TeleWell TW-EA510v4 User manual

TW-EA510v4
ADSL2+ WLAN 802.11g
VPN Firewall Router
User’s Manual

Table of Contents i
Table of Contents
CHAPTER 1: INTRODUCTION..........................................................................................................3
INTRODUCTION TO YOUR ROUTER..........................................................................................................3
FEATURES .............................................................................................................................................3
TW-EA510V4 ADSL ROUTER APPLICATION.........................................................................................6
CHAPTER 2: INSTALLING THE ROUTER......................................................................................7
IMPORTANT NOTE FOR USING THIS ROUTER.............................................................................................7
PACKAGE CONTENTS.............................................................................................................................7
THE FRONT LEDS.................................................................................................................................8
THE REAR PORTS ..................................................................................................................................9
CABLING.............................................................................................................................................10
CHAPTER 3: BASIC INSTALLATION.............................................................................................11
CONNECTING YOUR ROUTER ................................................................................................................11
FACTORY DEFAULT SETTINGS .............................................................................................................16
Web Interface (Username and Password).......................................................................................16
LAN Device IP Settings...................................................................................................................16
ISP setting in WAN site...................................................................................................................16
DHCP server..................................................................................................................................16
LAN and WAN Port Addresses........................................................................................................16
INFORMATION FROM YOUR ISP............................................................................................................17
CONFIGURING WITH YOUR WEB BROWSER...........................................................................................18
CHAPTER 4: CONFIGURATION.....................................................................................................19
STATUS...............................................................................................................................................20
ARP Table......................................................................................................................................20
Wireless Association Table.............................................................................................................20
Routing Table.................................................................................................................................21
DHCP Table...................................................................................................................................21
PPTP Status ...................................................................................................................................23
Email Status ...................................................................................................................................23
Event Log.......................................................................................................................................24
Error Log .......................................................................................................................................24
NAT Sessions..................................................................................................................................25
Diagnostic......................................................................................................................................25
UPnP Portmap...............................................................................................................................26
QUICK START......................................................................................................................................27
CONFIGURATION .................................................................................................................................29
LAN (Local Area Network).............................................................................................................29
Bridge Interface ..........................................................................................................................29
Ethernet......................................................................................................................................30
IP Alias .......................................................................................................................................30
Ethernet Client Filter...................................................................................................................31
Wireless......................................................................................................................................32
Wireless Security........................................................................................................................34
Wireless Client Filter...................................................................................................................36
Port Setting.................................................................................................................................37
DHCP Server..............................................................................................................................38
WAN (Wide Area Network).............................................................................................................39
ISP .............................................................................................................................................39

Table of Contents iii
DNS............................................................................................................................................48
ADSL..........................................................................................................................................49
System ............................................................................................................................................51
Time Zone ..................................................................................................................................51
Remote Access ..........................................................................................................................52
Firmware Upgrade......................................................................................................................52
Backup / Restore........................................................................................................................53
Restart Router............................................................................................................................53
User Management......................................................................................................................54
Firewall and Access Control...........................................................................................................55
General Settings.........................................................................................................................56
Packet Filter................................................................................................................................57
Intrusion Detection......................................................................................................................64
URL Filter ...................................................................................................................................66
IM / P2P Blocking .......................................................................................................................68
Firewall Log................................................................................................................................69
VPN (Virtual Private Networks)......................................................................................................70
PPTP (Point-to-Point Tunneling Protocol)...................................................................................70
QoS (Quality of Service).................................................................................................................78
Prioritization................................................................................................................................78
Outbound IP Throttling (LAN to WAN) ........................................................................................80
Inbound IP Throttling (WAN to LAN)...........................................................................................81
Virtual Server (“Port Forwarding”)...............................................................................................85
Add Virtual Server.......................................................................................................................86
Edit DMZ Host ............................................................................................................................88
Edit One-to-One NAT (Network Address Translation).................................................................89
Time Schedule ................................................................................................................................92
Configuration of Time Schedule..................................................................................................93
Advanced........................................................................................................................................94
Static Route................................................................................................................................94
Dynamic DNS.............................................................................................................................95
Check Email ...............................................................................................................................96
Device Management...................................................................................................................97
IGMP........................................................................................................................................101
VLAN Bridge.............................................................................................................................101
Mail Alert for WAN IP................................................................................................................105
SAVE CONFIGURATION TO FLASH ......................................................................................................106
LOGOUT............................................................................................................................................106
CHAPTER 5: TROUBLESHOOTING.............................................................................................107
PROBLEMS STARTING UP THE ROUTER ................................................................................................107
PROBLEMS WITH THE WAN INTERFACE .............................................................................................107
PROBLEMS WITH THE LAN INTERFACE ..............................................................................................108
APPENDIX A: PRODUCT SUPPORT AND CONTACT INFORMATION..................................109

