Tecnoclima ENERGY Series Quick setup guide

TECHNICAL SPECIFICATIONS
ASSEMBLY, USE AND MAINTENANCE INSTRUCTIONS
AIR CONDENSATION GENERATORS
RANGE
ENERGY

- 2 -
Dear Customer,
Thank you for choosing an ENERGY series HOT AIR CONDENSATION GENERATOR, an
innovative, modern and high-efficiency product which provides comfort, unparalleled
noiselessness and safety for a long time; in particular, if the generator is serviced by a
TECNOCLIMA After-Sales Service Centre, specifically qualified and trained to keep it at its
maximum efficiency level, with reduced operating costs, and, when needed, they can also provide
original spare parts.
This instruction manual contains important indications and suggestions that must be observed
for simpler installation and for best possible use of the HOT AIR CONDENSATION
GENERATOR of the ENERGY series.
Thank you. Tecnoclima S.p.A.
CONFORMITY
The hot air condensation generator mod. ENERGY complies with:
•Machinery directive 2006/42/EC
•Low Voltage Directive 2006/95/EC
•Regulation UE 2016/426 for Gas equipment
•Electromagnetic Compatibility Directive 2004/108/EC
PIN NUMBER
The PIN number of the certification is included in the technical data plate.
RANGE
This manual includes references to the TYPE. The following table shows the series and the correspondence
between the TYPE and the TRADE NAME
TYPE
TRADE NAME
1
ENERGY 60
2
ENERGY 105
3
ENERGY 160
4
ENERGY 220
5
ENERGY 320
6
ENERGY 460
7
ENERGY 640
8
ENERGY 970
WARRANTY
The ENERGY series hot air generator is covered by a SPECIFIC WARRANTY, which starts from the purchase
date, which should be proved by the Customer through the relevant documents; if the customer is unable to
present the relevant documents, the warranty starts from the machine manufacturing date. The warranty
conditions are detailed in the WARRANTY CERTIFICATE, supplied with the first ignition.

- 3 -
TABLE OF CONTENTS
GENERAL INFORMATION:
Compliance 2
Pin number 2
Range 2
Warranty 2
Index 3
General warnings 4
Basic safety rules 5
Notes for disposal 5
Description of the device 6
Product receipt 8
Identification 8
Structure of the warm air heater 9
Heat exchanger operating diagram 10
Net volume and weight 11
Technical data 12
Table of regulations 2016/2281 14
nox emission class 16
Gas categories 16
Characteristic graphics 17
INSTALLATION AND SETTING INSTRUCTIONS:
Handling and transport 21
Position 22
Transportation blocks 23
Respect area 23
Fuel connection 23
Smoke discharge 24
Condensation drain 26
Condensation drain syphon (supplied) 27
Air inlet-outlet connection 28
Fixed protections 28
Accessories 29
Burner assembly and setting 29
Burner combinations 29
Combinations with the burner at its max thermal power 30
Combustion air 31
Operating principles with two-stage burner 32
Operating principles with modulating burner 33
Electric connection 35
Wiring diagram reference 36
LIMIT and FAN safety thermostats 37
Automatic reset bi-thermostat (TR) 38
Thermostat safety positioning 39
TR SAFETY FAN-LIMIT-thermostat calibration 40
Setting the fan speed 40
Fan speed adjustments 41
INSTALLATION AND SETTING INSTRUCTIONS:
Checks 43
Controls 44
Indicators 44
Engine electric absorption 45
Maintenance 45
External panelling maintenance 45
Cleaning of gas or oil burner 46
Cleaning of condensation drain system 46
Ventilation unit maintenance 46
Safety thermostat maintenance 46
Maintenance of safety elements 46
Cleaning of the heat exchanger 47
Position of the inlet for taking smoke sample 48
Customer service 48
Problems and solutions 49
In the manual, the following symbols are used:
WARNING = operations requiring appropriate care and preparation.
FORBIDDEN = operations that MUST NOT be performed, in any case

