680mm f/5.3 IMAGING SYSTEM
4-ELEMENT APO ASTROGRAPH
Thank you for purchasing the Tele Vue-NP127fli. It has been our pleasure to craft this fine instrument for you.
Nearly thirty years ago, Al Nagler received a U.S. patent for a fast, refracting telescope design based on
Josef Petzval’s portrait camera lens concept. Petzval’s design uses widely spaced doublets to produce a
flat focal plane over a relatively narrow field of view, just the sort of field a fast telescope can see. Nagler’s
combination of flat-field, fast focal ratio, and unobstructed system lent itself perfectly for testing eyepieces.
The 5” f/4 MPT (Multi-Purpose Telescope) with its fast speed and wide, flat field, led to a series of
continuous improvements, primarily in color correction. The “Halley Commemorative,” 4” f/5.5 started
the parade where more advanced glasses including special dispersion, fluorite and fluorite substitute
glasses brought steady improvements. The 4” f/5 Genesis employed fluorite in the rear doublet, and the
subsequent SDF and Tele Vue-101 versions at f/5.4 brought us even closer to perfection. Maintaining
this fast f/5.4 speed while reducing tube length in a totally new design with new glasses allowed virtually
ideal color correction and improved field flatness in this, the ideal form culminating the 20 year refinement
toward perfection with the Nagler-Petzval 101, and NP127 with an even faster f/5.2 speed.
The Tele Vue-NP127fli is Tele Vue’s first dedicated imaging instrument. It was developed in collabo-
ration with Finger Lakes Instrumentation to provide you with, what we hope you will agree, is the easiest,
most carefree imaging setup you’ve ever used. The NP127is optics plus Large Field Corrector produce
an f/5.3 system that mates beautifully with the variety of CCD chips available in FLI’s Proline camera
series. The Atlas focuser with its incredible resolution of 85nm/step is also ideally matched to our optical
system. The patented Zero Tilt Adapter system ensures all components lock squarely together, while the
unique end-plate tilting feature allows for any final adjustment that might be necessary.
Operating Guide
®

2
WARNING: NEVER image the sun or point the telescope toward or near the sun without pro-
fessional solar equipment rigidly secured in front of the objective lens. Remove any sighting
devices such as Starbeam from the telescope. Use only the Tele Vue Sol Searcher to find the
sun. Instant and permanent eye damage may result from viewing the sun directly, even during
a solar eclipse, or when viewing through thin clouds, or when the sun is near the horizon.
Standard Features - Optical tube assembly includes: captive sliding dew shield, , tilt adjustment end plate
with integrated Zero Tilt Adapter, front and rear screw-on metal lens cover (not shown), universal tube rings,
custom hard-shell case, Allen Keys for end plate tilt adjustment.
1.0 Getting Acquainted with the Tele Vue-NP127fli
1.1 Optical tube assembly
The NP optical design contains four elements consisting of two widely spaced, air-spaced doublet groups.
The forward group of lenses are contained in a stainless steel lens cell. The cell attaches to the main tube via
three alignment screws. The front cell is encased within the sliding dew shield. The rear doublet, making up
the rest of the objective, is larger in diameter than the previous NP127 and provides additional illumination
at the edge of the field. This benefit is especially useful for large format CCD chips which are extremely
sensitive to light fall-off. The rear lens group is housed in the cell that threads on to the back of the tube.
1.2 Large Field Corrector
The placement of the large field corrector lens at the very end of the OTA is critical to the edge of field
performance and is dependant on the camera used. The lens
assembly has been factory set and locked to be properly spaced
for the back focus of the combination of Atlas focuser, CenterLine
filter wheel, and ProLine series cameras. These products have been
tested and proven together as a system with NP127fli. Should
you choose to adapt any other camera to this system or use any
other products, you may need to adjust the lens position. You may
do so by first loosening the set screw located in the knurled ring.
While holding the Large Field Corrector lens assembly, loosen the
knurled ring. You are now free to thread the Large Field Corrector
lens assembly in or out as necessary. To tighten the assembly,
hold the Large Field Corrector assembly in place and fully tighten
the knurled ring. Finish by tightening the set screw.
127mm Front
Lenses and Cell
Dew Shield in
retracted position
Main Tube
Rear Lens Cell
Supplemental Tube Ring
Large Field
Corrector
Adapter Tube
FLI Zero Tilt Adapter
Connection
Tilting End
Plate Spacer Block
Adjustable Top Bar
Accessory
Channel
Main Tube Rings
Removeable
Mounting
Hardware
Locking Bat
Handle
Knurled Ring
Large Field Corrector
Lens Assembly
Tilting End Plate
with ZTA Adapter