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 1: Introduction
3
Chapter 1: Introduction
Introduction to your Router
Welcome to the TeleWell TW-EA510v4 Router. The router is an “all-in-one” unit, combining an ADSL
modem, IEEE 802.11g wireless access point, ADSL router with four-port 10/100M auto-crossover
Switch, and Firewall, enabling you to maximize the potential of your existing resources. The TW-EA510
version 4 can provide everything you need to get the machines on your network connected to the
Internet over your ADSL broadband connection. It supports the latest ADSL2/2+ technology enabling up
to and beyond ADSL2+ wire-speed. Its powerful QoS feature for traffic priority and bandwidth
management makes the device a perfect mate to the office user. With integrated 54Mbps 802.11g
Access Point in this device, the router brings up the productivity and mobility to office users.
With features such as an ADSL Quick-Start wizard and DHCP Server, you can be online in no time at all
and with a minimum of fuss and configuration, catering for first-time users to the guru requiring
advanced features and control over their Internet connection and network.
Features
Express Internet Access
The router complies with ADSL worldwide standards. It supports downstream rate up to 12/24
Mbps with ADSL2/2+, 8Mbps with ADSL. Users enjoy not only high-speed ADSL services but also
broadband multimedia applications such as interactive gaming, video streaming and real-time
audio much easier and faster than ever. It is compliant with Multi-Mode standard (ANSI T1.413,
Issue 2; G.dmt (ITU G.992.1); G.lite (ITU G.992.2); G.hs (ITU G994.1); G.dmt.bis (ITU G.992.3);
G.dmt.bisplus (ITU G.992.5)).
Virtual Private Network (VPN)
It allows user to make a tunnel with a remote site directly to secure the data transmission among
the connection. User can use embedded PPTP client/server which is supported by this router to
make a VPN connection or users can run the PPTP client in PC and the router already provides
PPTP pass through function to establish a VPN connection if the user likes to run the PPTP client
in his local computer.
802.11g Wireless AP with WPA Support
With integrated 802.11g Wireless Access Point in the router, the device offers a quick and easy
access among wired network, wireless network and broadband connection (ADSL) with single
device simplicity, and as a result, mobility to the users. In addition to 54 Mbps 802.11g data rate, it
also interoperates backward with existing 802.11b equipment. The Wireless Protected Access
(WPA) and Wireless Encryption Protocol (WEP) supported features enhance the security level of
data protection and access control via Wireless LAN.
Fast Ethernet Switch
A 4-port 10/100Mbps fast Ethernet switch is built in with automatic switching between MDI and
MDI-X for 10Base-T and 100Base-TX ports. An Ethernet straight or crossover cable can be used
directly for auto detection.
Multi-Protocol to Establish A Connection
It supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483 encapsulation over
ATM (bridged or routed) and PPP over Ethernet (RFC 2516) to establish a connection with the
ISP. The product also supports VC-based and LLC-based multiplexing.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 1: Introduction
4
Quick Installation Wizard
It supports a WEB GUI page to install this device quickly. With this wizard, end users can enter the
information easily which they get from their ISP, then surf the Internet immediately.
Universal Plug and Play (UPnP) and UPnP NAT Traversal
This protocol is used to enable simple and robust connectivity among stand-alone devices and
PCs from many different vendors. It makes network simple and affordable for users. UPnP
architecture leverages TCP/IP and the Web to enable seamless proximity networking in addition to
control and data transfer among networked devices. With this feature enabled, users can now
connect to Net meeting or MSN Messenger seamlessly.
Network Address Translation (NAT)
Allows multi-users to access outside resources such as the Internet simultaneously with one IP
address/one Internet access account. Many application layer gateway (ALG) are supported such
as web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and
others
SOHO Firewall Security with DoS and SPI
Along with the built-in NAT natural firewall feature, the router also provides advanced hacker
pattern-filtering protection. It can automatically detect and block Denial of Service (DoS) attacks.
The router is built with Stateful Packet Inspection (SPI) to determine if a data packet is allowed
through the firewall to the private LAN.
Domain Name System (DNS) relay
It provides an easy way to map the domain name (a friendly name for users such as
www.yahoo.com) and IP address. When local machine sets its DNS server with this router’s IP
address, every DNS conversion request packet from the PC to this router will be forwarded to the
real DNS in the outside network.
Dynamic Domain Name System (DDNS)
The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This
dynamic IP address is the WAN IP address. For example, to use the service, you must first apply for
an account from a DDNS service like http://www.dyndns.org/. More than 5 DDNS servers are
supported.
Quality of Service (QoS)
QoS gives you full control over which types of outgoing data traffic should be given priority by the
router, ensuring important data like gaming packets, customer information, or management
information move through the router ay lightning speed, even under heavy load. The QoS features
are configurable by source IP address, destination IP address, protocol, and port. You can throttle
the speed at which different types of outgoing data pass through the router, to ensure P2P users
don’t saturate upload bandwidth, or office browsing doesn’t bring client web serving to a halt. In
addition, or alternatively, you can simply change the priority of different types of upload data and let
the router sort out the actual speeds.
Virtual Server (“port forwarding”)
Users can specify some services to be visible from outside users. The router can detect incoming
service requests and forward either a single port or a range of ports to the specific local computer
to handle it. For example, a user can assign a PC in the LAN acting as a WEB server inside and
expose it to the outside network. Outside users can browse inside web servers directly while it is
protected by NAT. A DMZ host setting is also provided to a local computer exposed to the outside
network, Internet.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 1: Introduction
5
Rich Packet Filtering
Not only filters the packet based on IP address, but also based on Port numbers. It will filter
packets from and to the Internet, and also provides a higher level of security control.
Dynamic Host Configuration Protocol (DHCP) client and server
In the WAN site, the DHCP client can get an IP address from the Internet Service Provider (ISP)
automatically. In the LAN site, the DHCP server can allocate a range of client IP addresses and
distribute them including IP address, subnet mask as well as DNS IP address to local computers. It
provides an easy way to manage the local IP network.
Static and RIP1/2 Routing
It has routing capability and supports easy static routing table or RIP1/2 routing protocol.
Simple Network Management Protocol (SNMP)
It is an easy way to remotely manage the router via SNMP.
Web based GUI
It supports web based GUI for configuration and management. It is user-friendly and comes with
on-line help. It also supports remote management capability for remote users to configure and
manage this product.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.
Rich management interfaces
It supports flexible management interfaces with local console port, LAN port, and WAN port. Users
can use terminal applications through the console port to configure and manage the device, or
Telnet, WEB GUI, and SNMP through LAN or WAN ports to configure and manage the device.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 1: Introduction
6
TW-EA510v4 ADSL Router Application
Figure 1.1 Application Diagram of TW-EA510v4
Thank you for your purchase, and welcome to the world of broadband Internet