- 4 -
GENERAL REMARKS
This manual is an integral part of the machine, therefore it should always be carefully kept and it should always be
provided together with the machine, if it is transferred to another owner or user. If this manual is damaged or lost,
a new one should be requested from the local Technical Assistance Service or from the Manufacturer.
After unpacking the product, check the integrity and completeness of the contents. If not, contact the Agency that
sold the unit.
Installation of the air generator must be carried out by an authorised company that, at upon completion of the work,
issues the declaration of conformity of installation performed to a professional standard, i.e. in compliance with the
current regulations and with the instructions provided by the Manufacturer in this instruction manual.
This appliance has been manufactured for room heating and it must be used for this purpose, compatibly with its
performance characteristics.
Any contractual or extra-contract liability of the Producer in respect of damages caused to people, animal or things
by a non correct installation, setting or maintenance or by the improper use of the machine is excluded.
If the temperature is too high, it could be harmful to health and would be a useless waste of energy.
Do not leave the rooms closed for a long time. Periodically open the windows to ensure proper ventilation.
During the initial start-up, there may be the formation of odours and fumes due to the evaporation of the liquid
added to protect the heat exchanger during storage; this is normal and it will disappear after a short period. It is
recommended to suitably ventilate the room.
If you will not be using the unit for long periods, carry out the following operations:
• turn the main switch of the unit and the general switch of the plant to "OFF"
• close the main fuel supply valve
If the air heater has not been used for a long time, we suggest having the Technical Assistance Service or other
skilled personnel put it back in service.
The machine shall be fitted only with original accessory equipment. The Producer is not liable for damages arising
from the improper use of the machine or from the use of non-original materials or accessories.
References to Laws, Regulations, Directives and Technical Rules mentioned in this manual are provided only for
information purposes and as they are in force when the manual is printed. The entry into force of new provisions or
amendments to current laws does not represent an obligation of the manufacturer towards third parties.
Repairs or maintenance must be performed by the Technical Assistance Service or by qualified personnel in
accordance with this manual. Do not modify or tamper with the appliance as dangerous situations can be created
and the manufacturer will not be liable for any damage caused.
The systems that are to be carried out (gas pipes, power supply, etc,) must be suitable secured and must not be
dangerous with the risk of tripping.
The Producer is responsible for the product compliance with Laws, Directives or Construction Rules in force when
the product is marketed. The knowledge and observance of the laws and standards regarding plant design,
installation, operation and maintenance are the sole responsibility of the designer, installer and user.
The Producer shall not be held responsible for failure to comply with the instructions of this manual, for the
consequences of any operations carried out and not specifically provided for or for translations open to
misinterpretation.
Operation is envisaged with air flow and variable thermal power also with condensation of the combustion products.
In the case of poor lighting, use a light source to carry out all the installation and maintenance operations.
During handling, installation and maintenance it is mandatory to comply with the general principles of health and
safety using the personal protective equipment (PPE), in compliance with the relevant laws and regulations.

- 5 -
MAIN SAFETY RULES
Bear in mind that if you use products powered trough electric power, gas, etc., you should comply with some basic
rules, such as:
Children and unassisted disabled people must not use the hot air generator.
Do not operate electrical devices such as switches, electrical appliances, etc. if you can smell fuel. In this case:
• air the room by opening doors and windows;
• close the fuel control device;
• promptly request the intervention of the Technical Assistance Service or of skilled personnel.
Do not touch the unit barefoot or when parts of the body are wet or damp.
Do not clean or perform maintenance before disconnecting the unit from the electrical power supply by turning the
main switch of the system to "OFF", and shutting-off the fuel.
Do not modify the safety or adjustment systems without authorization and the instructions of the manufacturer of
the unit.
Do not pull, disconnect and twist the electrical cables coming from the unit, even if it is disconnected from the
electrical power supply.
Do not open the access doors to the inside of the unit, without turning the main switch of the unit to "OFF".
Do not dispose of, abandon or leave within the reach of children, the packaging materials (cardboard, staples, plastic
bags, etc.), as they may be potentially dangerous.
Do not install the unit near flammable material, or in rooms with an aggressive atmosphere.
No object should be placed over the machine nor inserted through its case grill or through the combustion product
exhaust ducts.
The exhaust duct should not be touched, since during normal operations it might reach high temperatures, being
therefore dangerous to be touched.
Do not use adaptors, power strips and extension cables for the electrical connection of the unit.
Do not install the unit beyond the limits of use and operation shown in the instruction manual.
The warm air heater shall not be directly installed in small areas lacking proper ventilation, since the air intake might
cause a remarkable depression within the room, causing serious problems.
The burner should not be installed outside and should not be directly exposed to bad weather
DISPOSAL INSTRUCTIONS
Disposing of the appliance must be performed by an authorised company and in compliance
with the applicable laws.
Before taking waste to Authorised Collection Centres, dismantle and separate the various
materials that compose it which in summary are:
•ferrous materials;
•aluminium;
•electrical wiring;
•gaskets;
•insulating materials;
•plastic materials;
•electronic cards.

