Telex IP-223 User manual

Model IP-223
Remote Adapter Panel
Technical Manual
up to and including version 4.100
803641 Rev K 07/2008

PROPRIETARY NOTICE
The product information and design disclosed herein were originated by
and are the property of Telex Communications, Inc. Telex reserves all
patent, proprietary design, manufacturing, reproduction, use and sales
rights thereto, and to any article disclosed therein, except to the extent
rights are expressly granted to others.
COPYRIGHT NOTICE
Copyright 2008 by Telex Communications, Inc. All rights reserved.
Reproduction, in whole or in part, without prior written permission from
Telex is prohibited.
WARRANTY NOTICE (LIMITED)
All Telex manufactured signaling products are guaranteed against
malfunction due to defects in materials and workmanship for three (3)
years, beginning at the original date of purchase.If such a malfunction
occurs, the product be repaired or replaced (at our option) without
charge during the three (3) year period, if delivered to the Telex factory.
Warranty does not extend to damage due to improper repairs, finish or
appearance items, or malfunction due to abuse or operation under other
than the specified conditions, nor does it extend to incidental or
consequential damages. Some states do not allow the exclusion or
limitation of incidental or consequential damages. Some states do not
allow the exclusion or limitation of incidental or consequential damages,
so the above limitation may not apply to you. This warranty gives the
customer specific legal rights, and there may be other rights which vary
from state to state.
FACTORY SERVICE CENTER
Factory Service Center
Telex Communications, Inc.
Radio Dispatch Products
8601 East Cornhusker Highway
Lincoln, Nebraska, 68507
PHONE NUMBERS
Sales:
Phone ...................................................................[phone]
Fax........................................................................[phone]
E-mail...........................................Te[email protected]
Customer Service Repair:.................................................[phone]
Technical Support:
Phone ...................................................................[phone]
E-mail ........................ Tel[email protected]
Web ..................................................................................www.telex.com
CLAIMS
No liability be accepted for damages directly or indirectly arising from
the use of our materials or from any other causes. Our liability shall be
expressly limited to replacement or repair of defective materials.

Table
of
Contents
OVERVIEW..................................................... 13
Operating Modes ..................................................13
FEATURES ...................................................................14
IP-223 ACCESSORIES ..................................................15
IP-223 Specifications ............................................16
Front Panel ...........................................................16
TEST AND ADJUSTMENT POINTS ..................................16
HANDSET JACK ...........................................................17
IC BUTTON .................................................................17
LCD DISPLAY .............................................................17
LINE BUTTON .............................................................18
TX LED .....................................................................18
LNK LED ..................................................................18
Back Panel ............................................................19
10/100 ETHERNET CONNECTOR ..................................19
SERIAL CONNECTOR ...................................................19
RADIO 1 AND RADIO 2 (LINE 1 AND LINE 2)
CONNECTORS ..............................................................20
POWER CONNECTION ..................................................20
COMMUNICATIONS SYSTEM DESIGN.... 23
Network Requirements ..........................................23
BANDWIDTH ................................................................23
MULTICAST .................................................................23
INTERNET GROUP MANAGEMENT PROTOCOL (IGMP) 24
NETWORK PERFORMANCE ...........................................24
INSTALLATION AND LEVEL SETTINGS . 25
Local/Radio Connections .....................................25
JUMPER POSITIONS .....................................................25
TX AUDIO CONNECTION .............................................27
RX AUDIO CONNECTION .............................................27
COR (CARRIER OPERATED RELAY) I/O
(INPUT/OUTPUT) ........................................................28
PTT CONNECTION ......................................................28
MONITOR CONNECTION ..............................................28
R1 AND R2 RELAYS .....................................................28
DIGITAL I/O ...............................................................29
CTCSS (CONTINUOUS TONE CODED SQUELCH SYSTEM)
CONNECTION ............................................................. 29
Tone/Console Operation .......................................29
2-/4-WIRE JUMPER SETTINGS ..................................... 29
TX SIDE SETTINGS ..................................................... 29
LOCAL PTT I/O ......................................................... 30
CROSS MUTE I/O ....................................................... 30
SUPERVISORY I/O ....................................................... 30
Level Adjustments .................................................30
GENERAL ALIGNMENT ................................................ 31
RADIO/LINE TX LEVEL ............................................... 31
RADIO/LINE RX LEVEL ............................................... 31
LINE TX MONITOR LEVEL (TONE AND CONSOLE MODE
ONLY) ......................................................................... 31
CTCSS LEVEL ........................................................... 32
Frequency Decoding .............................................32
SETUP INFORMATION................................ 33
Setting the IP Address Information ......................33
USING HYPERTERMINAL ............................................. 34
Accessing IP-223 Web Browser Configuration
Windows ................................................................39
IP-223 Web Setup Windows Standards ................40
LINKS ......................................................................... 40
Welcome Window .................................................42
Basic Ethernet Setup Window ...............................43
SERIAL NUMBER FIELD .............................................. 43
MAC ADDRESS .......................................................... 43
USE DHCP SERVER CHECK BOX ............................... 44
UNIT IP ADDRESS FIELD ............................................ 44
SUBNET MASK FIELD ................................................. 44
GATEWAY ADDRESS FIELD ......................................... 44
DNS (DOMAIN NAME SERVER) NUMBER 1–3 FIELDS .44
PACKET DELAY BEFORE PLAYBACK FIELD ................. 44
QOS (QUALITY OF SERVICE): PRECEDENCE BITS
FIELD ........................................................................ 44
QOS: D, T, AND R (DELAY, THROUGHPUT, AND
RELIABILITY) BITS FIELD ............................................ 45
LOCAL COMPUTER IP ADDRESS 1-10 FIELDS ............ 45