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 2: Installing the router
7
Chapter 2: Installing the Router
Important note for using this router
Package Contents
802.11g ADSL2+ Firewall Router
RJ-11 ADSL/telephone Cable
Ethernet (CAT-5 LAN) Cable
RJ-45 to RS-232 Console Kit
AC-DC power adapter (12VDC, 1A)
A detachable antenna
Manual

Do not use this router in high humidity or high temperatures.

Do not use the same power source for this router as other
equipment.

Do not open or repair the case yourself. If this router is too hot,
turn off the power immediately and have it repaired at a qualified
service center.

Avoid using this product and all accessories outdoors.
Warnin
g

Place this router on a stable surface.

Only use the power adapter that comes with the package. Using
a different voltage rating power adaptor may damage this router.
Attention

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 2: Installing the router
8
The Front LEDs
LED Meaning
1 Internet
Lit green when IP connected.
Flashes green when IP connected and IP traffic is passing thru the
device.
Lit red when device attempted to become IP connected and failed.
2 DSL Lit green when successfully connected to an ADSL DSLAM
(“linesync”).
3 Ethernet Port
1X — 4X
(RJ-45 connector)
Lit when the LAN link is connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
4
Wireless
Lit green when the wireless connection is established.
Flashes when sending/receiving data.
Flashes at 1Hz when WPS is active.
5 Mail Lit and flashed periodically when there is email in the Inbox.
6 Power
Lit green when power on.
Lit red when POST(Power On Self Test) failure (not bootable) or
device malfunction.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 2: Installing the router
9
The Ethernet Port # 4 can be used as a console port. You need a special
console tool that already includes in the package to connect with LAN port 4
and PC’s RS-232 port (9-pin serial port).
The Rear Ports
Port Meaning
1 Power Switch Power ON/OFF switch
2 Power Connect the supplied power adapter to this jack.
3 RESET
To be sure the device is being turned on press RESET button for:
1-3 seconds: quick reset the device.
6 seconds above, and power off, power on the device: restore to
factory default settings. (Cannot login to the router or forgot your
Username/Password. Press the button for more than 6 seconds).
Caution: After pressing the RESET button for more than 6 seconds, to be
sure you power cycle the device again.
4
Ethernet Port
1X — 4X
(RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four
LAN ports when connecting to a PC or an office/home network of
10Mbps or 100Mbps.
Caution: Port 4 can be either a LAN or Console port at a time but not both.
5
WPS Push Button WPS (Wi-Fi Protected Setup) is designed to ease set up of security-
enabled Wi-Fi networks in the home and small office environment.
Note: This feature is suppted later by software update. Press WPS Push
Button to activate WPS feature.
6 DSL Connect the supplied RJ-11 (“telephone”) cable to this port when
connecting to the ADSL/telephone network.
2
5
6
1
3
4