3
1.3 Tilting End Plate
The tilt of the end plate to the optical axis can be changed to compensate for any tilt errors you may see
in your images. The telescope has been factory
aligned with the end plate square to the optical axis.
However, this alignment process cannot take into
account production tolerances contributed by other
pieces of equipment. The good news is that in our
testing with random selections of FLI equipment, no
additional tilt compensation has been necessary. We
have, however, left this capability accessible should
you ever find it necessary.
To determine which way to tilt the end plate, it
is necessary to focus on the part of the image that
comes to focus first when moving the focuser out
from its “in” position. That will permit adjusting, or
“jacking,” the end plate “out” to match that focus point in the field. The goal is to get the star images in
the four corners as uniform to each other as possible.
To make an adjustment, slightly loosen the three Jamb Screws located on the forward facing side of
the end plate. Then, “jack” the end plate a little using the appropriate Allen key jack screws. Tighten the
Jamb Screws against the end plate. Some trial and error imaging will be necessary, so it is best to carry
out any necessary adjustments during a test imaging session.
2.0 Mounting Options and Set Up
The telescope tube diameter is 5”. Dual rings are supplied on the tube and can be used tied together
with the top mounting bar for additional rigidity. This bar is easily removable should your mounting plate
require a ring spacing beyond its adjustment range. In addition, a third mount ring is located on the
adapter tube to add extra rigidity. In practice we found that the adapter tube did not present any flexure
issues with the weight of the FLI equipment. However, we have provided it should you wish to fashion a
custom mount adapter. Please note that this ring must remain fixed in its position along the adapter tube.
Therefore, any custom adapter plate should be designing after achieving balance and knowing the final
position of the 5” rings.
The bottom of the tube rings have ¼-20 holes to accept mounting studs or screws. The 5” rings have
additional locating pins and the 4” adapter tube ring has a spacer block to create an even plane to the
base of the 5” rings. Telescope balance is achieved by unlocking the “bat handle” screws and sliding
the tube fore or aft. Once the O.T.A. is repositioned, retighten the bat handle screws. Each tube ring has
two machined channels with #10-32 threaded holes for mounting accessories.
3.0 Caring for your NP127fli
The Tele Vue-NP127fli requires no special care. Treat it as you would any fine camera lens. Use the lens
cap when the telescope is being stored or not in use. The captive dew shield provides protection from glare,
helps protect the lens from dust or spray blown in by the wind and minimizes dew formation on the lens.
If dew forms on the lens during cold weather, it is best to use a hair dryer (on the lowest setting) to
gently warm it away. A few specks of dust will have no effect on image quality and may be gently blown
off with a squeeze bulb. Do not use compressed air cans to blow dust off optical surfaces.
Fingerprints, however should be cleaned off. Though the anti-reflection coatings are durable, they are
easily scratched. The simplest cleaning method is to moisten (not soak) a very soft, lint-free tissue, cloth,
“Q-Tip” or surgical cotton with a lens or glass cleaner and gently whisk away the stain. Do not apply
any solutions directly to the glass surfaces. After every cleaning stroke, use a fresh applicator. The fewer
strokes the better! Any residual “film” will not affect performance.
Jack Screw
Jamb Screw

4
Collimation of your Tele Vue-NP127fli has been locked at the factory. With reasonable care it will
remain aligned. However, rough handling can cause misalignment. WARNING: Do not loosen the but-
ton head screws in the front or rear lens cells as this will cause misalignment. If necessary, contact Tele
Vue for re-collimation.
The tube is powder-coated for durability and requires no special care. Black anodized surfaces can
be cleaned with Windex. If you have any questions about the care, operation or performance of your
Tele Vue-NP127fli, please call us at [phone] from 9:30 am to 5:00 pm EST.
4.0 Warranty
Tele Vue telescopes are warranted to be free of manufacturing or workmanship defects for 5 (five) years
from the date of purchase, to the original owner. Please return the warranty card as validation of your
ownership and for easy identification. If your Tele Vue telescope requires warranty service, please call
Tele Vue to discuss the problem, upon which you will receive a return authorization. NO RETURNS ARE
ACCEPTED WITHOUT PRIOR AUTHORIZATION.
The warranty does NOT include: collimation, defects caused by mishandling, defects of subjective
nature, or coverage for any telescope purchased through an unauthorized Tele Vue dealer.
Warranty work will be performed at Tele Vue’s discretion and may only be performed by Tele Vue
Optics. The telescope must be shipped in its case with proper inner and outer packaging. Return shipping
and insurance charges are the purchaser’s responsibility.
5.0 Specifications
Type 4-element Nagler-Petzval APO with integrated Large Field Corrector
Clear Aperture 5 inches (127mm)
Focal Length 680mm
Focal Ratio f/5.3
Resolution (photographic) 272 line pairs per mm
Field (photographic) 4.4owith 16803 chip
Mounting two 5” mount rings, one 4” mount ring
Weight 15.75 lbs. (tube assembly) 28.5 lbs. in case
Length 36-inches (O.T.A. only)
Accessories included as standard: custom fitted case, screw-on lens covers, sliding dew shield
Tube Powder-coated aluminum
Specifications subject to change without notice.