SUBMIT BUTTON .........................................................46
General Gain Setup ............................................. 47
HANDSET MIC GAIN DROP DOWN MENU ....................47
HANDSET SIDETONE GAIN DROP DOWN MENU ...........47
RECEIVE GAIN DROP DOWN MENU ............................47
TRANSMIT GAIN DROP DOWN MENU ..........................48
CTCSS GAIN DROP DOWN MENU ..............................48
TX VOICE GAIN FIELD ...............................................48
SUBMIT BUTTON .........................................................48
Multicast Address Setup Window ........................ 49
LINE NUMBER FIELD ..................................................49
ENABLE VIA ETHERNET CHECK BOX ...........................49
LINE TYPE DROP DOWN MENU ..................................50
LINE NAME FIELD ......................................................50
RX MCAST ADDRESS FIELD ........................................50
RX PORT FIELD ..........................................................51
TX GROUP PORT FIELD .............................................51
TTL FIELD .................................................................51
VOCODER TYPE DROP DOWN MENU ..........................52
ENABLE CHECK BOX ..................................................52
LINE NAME FIELD ......................................................52
MULTICAST ADDRESS FIELD .......................................52
OUTGOING PORT FIELD .............................................53
TTL FIELD .................................................................53
ENABLE CHECK BOX ..................................................53
NAME FIELD ...............................................................53
MULTICAST ADDRESS FIELD .......................................53
INCOMING PORT FIELD ..............................................53
OUTGOING PORT FIELD .............................................53
TTL FIELD .................................................................53
ENABLE CHECK BOX ..................................................53
VOCODER TYPE DROP DOWN MENU ..........................54
LINE NAME FIELD ......................................................54
MCAST ADDRESS FIELD ..............................................54
PORT FIELD ................................................................54
TTL FIELD .................................................................54
SUBMIT BUTTON .........................................................54
Per Line Setup Window ........................................ 55
Per Line Setup Window—
Local, Tone, and Console Mode Configuration .. 56
LINE 1 BUTTON ..........................................................56
LINE 2 BUTTON ..........................................................57
SUBMIT BUTTON .........................................................57
LINE MODE STATUS FIELD .........................................57
PORT ENABLED CHECK BOX .......................................57
ALWAYS ONRADIO BUTTON .......................................57
ONWITH PTT RADIO BUTTON ...................................58
TAPE OUTPUT RADIO BUTTON ....................................58
TX DELAY FIELD ........................................................58
RX DELAY FIELD ........................................................58
SQUELCH TAIL DELAY FIELD ......................................58
JUMP TOENTRY DROP DOWN MENU .........................58
UPDATE BUTTON ........................................................58
TONE ENABLE CHECK BOX .........................................59
RELAY DROP DOWN MENU .........................................59
RELAY GROUP DROP DOWN MENU .............................59
RELAY TIME (MS) FIELD .............................................59
DIGITAL OUTPUT FIELD - LOCAL MODE ONLY ...........60
CTCSS FREQ FIELD - LOCAL MODE ONLY .................60
CTCSS DEFAULT CHECK BOX - LOCAL MODE ONLY .60
SYSTEM FIELD - LOCAL MODE ....................................60
CHAN FIELD - LOCAL MODE .......................................60
LAM LEVEL FIELD .....................................................61
LAM TIME FIELD .......................................................61
OPTIONS .....................................................................62
Supervisor Check Box ........................................... 62
Cross Mute Check Box.......................................... 62
Full Duplex Check Box ......................................... 62
RxAGC Check Box................................................ 62
Hi-Pass RX Check Box.......................................... 62
Pre-Emphasize TX Check Box.............................. 62
TX Monitor Check Box ......................................... 62
2-Wire Check Box ................................................. 63
Parallel Console Check Box .................................. 63
PTT Notch Filter Check Box................................. 63
PTT TIMEOUT FIELD ..................................................63
Serial Port Mode Drop Down Menu...................... 63
Serial Port Params Drop Down Menu ................... 64
FleetSync Decode Check Box
(Tone and Local Modes)........................................ 65
FleetSync Encode Check Box (Local Mode Only) 66
MDC Decode Check Box
(Tone and Local Modes)........................................ 66
MDC Encode Check Box....................................... 66
Tone Type Drop Down Menu................................ 66
ANI Suffix Field.................................................... 67
Digit Duration Field............................................... 67
Interdigit Duration Field ........................................ 67
Pause Duration Field.............................................. 67
Preamble Duration Field........................................ 67
Group Digit Field................................................... 67
Repeat Digit Field.................................................. 67
ANI Decoder # Field.............................................. 67
ANI Call Type Drop Down Menu ......................... 68
ANI Call Format Field........................................... 68
Per Line Setup Window—
Phone Mode Configuration ................................. 69
Auto Answer Field................................................. 69
Auto Disconnect Time Field.................................. 69
TX DELAY FIELD ........................................................69
RX DELAY FIELD ........................................................70
LAM LEVEL FIELD .....................................................70
LAM TIME FIELD .......................................................70
Mic Click Call Enabled Check Box....................... 70
Number of Clicks Field.......................................... 70
Time Between Clicks Field.................................... 70
Click Dial String Field........................................... 70
Click Dial Timeout Field....................................... 71
Relay Closure......................................................... 71
R1 - Ring Check Box.......................................... 71