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 2: Installing the router
10
Cabling
One of the most common causes of problems is bad cabling or ADSL line(s). Make sure that all
connected devices are turned on. On the front of the product is a bank of LEDs. Verify that the LAN Link
and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.
Ensure that all other devices connected to the same telephone line as your router (e.g. telephones, fax
machines, analogue modems) have a line filter connected between them and the wall socket (unless
you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and
ensure that all line filters are correctly installed and the right way around. Missing line filters or line filters
installed the wrong way around can cause problems with your ADSL connection, including causing
frequent disconnections.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
11
Any TCP/IP capable workstation can be used to communicate with or
through the router. To configure other types of workstations, please consult
the manufacturer’s documentation.
Chapter 3: Basic Installation
The router can be configured with your web browser. A web browser is included as a standard
application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me, etc. The
product provides a very easy and user-friendly interface for configuration.
Please check your PC’s network components. The TCP/IP protocol stack and Ethernet network adapter
must be installed. If not, please refer to your Windows-related or other operating system manuals.
There are ways to connect with the router, either through an external repeater hub to the router or
directly connecting with PCs. However, to be sure PCs have an Ethernet interface installed properly
prior to connecting to the router device. You ought to configure your PCs to obtain an IP address
through a DHCP server or a fixed IP address that must be in the same subnet as the router. The default
IP address of the router is 192.168.0.254 and the subnet mask is 255.255.255.0 (i.e. any attached PC
must be in the same subnet, and have an IP address in the range of 192.168.0.1 to 192.168.0.253). The
best and easiest way is to configure the PC to get an IP address automatically from the router using
DHCP. If you encounter any problem accessing the router’s web interface it may also be advisable to
uninstall any kind of software firewall on your PCs, as they can cause problems accessing the
192.168.0.254 IP address of the router. Users should make their own decisions on how to best protect
their network.
Please follow the steps below for your PC’s network environment installation.
Connecting your router
1. Connect this router to a LAN (Local Area Network) and the ADSL/telephone (ADSL) network.
2. Power on the device.
3. Make sure the Power LED is lit green steadily and that the LAN LED is lit.

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
12
Configuring PCs in Windows in Window XP
1. Go to Start / Control Panel (in Classic View). In the Control
Panel, double-click Network Connections.
2. Double-click Local Area Connection. (See Figure 3.1)
3. In the LAN Area Connection Status window, click
Properties. (See Figure 3.2)
4. Select Internet Protocol (TCP/IP) and click Properties.
(See Figure 3.3)
5. Select the Obtain an IP address automatically and Obtain
DNS server address automatically radio buttons. (See
Figure 3.4)
6. Click OK to finish the configuration.
Figure 3.1: LAN Area Connection
Figure 3.2: LAN Connection Status
Figure 3.3: TCP / IP
Figure 3.4: IP Address & DNS
Configuration

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
13
Configuring PCs in Windows 2000
1. Go to Start / Settings / Control Panel. In the Control Panel,
double-click Network and Dial-up Connections.
2. Double-click Local Area (“LAN”) Connection.(See Figure
3.5)
3. In the LAN Area Connection Status window, click
Properties. (See Figure 3.6)
4. Select Internet Protocol (TCP/IP) and click Properties.
(See Figure 3.7)
5. Select the Obtain an IP address automatically and Obtain
DNS server address automatically radio buttons. (See
Figure 3.8)
6. Click OK to finish the configuration.
Figure 3.5: LAN Area Connection
Figure 3.6: LAN Connection Status
Figure 3.7: TCP / IP
Figure 3.8: IP Address & DNS
Configuration

