Teknion WWTWKS User manual

Work Table Straight Leg (WWTWKS)
Work Table Angled Leg (WWTWKA)
Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No: 2
WORK TABLE 60" - 96" WIDTH
TABLES
Jan 2018 1 of 6
INT_502a
interpret Installation Guides
A - Worksurface for Complete
Table with Cut-out
(C05-7494) x 1
OR
Worksurface for Complete
Table without Cut-out
(C05-7493) x 1
B - End Leg Assy
Straight
(N02-3686) x2
End Leg Assy
Angled
(N02-3687) x2
OR
C1 - Transverse Beam
Sub-Assembly (N02-3688) x2
C2 - 5/16 - 18 x 2.5 Soc.
Head Cap Screw
(E01-0756) x8 per beam
C3 - 5/16-18 Hex Nut 1/2
A/F.265 Thick
(E01-0755) x8 per beam
F - Centre Spacer
(A16-1652) x2
D - 1/4-20 x 3 -1/2
Flat Hd, Mach Sc.
(E01-0771) x4
E - Front Standoff
(B02-0658)
x2 for 60"-71"
x4 for 71"-96"
G - 1/4-20x5/8" Mach.
Screw (E01-0098) x4
C - Transverse Beam
Sub-Assembly
F
A
E
C
60" Straight Leg Frame
shown as example
Complete Table
Worksurface with cut-out
(WWTWKSC)
B
Leveler Cover is located inside Leg,
assembled and secured in place with tape.
OR
Worksurface for Complete
Table with CALA Cut-out
(C007-2683) x 1

Section:
Description: Page No:
Date:
REMOVE MOUNTING NUTS AND SCREWS
Jan 2018 2 of 6
INT_502a
WORK TABLE 60" - 96" WIDTH
TABLES
STEP 1: Remove Screw and Nut from Clamp as shown in the illustration.
Do Not Remove
C2
C3
C1
C3
C2
C1
interpret Installation Guides
C1

Section:
Description: Page No:
Date:
DETAIL
Jan 2018 3 of 6
INT_502a
WORK TABLE 60"- 96" WIDTH
TABLES
STEP 2: Clamp location.
interpret Installation Guides
Clamps at End Gable Location
Clamps at Mid Gable Location
Clamp to be removed and repositioned to
End Gable Postion
Clamps at End Gable Location
Refer to highlighted holes to
fasten Clamps for End Gable
Position.
C2
C3

Section:
Description: Page No:
Date:
CONNECT BEAMS TO LEGS FASTEN AND LEVEL
INT_502a
4 of 6
Jan 2018
WORK TABLE 60"- 96" WIDTH
TABLES
interpret Installation Guides
B
C1
STEP 3: Bring End Gables and Transverse Beam Assembly together. Line up the set of holes
on the top of Gable Cross Beams with Clamp Brackets holes.
STEP 4: Fasten together using Socket Cap Screw and Nuts. Level and square the whole
assembly. Tighten Screws and Nuts.
NOTE: Do not fully tighten until fully leveled.
E
E
Side View
of Standoff
E
NOTE: Do not fully tighten
until fully leveled.
Remove tape so
Leveler Cover can
slide down.

Section:
Description: Page No:
Date:
INSTALL CENTRE SPACER
Jan 2018 5 of 6
INT_502a
WORK TABLE 60"- 96" WIDTH
TABLES
interpret Installation Guides
STEP 5: Align Pilot holes from underside of Worksurface to holes of Spacer and fasten with screws provided.
NOTE: Ensure the Center Spacer is oriented as shown.
Underside View
F
G
H1
NOTE: Ensure the Center Spacer is oriented as shown.

Section:
Description: Page No:
Date:
LOWER WORKSURFACE TO FRAME INSTALL WORKSURFACE
INT_502a
6 of 6
Jan 2018
WORK TABLE 60"- 96" WIDTH
TABLES
interpret Installation Guides
STEP 6: Lower worksurface onto frame. Make sure Spacer will hang on transverse beam. STEP 7: Line up Workusrface inserts with circular holes on Clamp Brackets. Drop it on the
Frame and fasten with Flat Head Machine Screws and Washer Screws as shown.
Pilot holes-
End Gable Condition
NOTE: For Middle
Gable condition use
pilot holes closer to the
edge.
D
A
Underside View
A
D