R2 - OffHook Check Box................................... 72
Rx AGC Enabled Check Box ................................ 72
Keep Alive Digits Enabled Check Box ................. 72
Star/Pound Keying Enabled Check Box................ 72
Detect Tones Enabled Check Box ......................... 72
Hook Flash Time Field .......................................... 72
Network Call Timeout Field.................................. 72
Station ID Field...................................................... 72
Busy Channel Lockout Check Box........................ 72
C550 Operation Enabled Check Box..................... 73
RP251 Operation Enabled Check Box................... 73
RP251 Access Digits Field .................................... 73
RP251 Connect Digits Field .................................. 73
SERIAL PORT MODE DROP DOWN MENU ....................73
SERIAL PORT PARAMETERS DROP DOWN MENU ..........73
FleetSync Decode Check Box ............................... 75
MDC Decode Check Box ...................................... 75
Tone Type Drop Down Menu................................ 75
ANI Suffix Field.................................................... 75
Digit Duration Field............................................... 75
Interdigit Duration Field........................................ 76
Pause Duration Field.............................................. 76
Preamble Duration Field........................................ 76
Group Digit Field................................................... 76
Repeat Digit Field.................................................. 76
ANI Decoder Field................................................. 76
ANI Call Type Drop Down Menu ......................... 76
ANI Call Format Field........................................... 77
Per Line Setup Window—
iDEN Radio Configuration ...................................77
TX DELAY FIELD ........................................................78
RX DELAY FIELD ........................................................78
SQUELCH TAIL DELAY FIELD ......................................78
THE RANGE FOR THIS FIELD IS 0 TO 5000. ..................79
JUMP TOENTRY DROP DOWN MENU ..........................79
UPDATE BUTTON ........................................................79
TONE ENABLE CHECK BOX .........................................79
RELAY DROP DOWN MENU .........................................80
RELAY GROUP DROP DOWN MENU .............................80
RELAY TIME (MS) FIELD .............................................80
CALL TYPE DROP DOWN MENU ..................................81
IDEN NUMBER FIELD .................................................81
LAM LEVEL FIELD .....................................................82
LAM TIME FIELD .......................................................82
Full Duplex Check Box ......................................... 82
RxAGC Check Box................................................ 82
Hi-Pass RX Check Box.......................................... 82
Pre-Emphasize TX Check Box.............................. 82
F1 Last Call Check Box (iDEN Mode only) ......... 83
PTT Notch Filter Check Box................................. 83
Busy Channel Lockout Check Box........................ 83
PTT TIMEOUT FIELD ..................................................83
SERIAL PORT MODE DROP DOWN MENU ....................83
SERIAL PORT PARAMETERS DROP DOWN MENU ..........83
Per line Setup Window—
Tetra Radio Configuration .................................. 84
JUMP TOENTRY DROP DOWN MENU ......................... 84
UPDATE BUTTON ....................................................... 84
TONE ENABLE CHECK BOX ........................................ 84
RELAY DROP DOWN MENU ........................................ 85
RELAY GROUP DROP DOWN MENU ............................ 85
RELAY TIME (MS) FIELD ............................................. 85
TYPE DROP DOWN MENU .......................................... 85
ISSI/GSSI NUMBER FIELD ......................................... 86
TX DELAY FIELD ....................................................... 87
RX DELAY FIELD ....................................................... 87
LAM LEVEL FIELD ..................................................... 88
LAM TIME FIELD ....................................................... 88
Full Duplex Check Box......................................... 88
RxAGC Check Box............................................... 88
Hi-Pass RX Check Box......................................... 88
Pre-Emphasize TX Check Box ............................. 89
PTT Notch Filter Check Box ................................ 89
Busy Channel Lockout Check Box....................... 89
PTT TIMEOUT FIELD ................................................. 89
SERIAL PORT MODE DROP DOWN MENU ................... 89
SERIAL PORT PARAMETERS DROP DOWN MENU ......... 89
Save to EEPROM Window ................................... 90
SAVE PARAMETERS BUTTON ....................................... 90
RESET IP-223 BUTTON .............................................. 90
Account Setup Window ........................................ 91
Admin System Account ........................................ 91
User System Account............................................ 91
Enable Check Box................................................. 92
Username Display Column ................................... 92
Password Field ...................................................... 92
New Password Field.............................................. 92
Confirm Password Field........................................ 93
Edit Button ............................................................ 93
Save Button........................................................... 93
Submit Button ....................................................... 93
Delete, Username, Password, New Password,
Confirm Password Display Columns.................... 93
Delete Button......................................................... 94
Add New User Button........................................... 94
Reset System Parameters Button........................... 94
Edit System Accounts Window ............................. 94
Add New User Window ........................................ 96
Username Field ..................................................... 96
Password Field ...................................................... 96
Confirm Password Field........................................ 96
Additional Feature Check Box.............................. 97
Save To EEPROM Check Box.............................. 97
Welcome Page Check Box.................................... 97
Account Setup Check Box .................................... 97
Basic Ethernet & Multicast Setup Check Box...... 97
Clone Console & Pass Change Check Box........... 97
CRP Setup & PIN Table Check Box..................... 97