- 6 -
DESCRIPTION OF THE UNIT
The warm air generator is basically a thermal unit that exchanges the products resulting from the combustion
of a forced draught burner for the air flow produced by a high-performing ventilation unit.
The air to be heated is sucked by the ventilation unit and, when it laps the hot surface of the heat exchanger,
it is heated - increasing its temperature; then it can be distributed both directly and through proper channels.
Thanks to its features, the centrifugal fan can be installed in plants requiring the distribution of the heated
through channels or, in general, where static pressure is needed.
Through this heating system, the plant costs can be remarkably reduced and a reliable operating economy
can be reached; therefore, it is particularly fit for those cases where it will be used occasionally and
discontinuously.
The specific hot air generator has been designed to be combined with a gas burner with variable thermal
power (two-stage or modulating); in reduced thermal power operation, the flue gas temperature drops below
the dew point, the condensation phenomenon starts, and recovery of the "latent energy" contained in the
water vapour that normally occurs in the chemical process of combustion takes place.
The high-quality materials used to manufacture the heat exchanger ensure safe and long-lasting operation
even under with condensation of the combustion products, which is discharged to the outside through a
dedicated connection.
Combination with a burner with variable thermal power allows the continuous and linear control of the thermal
power of the appliance in relation to the immediate needs of the user, maximising operating economy.
In summer, it is also possible to use only the fan unit.
CONSTRUCTION FEATURES AND GENERAL FUNCTIONS:
Heat Exchanger:
It is made of welded stainless steel, it can be easily inspected for ordinarily cleaning and maintenance
operations and it comprises the following elements:
•Combustion chamber made ofAISI 430 stainless steel, with low thermal load, cylindrical or egg-
shaped and of the appropriate size.
•Exchange elements in stainless steel AISI 304 stainless steel with a large surface, with turbulent
impressions and equipped with special reticular turbulators.
•Smoke manifold in stainless steel AISI 304 stainless steel, equipped with inspection door and
condensate discharge connection.
External casing:
The case is made up of removable boards of pre-painted sheets and/or powder-painted and it includes also:
•Anti-radiant thermal insulation of the surfaces exposed to the heater irradiation.
•Outlet flange to connect the warm air distribution circuit.
•Intake flanged plenum to connect the treated air intake circuit.
The 38 type devices include a press-formed galvanised steel profile, which has been powder-painted with
corner-joints made of strong and special pressure-cast aluminium profiles, completely designed by the
Manufacturer.

