molded Polyurethane
Product Finish • Main Assembly: Black-Anodized Finish
• An-Rotaon Micro Disc: Silver Anodized Finish
Environmental Regulaons Complying with RoHS 3
Temperature of Usage -31° F to 113° F (- 35° C to 45° C)
Cercaon Tested in compiance with SAE J3043
Installaon Device Retained on Main Assembly with Red Quick Release Mechanism
Aachment Opons An-Rotaon Micro Disc and Boom Micro Disc
Transportaon System Compability Compable with Technimount's:
• Safety MD-Transporter (vercal and horizontal)
• Vercal Mounng System
• Micro Base
• Wall System
Features • Access to all Medical Device Monitors, Connectors and Accessories
• Rubber Pads Protecng the Bracket when Placed on a Surface
• Molded Polyurethane Transport Handle
• Rubber Cushions Inside the Bracket to Protect Medical Device
• Red Quick Release Mechanism for Easy Installaon and Removal of
Medical Device
• An-Rotaon Micro Disc for Installaon on Vercal and Wall Mounng
Systems
• Installaon of monitor with or without IntelliVue Microstream CO2
Extension
Physical Overall Dimensions Width 8.59 in (20.32 cm), Depth 8.75 in (20.32 cm), Height 7.55 in (17.78 cm)
Weight 4.27 lb (1.94 kg)
Part Number 330-11-PHX3
Other Models and Conguraon Opons Contact Technimount EMS for more informaon or for other opons at
customer[email protected]
* Product and medical equipment manufacturers names are trademarks™ or registered trademarks® of their respecve holders.
Technimount does not have a commercial relaonship with these medical equipment manufacturers.

Return to Table of Contents
12 BP71-UG-202207-02 www.technimount.com
WARNING/CAUTION/NOTE
Carefully read and strictly follow all Warnings and Cauons listed in this user guide. Servicing and maintenance should
only be done by qualied personnel.
WARNING
9Always hold the bracket rmly when you manipulate it.
9Operate the bracket only as described in this user guide.
9Do not modify the bracket, or any components of Technimount systems. Modifying the product can cause
unpredictable operaon resulng in injury to the paent or operator.
9It is the responsibility of the operator of the bracket or any of its opons, to ensure equipment being used with the
Technimount products meets the installaon specicaons. Injury may result if non-compable products are used
with Technimount System products.
9Do not aempt to operate, install or remove the equipment while mobile. Ensure that installaon and removal of
equipment is done while ight or ground emergency service is immobilized.
9Verify that the bracket is inserted correctly into a mounng system and locked. If equipment is improperly installed
and locked, it can cause the equipment to fall and cause injury to the paent or operator and/or damage to the
medical equipment.
9Never use the bracket if not properly installed and locked on a base, a cot/stretcher, or on a wall mount or oor
mount. If not installed properly, the medical device could fall during transport and may cause injury to the paent
or operator and/or damage to the product.
9Do not allow untrained sta to assist in the operaon of the mounng system. Untrained technicians/sta can
cause injury to the paent or themselves.
9Do not place addional equipment or items onto the bracket or mounts other than approved Technimount or
components, as this could damage the product and may result in injury to the paent or operator.
9Operators must be able to able to safely li the total weight of the bracket system and medical device.
9Do not aach restraints to the bracket frame. It may result in damage to the System and/or result in injury to the
paent or operator.
9Always reposion the equipment with care, avoid any improper pushing or violent manipulaon, as it may result in
unbalanced equipment and may cause injury to the paent or operator and/or damage to the product.
9Improper maintenance can cause injury to paent or operator or damage to the product. Maintain the bracket
and mounng systems as described in this user guide. Use only Technimount approved parts and maintenance
procedures. Using unapproved parts and procedures could cause unpredictable operaon and/or injury and will
void the product warranty.
9Failure to properly clean or dispose of corrosive products will increase the risk of premature damage and may
cause injury to the paent or operator.
9Any installaon on a surface, wall or on the structure of the vehicle has to be validated or inspected in order to
ensure it maintains the integrity of the vehicle.
SUMMARY OF SAFETY PRECAUTIONS