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
14
Configuring PC in Windows 95/98/ME
1. Go to Start / Settings / Control Panel. In the Control Panel,
double-click Network and choose the Configuration tab.
2. Select TCP / IP -> NE2000 Compatible, or the name of any
Network Interface Card (NIC) in your PC. (See Figure 3.9)
3. Click Properties.
4. Select the IP Address tab. In this page, click the Obtain an
IP address automatically radio button. (See Figure 3.10)
5. Then select the DNS Configuration tab. (See Figure 3.11)
6. Select the Disable DNS radio button and click OK to finish
the configuration.
Figure 3.9: TCP / IP
Figure 3.10: IP Address
Figure 3.11: DNS Configuration

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
15
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In the Control
Panel, double-click Network and choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties. (See Figure
3.12)
3. Select the Obtain an IP address from a DHCP server radio
button and click OK. (See Figure 3.13)
Figure 3.12: TCP / IP
Figure 3.13: IP Address

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
16
Factory Default Settings
Before configuring your, you need to know the following default settings.
Web Interface (Username and Password)
Username: admin
Password: admin
The default username and password are “admin” and “admin” respectively.
LAN Device IP Settings
IP Address: 192.168.0.254
Subnet Mask: 255.255.255.0
ISP setting in WAN site
RFC-1483 Bridged IP LLC
DHCP server
DHCP server is enabled.
Start IP Address: 192.168.0.100
IP pool counts: 100
LAN and WAN Port Addresses
The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown below.
LAN Port WAN Port
IP address 192.168.0.254
Subnet Mask 255.255.255.0
DHCP server function Enabled
IP addresses for
distribution to PCs 100 IP addresses continuing from 192.168.0.100 through 192.168.0.199
The RFC-1483 Bridged IP LLC
function is enabled to
automatically get the WAN IP
address from the ISP.
Attention
If you ever forget the username/password to login to the router, you may
press the RESET button up to 6 seconds to restore the factory default
settings.
Caution: After pressing the RESET button for more than 6 seconds, to be sure you power
cycle the device again.
Attention

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
17
Information from your ISP
Before configuring this device, you have to check with your ISP (Internet Service Provider) to find out
what kind of service is provided such as DHCP (Obtain an IP Address Automatically, Static IP (Fixed IP
Address) and PPPoE.
Gather the information as illustrated in the following table and keep it for reference.
PPPoE VPI/VCI, VC / LLC-based multiplexing, Username, Password, Service Name, and Domain Name System (DNS) IP address (it ca be automatically assigned
by your ISP when you connect or be set manually).
PPPoE / PPPoE
with Pass-through
VPI/VCI, VC / LLC-based multiplexing, Username, Password, Service Name,
and Domain Name System (DNS) IP address (it ca be automatically assigned
by your ISP when you connect or be set manually). In addition, additional
WAN address can be assigned using PPPoE dialer.
PPPoA VPI/VCI, VC / LLC-based multiplexing, Username, Password and Domain Name System (DNS) IP address (it ca be automatically assigned by your ISP
when you connect or be set manually).
RFC 1483 Bridged VPI/VCI, VC / LLC-based multiplexing to use Bridged Mode.
RFC 1483 Routed VPI/VCI, VC / LLC-based multiplexing, IP address, Subnet mask, Gateway address, and Domain Name System (DNS) IP address (it is a fixed IP
address).

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 3: Basic Installation
18
Configuring with your Web Browser
Open your web browser, enter the IP address of your router, which by default is 192.168.0.254, and click
“Go”, a user name and password window prompt will appear. The default username and password
are “admin” and “admin”. (See Figure 3.14).
Figure 3.14: User name & Password Prompt Widonw
Congratulation! You are now successfully logon to the Router!

TW-EA510 version 4 ADSL2+, WLAN 802.11g, VPN, Firewall Router
Chapter 4:Configuration
19
Chapter 4: Configuration
At the configuration homepage, the left navigation pane where bookmarks are provided links you directly
to the desired setup page, including:
Status
- ARP Table
- Wireless Association
- Routing Table
- DHCP Table
- PPTP Status
- Email Status
- Event Log
- Error Log
- NAT Sessions
- Diagnostic
- UPnP Portmap
Quick Start
Configuration
- LAN
- WAN
- System
- Firewall
- VPN
- QoS
- Virtual Server
- Time Schedule
- Advanced
Save Config to FLASH
Language (provides user interface in Finnish and English languages)
Logout
