TEKNIX TKGF61X User manual

Instruction manual
Gas Cooker
TKGF61X
TKGF61BL
TKGF61W

2
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
You’ll soon be enjoying your new Gas Cooker.
It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running
quickly. Sound good? Then let’s get started.
If you still require further assistance, call one of our experts on 01759 487 823.

3
Contents
31
32
35
36
36
37
Care and maintenance
Cleaning
Maintenance
Product support
Troubleshooting
Declaration of conformance to product
standards
Disposal
Guarantee
6
7
4
8
9
10
13
14
16
17
20
20
20
27
Safety information
Safety information
Getting to know your gas
cooker
Ready? Let’s begin
Product features
Control panel
Installing your gas cooker
Installatıon and preparatıon for use
Gas connection
Gas conversion (If available)
Electrical connection and safety
Adjusting the feet
Functions
Use of gas burners
Hob controls
Oven controls
Using your gas cooker
Accessories
Technical specifications 29
1
2
3
4
5
9

Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
4
• Carefully read all instructions before using your
appliance and keep them in a convenient place for
reference when necessary.
• This manual has been prepared for more than one
model therefore your appliance may not have some
of the features described within. For this reason, it is
important to pay particular attention to any figures
whilst reading the operating manual.
General safety warnings
• This appliance can be used by children aged from
8 years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children should not play with the
appliance. Cleaning and user maintenance should
not be made by children without supervision.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Keep children less than 8
years of age away unless they are continually
supervised.
WARNING: Unattended cooking on a hob
with fat or oil can be dangerous and may result in fire.
NEVER try to extinguish such a fire with water, but
switch off the appliance and cover the flame with a lid
or a fire blanket.
WARNING: Danger of fire: Do not store items
on the cooking surfaces.
WARNING: If the surface is cracked, switch
off the appliance to avoid the possibility of electric
shock.
• For models which incorporate a hob lid, clean any
spillages off the lid before use and allow the cooker
to cool before closing the lid.
• Do not operate the appliance with an external timer
or separate remote-control system.
WARNING: To prevent the appliance tipping, the
stabilising brackets must be installed. (For detailed
information refer to the anti-tilting kit set guide.)
• During use the appliance will get hot. Care should
be taken to avoid touching heating elements inside
the oven.
• Handles may become hot after a short period
during use.
• Do not use harsh abrasive cleaners or scourers to
clean oven surfaces. They can scratch the surfaces
which may result in shattering of the door glass or
damage to surfaces.
• Do not use steam cleaners to clean the appliance.
• WARNING: To avoid the possibility of
electric shock, make sure that the appliance is
switched off before replacing the lamp.
• CAUTION: Accessible parts may be hot when
cooking or grilling. Keep young children away from
the appliance when it is in use.
• Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
• Maintenance and repair work should only be carried
out by authorised service technicians. Installation
and repair work that is carried out by unauthorised
technicians may be dangerous. Do not alter or
modify the specifications of the appliance in any
way. Inappropriate hob guards can cause accidents.
• Before connecting your appliance, make sure
that the local distribution conditions (nature of
the gas and gas pressure or electricity voltage and
frequency) and the specifications of the appliance
are compatible. The specifications for this appliance
are stated on the label.
CAUTION: This appliance is designed only for
cooking food and is intended for indoor domestic
household use only. It should not be used for any other
purpose or in any other application, such as for non-
domestic use, in a commercial environment or for
heating a room.
• Do not use the oven door handles to lift or move
the appliance.
• This
appliance
is not
connected to
a ventilation
device. It
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Safety information
Important - Please read these instructions fully before
installing or operating
5
Safety information
should be installed and connected in accordance
with current installation regulations. Particular
attention shall be given to the relevant requirements
regarding ventilation.
• If the burner has not lit after 15 seconds, stop
operating the device and open the compartment
door. Wait at least 1 minute before attempting to
ignite the burner again.
• These instructions are only valid if the correct
country symbol appears on the appliance. If the
symbol does not appear on the appliance, refer to
the technical instructions which describe how to
modify the appliance to match the conditions of
use of the country.
• All possible measures have been taken to ensure
your safety. Since the glass may break, care should
be taken while cleaning to avoid scratching. Avoid
hitting or knocking the glass with accessories.
• Make sure that the supply cord is not trapped or
damaged during installation. If the supply cord is
damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in
order to prevent a hazard.
• Do not let children climb on the oven door or sit on
it while it is open.
• If your appliance is provided with a cooking hotplate
made of glass or glass ceramic:
CAUTION: “In case of hotplate glass breakage”:
- immediately shut off all burners and any
electrical heating element and isolate the appliance
from the power supply
- do not touch the appliance surface
- do not use the appliance.
Installation warnings
• Do not operate the appliance before it is fully
installed.
• The appliance must be installed by an authorised
technician. The manufacturer is not responsible
for any damage that might be caused by incorrect
placement and installation by unauthorised people.
• When the appliance is unpacked, make sure that
it is has not been damaged during transportation.
In the case of a defect do not use the appliance
and contact a qualified service agent immediately.
The materials used for packaging (nylon, staplers,
styrofoam, etc.) may be harmful to children and
they should be collected and removed immediately.
• Protect your appliance from the atmosphere. Do
not expose it to sun, rain, snow, dust or excessive
humidity.
• Materials around the appliance (i.e. cabinets) must
be able to withstand a minimum temperature of
100°C.
During use
• When you first use your oven you may notice a
slight smell. This is perfectly normal and is caused
by the insulation materials on the heater elements.
We suggest that, before using your oven for the
first time, you leave it empty and set it at maximum
temperature for 45 minutes. Make sure that the
environment in which the product is installed is well
ventilated.
• Take care when opening the oven door during or
after cooking. The hot steam from the oven may
cause burns.
• Do not put flammable or combustible materials in
or near the appliance when it is operating.
• Always use oven gloves to remove and replace food
in the oven.
Do not leave the cooker unattended when
cooking with solid or liquid oils. They may catch fire
under extreme heating conditions. Never pour water
on to flames that are caused by oil, instead switch the
cooker off and cover the pan with its lid or a fire
blanket.
• Always position pans over the centre of the cooking
zone, and turn the handles to a safe position so they
cannot be knocked.
• If the product will not be used for a long period of
time, turn the main control switch off. Turn the gas
valve off when gas appliances are not in use.
• Make sure the appliance control knobs are always
in the “0” (stop) position when the appliance is not

Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
6
in use.
• The trays incline when pulled out. Take care not to
spill or drop hot food when removing it from the
oven.
CAUTION: The use of a gas cooking appliance
results in the production of heat, moisture and
products of combustion in the room in which it is
installed. Ensure that the kitchen is well ventilated
especially when the appliance is in use, keep natural
ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
• Prolonged intensive use of the appliance may
call for additional ventilation, such as opening
a window, or for more effective ventilation, for
example by increasing the level of mechanical
ventilation where present.
• While using the grill burner, keep the oven door
open and always use the grill deflector shield
supplied with the product. Never use the grill burner
with the oven door closed.
CAUTION: Glass lids may shatter
when heated. Turn off all the burners and
allow the hob surface to cool before
closing the lid.
• Do not place anything on the oven door when it is
open. This could unbalance the oven or damage
the door.
• Do not place heavy or flammable items (e.g. nylon,
plastic bags, paper, cloth, etc.) into the drawer. This
includes cookware with plastic accessories (e.g.
handles).
CAUTION: The inside surface of the storage
compartment may get hot when the appliance is in
use. Avoid touching the inside surface.
• Do not hang towels, dishcloths or clothes from the
appliance or its handles.
During cleaning and maintenance
• Make sure that your appliance is turned off at
the mains before carrying out any cleaning or
maintenance operations.
• Do not remove the control knobs to clean the
control panel.
• To maintain the efficiency and safety of your
appliance, we recommend you always use original
spare parts and to call our authorised service agents
when needed.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives,
Decisions and Regulations and the
requirements listed in the standards
referenced.
This appliance has been designed to be used only for
home cooking. Any other use (such as heating a room)
is improper and dangerous.
The operating instructions apply to several
models. You may notice differences between these
instructions and your model.