- 7 -
Fan assembly:
It is made up by one or more low noise emission and high-performing centrifugal fans, powered by an electric
engine connected to a pulley and belt driving system. If possible, the engine is equipped with a variable-pace
pulley, which ensures that the machine will easily adapt to the destination plant.
Control and safety thermostat:
The machines are equipped with thermostats; their sensor shall be placed on the air outlet (prepared and
electrically connected in the manufacturing plant), with the following functions:
•"FAN" function (FAN thermostat –calibration: +25/+35°C), it activates the fans max. 60 seconds
after the burner has started and it stops them approx. 4 minutes after it has stopped. Thus, it prevents
unpleasantly cold air from being released in the room when the machine is activated and the thermal
energy accumulated by the heat exchanger can be exhausted, by completely using it before the
machine stops.
•“SAFETY” function (TR safety thermostat - pre-set calibration: +80°C ). It is installed on the 3÷8
types. It stops the burner if the air is anomalously overheated. It is automatically restored. It shall be
correctly calibrated when it is used for the first time.
•"LIMIT" function (LM Thermostat - sealed calibration: +100°C): it stops the burner if the air is
anomalously overheated. It shall be manually restarted.
Smoke discharge inlet
The machine is fitted with a round inlet where a metal pipe should be safely inserted and fixed, in order to
discharge the combustion products. The flue to be used must be in accordance with and certified
standard .
Condensate drainage connector
Since the combustion products are expected to function with an output of condensation, the device is equipped
with a threaded connection for the discharge of condensation; it must be connected according to current
standards in force.

- 8 -
RECEIVING THE PRODUCT
The warm air heater is supplied together with:
•Document envelope including:
oInstruction booklet;
oWarranty certificate;
oBar code tags.
•Condensate drain syphon;
•Reticular turbulator extraction hook;
•Pressure intake for combustion chamber;
•Lifting eyebolts for devices TYPE 6-7-8;
•Sealing gasket;
•Various fixing screws of the individual elements.
IDENTIFICATION
The warm air heaters can be identified through:
The Technical Plate, applied on the machine, specifying the main technical-performance data.
ATTENTION!!!
In the event of damage or loss, request a duplicate from the Technical Assistance Service.
MANUFACTURER IDENTIFICATION DATA 0694
WARM AIR HEATER
Model
Registration Number
Country
PIN
Category
Code
Type
Year
Max thermal capacity
kW
Max thermal power
kW
Max air flow rate
m³/h
Useful static pressure
Pa
Three-phase power supply
Fan motor power
kW
Max electric power to the fan engine
A
Electric protection degree
IP

- 9 -
STRUCTURE HOT AIR GENERATOR
1) Smoke pipes
2) Combustion chamber
3) Front smoke manifold
4) Rear smoke manifold
5) Inspection shutter of the heat exchanger
6) Smoke discharge pipe connector
7) Burner nozzle
8) Flame eyehole
9) Ventilation unit
10)Ventilation unit engine
11)Condensate drainage connector
12)Electrical panel
13)FAN-LIMIT double thermostat

- 10 -
HEAT EXCHANGER OPERATING DIAGRAM
Axonometric image of a significant heat exchanger:
Operating diagram:
Legend:
1. Chimney connector
2. Rear smoke manifold
3. Smoke pipes
4. Front smoke manifold
5. Flame eyehole
6. Gas or fuel burner
7. Combustion chamber
Combustion products:
•perform an inversion in the combustion chamber;
•are routed to the first exhaust manifold (front manifold) and are channelled in the exchange elements
(smoke pipes);
•arrive in the second exhaust manifold (rear collector) and then they are discharged trough the circular
connector.

- 11 -
NET VOLUME AND WEIGHT
TABLE OF DIMENSIONS AND WEIGHTS:
TYP
E
A
B
C
D
E
F
G
H
I
L
M
N
P
WEIGH
T
mm
kg
1
812
554
1,58
0
600
-
490
-
685
625
460
400
-
-
135
2
1,06
0
774
1,92
6
900
-
700
-
960
900
560
500
-
-
255
3
1,30
0
900
2,12
0
1,30
0
1,24
0
900
840
1,22
5
1,15
5
825
755
-
-
450
4
1,50
0
1,00
0
2,12
0
1,50
0
1,44
0
1,00
0
940
1,42
5
1,35
5
825
755
-
-
535
5
1,70
0
1,20
0
2,35
0
1,70
0
1,64
0
1,20
0
1,14
0
1,62
5
1,55
5
825
755
-
-
750
6
2,09
0
1,27
0
2,87
0
2,09
0
2,03
0
1,27
0
1,21
0
950
880
925
855
1,00
0
1,87
0
1,180
7
2,50
0
1,50
0
3,12
0
2,50
0
2,44
0
1,50
0
1,44
0
1,15
5
1,08
5
925
855
1,00
0
2,12
0
1,650
8
3,50
0
1,50
0
3,32
0
3,50
0
3,44
0
1,50
0
1,44
0
1,65
5
1,58
5
1,12
5
1,05
5
1,20
0
2,12
0
2,100