General Gain Check Box....................................... 97
Per Line Setup Check Box..................................... 97
Tone Freq & Durations Check Box....................... 98
Submit Button........................................................ 98
Cancel Button ........................................................ 98
Edit Created Accounts Window ........................... 99
Additional Feature Setup Window ..................... 100
Clone Console Window ...................................... 101
Crosspatch Setup Window ................................. 102
Enable Line – Line Check Box............................ 103
Start Patch FTone Drop Down Menu.................. 103
Stop Patch FTone Drop Down Menu .................. 103
RCP Enable Check Box....................................... 103
Dialing Digits Field ............................................. 103
Interdigit Time Field............................................ 103
Beep Dly Field..................................................... 103
Patch Timeout Field............................................. 104
Global Field ......................................................... 104
Drop All Field...................................................... 104
RCP TABLES .............................................................104
JUMP TOENTRY DROP DOWN MENU AND
GOBUTTON ..............................................................104
Entry Field ........................................................... 104
Add String Field .................................................. 104
Delete String Field............................................... 105
Mode Drop Down Menu...................................... 105
Phone Field (DIAL option only).......................... 105
#1 or #2 Drop Down Menu
(XPATCH option only) ....................................... 105
IP Address Field (XPATCH option only) ........... 106
Rx Multicast Field (DLVOIP option only).......... 106
Rx Port Field (DLVOIP option only).................. 106
Tx Multicast Field (DLVOIP option only).......... 106
Tx Port Field (DLVOIP option only) .................. 106
COMMAND BUTTONS ................................................106
Prev 10 Button..................................................... 106
Next 10 Button..................................................... 107
CRP PIN Table Window .................................... 108
JUMP TOENTRY DROP DOWN MENU AND
GOBUTTON ..............................................................109
SUBMIT BUTTON .......................................................109
PIN ENABLE CHECK BOX .........................................109
ENTRY FIELD ............................................................109
PIN FIELD ................................................................109
SUBMIT BUTTON .......................................................109
Prev 30 Entries Button......................................... 110
Next 30 Entries Button ........................................ 110
Pass Change Window ........................................ 111
Tone Frequency & Durations Window .............. 112
MONITOR FREQUENCY FIELD ...................................112
PTT FREQUENCY DROP DOWN MENU ......................113
GUARD TONE DURATION FIELD ................................113
GUARD TONE MAGNITUDE FIELD .............................113
HOLD TONE MAGNITUDE FIELD ...............................113
HOLD TONE HANGTIME FIELD ..................................113
FUNCTION TONE DURATION FIELD ...........................114
FUNCTION TONE MAGNITUDE FIELD ........................114
FTONE 1-16 FREQUENCY FIELDS .............................114
UPDATE FIRMWARE ................................. 117
Update Firmware ............................................... 117
INSTALL TSM ............................................................117
DOWNLOAD TELEX FIRMWARE ..................................119
UPDATE FIRMWARE TOOL WINDOW ..........................120
File Field.............................................................. 120
Device Type Field................................................ 120
Firmware Version Field....................................... 120
Left Navigation Pane ........................................... 120
Manual Entry Field .............................................. 121
Username Field.................................................... 121
Password Field..................................................... 121
Write Firmware Button........................................ 121
Close Button......................................................... 121
UPLOAD VOIP HARDWARE FIRMWARE ......................121
IP-223 SETTINGS - QUICK REFERENCE 123
I/O Connectors ................................................... 123
Adjustments ........................................................ 123
Jumper Settings .................................................. 124
PCB 750743 OR PCB 750630 REVISION F ...............124
PCB 750743 OR PCB 750630 REVISION
C, D, E, AND F ........................................................ 124
PCB 750630 REVISION A ......................................... 124
Jumper Locations ............................................... 125
Additional Resources ......................................... 127
CTCSS Tone Frequency Table ........................... 131
Digital Output Table .......................................... 133
Tone Frequency Table ....................................... 135