Safety information
Important - Please read these instructions fully before
installing or operating
7
Safety information

Getting to know your gas cooker
You’ll be up and running in no time
Getting to know your Gas Cooker
8
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the best
from your Gas Cooker and ensure safe and correct
installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.

Getting to know your gas cooker
You’ll be up and running in no time
Getting to know your Gas Cooker
9
Product features
Important: Specifications for the product vary and
the appearance of your appliance may differ from
that shown in the figures below.
Accessories
The Wire Grid for Deep Trays
The Deep Tray
The wire grid
Control panel
List of Components
1. Gas Hob
2. Control Panel
3. Oven Door Handle
4. Oven Door
5. Adjustable Feet
1. Main Oven Thermostat And Control
2. Left Rear Burner (Semi Rapid Burner)
3. Left Front Burner (Auxiliary Burner)
4. Right Front Burner (Wok Burner)
5. Right Rear Burner (Semi Rapid Burner)
6. Lamp
7. Igniter
1 2 3 4 5
6
7
1
2
3
4
5

Installing your gas cooker 3
10

Installing your gas cooker
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Installatıon and preparatıon for use
WARNING : This appliance must be installed by an
authorised service person or qualified technician,
according to the instructions in this guide and in
compliance with the current local regulations.
• Incorrect installation may cause harm and
damage, for which the manufacturer accepts no
responsibility and the warranty will not be valid.
• Prior to installation, ensure that the local distribution
conditions (electricity voltage and frequency and/
or nature of the gas and gas pressure) and the
adjustments of the appliance are compatible. The
adjustment conditions for this appliance are stated
on the label.
• The laws, ordinances, directives and standards in
force in the country of use are to be followed (safety
regulations, proper recycling in accordance with the
regulations, etc.).
Instructions for the Installer
Ventilation requirements
• For rooms with a volume of less than 5 m3,
permanent ventilation of 100 cm2 free area is
required.
• For rooms with a volume of between 5 m3 and 10
m3, permanent ventilation of 50 cm2 free area will
be required, unless the room has a door which
opens directly to outside air in which case no
permanent ventilation is required.
• For rooms with a volume greater than 10 m3, no
permanent ventilation is required.
Important: Regardless of room size, all rooms
containing the appliance must have direct access
to outside air via an openable window or equivalent.
Emptying of burned gases from the
environment
Gas appliances expel burned gas waste to the outside
air, either directly or via a cooker hood with a chimney.
If it is not possible to install a cooker hood, install a fan
on the window or wall that has access to fresh air. The
fan must have the capacity to change the volume of air
in the kitchen a minimum of 4-5 times per hour.
Air inlet section min.
100 cm2
Air inlet section min.
100 cm2
COOKER
Air inlet section
min. 100 cm2
Air inlet section min.
100 cm
2
Cooker
hood flue
Electrical ventilator
COOKER
COOKER
General instructions
• After removing the packaging material from the
appliance and its accessories, ensure that the
appliance is not damaged. If you suspect any
damage, do not use it and contact an authorised
service person or qualified technician immediately.
COOKER
11

Installing your gas cooker
Bringing it all together
Installing your gas cooker
• Make sure that there are no flammable or
combustible materials in the close vicinity, such as
curtains, oil, cloth etc. which may catch fire.
• The worktop and furniture surrounding the
appliance must be made of materials resistant to
temperatures above 100°C.
• The appliance should not be installed next to a
dishwasher, fridge, freezer, washing machine or
clothes dryer.
• The appliance can be placed close to other
furniture on condition that, in the area where the
appliance is set up, the furniture’s height does not
exceed the height of the cooktop.
Installation of the cooker
• If the kitchen furniture is higher than the cooktop,
the kitchen furniture must be at least 10 cm away
from the sides of appliance for air circulation.
• There should be a minimum 2cm blank space
around the appliance for air circulation.
• If a cooker hood or cupboard is to be installed
above the appliance, the safety distance between
cooktop and any cupboard/cooker hood should be
as shown below.
A (mm) 420
B (mm) Cooker Hood/Cupboard 650/700
C (mm) 20
D (mm) Product Width
E (mm) 100
ABCC
DE
Gas connection
Assembly of gas supply and leakage
check
Connect the appliance in accordance with applicable
local and international standards and regulations. First,
check what type of gas is installed on the cooker.
This information is available on a sticker on the back
of the cooker. You can find the information related to
appropriate gas types and appropriate gas injectors in
the technical data table. Check that the feeding gas
pressure matches the values on the technical data
WARNING: This appliance must be installed
by an authorised service person or qualified
technician.
12

