tedee TLV1.0 Assembly instructions

tedee lock | page 1www.tedee.com
INSTALLATION GUIDE
AND USER MANUAL
tedee lock TLV1.0 and TLV1.1
Read installation guide and user manual
and learn how to use your device in a safe and proper manner.
EN

page 2 | tedee lock www.tedee.com
table of contents
table of contents
quick start with tedee lock
safety information
safety guidelines / warnings
charging and maintenance guidelines/warnings
set of items – what’s in the box?
activation code
setup - 3 easy steps
step 1: install tedee lock
step 2: download tedee app, create new account, and log in
step 3: use tedee app to activate and calibrate your tedee lock
charging tedee lock
deinstallation of tedee lock
factory reset
additional and technical information
technical specications
radio frequency
micro USB Cable
power supply, battery and charging
software
LED signals
legal / environmental notes
warranty
technical support
Page 2
Page 3
Page 4
Page 4
Page 5
Page 7
Page 8
Page 9
Page 9
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 17
Page 18
Page 18
Page 19
Page 19
Page 20
Page 22
Page 22
Page 23

tedee lock | page 3www.tedee.com
Page 2
Page 3
Page 4
Page 4
Page 5
Page 7
Page 8
Page 9
Page 9
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 17
Page 18
Page 18
Page 19
Page 19
Page 20
Page 22
Page 22
Page 23
quick start with tedee lock
tedee lock setup - go to page 9
3 easy steps
Tedee lock is a smart door lock that can be tted to
GERDA modular cylinder or any other euro-prole
cylinder using a special adapter.
Tedee smart lock allows you to unlock the door,
share access, and check all activities remotely.
This booklet will give you an overview of the ba-
sic features of tedee lock and will help you walk
through the setup in three easy steps.
INSTALL
tedee lock
GET
tedee app
ACTIVATE
and CALIBRATE
your lock
1 2 3

page 4 | tedee lock www.tedee.com
safety information
safety guidelines / warnings
Do not
Do not open, modify or disassemble your device.
Do not self-service any part of the device.
Do not immerse device in any liquid or expose it to moisture.
Do not use the device near extreme heat source or open re.
Do not use the device in an environment of a high humidity or dust levels, as well as pollution
degree II.
Do not insert any conductive objects in device openings and gaps.
The device should not be used by children without adult supervision.
The device cannot be used as the only mean of access control to rooms or premises that require
increased access control.
Do
If repairs are required, please contact tedee technical support.
Use only power supply devices provided or recommended by tedee.
Read the installation guide and learn how to start working with your device, how to add
it to your tedee app and how to pair it with other tedee devices. You can also follow the link:
www.tedee.com/installation-guide
Moving parts
The device contains moving parts. When operating the device remotely, it is not
recommended to keep your hands on the housing.
WARNING: Read all safety guidelines and warnings. Failure to follow the guidelines and warnings
may result in electric shock, re, and / or serious injury.

tedee lock | page 5www.tedee.com
Other information
This device is safe to use under normal and reasonably foreseeable misuse operating code of
conduct. If you notice any signs of errors or hardware malfunction, contact tedee technical sup-
port for help. In such case this device should be returned to tedee for necessary repairs under the
warranty conditions. Any changes or modications to the device’s hardware or software which
are not approved, recommended, or provided by tedee may void your warranty.
charging and maintenance guidelines/warnings
Battery - please read all precautions before use
Your product is powered by a rechargeable LiPo battery.
LiPo Batteries used in this product may present risk of re or chemical burn if mistreated.
LiPo Batteries may explode if damaged.
Hot or cold environment may reduce the capacity and lifetime of the battery.
A fully charged battery will lose its charge over time when left unused.
For the best performance, the battery needs to be charged at least every 3 months.
Do not dispose as household waste or in a re as they may explode.
Do not leave devices with LiPo battery unattended during charging.
Avoid direct contact with a leaky / damaged battery.
Do not insert any conductive objects in device openings and gap – it may cause short-circuits.
Dispose of batteries according to your local regulations. Please recycle when possible.
Information about the battery level is available in the tedee app. Do not leave a fully charged
battery connected to a charger - overcharging may shorten its lifetime.
Neither Tedee Sp. z o.o. nor our retailers assume any liability for failures to comply with these
warnings and safety guidelines. By purchasing this device, the buyer assumes all risks associat-
ed with LiPo batteries. If you do not agree with these conditions, return the device immediately
before use.
Batteries in tedee lock are not interchangeable. Do not remove or replace the battery in your
device. Any attempt to do so is risky and may result in product damage and / or injury.

