FSH FEL990 Series User manual

For left hand VESTIBULE
For right hand VESTIBULE
To set for CCOMBINATION
Remove outer Face Plate1.
2. Pull & Rotate Latch Bolt 180 degrees clockwise
HANDING AND LOCKING FUNCTION SELECTION
TO REVERSE LATCH BOLT
NOTE:
If the handing and locking function selector is not visible through the
view hole - the lock is set for Fail Secure (FSE). To make
the handing and locking function selector visible, use the holdback clip
- see overleaf for Fail Safe (FSA) Fail Secure (FSE) selection.
FEL990 Series lectric Mortice Lock
Installation Instructions
E
FSH is an Allegion™ Company
selector
HANDING AND LOCKING
FUNCTION SELECTOR
selector
selector

FAIL SAFE (FSA) / FAIL SECURE (FSE) SELECTION
SECURING THE CYLINDER
Use only the Cylinder Retaining Screw
supplied, ensuring the
Retaining Screw Head is flush with the
Inner Forend Face.
nip
1. Mark out for strike on door frame.
LOCK INSTALLATION
When installing the lock, leave
the plastic cylinder dust covers
covering the cylinder hole to
prevent particles from entering the
lock. Where a cylinder is required,
extract the dust cover as shown in
the illustration.
2. Door frame to be morticed out for strike
and strike box.
3. Fix strike box and strike to door frame
using 2 screws as supplied with the lock.
4.
MOUNTING STRIKE AND MAGNET
Drill 19mm DIA hole (depth to suit magnet),
62mm above centre line of strike. Magnet
to be inserted into hole.
WARNING - Do not use instruments such as screw
drivers to retract the latch bolt through the cylinder
hole. Damage to the lock circuitry could occur.
20mm
FEL990
FEL990 SERIES
(FSA)
(FSA)
FSA
FSA
FSA
FSA
FSA
FSA
FSA
FSA
FSA
FSA

9PIN PLUG CONNECTION
(1.6m of cable supplied as standard)
LOCK INSTALLATION
(swapping LED wires)
SWAPPING WIRES
Gently lift plastic tag
holding terminal & slide
wire terminal from plug.
To insert wire terminal,
slide back into plug.
This product is the subject of any one or more of the following patents,
NZ299577, AU717917, NZ529951, NZ535262, NZ534706, NZ534938,
NZ537284, NZ534626.
N
*
*Hub monitoring is exit side only
FSH Australia Pty Ltd
Phone [phone]
Website www.fshlocking.com.au
NOTES: Swaping LED wires
over for Fail Secure (FSE) for
both LH/RH sides of lock.
LED cables are supplied as
standard to suit Fail Safe (FSA)
for both LH/RH sides of the
lock. On the occasion where
Fail Secure is selected the red
and green wires on the LED
cable will have to be swapped
over to suit LH/RH sides of
the lock.
FEL990 Series Monitoring Functions
Door Position Monitoring by Reed Switch
Lock Status Monitoring by a combination of 3 locking perimeters
• Locking Bar (Hub/Handle/s locked)
• Deadlatching Bolt (suppressed)
• Latchbolt (out)
Dual Key Override Monitoring (KOM)
Request to Exit (REX) via Hub/Handle(s)
LED Indication
ON OFF
FSH is an Allegion™ Company
Electrical Specications
Solenoid Activation
12-24V DC 350mA momentary, 100mA max operating
Including LED if applicable
Lock Secure Status/Key Override Monitor
Microswitch max. rating 500mA @30V DC
Door Status Monitor
Magnetic Reed Switch 100mA operating
Plug arrangement
9 pin plug with 1.6m cable
Request to Exit (REX) Switches
Microswitches max. rating 1A @125VAC
1
Solenoid Off
Solenoid On
Solenoid
NC
NO
Right Hand Operation (RH)
DIP 3
DIP 4
Reed Switch
NC
NO
Left Hand Operation (LH)
DIP 6
DIP 5
Dead Latching Bolt
NC
NO
Key Override
DIP2
DIP 1
Regulator
LED Drive
2
Black
Red
0 VDC
Solenoid
GreenLED (+) for Solenoid Off
Yellow Reed Switch
Grey Signals
Unused
Blue Hub Monitor (Handle)
Violet Key Overirde Monitor
Orange Latch Bolt, Dead Latching
Red LED
Lock Status :
Green LED
FEL990(M) Wire Connection Diagram
12-24VDC
Common
12-24VDC
(RH/LH, NO/NC)
Bolt & Lock/Unlock
(Both Sides)
Door Open at Rest
Unlocked (Fail Safe)
Door Locked
Fail Safe (FS)
Door Unlocked
Fail Safe (FS)
Swap LED Leads
for Fail Secure
(Secure Status)
(Door Closed Status)
9 Pin
Plug
NC
NO
Latch Bolt Monitor
Brown
Monitored version (M)
5
4
3
6
7
8
9
Locking Bar, (Handle(s) Locked)
POWER