List
of
Figures
FIGURE 1. Local and Tone Mode Connections .................................................................................................13
FIGURE 2. Console Mode Connection ...............................................................................................................14
FIGURE 3. IP-223 Front Panel ..........................................................................................................................16
FIGURE 4. IP-223 Case Top Test Points ...........................................................................................................17
FIGURE 5. IP-223 Back Panel ...........................................................................................................................19
FIGURE 6. DB25 Connector Pinout Configuration ...........................................................................................21
FIGURE 7. Jumper Positions ..............................................................................................................................25
FIGURE 8. IP-223 PCB Assembly ......................................................................................................................26
FIGURE 9. HyperTerminal Navigation ..............................................................................................................34
FIGURE 10. Com Terminal Setup Windows .......................................................................................................35
FIGURE 11. HyperTerminal Window Password ................................................................................................36
FIGURE 12. HyperTerminal Factory Setup Options – Serial Port Access Window ..........................................37
FIGURE 13. Connect to [IP Address] Window ..................................................................................................39
FIGURE 14. IP-223 Links ...................................................................................................................................40
FIGURE 15. Welcome Window ...........................................................................................................................42
FIGURE 16. Basic Ethernet Setup Window ........................................................................................................43
FIGURE 17. General Gain Setup Window ..........................................................................................................47
FIGURE 18. Multicast Address Setup..................................................................................................................49
FIGURE 19. Line Type Drop Down Menu ..........................................................................................................50
FIGURE 20. Vocoder Type Drop Down Menu ...................................................................................................52
FIGURE 21. Vocoder Type Drop Down Menu ...................................................................................................54
FIGURE 22. Per Line Setup - Local, Tone, and Console Modes (view 1) ..........................................................56
FIGURE 23. Relay Drop Down Menu—Per Line Setup .....................................................................................59
FIGURE 24. Per Line Setup - Local Tone and Console Modes (view 2) ............................................................61
FIGURE 25. Serial Port Drop Down Menu - Local Mode .................................................................................64
FIGURE 26. Serial Port Params Drop Down Menu - Normal Mode .................................................................64
FIGURE 27. Per Line Setup - Local, Tone, and Console Mode (view 3) ...........................................................65
FIGURE 28. Tone Type Drop Down Menu .........................................................................................................66
FIGURE 29. ANI Call Type Drop Down Menu-Per Line Setup .........................................................................68
FIGURE 30. Per Line Setup - Phone Mode (view 1) ..........................................................................................69
FIGURE 31. Per Line Setup - Phone Mode (view 2) ..........................................................................................71
FIGURE 32. Serial Port Params Drop Down Menu - Phone Mode ...................................................................74
FIGURE 33. Per Line Setup - Phone Mode (view 3) ..........................................................................................74
FIGURE 34. Tone Type Drop Down Menu .........................................................................................................75
FIGURE 35. ANI Call Type Drop Down Menu ..................................................................................................77
FIGURE 36. Per Line Setup - iDEN Radio Mode (view 1) .................................................................................78
FIGURE 37. Relay Drop Down Menu-Per Line Setup .......................................................................................80

