iBall Baton iB-WRT300N User manual

1
300M MIMO Triple Smart Router
Model No. iB-WRT300N
User Manual
Ver.: 1.0.0

2
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not in-stalled and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
 Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

3
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.

4
TABLE OF CONTENTS
300M MIMO TRIPLE SMART ROUTER 1
CHAPTER 1 INTRODUCTION 5
CHAPTER 2. EASY SETUP WIZARD UTILITY 9
CHAPTER 3 ROUTER CONFIGURATION 19
PORT FORWARDING 39
SECURITY SETTINGS 46
ADVANCED SETTINGS 46
SYSTEM TOOLS 58
CHAPTER 4 TROUBLESHOOTING 61
APPENDIX A. SPEC SUMMARY TABLE 65
APPENDIX B. GLOSSARY 67
APPENDIX C. CONTACT INFORMATION 70

5
Chapter 1 . Introduction
iBall Baton 300M MIMO Triple smart Router complies with IEEE 802.11 b/g/n wireless
standards.
MIMO Technology - Wireless Transmission speed up to 300Mbps.
Triple Smart Router
Supports ADSL Internet (xDSL): 1 - 10/100M RJ11 WAN port
Supports Broadband Internet (Cable / DSL): 1 - 10/100M RJ45 WAN port
Supports 2G/3G Internet (GSM/CDMA) - USB slot for wireless modem
Easy Setup Wizard - Utility helps users to configure the router easily.
1.1Package List
 300M MIMO Triple Smart Router (iB-WRT300N)
 2 Antenna (Fixed)
 Power Adapter
 RJ45 Patch cord
 ADSL Splitter
 RJ11 Patch cord
 USB Cable
 Cd
 Quick Installation Guide
 Note:
Make sure that the package contains the above items. If any of the listed items are damaged
or missing, please contact your nearest dealer.

6
1.2 Hardware Installation
 Back View
 Front View
Antenna
Power
Antenna
RJ45 LAN Ports
RJ-11 Port
LAN / WAN
LAN1~LAN4 LEDs
WLAN LED
A
DSL LED
Status
/USB
WPS/Wireless/
Reset Button
LAN/WAN LEDs
USB Ports

7
B. Installation Steps
Note: DO NOT connect the router to power before performing the installation steps
below.
a. Locate an optimum location for the router. The best place is usually near the center
of the area in which your PC(s) will wirelessly connect.
b. Adjust the direction of the antenna. Normally, upright is a good direction.
Step 1.
Connect the DSL/Cable Modem/Ethernet to the WAN port / ADSL to the RJ11 port or
3G USB wireless modem on the router as shown below is the following image.
USB Port Broadband WAN DSL - WAN
Step 2.
Insert RJ45 UTP Patch cord one end into the Router LAN Port and another end to th
e PC LAN
port.
Step 3.
Connect the power adapter one end to the router and other end into an electrical outlet.
Step 4.
Power on your PC and Cable/DSL modem.
Step 5.
When all of the devices boot up completely, make sure that the router's LEDs light
ON as per your connection.

8
1.2.2 LED indicators
LED Status Description
Status (USB)
Green in flash Power is on
Green in fast
flash Reset mode
Green 2G /3G USB modem
Green in flash Data access
ADSL
Green in flash xDSL connection is established
Green in fast
flash Data packet transferred via DSL Line
WLAN Green WiFi is on.
Green in flash Data access
LAN Green RJ45 cable is plugged, and Ethernet
connection is established.
Green in flash Data access
How to Operate
Step 1.
Plug the RJ45 cable into LAN port 1~4 and
connect with your Computer or Laptop.
Step 2
Connect 2G/3G dongle and then plug into
the USB port.
Or

9
Step 2.
Plug your RJ-11 port into the ADSL port.
Or
Plug your Broadband connection on router
RJ45 WAN port
Step 3.
Plug the power jack into it.
Step 4.
Connect the power adapter one end to the router and other end into an electrical
outlet.
Step 5.
Power on your PC and Cable/DSL modem
Step 6.
When all of the devices boot up completely, make sure that the router's LEDs light
ON as per your connection.
Step .
When all of the devices boot up completely, make sure that the router's LEDs light is
ON as per the corresponding connection.