Installing your gas cooker
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
table, to be able to get the most efficient use and to
ensure the minimum gas consumption. If the pressure
of used gas is different than the values stated or is not
stable in your area, it may be necessary to assemble an
available pressure regulator on the gas inlet. You should
contact an authorised service centre to make these
adjustments.
Points that must be checked during
flexible hose assembly
• If the gas connection is made by a flexible hose
fixed onto the gas inlet of the hob, it must be fixed
on by a pipe collar.
• Connect your appliance with a short and durable
hose that is as close as possible to the gas source.
• The permitted maximum length of the hose is 1.5
m.
• The hose that supplies the appliance with gas must
be changed once a year for your safety.
• The hose must be kept clear of areas that may heat
up to temperatures of more than 90°C.
• The hose must not be cracked, torn, bent or folded.
• Keep the hose clear of sharp corners and objects
that could move.
• Before you assemble the connection, you must
make sure the hose is not damaged. Use bubbly
water or leakage fluids to perform the check. Do
not use a naked flame to check for gas leakage.
• All metal items that are used during gas connection
must be free from rust. Check the expiry date of any
components used for connection.
Points that must be checked during
fixed gas connection assembly
The method used to assemble a fixed gas connection
(gas connection made by threads, e.g. a nut varies
according to the country you are in. The most common
parts for your country will be supplied
with your appliance. Any other parts required can be
supplied as spare parts.
During connection, always keep the nut on the gas
manifold fixed while rotating the counter-part. Use
appropriately-sized spanners for a safe connection. For
surfaces between different components always use the
seals provided in the gas conversion kit.
The seals used during connection should also be
approved to be used in gas connections. Do not use
plumbing seals for gas connections.
Remember that this appliance is ready to be connected to
the gas supply in the country for which it has been
produced. The main country of destination is marked on
the rear cover of the appliance. If you need to use it in
another country, any of the connections in the figure
below may be required. In such a case, contact local
authorities to learn the correct gas connection.
Gas pipe
Gas pipe
Seal
Seal
Hose
fitting
Adapter
Gas hose
with collar
Mechanical
gas hose
WARNING: This appliance must be installed
by an authorised service person or qualified
technician.
13

Installing your gas cooker
Bringing it all together
Installing your gas cooker
Gas pipe
Mechaniccal
gas hose
Seal
Mechanical gas
hose
Mechanical
gas hose
WARNING: The Cooker must be installed and
maintained by a suitably qualified gas registered
technician in accordance with current safety legislation.
WARNING: Do not use a naked flame to
check for gas leaks.
Gas conversion
Your appliance is designed to be operated with LPG/
NG gas. The gas burners can be adapted to different
types of gas, by replacing the corresponding injectors
and adjusting the minimum flame length suitable to the
gas in use. For this purpose, the following steps should
be performed:
Changing injectors
Hob burners
• Cut off the main gas supply and unplug the
appliance from the mains electrical supply.
• Remove the burner caps and the adapters.
• Use a 7 mm spanner to unscrew the injectors.
• Replace the injector with the ones from the gas
conversion kit, with the correct diameters for the
type of gas that is going to be used, according to
the gas injector table.
Adapter
Spanner
Adapter
Cup
Burner cap
Oven/Grill (if available) Injectors
Removal of the Cathedral Burner: The burner
protection sheet is fixed with two screws. As shown in
figure 8, use a screwdriver to remove it. As shown in
figure 9, press the spring clip in the direction of the
arrow to remove the burner from the slot. As shown in
figure 10, remove the injector in the bearing with a
socket wrench. In order to re-place the burner,apply
the removal process reversely.
14