FIGURE 38. Call Type Drop Down Menu - iDEN Mode ................................................................................... 81
FIGURE 39. Per Line Setup - iDEN Mode (view 2) ........................................................................................... 81
FIGURE 40. Per Line Setup - Tetra Mode (view 1) ........................................................................................... 84
FIGURE 41. Relay Drop Down Menu ................................................................................................................ 85
FIGURE 42. Type Drop Down Menu - Tetra Mode ........................................................................................... 86
FIGURE 43. Per lIne Setup - Tetra Mode (view 2) ............................................................................................ 87
FIGURE 44. Save to EEPROM .......................................................................................................................... 90
FIGURE 45. Reset IP-223 .................................................................................................................................. 91
FIGURE 46. Account Setup ................................................................................................................................ 92
FIGURE 47. Edit System Account ...................................................................................................................... 94
FIGURE 48. Success Message ............................................................................................................................ 95
FIGURE 49. Add New User—Account Setup ..................................................................................................... 96
FIGURE 50. Edit Created Account—Account Setup .......................................................................................... 99
FIGURE 51. Additional Feature Access ........................................................................................................... 100
FIGURE 52. Clone System Parameters ............................................................................................................ 101
FIGURE 53. Crosspatch Setup ......................................................................................................................... 102
FIGURE 54. Crosspatch Setup - Mode Drop Down Menu .............................................................................. 105
FIGURE 55. #1 or #2 Drop Down Menu-Crosspatch Setup ............................................................................ 106
FIGURE 56. Remote Crosspatch Pin ............................................................................................................... 108
FIGURE 57. Account Password Change .......................................................................................................... 111
FIGURE 58. Tone Frequency and Durations ................................................................................................... 112
FIGURE 59. PTT Frequency Drop Down Menu .............................................................................................. 113
FIGURE 60. Select Installation Folder ............................................................................................................ 118
FIGURE 61. Confirm Installation .................................................................................................................... 118
FIGURE 62. Telex Website Firmware Downloads. .......................................................................................... 119
FIGURE 63. Firmware Update Tool ................................................................................................................ 120
FIGURE 64. Firmware Update Tool— Success Messages .............................................................................. 122
FIGURE 65. Jumper Locations ........................................................................................................................ 125

List
of
Tables
Table 66. IP-223 Specifications ...........................................................................................................................16
Table 67. Jumper Position ...................................................................................................................................19
Table 68. DB9 Pinout ..........................................................................................................................................20
Table 69. DB25 Connector Pinout Connections ..................................................................................................21
Table 70. IP-2002 Links .......................................................................................................................................40
Table 71. D, T, R Binary Reference .....................................................................................................................45
Table 72. Standard Function Tone Frequencies ................................................................................................114
Table 73. CTCSS Tone Frequencies ..................................................................................................................131
Table 74. Digital Output Values ........................................................................................................................133
Table 75. Supported Radio Dispatch Tone Frequencies ...................................................................................135

13
CHAPTER 1
Overview
The IP-223 Remote Adapter Panel provides a reliable means of remotely controlling two (2) audio devices. The adapter has
multiple modes allowing it to connect to both digital and analog consoles, and performs a variety of other tasks related to
putting radios on a digital network.
The IP-223 is interconnected to the distant remote control console(s) by means of any available WAN (Wide Area Network) or
LAN (Local Area Network) connection.
Operating Modes
The IP-223 is capable of operating each audio port in different modes:
Local Mode – The radio is connected directly to the IP-223 allowing for simple migration and local control of the radio.
Tone Mode – The IP-223, based on Ethernet traffic, generates the keytones required to control standard industry tone-
equipped radio circuits. This allows an existing tone decoder and radio to be connected. This mode also supports a parallel
analog console.
FIGURE 76. Local and Tone Mode Connections

Overview
14
Console Mode – Allows the use of existing tone-based consoles. The IP-223 decodes industry standard tones, converts it
to Ethernet traffic to another IP-223 that can be in tone or local mode.
Phone Mode – Using a PIB (Phone Interface Box) or TDI (Telephone Dispatch Interface), a line on the IP-
223 is used to connect to an analog phone line.
iDen Radio Mode – Using the NI-223, allows interface with a Falcon Class PTT (Push-To-Talk) mobile phone
system.
TETRA Radio Mode – Used to interface to a TETRA digital trunked system using the IP-223 and the Sepura
SRM2000 mobile radio. The IP-223 interfaces the radio through the PEI (Peripheral
Equipment Interface) allowing dispatch access to TETRA radio assets.
Features
NOTE: The features listed below for the IP-223 version 4.100 do not comprise the full feature set. For more information
on all the features available, contact Radio Dispatch Sales listed on www.telex.com
.
FIGURE 77. Console Mode Connection
•Ethernet TX and LINK LEDs
•PTT, Monitor, F1 and F2 relays (programmable to any
function tone or revert to F1)
•Four (4) PTT modes and three (3) monitor modes
•Nine (9) selectable PTT frequencies
•Seven (7) digital outputs for channel selection,
completely programmable per function tone
•CTCSS (Continuous Tone Coded Squelch System)
generation (64 frequencies)
•Hardware and software gain control
•Local handset port for monitoring activity and
transmission back to base or to radio
•RS-232C port on rear for initial configuration and
direct radio control
•Single function tone recognition (16 function tones)
•RX (Receive) audio squelch
•Crosspatch capability
•ANI (Automatic Number Identification) over-the-air-
protocol—decode and display
•Provides iDEN interface
•Supports Sepura SRM2000, TETRA radio
•E.F. Johnson RS5300 P25 radio interface
•Remote Crosspatch capabilities
•POTS line fail-over
•Phone line interface
•MDC and Fleetsync Decode
•5/6 Tone signalling encode/decode
•Kenwood radios interface