- 12 -
TECHNICAL SPECIFICATIONS
TYPE
1
2
3
4
5
6
7
8
OPERATING REGIME
MAX
Thermal power
(burned)
kW
68.2
115.1
175.7
246.1
354.8
502.9
715.2
1,089.8
kcal/h
58,635
99,025
151,145
211,670
305,120
432,495
615,045
937,300
Performance (1)
%
88.2
90.0
91.2
88.2
91.3
92.5
90.7
89.0
Thermal output
(produced)
kW
60.1
103.5
160.3
217.1
323.9
465.2
648.6
970.0
kcal/h
51,715
89,020
137,845
186,695
278,575
400,060
602,810
834,200
Combustion chamber pressure
mm H2O
3.2
4.9
4.2
4.6
8.0
11.5
12.2
10.0
Net fume temperature (2)
°C
260
210
185
240
184
154
182
250
Fume mass flow rate
Kg/h
107
181
277
388
559
792
1,130
1,690
Air temperature gradient
°K
39
38
43
43
45
44
45
41
Consumption (3)
• G20 methane gas
Nm³/h
7.2
12.1
18.6
26.0
37.5
53.2
75.7
115.3
• G25 methane gas
Nm³/h
8.4
14.1
21.6
30.3
43.6
61.9
88.0
134.1
• G31 propane gas
Nm³/h
2.8
4.7
7.2
10.0
14.5
20.6
29.3
44.6
• G30 butane gas
Nm³/h
2.1
3.6
5.4
7.6
11.0
15.6
22.2
33.8
• fuel oil
Kg/h
5.7
9.7
14.8
20.7
29.9
42.4
60.3
91.9
OPERATING REGIME
NOMINAL
Thermal power
(burned)
kW
58.8
115.1
175.7
210.9
354.8
502.9
715.2
987.8
kcal/h
50,570
99,025
151,145
181,375
305,120
432,495
615,045
849,510
Performance (1)
%
90.1
90.0
91.2
90.1
91.3
92.5
90.7
90.0
Thermal output
(produced)
kW
53.0
103.5
160.3
190.0
323.9
465.2
648.6
890.0
kcal/h
45,580
89,020
137,845
163,400
278,575
400,060
602,810
765,400
Combustion chamber pressure
mm H2O
3.2
4.9
4.2
4.6
8.0
11.5
12.2
10.0
Net fume temperature (2)
°C
205
210
185
205
184
154
182
210
Fume mass flow rate
Kg/h
93
181
277
334
559
792
1,130
1,563
Air temperature gradient
°K
34
38
43
38
45
44
45
37
Consumption (3)
• G20 methane gas
Nm³/h
6.2
12.1
18.6
22.3
37.5
53.2
75.7
104.5
• G25 methane gas
Nm³/h
7.2
14.1
21.6
25.9
43.6
61.9
88.0
121.6
• G31 propane gas
Nm³/h
2.4
4.7
7.2
8.6
14.5
20.6
29.3
40.4
• G30 butane gas
Nm³/h
1.8
3.6
5.4
6.5
11.0
15.6
22.2
30.6
• fuel oil
Kg/h
4.9
9.7
14.8
17.8
29.9
42.4
60.3
83.3
OPERATING REGIME
MINIMUM
Thermal power
(burned)
kW
22.6
36.8
55.1
65.4
119.1
196.6
154.6
232.0
Kcal/h
19,430
31,665
47,345
56,280
102,465
169,075
132,990
199,520
Thermal output
(produced)
kW
22.7
37.1
55.9
66.5
119.9
196.8
159.7
234.3
Kcal/h
19,540
31,950
48,040
57,155
103,115
169,265
137,370
201,150
Performance (1)
%
100.6
100.9
101.5
101.6
100.6
100.1
103.3
101.0
Combustion chamber pressure
mm H2O
0.2
0.2
0.5
0.7
1.0
2.0
0.8
0.7
Net fume temperature (2)
°C
53
54
49
54
47
53
32
46
Fume mass flow rate
Kg/h
35
58
86
103
187
311
244
366
Thermal gradient
°C
14
14
15
13
16
19
11
9.8
Consumption (3)
• G20 methane gas
Nm³/h
2.4
3.9
5.8
6.9
12.6
20.9
16.4
24.55
• G25 methane gas
Nm³/h
2.8
4.5
6.8
8.0
14.7
24.3
19.0
28.56
• G31 propane gas
Nm³/h
0.9
1.5
2.2
2.7
4.9
8.0
6.3
9.49
• G30 butane gas
Nm³/h
0.7
1.1
1.7
2.0
3.7
6.1
4.8
7.2
• fuel oil
Kg/h
1.9
3.1
4.6
5.5
10.0
16.6
13.0
19.5
1) Referred to a lower heating power (Hi)
2) Referred to combustion air temperature +15°C
3) G20 methane gas Hi = 34.02 MJ/Nm3
Methane gas G25: Hi = 29.25 MJ/Nm3
Propane gas G31: Hi = 88.00 MJ/Nm3
G30 butane gas: Hi = 116.09 MJ/Nm3
Fuel oil: Hi = 10,200 kcal/kg

