Technosmart Atmopure 320 User manual

Contents
I. INTRODUCTION.
II. SAFETY NOTES
III. PRECAUTIONS
IV. MAINTENANCE
V. HOW DOES YOUR ATMOPURE 320 WORK?
VI. FEATURES OF ATMOPURE 320
VII. OPERATING YOUR ATMOPURE 320
1. DIGITAL TOUCH SCREEN FUNCTION
2. SETTING UP
3. OPERATIONAL STAGE
4. CLEANING AND REPLACEMENT OF FILTERS
i. Cleaning
ii. Sterilization
iii. Replacement
5. ATTENTION
VIII. TROUBLE SHOOTING
IX. TECHNICAL SPECIFICATIONS
Note：We reserves the right to at any time without notice make
any changes / amendments / deletions and / or variations to the
contents of this manual.

INTRODUCTION
Thank you for purchasing the ATMOPURE 320. The ATMOPURE 320 is a new,
state-of-the-art water-generating machine, which uses some of the latest
and most sophisticated technology available in the industry today with
•Steam
•Hot water
•Cold water
•Pressurised Water
We have designed your ATMOPURE 320 with one objective in mind
i.e. to produce the most maximum amount of high quality drinking water
while using only minimum amount of electricity, the machine can produce
purified drinking water thus makes it a unique -functional machine.
SAFETY NOTES
1. The socket should be equipped with reliable protection earthing.
2. Do not remove earthing terminal from the power cord.
3. Do not use extension plug nor extension adaptor.
4. Always keep the unit from poisonous gas and liquid.
5. Do not use damaged electrical plug or power cable.
6. Unplug power cord before maintenance.
7. Do not share the electrical socket with other high power consumption
appliance.
8. Always use correct replacement parts.
9. Do not unplug power cord with wet hands.
10. Use the enclosed water pipe kids to connect with city water input. Do not
use any old water pipelines to
connect to the unit.
11. When moving the machine, please unplug the power cord and empty
water in all tanks. Do not tilt the
machine more than 20º during moving.

PRECAUTIONS
1. Do not place the unit too close to the wall. Best performance is obtained
when the unit is placed at least 30 cm from the wall.
2. This unit is not for outdoor use.
3. Avoid prolonged exposure to direct sunlight.
4. Keeps the unit working in standing position.
5. Operating voltage must not drop below 10% of standard Power
Supply. When the unit operates below this level, the unit becomes
noisy with the possibility of overheating. When this occurs,
immediately switch the unit off until the voltage returns to normal.
6. Avoid prolonged direct eye exposure to ultraviolet device as it may
damage the eye.
7. Prevent children playing with HOT knob to avoid scalding.
8. This unit is not suitable for use at places with spray water. Do not use
spray water to clean the unit.
9. To prevent the machine from damage caused by freezing, please
drain off the remaining water and stop operating the machine if the
environment temperature during its working is below 0℃.
10. If there is any damage to the power cables, the cables must be
repaired or replaced by an authorized person to avoid danger.
11. For the condition of operating on uneven ground, a fixer should be
mounted to the unit (as pictures).
12. Do not place any object on top of the machine. Good ventilation is
required to ensure optimum performance.
MAINTENANCE
1. Always keep the unit clean. Wipe the outer casing with soft, damp fabric to
clean. Use water to clean, avoid
using harsh cleaning agent.
2. Do not use cleaning agent to clean storage tanks.
3. Clean air filters regularly to ensure proper air flow.
4. When machine not use for a longer period of time, drain out all water
completely and clean all tanks. Please
follow sterilization process in the user menu.