www.technimount.com BP71-UG-202207-02 13
Return to Table of Contents
WARNING/CAUTION/NOTE (CONTINUED)
CAUTION
9Only cered technical personnel familiar with the bracket installaon and use should manipulate it. Always refer
to Technimount's user guides for all instrucons for installing and using any Technimount Mounng System.
9Inspect regularly all components on the equipment for any issue and loose screws, bolts and nuts.
9Never install the mount into or on other similar mounng systems or brackets without wrien conrmaon by
Technimount EMS as these dierent systems may be from other brands or models and may not be compable with
Technimount Systems.
NOTE
9Some cleaning products are corrosive in nature and may cause damage to the product if used improperly. If such
products are used to clean Technimount equipment, the equipment must be rinsed with clean water and thoroughly
dried following the cleaning. Failure to properly rinse and dry the Mounng Systems will leave a corrosive residue
on the surface, possibly causing premature corrosion of crical components.
9When ordering, it is important to idenfy on which mounng system you need to mount the bracket on as there
are dierent systems for dierent applicaons (ground and ight).
9A maintenance program should be established for all Technimount equipment. Prevenve maintenance may need
to be performed more frequently, based on the level of use of the product. Close aenon should be given to
safety features (i.e.: screws, quick release mechanisms, and aachment points).
9Failure to use authorized parts, and lubricants, could cause damage to the equipment and will void the warranty
of the product.
9This user guide should be considered a permanent part of the bracket, and should remain with the product even if
the equipment is subsequently sold.
9Technimount connually seeks advancements in product design and quality. Therefore, while this user guide
contains the most current product informaon available at the me of prinng, there may contain minor dierences
between your mounng system and this user guide.
If you have any quesons, or for more informaon, please contact Technimount Customer Service customerservice@
technimount.com.
SUMMARY OF SAFETY PRECAUTIONS

Return to Table of Contents
14 BP71-UG-202207-02 www.technimount.com
NOTICE
The Bracket Pro Serie® 71 is designed to comply with the essenal requirements and other relevant provisions of the
SAE J3043. For more informaon, please contact Technimount Customer Service (customerservice@technimount.
com).
Technimount E.M.S. Holding Inc.
C/O: Regulatory Aairs
3770, Jean Marchand Street, Suite 100-C
Quebec (QC) G2C 1Y6
Canada
T + 1 581.700.6613
TF + 1 888.639.2758
technimount.com
[email protected]
WARNING
The end user and administrator are responsible to validate regulaons and standards for safety in their region, in
order to comply with applicable safety regulaons. Technimount is not responsible to inform the end user and/or
administrator of applicable legislaon for safety in their area.

www.technimount.com BP71-UG-202207-02 15
Return to Table of Contents
INSTALLATION GUIDE
REMOVING THE PACKAGING FOR INSTALLATION
1. Unpack boxes and check all items are included for installaon.
2. Ensure that all shipping and packaging materials have been properly removed from the product(s) prior to
installaon.
3. Idenfy all of the product components and hardware prior to starng the installaon.
4. The bracket must work properly before it is put into service.
5. Refer to the idencaon of components at the beginning of this user guide if needed.
TOOLS REQUIRED FOR INSTALLATION
Below are the basic tools required for installaon. Other tools may also be required. If you have any quesons regarding
the installaon, or need assistance, please contact our Technical Support team at [e-mail].
9Phillips Screwdriver
NOTE
9Electrical tools are not recommended, as there is a potenal risk of damage to the threads.
9During the installaon process, Technimount recommends the use of medium strength thread-locking adhesive
(blue Locte) to prevent the screws from loosening during normal use. Put a few drops of medium strength thread-
locking adhesive (blue Locte) on each screw before installaon.
LIST OF MATERIAL
9Bracket Pro Serie 71