- 13 -
TYPE
1
2
3
4
5
6
7
8
VERSION
STANDARD USEFUL STATIC PRESSURE
Nominal airflow rate
m³/h
4,600
8,000
11,000
15,000
21,500
31,000
43,000
71,000
Standard static pressure
Pa
220
220
220
220
220
220
220
220
Fan
• Quantity
No.
1
1
1
1
1
2
3
2
• Size
Mod.
AT 12-
9 S
AT
15-15
S
AT 18-
13 S
AT 15-
11 G2L
AT 18-
13 G2L
AT 18-
18 SM
AT 18-
13 SM
AT 18-
18 G2L
Fan motor
• Quantity
No.
1
1
1
1
1
1
1
2
• Unit power
kW
1.1
2.2
3.0
4.0
5.5
9.25
15.0
11.0
• Unit current
A
2.55
4.65
6.18
8.13
10.9
18.0
28.1
21.0
• Start-up
Type
direct
direct
direct
direct
direct
Y - ∆
Y - ∆
Y - ∆
VERSION
HIGH AVAILABLE PRESSURE
Nominal airflow rate
m³/h
4,600
8,000
11,000
15,000
21,500
31,000
43,000
71,000
Standard static pressure
Pa
450
450
450
450
450
450
450
450
Fan
• Quantity
No.
1
1
1
2
1
2
3
3
• Size
Mod.
AT 12-
9 S
AT
15-15
S
AT 18-
13 S
AT 15-
11 S
18-13
G2L
AT 18-
18 S
AT 18-
13 S
ADH
560 L
Fan motor
• Quantity
No.
1
1
1
2
1
2
1
3
• Unit power
kW
1.5
3.0
4.0
3.0
7.5
5.5
18.5
9.25
• Unit current
A
3.31
6.18
8.13
6.18
14.4
10.9
34.3
18.0
• Start-up
Type
direct
direct
direct
direct
Y - ∆
direct
Y - ∆
Y - ∆
TYPE
1
2
3
4
5
6
7
8
Electrical power supply
type
THREE PHASE WITH NEUTRAL
Electrical voltage
V -
50Hz
400 ~ 50 Hz 3 Ph + N (5%)
Electric protection degree
IP
44
Type
B23
Operating range
°C
-15 / +40
The specified aeraulic performances do not take into account the friction losses of the heater
fittings, if any (filters, shutters, intake grills, etc.)