Installing your gas cooker
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Installing your gas cooker
Bringing it all together
Remove the injectors using a 7mm spanner and
replace the injector with the ones from the spare set.
Make sure you use corresponding diameters suitable to
the type of gas that is going to be used, according to
the information chart (which is also supplied in the gas
conversion kit).
Adjusting the minimum flame position
First of all, make sure that the appliance is unplugged
from the mains electrical supply and that the gas feed
is open. The minimum flame position is adjusted with a
flat screw located on the valve. As shown in the figures
below; for valves with a flame failure safety device, the
screw is located on the side of the valve spindle and for
valves without a flame failure safety device, the screw is
located inside the valve spindle. To make adjusting the
flame position easier, we recommend that you remove
the control panel (and the micro switch if your model
has one) during the alteration. The bypass screw must
be loosened for conversion from LPG to natural gas.
For conversion from natural gas to LPG, the bypass
screw must be tightened.
Bypass screw Screw(inside
the hole)
Valve with ame failure device Valve without ame failure
device
Determining the minimum flame
position
To determine the minimum position, ignite the burners
and leave them on in the minimum position. Remove
the knobs to gain access to the screws. With the help
of a small screwdriver, fasten or loosen the bypass
screw by around 90 degrees. When the flame has a
length of at least 4mm, the gas is well distributed. Make
sure that the flame does not die out when passing
from the maximum position to the minimum position.
Create an artificial wind with your hand towards the
flame to see if the flames are stable.
For the oven burner, operate the oven burner at the
minimum position for 5 minutes, then open and close
the oven door 2-3 times to check the flame stability of
the burner.
Bypass screw
Bypass screw
Thermostatic oven valve
Non-thermostatic
oven valve
Changing the gas inlet
For some countries, the gas inlet type can be different
for NG/LPG gases. In this case, remove the current
connection components and nuts (if any) and connect
the new gas supply accordingly. In all conditions,
all components used in gas connections should be
approved by local and/or international authorities. In all
gas connections, refer to the “Assembly of gas supply
and leakage check” clause explained above.
1.1. Electrical Connection
and Safety (if available)
WARNING: The electrical connection of this
appliance should be carried out by an authorised
service person or qualified electrician, according to the
instructions in this guide and in compliance with the
current local regulations.
WARNING: THE APPLIANCE MUST BE EARTHED.
• Before connecting the appliance to the power
supply, the voltage rating of the appliance (stamped
on the appliance identification plate) must be
checked for correspondence to the available mains
supply voltage, and the mains electric wiring should
be capable of handling the appliance’s power rating
(also indicated on the identification plate).
WARNING: This appliance must be installed
by an authorised service person or qualified
technician.
15

Installing your gas cooker
Bringing it all together
Installing your gas cooker
• During installation, please ensure that isolated cables
are used. An incorrect connection could damage
your appliance. If the mains cable is damaged and
needs to be replaced this should be done by a
qualified person.
• Do not use adaptors, multiple sockets and/or
extension leads.
• The supply cord should be kept away from hot parts
of the appliance and must not be bent or
compressed. Otherwise the cord may be damaged,
causing a short circuit.
• If the appliance is not connected to the mains with a
plug, an all-pole disconnector (with at least 3 mm
contact spacing) must be used in order to meet the
safety regulations.
• The appliance is designed for a power supply of
220-240 V~. If your supply is different, contact the
authorized service personnel or qualified electrician.
• The power cable (H05VV-F) must be long enough
to be connected to the appliance.
• The fused switch must be easily accessible once the
appliance has been installed.
• Ensure all connections are adequately tightened.
• Fix the supply cable in the cable clamp and then
close the cover.
• The terminal box connection is placed on the
terminal box (as per image on the right)
WARNING: This appliance must be installed
by an authorised service person or qualified
technician. Safety chain
The appliance must be secured against the possibility
of tipping forward by using the supplied safety chains
attached to the rear of your oven.
Fasten the stability hook provided by inserting a wall
plug into the kitchen wall and then connect the safety
chain to the hook via the locking mechanism.
Earth
Terre
Erdung
L1
H05 VV-F 3G 1.5mm²
Neutral
Neutre
220-240V~50/60Hz
16

