Telex IP-223 Installation and operating instructions

AN-DISPATCH-033 Rev B 11 FEB 2011
ICOM IC-A200 Aircraft Radio to
223 Series Adapter Panels

2AN-DISPATCH-033
Table of Contents
1.0General .....................................................................................................................3
2.0Interconnect Cable assembly..................................................................................3
3.0223 Series Panels......................................................................................................3
3.1TRA-223 Setup..........................................................................................................................3
3.2TRA-223 Dip-Switch Settings..................................................................................................4
3.3DSP-223 Jumper Settings.........................................................................................................4
3.4IP-223 Setup ..............................................................................................................................5
3.5ICOM IC-A200 Radio Setup ...................................................................................................5

AN-DISPATCH-033 3
1.0 General
This application note is intended to show how to assemble a cable and setup the hardware of
different 223 series adapter panels (TRA-223, DSP-223 and IP-223) to an ICOM*1IC-A200
series aircraft radio.
NOTE: This application note only supports control on a dedicated radio channel.
2.0 Interconnect Cable assembly
A cable assembly is required to connect the ICOM IC-A200 30-pin accessory connector to the
various 223 Series adapter panels.
Use the following chart to manufacture this cable assy.
3.0 223 Series Panels
3.1 TRA-223 Setup
The TRA-223 requires the TO-23 option is installed to support a connection to the
ICOM IC-A200.
REFERENCE: For more information, see the TRA-223 Technical Manual (P/N 803570).
This document is available for download at www.telexradiodispatch.com/.
1.See “Copyright Notice” on page 7.
TABLE 1. Interconnect Cable Assembly
TRA-223
DB-25 Pin DSP-223 DB-25 Pin IP-223 DB-25 Pin IC-A200 30-Pin Signal
25 25 25 J MIC+
24 24 24 H RX+
12 12 12 7 RX-
14 14 14 9 PTT
7776&8GND
ICOM IC-A200 Aircraft Radio to 223 Series
Adapter Panels

ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels
4 AN-DISPATCH-033
3.2 TRA-223 Dip-Switch Settings
Use Table 2 to set the dip switches for the TRA-223.
3.3 DSP-223 Jumper Settings
To set the DSP-223 jumpers, do the following:
1. Set to the A position:
•J14, J15, J22, J23.
2. Set to the B position:
•J24, J25, J27, J12 and J13.
3. Solder closer JP2.
NOTE: J19, J20 and J21 are for selecting 2- or 4-wire operation.
REFERENCE: For more information, see the DSP-223 Technical Manual (P/N 803274).
This document is available for download at www.telexradiodispatch.com/.
TABLE 2. TRA-223 Dip Switch Settings
Switch Setting Signal
1 As appropriate 2–Wire = On
4-Wire = Off
2 As appropriate 4–Wire = On
2–Wire = Off
3 As appropriate Full Duplex = On
Half Duplex = Off
4 Off Squelch
5Off
Radio Rx Level
Speaker = On
High Impedance = Off
6On
Radio Tx Level
Low Level = On
High Level = Off
7 On Ground on PTT Relay Common
8 Off Ground on Monitor Relay Common

223 Series Panels
AN-DISPATCH-033 5
3.4 IP-223 Setup
Set up the appropriate IP-223 lines for Local mode.
Using control and set the jumpers as follows.
3.5 ICOM IC-A200 Radio Setup
Set front panel volume control to mid-range.
No further configuration or radio programming is required.
TABLE 3.
Line 1 Jumper Setting Line 2
J33, J34 B = 4-wire J5, J6
J16, J21 B = Balanced J19, J20
J14 Hanging on center pin = 10K Ohm J24
J3, J9, J11 A = Single Ended J25, J28, J29
J13 A = Low J27
J17, J22 B = 600 Ohms J10, J15
R377 Solder Bridge pads together R381

ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels
6 AN-DISPATCH-033