Return to Table of Contents
16 BP71-UG-202207-02 www.technimount.com
1. The Bracket Pro Serie 71 is designed to be
installed on the Philips IntelliVue X3 Monitor
with or without the Microstream CO2 Extension.
2. The Bracket is shipped fully assembled. To install
the Philips Intellivue X3, remove the two (2)
screws from the front support plate.
3. Align and insert the IntelliVue X3 Dock into the
main assembly.
INSTALLATION GUIDE
INSTALLATION OF THE DOCK, MONITOR AND MICROSTREAM INTO THE BRACKET
DOCK

www.technimount.com BP71-UG-202207-02 17
Return to Table of Contents
INSTALLATION OF THE DOCK, MONITOR AND MICROSTREAM INTO THE BRACKET
(CONTINUED)
4. Verify that the Dock is inserted properly into the
main assembly and ensure that there is no gap
between the Dock and the main assembly.
5. Align the front support plate with the main
assembly.
6. Insert the two (2) Black Oxide Stainless Steel Flat
Head Phillips Screws 10-32 x 1/2 in.
NOTE
Put a few drops of medium strength thread-locking
adhesive (blue Locte 242) on each screw before
installaon to prevent the screws from loosening
during normal use.
7. Tighten both screws.
CAUTION
9Do not use electrical tools to install the screws.
9Do not overghten the screws.
INSTALLATION GUIDE
DOCK (CONTINUED)

Return to Table of Contents
18 BP71-UG-202207-02 www.technimount.com
INSTALLATION GUIDE
INSTALLATION OF THE DOCK, MONITOR AND MICROSTREAM INTO THE BRACKET
(CONTINED)
1. Rotate the adjustable plate to its closed posion.
2. Align and insert the Philips IntelliVue X3 Monitor
from the right side of the bracket and gently slide
into the Dock unl you hear a clicking sound that
indicates the monitor is locked inside the Dock.
CAUTION
9Ensure that the monitor is proprely inserted and
locked by gently pulling on the monitor.
3. The Philips IntelliVue X3 Monitor, in its Dock is
ready to transport once properly inserted into its
bracket and the stretcher mounng system.
MONITOR

www.technimount.com BP71-UG-202207-02 19
Return to Table of Contents
1. Rotate the adjustable plate to its opened posion.
2. Align and insert the IntelliVue Microstream CO2
Extension from the right side of the bracket and
gently slide into the Dock unl you hear a clicking
sound that indicates the monitor is locked inside
the Dock.
3. Align and insert the Philips IntelliVue X3 Monitor
from the right side of the bracket, and gently slide
into the Microstream unl you hear a clicking
sound that indicates the monitor is locked inside
the Microstream.
CAUTION
9Ensure that the monitor is proprely inserted and
locked by gently pulling on the monitor.
4. The Philips IntelliVue X3 Monitor and the
Microstream CO2 Extension is ready for transport
once properly inserted into its bracket and the
stretcher mounng system.
MICROSTREAM AND MONITOR
INSTALLATION OF THE DOCK, MONITOR AND MICROSTREAM INTO THE BRACKET
(CONTINED)
INSTALLATION GUIDE

Return to Table of Contents
20 BP71-UG-202207-02 www.technimount.com
REMOVING THE PHILIPS INTELLIVUE X3 MONITOR AND EXTENSION FROM THE
BRACKET
1. To remove the Philips IntelliVue X3 Monitor
from the bracket, press and hold the Red Quick
Release Mechanism.
2. While holding the Red Quick Release Mechanism,
press on the top Dock buon.
3. Take the handle of the Philips IntelliVue X3
Monitor and slide it to the right to remove from
the bracket.
CAUTION
9Always remove the medical device by sliding it to
the right. Do not slide it forward.
4. To remove the Philips IntelliVue X3 Monitor and
Microstream from the bracket, press and hold
the Red Quick Release Mechanism.
OPERATION GUIDE
MONITOR
MONITOR AND MICROSTREAM