Installing your gas cooker
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Adjusting the feet
Your product stands on four adjustable feet. For safe
operation, it is important that your appliance is correctly
balanced. Make sure the appliance is level prior to
cooking. To increase the height of the appliance, turn
the feet anti-clockwise. To decrease the height of the
appliance, turn the feet clockwise.
It is possible to raise the height of the appliance up to
30 mm by adjusting the feet. The appliance is heavy
and we recommend that a minimum of 2 people lift it.
Never drag the appliance.
17

Installing your gas cooker
Bringing it all together
Installing your gas cooker
18

Functions 4
19

Functions
Functions
Simple everyday use
Use of gas burners
Ignition of the burners
The position symbol above each control knob indicates
the burner that the knob controls.
Ignition by igniter button: Push in the knob
of the burner you wish to ignite and keep it pressed
while turning it anti-clockwise until the knob is in
Maximum position, now press the Igniter button which
will create sparks at the burner - Do not continuously
operate the igniter for more than 15 seconds. If the
burner does not ignite - Wait for 60 seconds before
trying again.
Manual ignition of the gas burners
If the igniter fails for any reason, follow the procedures
listed below.
For hob burners: Push in the knob of the burner
you wish to ignite and keep it pressed while turning
it anti-clockwise until the knob is in the ‘maximum’
position. Continue pressing the knob and hold a
lit match, taper or other manual aid to the upper
circumference of the burner. Move the ignition source
away from the burner as soon as you see a stable flame.
For oven burner: Push in and turn the oven
control knob anti-clockwise until the knob is in the
‘maximum’ position. Hold a lit match, taper or other
manual aid to the ignition hole that is located on the
front left corner of the burner. Move the ignition source
away as soon as you see a stable flame.
For grill burner: Push in and turn the grill control
knob clockwise until the marker on the knob points at
the grill sign. Continue pressing the knob and hold a lit
match, taper or other manual aid to the holes on the
burner. Move the ignition source away from the burner
as soon as you see a stable flame.
Electrical ignition by spark button
Push in the knob of the burner you wish to ignite and
keep it pressed while turning it anti-clockwise until the
knob is in the ‘maximum’ position. While keeping the
knob pressed in, push the ignition button. Make sure
that you press the ignition button immediately as a
delay could cause a build up of gas which may result in
the flame spreading. Continue pressing the ignition
button until you see a stable flame on the burner.
Flame safety device
Hob burners
Hobs equipped with a flame failure device provide
security in case of an accidentally extinguished flame. If
such a case occurs, the device will block the burners
gas lines and will avoid any accumulation of unburned
gas. Wait 90 seconds before re-igniting an
extinguished gas burner.
Oven / Grill Burners
All oven burners are equipped with a gas safety device.
For this reason, during ignition, keep the oven knob
pressed until you see stable flames. If the flames are
cut out after you release the knob, repeat the ignition
procedure. If the oven burner does not ignite after you
keep the burner knob pressed for 30 seconds, open
the oven door and do not attempt re-ignition for at
least 90 seconds. If the oven flames go out
accidentally, repeat the same procedure.
1.2. Hob Controls
Hob burner
The knob has 3 positions: off (0), maximum (big flame
symbol) and minimum (small flame symbol). Ignite the
burner with the knob in the ‘maximum’ position; you
can then adjust the flame length between the
‘maximum’ and ‘minimum’ positions. Do not operate
the burners when the knob is between the ‘maximum’
and ‘off’ positions.
OFF position MAX position
MIN. position MODULATE
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
20