- 14 -
REGULATION TABLE 2016/2281
OPERATING SYSTEM: TWO-STAGE
TYPE
1
2
3
4
Configuration:
B23
B23
B23
B23
Fuel type:
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Capacity:
P rated,h
kW
60.1
60.1
103.5
103.5
160.3
160.3
217.1
217.1
P min
kW
35
41.5
65
77
65
89
110
89
Useful efficiency (1):
nom
%
79.4
82.7
81
84.4
82
85.6
79.4
88.2
pl
%
85.9
85.38
87
88.1
85.9
91.8
88.4
97.8
Electrical energy consumption:
el max
kW
0.18
0.18
0.35
0.47
0.35
0.6
0.53
0.6
el min
kW
0.18
0.18
0.35
0.47
0.35
0.6
0.53
0.6
el sb
kW
0.002
0.002
0.002
0.002
0.002
0.002
0.002
0.002
Other elements:
F env
%
0
0
0
0
0
0
0
0
P ign
kW
-
-
-
-
-
-
-
-
s,flow
%
91.5
90.3
91.1
89.8
92.7
90.9
91.5
92.7
s,h
%
74.4
73
74.7
74.3
76.8
79.2
76.85
81.4
TYPE
5
6
7
8
Configuration:
B23
B23
B23
B23
Fuel type:
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Capacity:
P rated,h
kW
323,9
323,9
465,2
465,2
648,6
648,6
970
910
P min
kW
119,1
166
196,6
196,6
154,6
188
300
234,3
Useful efficiency (1):
nom
%
82,2
85,7
83,3
86,8
81,6
85,1
80,1
83,5
pl
%
90,5
92,7
90
93,9
92,9
95,3
89,5
94,7
Electrical energy consumption:
el max
kW
0.6
0.6
0.75
1.8
2
1.8
2.8
2.2
el min
kW
0.6
0.6
0.75
1.8
2
1.8
2.8
2.2
el sb
kW
0.008
0.008
0.008
0.008
0.05
0.05
0.05
0.05
Other elements:
F env
%
0
0
0
0
0
0
0
0
P ign
kW
-
-
-
-
-
-
-
-
s,flow
%
93
91,2
92,3
92,3
94,5
93,9
94,2
95,1
s,h
%
80,9
80,8
79,9
82,9
84,5
81,4
81,2
86,8
1) Referring to a higher calorific value (Hs):
•Gaseous : gas G20 (37.78 MJ/Nm³);
•Liquid: fuel oil (45.5 MJ/kg).
Legend:
P rated,h Nominal heating capacity
P rated,h Minimum heating capacity
nom
Nominal heating capacity useful efficiency
pl
Minimum capacity useful efficiency
el max At nominal heating capacity
el max At minimum heating capacity
el sb In "stand-by" mode
F env Envelope loss factor
P ign Ignition burner consumption
s,flow Emission efficiency
s,h Ambient heating seasonal energy efficiency
Notes:
The data reported in the table refer to the calorific value higher than the fuel (GCV)