HOW DOES YOUR ATMOPURE 320 WORK?
It is important to be aware that your ATMOPURE 320 is a humidity and
temperature driven machine. This means the machine totally depends on the
level of humidity in the air and the temperature to produce water. Ideally, the
humidity level should be at least 50% or above to achieve the machine’s
optimum performance. In places with lower humidity level, the machine will
still produce water but not as quickly, nor as much as in places with high level
of humidity. In the house environment, higher level of humidity tends to be
around the kitchen area, near an open window or in more spacious rooms.
This unit also performs well in an air-conditioned room, but it is recommended
to open the window at night to make the room ventilated. Because your
ATMOPURE 320 works by converting the humidity in the air to water, this unit
also acts as an effective dehumidifier. In areas with high humidity, It not only
acts as a good water generator, but also a perfect dehumidifier to keep you
healthy and ensure your home appliances a long service time. To ensure high
quality of drinking water, The ATMOPURE 320 is utilizing multiple filtration
technologies.
When the air is dry or during cold season, water generation will be slow. At
this moment, connection to city water will make the machine serve as water
purifier by utilization of the filtration and sterilization system.
FEATURES OF ATMOPURE 320.
1. Microcomputer
The unit is fitted with a microcomputer, which ensures proper working of
internal parts. The machine has preset hot/cold temperature adjustable
functions. Temperature of hot or cold water can preset
according to personal preference.
2. Electronic Sensors
Various electronic sensors are attached to parts such as UV light, heating
mechanism and storage tanks. These sensors ensure that all parts are working

properly and warn you should a breakdown or performance irregularities
occur in the machine.
3. Energy Saving Features
To conserve electricity, electronic sensors have been placed in the storage
tank to automatically stop the machine from making more water when the
tank is full and hot/cold water reaches the preset data.
4. Child-proof Hot Water Lock Out
The function of hot water lock out is to prevent child from scalding upon
touching the water tap.
5. Water Leakage Detector
In case of any unexpected situation of water leakage, the machine can stop
working automatically and accompany with warning sound and flashing
screen.
6. Condensing Coils
The condenser is designed especially and with food class coating to prevent
any metal pollution and improve water production efficiency.
7. Multi-Stage Filtration System
Our dedication to providing high-quality, great tasting water to our
consumers is accomplished by our unique multi-stage filtration system. It can
remove odor and infectant.
7.1. Anti-static patented air-filter:
Before air become water drop through condensation, the air must go
through anti-bacterial air filter to
filter out dust particles and effectively block dust in the air from entering
the machine.
7.2. LF2 zeolite + active carbon filter at the bottom tank:
This device can remove organic compound, dust and large particles in
the air. It can also reduce ammonia
level in the water.
7.3. Sediment filter: Remove micro particles to protect RO booster
pump.
7.4. Multi stage filtration system:
Our filter system not only can produce light alkaline water with pH
between 7.2-7.8 but also producing
tasteful purified water with mineral which bring health to our body.
7.4.1. Pre-carbon filter

Remove organic compounds, odor, free chlorine, heavy metal,
etc.
7.4.2. Post carbon filter
Further remove any color, odor, heavy metal, organic
compound and chlorine, at the same time
protecting the RO membrane from chlorine and thus extend the
life span on the RO membrane.
7.4.3. RO membrane
To remove micro impurity,colloid,heavy metal,soluble
solids,bacteria and other harmful substances.
7.4.4. TCR carbon filter
Provide elements and minerals for human body, raise pH level to
light alkaline, improve taste.
8. Ultraviolet Sterilization System
The proprietary ultraviolet lamp treats the water for sterilization to ensure that
all bacteria and microorganism
are eliminated. Sterilization process is controlled by microcomputer
automatically.
8.1. Top tank UV device: Eliminate bacteria grow in top tank, reduce
bacteria level to minimal.
8.2. Cool water out UV device: Eliminating bacteria from dispensing
tubing. To ensure water is safe to
drink.
8.3. Bottom tank UV device: Eliminate bacteria grow in bottom tank,
reduce bacteria level to
minimal.
9. Water Recirculation
Our exclusive technology ensures that stored water remains fresh and clean
and avoids second pollution.
10. Overheat Protector
Overheat protector offers further protection for your machine. In case of
overheat in hot pot during heating process, this protector will automatically
shut off heating device.
11. Novel and Noble Body
The attractive modern design together with digital touch screen makes the
machine easy to operate and more
options to select personal preference.

Please contact your Installation and Training Executive
