Tecnoinox MODULAR 1 User manual

INSTRUCCIONES DE MONTAJE
ESCURREPLATOS
www.cucineoggi.com

224 52
10 depth.10mm
48
A
Drill sides as shown in the drawing here to the side
a 9.5mm tip. The holes must have a depth of 10mm.
20825 BARLASSINA (MI) - via Longoni, 112/114
www.tecnoinoxsrl.it - [email protected]
minimum size to be added to the frame
dimension to ensure the extraction of tray.
Also check that there are no interference
with the hinges of the furniture.
frame dimension
Pag.1 di 2
ASSEMBLY INSTRUCTION MODULAR 1

B
A

CUP HOLDER
L
DETAIL L
SCALE 1 : 1
DETAIL A
SCALE 2 : 1

Make sure the pins are fully inserted in the holes
sides of furniture.
Press the pins (B) of the cup holder and hold them down
insert the drawer in the cabinet.
Release the pins by inserting them into the appropriate holes (A).
1. For proper maintenance, it is recommended that:
- Wash the product frequently with soap and water and dry with a soft cloth.
- Use an anti-lime treatment to remove any deposits of limestone. Then rinse thoroughly with water.
- Avoid contact with hydrochloric acid fumes coming from, for example, floor washing.
- Avoid direct use on stainless steel of chlorine-containing detergents.
2. For correct use of the tray:
- Be sure to level with a level that drains it and the bowl is flat.
- Empty the water from the jar after each use and dry.
- Avoid stagnating water in the collecting tray to avoid the formation of limestone, deposits, molds.
3. Plastic casings and plastic holders can be washed separately in the dishwasher at a temperature
maximum of 50 ° C.
Pag.2 di 2
20825 BARLASSINA (MI) - via Longoni, 112/114
www.tecnoinoxsrl.it - [email protected]
ASSEMBLY INSTRUCTION MODULAR 1

224 52
10 depth.10mm
224
48
A
Drill sides as shown in the drawing here to the side
a 9.5mm tip. The holes must have a depth of 10mm.
20030 BARLASSINA (MI) - via Machiavelli, 16
www.tecnoinoxit.com - [email protected]
minimum size to be added to the frame
dimension to ensure the extraction of tray.
Also check that there are no interference
with the hinges of the furniture.
frame dimension
Pag.1 di 2
ASSEMBLY INSTRUCTION INOXMATIC

B
A

C
D
PLATE HOLDER
CUP HOLDER
L
DETAIL L
SCALE 1 : 1
DETAIL A
SCALE 2 : 1

Make sure the pins are fully inserted in the holes
sides of furniture.
Press the pins (B) of the cup holder and hold them down
insert the drawer in the cabinet.
Release the pins by inserting them into the appropriate holes (A).
Repeat the operation with the plate holder by matching pins (D)
with holes (C).
1. For proper maintenance, it is recommended that:
- Wash the product frequently with soap and water and dry with a soft cloth.
- Use an anti-lime treatment to remove any deposits of limestone. Then rinse thoroughly with water.
- Avoid contact with hydrochloric acid fumes coming from, for example, floor washing.
- Avoid direct use on stainless steel of chlorine-containing detergents.
2. For correct use of the tray:
- Be sure to level with a level that drains it and the bowl is flat.
- Empty the water from the jar after each use and dry.
- Avoid stagnating water in the collecting tray to avoid the formation of limestone, deposits, molds.
3. Plastic casings and plastic holders can be washed separately in the dishwasher at a temperature
maximum of 50 ° C.
Pag.2 di 2
20030 BARLASSINA (MI) - via Machiavelli, 16
www.tecnoinoxit.com - [email protected]
ASSEMBLY INSTRUCTION INOXMATIC