- 15 -
OPERATING SYSTEM: MODULATING
TYPE
1
2
3
4
Configuration:
B23
B23
B23
B23
Fuel type:
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Capacity:
P rated,h
kW
60,1
-
103,5
-
160,3
-
217,1
-
P min
kW
26
-
48
55,9
-
68
-
Useful efficiency (1):
nom
%
79,4
-
81
-
82,1
-
79,4
-
pl
%
88,6
-
89
-
89
-
91,8
-
Electrical energy consumption:
el max
kW
0,18
-
0,35
-
0,35
-
0,53
-
el min
kW
0,18
-
0,35
-
0,35
-
0,53
-
el sb
kW
0,002
-
0,002
-
0,002
-
0,002
-
Other elements:
F env
%
0
-
0
-
0
-
0
-
P ign
kW
-
-
-
-
-
-
-
-
s,flow
%
93,1
-
92,9
-
94
-
93,8
-
s,h
%
80
-
80
-
82
-
84
-
TYPE
5
6
7
8
Configuration:
B23
B23
B23
B23
Fuel type:
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Gassy
Liquid
Capacity:
P rated,h
kW
323,9
-
465,2
465,2
648,6
648,6
970
910
P min
kW
119,1
-
196,8
196,6
154,6
188
300
234
Useful efficiency (1):
nom
%
82,1
-
83,2
86,8
81,6
85,1
80,1
83,5
pl
%
90,5
-
90,1
91,4
93,0
95,3
89,5
94,8
Electrical energy consumption:
el max
kW
0,6
-
0,75
1,8
2
1,8
2,8
2,2
el min
kW
0,6
-
0,75
1,8
2
1,8
2,8
2,2
el sb
kW
0,03
-
0,03
0,05
0,05
0,05
0,05
0,05
Other elements:
F env
%
0
-
0
0
0
0
0
0
P ign
kW
-
-
-
-
-
-
-
s,flow
%
92,9
-
92,3
92,3
94,5
93,9
95,2
95,2
s,h
%
82,3
-
81,2
82,3
86,2
87,7
82,5
88,5
1) Referring to a higher calorific value (Hs):
•Gaseous : gas G20 (37.78 MJ/Nm³);
•Liquid: fuel oil (45.5 MJ/kg).
Legend:
P rated,h Nominal heating capacity
P rated,h Minimum heating capacity
nom
Nominal heating capacity useful efficiency
pl
Minimum capacity useful efficiency
el max At nominal heating capacity
el max At minimum heating capacity
el sb In "stand-by" mode
F env Envelope loss factor
P ign Ignition burner consumption
s,flow Emission efficiency
s,h Ambient heating seasonal energy efficiency
Notes:
The data reported in the table refer to the calorific value higher than the fuel (GCV)

- 16 -
EMISSIONS NOX
The NOx emissions class depends on the version of the burner being installed. Consult the Manufacturer for
combinations other than those listed in the manual.
The NOx emissions of the hot air generator series ENERGY combined with the burners stated in
this manual are lower then 100 mg/kWh for fuel type gassy and lower then 180 mg/kWh for fuel
type liquid.
GAS CATEGORIES
The unit is certified in EU countries and in the countries that will soon enter the EU, according to
the gas categories shown below:
COUNTRY
CATEGORY
AL
II2H3B/P, II2H3P
AT
II2H3B/P
BE
I2E(R)B, I3P
BG
II2H3B/P, II2H3P
CH
II2H3B/P
CY
I3B/P, I3P
CZ
II2H3B/P, II2H3+, II2H3P
DE
II2ELL3B/P
DK
II2H3B/P
EE
II2H3B/P
ES
II2H3+
FI
II2H3B/P
FR
II2Er3P
GB
II2H3+
GR
II2H3B/P
HR
II2H3B/P, II2H3P
HU
II2H3B/P
IE
II2H3P
IT
II2H3+
LT
II2H3B/P, II2H3P
LU
II2E3B/P
LV
I2H
MT
I3B/P, I3P
NL
II2L3P
NO
I3P
PL
II2E3PB/P
PT
II2H3+
RO
II2H3B/P, II2H3P
SE
II2H3B/P
YES
II2H3B/P, II2H3P
SK
II2H3B/P, II2H3+, II2H3P
TR
II2H3B/P

- 17 -
CHARACTERISTIC GRAPHICS
Example of reading:
At the maximum air flow rate, with the burner regulated with a heat output of 30 kW, the thermal efficiency
(referring to the lower calorific value Hi) of the fumes is 95.5%, while the total efficiency (referring to the
lower calorific value Hi ) including the energy recovery of latent evaporation heat is approximately 97.5%.
In these conditions the temperature difference of the treated air is19°K.

- 18 -

- 19 -

- 20 -
