Technomad WallBox Series User manual

Technomad User Manual - WallBox
Thank you for purchasing a WallBox!
The WallBox series are perfect solutions for any application
where low profile, all-in-one weatherproof powered mixers
are needed.
The core of the WallBox is the audio mixer. The mixer offers
four separate audio inputs, each with level control. The
mixer includes a three-way ducking switch option as well as
internally accessible crossover points and a basic limiter
circuit.
The WallBox XL has an expansion bay where factory-
installed source options such as a wireless microphone
receiver, audio player and more can be mounted. Please
contact Technomad to discuss application requirements if the unit was not ordered with the needed
optional module. The unit also includes an accessory shelf where either an audio input or output ac-
cessory module can be mounted. There is a 3.5mm input cable located here so a portable device
such as phone or tablet can easily and quickly be connected to the system.
Installation
The BreakoutBox series are designed to be installed onto a vertical surface. Each unit includes a set
of mounting tabs which attach to the rear of the enclosure with included 10-32 flathead screws. These
allow the unit to easily mounted using appropriate hardware. Alternately, the enclosure can be mounted
using the four 10-32 inserts on the back of the unit to which the mounting tabs are bolted.
Connecting Audio Sources
To connect an external device to the unit, use an appropriate adaptor cable for the input. While the
WallBoxes are mono devices, an audio source with stereo output can be connected using the included
3.5mm to 1/4 adaptor on line input 1. If the unit is purchased with the optional Bluetooth™ receiver
module, that module will be wired in parallel to the unbalanced input so if both the Bluetooth receiver
and a source plugged into that jack are used at the same time, there will be no individual level control
for the two sources.

5 Tina Drive, South Deerfield MA 01373 USA
Telephone: [phone] • Fax: [phone]
www.technomad.com • [email protected]
Technomad
Audio. Anywhere.
Features
Four individual input channels
1x microphone/balanced line level
3x unbalanced line level
Three way ducking circuit
Wired mic ducking, line level ducking, off
Integrated limiter
Integrated crossover filters (factory set)
Full range, 85Hz high pass, 85Hz low
pass, 350Hz high pass
Weatherproof polycarbonate enclosure
Stainless steel lockable hasp closure
Three amplifier options:
2x 50W, 1x100W, 1x150W mono (8Ω)
Connections
Audio Input Jacks
1x XLR- 1/4” TRS combo jack (front)
XLR pins = mic. level
1/4” TRS pins = balanced line level
1x 1/4” jack, unbalanced line level (front)
1x expansion bay with internal connection header
(TE Connectivity PN 1375820-3)
1x 3.5mm input cable, unbalanced line level, (shelf)
2x NL4MP speaker jacks
Power (standard)
120VAC
12VDC aux. power (USB)

Technomad User Manual - WallBox
To connect a source module to WallBox in
the Expansion Bay after purchase, use the
Input 4 header on the mixer PCB (circled in
red on the schematic). Access to these
headers is gained by removing the front
panel of the WallBox and should only be done
by an experienced technician.
Output Connections
The standard WallBox configuration includes two
Neutrik Speak-on NL4MP connectors. These are
wired in parallel. Connecting more than two 8Ω
speakers to the unit is not recommended due to
impedance concerns. The amplifier output is wired
to pair 1+/1- on the NL4MP jacks.
Operation
The WallBox provides four separate audio level
controls, one for each channel. When setting
levels for an audio channel be sure to monitor
the ‘Clip’ LED to ensure that the mixer inputs
are not being overdriven. Overdriving, or clipping, the input to
the unit can lead to damage of the speakers connected to the
system and should be avoided. Be sure all input level controls
are turned fully down (max. counter-clockwise) before powering
the unit on or off.
Ducking Switch
The unit includes a three way switch which controls the ducking
feature. When the switch is set to the ‘Mic’ setting, any input
from the wired microphone connection will override (or duck)
any active input on other channels. When the switch is to the
‘W. Mic’ setting, any input from Expansion Bay will override
any active input on other channels.
Available Source Options
Bluetooth receiver: PN 1775
Shure™ PGX D handheld wireless mic system w/ mounting brackets: PN 1717
Shure™ PGX D headset wireless mic system w/ mounting brackets: PN 2117
Samson Airline88 waterproof header mic system: PN 2096
Available Output Options
Source Splitter: PN 1714 (for use with more than two external PowerChitons. Installs either on the
shelf or Expansion Bay.

5 Tina Drive, South Deerfield MA 01373 USA
Telephone: [phone] • Fax: [phone]
www.technomad.com • [email protected]
Technomad
Audio. Anywhere.
Mic and Line inputs
Level controls
Ducking switch
Expansion Bay
(shown with optional
Samson waterproof mic
Locking hasp
Storage shelf
Mixer schematic
