PRODUCT APPLICATION
Keypad Module (recommended) — Enter an
authorized access code on the Keypad Module to
open a handle. The Keypad Module can be placed
on or near the cabinets and can open any of the
cabinet handles in the system.
Communications Module (required) — Provides a single IP
addressable network connection for the Electronic ocking
System and is used to setup and configure the system.
Each Communications Module can support any
combination of up to 64 Electronic ock Control
Modules (512 handles, 256 cabinets), 64 Keypad
Modules and 64 Proximity Card Reader Modules. Control
access to equipment with computer terminals using the
included lock control software. Provide alarm outputs for
unauthorized entries. The software also keeps a log of
each access attempt and all configuration changes.
Electronic Lock Upgrade Kit (required)
— Replace the mechanical lock on the
cabinet’s swing handle with an electronic
solenoid that releases the spring-loaded
handle when the correct code is entered.
When the correct code is entered, the
handle springs open allowing the door to
be opened.
800-834-4969
[email protected]
www.chatsworth.com
Electronic Locking Sy tem
Electronic ock Upgrade Kit (2 per cabinet)
with Electronic ock Extension Cable
Electronic ock Control Module (8 handle)
Proximity Card Reader Module
Keypad Module
with Keypad Module Cable
Communications Module
Electronic Lock Control Module (required) —
Connects upgraded electronic locks to the
Electronic ocking System and controls the
solenoid that opens the cabinet handles.
Each Electronic ock Control Module
connects eight handles (four cabinets) to
the system. Each handle can have up to
five access codes and can be assigned to
24 user groups. The Electronic ock Control
Module also reports the status of the handle
(opened or closed).
Proximity Card Reader Module (optional) — Use with the
Keypad Module. The proximity card acts like a key replacing the
access code. The proximity card can be programmed with a
specific handle access code or with up to 24 user group codes to
open multiple cabinets. Proximity cards can also be programmed
to open handles a specific number of times and to expire at a
specific time and date.
Electronic Locking System For CPI Cabinets
Automate access control and monitoring in your data center, computer
room and network facilities with the Electronic ocking System.
• Automate data center cabinet access control and monitoring
• IP addressable system increases security
• Assign and program individual user ID access codes
• Access cabinets via a network-connected computer, keypad or
proximity cards
• Create a log entry for each access attempt and configuration change
• Monitor handle conditions — opened or closed
• Forward SNMP traps to designated computers during alarm conditions
• Quickly update the system configuration and users privileges
• Easily add modules as your network grows
Rear
View

PRODUCT APPLICATION SHEET
ORDERING INFORMATION
SOLUTION OVERVIEW:
• User specific accounts - assign each authorized user access to specific cabinets with an individual access code or proximity card
• Records each access attempt - the lock control software keeps a log with records of each access attempt and each configuration change
• Quick changes to access permissions - software allows the system administrator to add or remove authorized users and change access codes and
permissions quickly
• Create multiple user groups - the system administrator can associate users and latches by a group number to restrict access by service group, authorization
level, facility or region with the lock control software
• Remote access control over the network - the lock control software lets authorized users see the status of all latches and open door latches remotely
• Generates alarm outputs for unauthorized entries - the Communications Module has two alarm relay outputs that can be used to send SNMP traps to
designated computers, operate external devices or to connect to the CPI Remote Infrastructure Management (RIM-600) System to notify you if there is an
unauthorized entry
• Grows with your network - simply add modules as your network grows; a single network connection provides access to 256 cabinets (512 swing handles)
• Connect the Communications, Electronic ock Control and Proximity Card Reader Modules with RJ-45 patch cords; connect Keypad Modules with Keypad
Module Cables; connect Electronic ock Upgrade Kits and Electronic ock Control Modules with Electronic ock Extension Cables
Part Number Description S ipping Weig t
16147-050 Communications Module 5 lb (2.3 kg)
16147-010 Electronic ock Upgrade Kit for Enhanced SteelFrame Cabinet
for the Front or Rear Door (1/Door) 1 lb (0.5 kg)
16147-060 Electronic ock Upgrade Kit for TeraFrame™Cabinet System
with a Single Solid or Perforated Front Door (1/Door) 3 lb (1.4 kg)
16147-061 Electronic ock Upgrade Kit for TeraFrame Cabinet System with
a Single Solid Plexiglass Front Door (1/Door) 3 lb (1.4 kg)
16147-062
Electronic ock Upgrade Kit with Integrated Keypad Module
for a TeraFrame Cabinet with a Single Solid or
Perforated Front Door (1/Door)
4 lb (1.8 kg)
16147-063 Electronic ock Upgrade Kit for TeraFrame Cabinet System with
a Single or Double Solid or Perforated Rear Door (1/Door) 2 lb (0.9 kg)
16147-052 Electronic ock Control Module for 8 Swing Handles 5 lb (2.3 kg)
16147-008 Keypad Module with (1) Keypad Module Cable 1 lb (0.5 kg)
16147-054 Proximity Card Reader Module 5 lb (2.3 kg)
60070-007 Network Patch Cord, RJ-45, 7’ (2.1 m) 1 lb (0.5 kg)
60070-014 Network Patch Cord, RJ-45, 14’ (4.3 m) 1 lb (0.5 kg)
60070-025 Network Patch Cord, RJ-45, 25’ (7.6 m) 1 lb (0.5 kg)
16147-015 Electronic ock Extension Cable, 16’ (5 m) 1 lb (0.5 kg)
16147-016 Keypad Module Cable, 9’ (2.7 m) 1 lb (0.5 kg)
RECOMMENDED ACCESSORIES:
Part Number Description S ipping Weig t
60000-001 Remote Infrastructure Management (RIM-600)
System Host Module 14 lb (6.4 kg)
60052-002 Door Open/Closed Sensor 1 lb (0.5 kg)
60065-001 Axis®Network Camera 1 lb (0.5 kg)
60050-001 Dry Contact Bridge (NO/NC) 1 lb (0.5 kg)
60061-007 Motion Sensor, Passive Infrared 1 lb (0.5 kg)
All products quot d ar subj ct to availability bas d on manufacturing capacity and shipping dat s should b consid r d stimat s only. Whil
v ry ffort has b n mad to nsur th accuracy of all information, CPI do s not acc pt liability for any rrors or omissions and r s rv s th
right to chang information and d scriptions of list d s rvic s and products.
©2009 Chatsworth Products, Inc. All rights r s rv d. CPI, CPI Passiv Cooling, Saf-T-Grip, S ismic Fram , SlimFram and M gaFram ar
f d rally r gist r d trad marks of Chatsworth Products, Inc. Cub -iT Plus, Evolution, OnTrac, QuadraRack, Simply Effici nt and T raFram ar
trad marks of Chatsworth Products, Inc. All oth r trad marks b long to th ir r sp ctiv compani s. MKT-60020-355 R v.3 01/09
Not exactly w at you need?
For complete information visit
www.chatsworth.com/locks.
16147-050
16147-060
16147-052
16147-008
16147-054
60000-001
Note: Contact CPI Technical Support to configure TeraFrame Cabinets with electronic locks.
16147-062