page 6 | tedee lock www.tedee.com
Additional instructions for professional facilities dealing with battery and accumulator recy-
cling: (1) in order to remove the battery, remove the cover with tedee logo from the front side
of tedee lock, (2) using a T6 screwdriver remove the two mounting screws, (3) pry and remove
the PCB, (4 ) using a soldering iron, warm up both pads to release the motor wires connected
to the PCB, (5) after desoldering, you can disconnect the PCB from the motor, (6) you can now
manually remove the battery.
Charging and maintenance
Charge your device only with the provided approved accessories designated for this product.
Unplug the product before cleaning. Wipe it only with a dry cloth.
Do not use chargers with an output voltage greater than 5V and 2A.
When disconnecting the power cord or any other accessory, grasp and pull the plug, not the cord.
Never use a charger that is damaged.
Do not attempt to disassemble the charger or cord. It may expose you to an electric shock.

tedee lock | page 7www.tedee.com
set of items – what’s in the box?
6
7
10
8
11
9
12
5
tedee lock
Micro USB cable
with magnetic adapter
Allen key
1. Activation code
2. Cylinder shaft
mounting hole
3. Mounting screw
4. Activation code (QR)
5. Adapter mounting
holes (optional)
6. LED
7. Allen key hole
10. USB connector
11. Magnetic micro USB adapter
12. Allen key (size 2)
8. The button
9. Micro USB charging
port
1
2
3
4

page 8 | tedee lock www.tedee.com
Activation code (AC) of your tedee lock is
printed on:
last page of this installation guide (1)
rear side of your device (2)
While adding your device to tedee app you
can either:
scan the QR Code
type in AC manually (14 characters)
Helpful tip
Before tting tedee lock to the
cylinder, take a photo of your
activation code and keep it.
Location of the unique activation code (AC) of your tedee lock
REAR SIDE
OF TEDEE LOCK
2
LAST PAGE
OF THIS GUIDE
1
ACTIVATION
CODE
activation code
A
C
T
I
V
A
T
I
O
N
C
O
D
E
:
1
8
4
8
0
0
a
a
b
b
C
C
D
d

tedee lock | page 9www.tedee.com
setup - 3 easy steps
step 1: install tedee lock
1Align tedee lock with the shaft of the cylinder and push it forward. IMPORTANT: the mounting
screw that extands from the lock mounting hole must t into the groove on the cylinder shaft.
Note: Do not start tedee lock installation before the lock cylinder is installed in the
door lock. Make sure that the cylinder sticks out at least 3mm from the lock
escutcheon (from the inside of your apartment).
push forward
minimum
3mm

page 10 | tedee lock www.tedee.com
TEDEE LOCK (SIDE VIEW)
Note: double check if tedee lock rear wheel is fully adjusted and clutches the cylinder.
The lock is tted correctly if the wheel remains in a xed position when you rotate the lock
manually.
ALLEN KEY rotate
clockwise
2Fix tedee lock tightly on the cylinder
using the Allen key.
Note: to x your tedee lock on the cylinder, keep rotating the key until it stops
(at least two full turns).
NOT OK
OK

tedee lock | page 11www.tedee.com
nal check
2Check light signal (LED).
OK
RED - BLUE - GREEN - WHITE
Note: after the RED-BLUE-GREEN-WHITE sequential light signal your tedee lock is
ready to be added and calibrated in the app.
1Turn on the lock.
Hold the button
pressed for two
seconds

page 12 | tedee lock www.tedee.com
step 2: download tedee app, create new account, and log in
(skip this step if you already have an account)
Version
Connection
6.0
or higher
Android
DOWNLOAD
select
Create new
account
The registration page
will open
WELCOME
Internet and
Bluetooth® 4.0
or higher
Internet and
Bluetooth® 4.0
or higher
11.2
or higher
iOS
1 2
Download tedee application. Create an account and log in.

tedee lock | page 13www.tedee.com
Lock select:
step 3: use tedee app to activate and calibrate your tedee lock
select
select
Your Account
Add new device
Help
1
3
2
4
Enable Internet connection,
Bluetooth®, and location on your
smartphone.
Select ‘Add device’ in the lock section.
Log into tedee application and select ‘Add
new device’ option from the menu.
Provide activation code (AC) of your
tedee lock.
INTERNET
CONNECTION
Bluetooth®
CONNECTION
Add device Type activation code manually
Scan QR code
Note: after scanning the QR code or typing in the AC manually follow instructions in
the application.
LOCATION

page 14 | tedee lock www.tedee.com
Plug the micro USB magnetic adapter into tedee lock charging port and connect the cable.
Plug the USB cable to a power supply.
1
2
OK
plug
charging tedee lock
USB charger
Power bank
PC / laptop OK
plug

tedee lock | page 15www.tedee.com
1
3
2
Rotate the key
counter-clockwise.
Pull the lock off.
OK
deinstallation of tedee lock
Note: in order to deinstall tedee lock: rst use an Allen key to loosen the screw (three
full turns counter-clockwise), and then pull it off to detach from the cylinder.
ALLEN
KEY
TEDEE LOCK