15
Operating Modes
NOTE: Transient protection is provided near all audio inputs and outputs. The IP-223 line transformers are not designed
to operate on lines carrying DC (direct current). If a voltage is on the line, isolate with external capacitors. If the
line termination must conduct direct current, install a 600:600 Ohm transformer designed for the current
involved.
IP-223 Accessories
There are several optional accessories available for the IP-223:
Part Number Description
223RACK 1 unit high rack shelf to hold up to two (2) IP-223 units
2490248 Alignment Handset
730153 Power Supply
301611000 Fleetsync Over the Air Decode
301611004 FleetSync Encode/Decode
301611001 MDC Over the Air Decode
301912000 NI-223
PRD000003000 IP223 to EFJohnson 5300 Mobile Radio Advanced Control Interface Box
301953000 IP223DB9Splitter - Serial Port splitter cable DB9
301956000 IP223CAB150/180 - IP223-Kenwood TK-150/180 cable
301957000 IP223CAB90 - IP223-Kenwood TK-90 cable
301969000 IP223CABCDM1250 - IP-223-Motorola CDM and GM cable
301961000 IP223CAB2000 - IP-223-Sepura SRM2000 cable
879794 IP223CAB Tone - IP-223-Dual DB25 Tone cable 24ft.

Overview
16
IP-223 Specifications
The specifications for the IP-223 are listed in Table 1. The specifications are subject to change without notice.
CAUTION: This device is NOT PoE (Power Over Ethernet) compatible.
Front Panel
Test and Adjustment Points
Test and adjustment points for Radio 1 and Radio 2 are provided on the front panel. Newer versions of the IP-223 provide
access to additional test and adjustment points on the case top, as shown in Figure 79.
TABLE 1. IP-223 Specifications
Operating Temperature Range 0 to 70°C for full specifications
Power Requirements +12 to +16Vdc, semi-regulated, ~700mA
Ethernet Speed 10 BaseT or 100 BaseTX
Lease Lines 2W and 4W supported
Radio Interface ±45VDC withstand rating
Relay Contact Ratings 1A at 125Vac
Non-Relay Outputs Open collector, active low, 200mA maximum, 40V collector to emitter voltage
Radio Input Level 10mVpp to 10Vpp, adjustable
Radio Output Level 10mVpp to 10Vpp for mic level or -40 to +10dBm into 600Ωload, adjustable
Radio Output Impedance 600Ωfor balanced mode, 200Ωfor single ended mode
Frequency Response ±1.5dB, 300 to 3000Hz
Audio Distortion 2% THD maximum
DTMF Detection Bandwidth ±25 Hz around center of frequency
MON timer 10ms to 9999ms, adjustable
Dimensions 8 ½” (215.9mm) Wide, 9 3/4” (247.65mm) Deep, by 1 5/8” (41.275mm) High
Actual Weight 3.75lb (1.701kg)
Shipping Weight and Dimensions 5lbs (2.267kg) ~ 12”(304.8mm) x 10”(254mm) x3”(76.2mm)
FIGURE 78. IP-223 Front Panel
Test and
adjustment points Handset
jack LCD displayIC button Line button
TX LED
LNK LED

17
Front Panel
NOTE: Radio 1 and radio 2 are also referred to as line 1 and line 2 in this manual.
Handset Jack
An optional handset is available for the IP-223. When the optional handset is plugged into the handset jack, the ability to
monitor and talk on either line is available. The handset jack is located on the front of the unit, see Figure 78. When the
handset PTT switch is pressed, the selected radio connected to the IP-223 is keyed up on the existing frequency and the
handset microphone audio is transmitted.
Ethernet audio is also generated on the TX multicast and port for the selected line. This functionality can be used to test both
the Ethernet network and the analog connection.
IC Button
The IC button, when pressed, sends audio from the handset microphone back through the IP Network on the selected TX
multicast and port. It also sends audio to the transmit lines of the IP-223 without keying up the radio. This means no PTT relay
in local mode and no EIA (Electronic Industries Association) tones in tone mode.
NOTE: A handset is required to use the IC button.
LCD Display
The LCD display provides panel status information, such as the IP and subnet addresses, line status, and handset line selection.
•TX F# (# is the selected function tone) indicates a PTT is active.
•RX F# (# is the selected function tone) indicates the RX radio is active.
•ID # displays when a Fleetsync or MDC ANI ID is decoded. This does not include serial decoding.
FIGURE 79. IP-223 Case Top Test Points