10
Chapter 2. Easy Setup Wizard
There are two methods for you to set up the 300M MIMO easily.
 Method - I Easy Setup Wizard
 Method - II Web Based configuration through browser
Method - I Easy Setup Wizard
Configuring the Router via Easy Setup Wizard (Resource CD)
Step1.
a. Insert the Resource CD into your CD-ROM device.
b. The Easy Setup Wizard will automatically pop up on the computer’s screen.
Click START button and follow the steps as per easy setup configuration to complete the router.

11
Step 2.
Select Language then click
“Next” to continue.
Step 3.
Then click the “Wizard” to
continue.
Step 4.
Click “Next” to continue.

12
Step 5.
Select Wireless Enable, and
then click “Next” to continue.
Step 6.
Enter SSID, Channel and
Security options, and then
click “Next” to continue.
Step 7.
Select Ethernet WAN Service
by clicking Ethernet WAN icon
to configure Ethernet WAN
Connection.

13
Step 8.
Select Ethernet WAN
Connection Type by clicking
on proper icon to continue
Step 9.
Select ADSL WAN Service by
clicking ADSL WAN icon to
configure ADSL WAN
Connection.
Step 10.
a) Select ADSL WAN
Connection Type by
clicking on proper
icon to continue

14
b) Select PPPoE ADSL
WAN Type and fill the
User Name,
Password provided
by ISP (BSNL/MTNL)
c) Select Wireless WAN
to Configure 3G
Internet Connection
d) Default Setting is
Auto detection for
USB Modem

15
Step 11.
Click “Next” to save your
setting.
Step 12.
Click “Next” to WAN
Networking service.
Step 13.
Click “Next” to test the
Internet connection or you
can ignore test.

16
Step 14.
Setup is completed.
Method - II Configuring the Router by Web Console
Web-based utility, it is easy to configure and manage the iB-WRT300N 300M MIMO
Triple Smart Router.
Web-based utility can be used on any Windows, Macintosh or UNIX OS with a Web
browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.
 Login to the Router
To login to the router, you should set up the TCP/IP Protocol in "Obtain an IP
address automatically" mode on your PC(s).
a. To access the configuration utility, open a web-browser and type in the default
address http://192.168.1.1 in the address field of the browser.
I. After a moment, a login window will appear. Enter admin for the User Name
and Password, both in lower case letters. Then click OK or press Enter.

17
Router Configuration with the Quick Setup
Default Router Settings
IP Address: 192.168.1.1
User Name: admin
Password: admin
Step 1
Select Quick Setup for
Basic settings in a simple
way.
Step 2
Change System
Password. Set up your
system
password.(Default:admin)
.
Step 3
Select Time Zone

18
Step 4
Select WAN Type.
Choose Auto-Detecting or
Manually to set WAN
Type.
Step 5
Select WAN Type.
Image displays “ADSL”
WAN connection type as
the main internet access.
Step 6
You need to Manually
configure the User name
& password as per ISP.
Step 7
Set up your Wireless
Network.
Set up your SSID.
Step 8
Setup your Encryption
Key here, and then click
“NEXT” to continue.

19
Step 9
Apply your settings to
Continue.
Step 10
Click finish to Complete it.
Chapter 3 Router Configuration
Whenever you want to configure your network or this device, you can access the Configuration
Menu by opening the web-browser and typing in the IP Address of the device.
The default IP Address is: 192.168.1.1.
Enter the default username “admin” and password “admin” and then click ‘login’ button.
Afterwards, you can go Quick Setup, Status Info, Network Setting, Advance Settings or
System Tools on left hand side of web page.

20
Basic Network
Status Info.
Note : You can view the connection status on ‘Status’ page.