page 16 | tedee lock www.tedee.com
TEDEE LOCK
(VERTICAL POSITION)
remove tedee lock from the cylinder and set it in the vertical position (button up)
press and hold the button until the LED lights up
release the button
after releasing the button, tedee lock will conrm the factory reset with three quick red ashes
tedee lock will restart (it may take up to one minute)
Note: Remember to set tedee lock in a vertical position (button up).
factory reset

tedee lock | page 17www.tedee.com
additional and technical information
Models
Weight
Dimensions
Operating
temperature
Operating
humidity
Origin
Power supply
Bluetooth®
communication
Z-Wave®
communication
Security
Can be paired
with
Can be
installed on
3000 mAh
LiPo battery
BLE 5.0 2,4GHz
Z-Wave 868MHz
TLS 1.3
tedee bridge
Euro-prole
cylinders
Applies to:
TLV1.0 and TLV1.1
Applies to:
TLV1.1
Recommended:
GERDA SLR
modular cylinder
TLV1.0, TLV1.1
ca. 196g
Φ45mm x 55mm
10-40°C
(indoor only)
maximum 65%
Poland, EU
technical specications
tedee lock
Production
batch number
Marking of color
variants
Additional information: The production batch number of your device is the rst
eight characters of the "Device Serial Number (S/N)" visible on the label on the
package and the label on the device itself. For example, the production batch
number of the device with the "Device Serial Number (S/N)" 10101010-000001
is 10101010.
The color variant of the product is marked with a letter at the end of the model
name, on the label and on the product rating plate. For example, a device with model
TLV1.0 in color variant A is marked as "TLV1.0A".

page 18 | tedee lock www.tedee.com
radio frequency
Product
Weight
Length
Micro USB Cable
ca. 30g
1.5m or 2.0m
radio frequency
micro USB Cable
Tedee lock TLV1.0 is equipped with Bluetooth®BLE 5.0 2,4GHz radio interface. Bluetooth®interface
is used in communication between tedee lock, tedee bridge, and smartphones.
Tedee lock TLV1.1 is additionally equipped with Z-Wave®868 MHz radio interface.
Interface:
Bluetooth®BLE 5.0 2,4GHz
Z-Wave®868MHz
Frequency range:
from 2.4GHz to 2.483GHz
868.42MHz
Applies to models:
TLV1.0, TLV1.1
TLV1.1

tedee lock | page 19www.tedee.com
power supply, battery and charging
software
The lock is equipped with a non-removable LiPo 3000mAh battery. It can be charged using a micro
USB cable connected to a power supply, such as a USB charger (5V) included in the tedee bridge set
or a power bank. Battery life and charging time may vary depending on usage, type of power supply
and environmental conditions. A preview of the battery level is visible directly in tedee app. Tedee app
noties you when the battery is fully charged, after which it is recommended to disconnect the device
from the power supply. It is not recommended to use the device in temperatures other than 10-40 °C.
Other temperatures may lower the lifetime of the battery. It is recommended to charge the battery every
three months if the lock is not used regularly.
The current software version is visible in the tedee application: device / settings / general / software
version.
Tedee lock software can be updated in two ways: automatically or manually. Automatic updates are
only available when the lock is connected to tedee bridge which is connected to the Internet via local
Wi-Fi network.
If the lock is not connected to tedee bridge, you may update the software manually using tedee applica-
tion: device settings / general / rmware version.
Please report any problems with the application that may occur during use (such as login errors or ap-
plication hangs) to tedee technical support by email at suppor[email protected], at www.tedee.com/support
or by phone at ([phone] Monday to Friday during business hours from 8:00 to 16:00 (CET).

page 20 | tedee lock www.tedee.com
Additional information
LED ashes after turning on the device.
It conrms initialization process
and system check-up completion.
LED ashes after successful initialization of the
device. It conrms that your tedee lock
is ready to use.
Green LED is turned on while unlocking.
(OFF if the battery level is low)
Red LED turned on during the locking phase.
(OFF if the battery level is low)
LED ashes red when tedee lock is jammed and
needs attention. Please check if your device
is calibrated correctly – if the problem persists,
contact tedee support team.
LED ashes after 5 seconds of pressing the button
and keeps pulsating until the device is shut down.
It conrms the shutdown process.
The LED blinks with three quick red ashes when
the button is released. This conrms that the
factory settings have been restored.
LED signals
Meaning
(action)
Initialization
Ready
Unlocking
Locking
Jammed
Device
shutdown
Factory reset
Signal
(type)
Flashing
(fast)
Flashing
(sequential)
Constant
Constant
5 ashes
Pulsating light
Pulsating light
LED
(color)
Green
Red – Blue -
Green – White
Green
Red
Red
Red
Red