Overview
18
•When connected to a serially controlled radio, iDEN, Sepura, Kenwood or Johnson displays.
•INTCOM displays when the front panel IC button is pressed.
•EnetIC displays when the console generated intercom is received.
•CTX F# displays when the console mode IP-223 decodes tones from a tone console in Console mode.
•CRX F# displays when the IP-223 transmits wire-line audio to a legacy tone console in Console mode.
•PTX F# displays when the IP-223 decodes tones from a legacy tone console attached in parallel in Tone mode.
•CPT F# displays when the IP-223 transmits to a line if the line-to-line crosspatch is enabled.
•Ring displays when there is an incoming phone call in Phone mode.
•Offhook displays when the line is in use during a phone call.
•LLM displays when no phone line is connected to the PIB or TDI in Phone mode.
•NO LINE ENABLED displays after power-up if neither line is enabled.
•Scan List.... displays during power up while the IP-223 is communicating with serial controlled radios that
support the Scan List feature.
To toggle the LCD display, do the following:
1. Press and hold the line button and then momentarily press the IC button.
Three different displays are available with each press of the IC button:
•While pressing the line button, press the IC button once.
The IP Address and Mask Address of the unit displays.
•Continue to hold the line button, then press the IC button a second time.
The TX alignment tones are turned ON.
•Continue to hold the line button, then press the IC button a third time.
The RX VU meter displays.
2. Press the IC button a fourth time to clear the display and return to the normal LCD display.
3. Release the line button.
Line Button
The Line button is used to select which radio, or line, the handset audio is routed and which line is being monitored. The
handset line selection is displayed as an asterisk (*) in the right most column of the LCD display. An asterisk (*) on the top
line of the display indicates a connection to line 1, and an asterisk (*) on the bottom line of the display indicates a connection
to line 2.
TX LED
The TX LED provides a visual indication the IP-223 is generating IP packets. When the LED is illuminated, packets are being
transmitted to the network.
LNK LED
The LNK LED provides a visual indication of the Ethernet connection. When the LED is illuminated, a valid network
connection is established.

19
Back Panel
Back Panel
10/100 Ethernet Connector
The 10/100 Ethernet connector provides the LAN or WAN connection for the IP-223.
Serial Connector
The serial connector (DB9) is used for either of the following:
•To program an initial IP Address into the IP-223 unit, if the IP Address cannot be programmed through the
Ethernet port on the installed system.
NOTE: To communicate with HyperTerminal, the jumper setting must be RS-232.
•To provide serial communication to various radios. Both radio (or line) 1 and radio (or line) 2 are supported on
this connector, with the appropriate splitter cable.
NOTE: You must adjust the position of the jumper, on J35 when using line 1, or on J26 when using line 2, according to
the serial connection type for the radio interface shown below. See “Jumper Positions” on page 25 for more
information.
FIGURE 80. IP-223 Back Panel
Jumper position Connection type
A RS-232
BTTL
TABLE 2. Jumper Position
10/100
Ethernet
connector
Serial
connector
(DB9) Radio 1 and radio 2
connectors (DB25) Power
connection

Overview
20
Radio 1 and Radio 2 (Line 1 and Line 2) Connectors
Two (2) DB25 connectors are provided for connection to various audio devices. The pinouts shown in Table 4 are used when
custom cables need to be fabricated.
Power Connection
The IP-223 requires +12 to +16VDC, ~700mA of clean power. A 3-pin screw terminal receptacle is provided on the right rear
of the unit, pin 1 is the positive terminal, pin 2 is the ground terminal, and pin 3 is the earth ground terminal.
As with all communication equipment earth ground should be used. Earth ground is a low impedance path to earth for the
purpose of discharging lightening, static, and radiated energy.
SERIAL DB9 PINOUT
SIGNAL LINE # DB9 PIN #
TX 232 1 2
RX 232 1 3
TX TTL 1 9
RX TTL 1 1
Ground both 5
TX 232 2 8
RX 232 2 7
TX TTL 2 4
RX TTL 2 6
TABLE 3. DB9 Pinout

21
Back Panel
FIGURE 81. DB25 Connector Pinout Configuration
TABLE 4. DB25 Connector Pinout Connections
Pin # Signal Cable color
1 PTT Relay N.C. Brown
2 PTT Relay Common Red
3 MON Relay N.O. Orange
4 R1 Relay N.C. Pink
5 R1 Relay Common Yellow
6 R2 Relay N.O. Green
7 Ground Lt. Green
8 Digital 0/X-Mute Blue
9 Digital 2 Violet
10 Digital 4 Gray
11 CTCSS White
12 Radio RX- in / 4-wire RX Black
13 Radio TX- out / 4-wire TX or 2-wire Brown/White
14 PTT Relay N.O. Red/White
15 MON Relay N.C. Red/Black
16 MON Relay Common Orange/White
17 R1 Relay N.O. Orange/Black
18 R2 Relay N.C. Pink/Black
19 R2 Relay Common Yellow/Black
20 Digital 6/COR Green/White
21 Digital 1/Supervisory Green/Black
22 Digital 3 Blue/White
23 Digital 5/Local PTT Violet/White
24 Radio RX+ input / 4-wire RX Gray/Black
25 Radio TX+ out / 4-wire TX or 2-wire Black/White
Shield Ground

Overview
22
