Telex IP-223 User manual

IP-223
Remote Adapter Panel
Technical Manual
up to and including version 4.200
803641 Rev L 07/2009

PROPRIETARY NOTICE
The product information and design disclosed herein were originated by
and are the property of Bosch Security Systems, Inc. Bosch reserves all
patent, proprietary design, manufacturing, reproduction, use and sales
rights thereto, and to any article disclosed therein, except to the extent
rights are expressly granted to others.
COPYRIGHT NOTICE
Copyright 2009 by Bosch Security Systems, Inc. All rights reserved.
Reproduction, in whole or in part, without prior written permission from
Bosch is prohibited.
WARRANTY NOTICE (LIMITED)
All Bosch manufactured signaling products are guaranteed against
malfunction due to defects in materials and workmanship for three (3)
years, beginning at the original date of purchase.If such a malfunction
occurs, the product be repaired or replaced (at our option) without
charge during the three (3) year period, if delivered to the Bosch factory.
Warranty does not extend to damage due to improper repairs, finish or
appearance items, or malfunction due to abuse or operation under other
than the specified conditions, nor does it extend to incidental or
consequential damages. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above
limitation may not apply to you. This warranty gives the customer
specific legal rights, and there may be other rights which vary from state
to state.
FACTORY SERVICE CENTER
Factory Service Center
Bosch Security Systems, Inc.
Radio Dispatch Products
8601 East Cornhusker Highway
Lincoln, Nebraska, 68507
PHONE NUMBERS
Sales:
Phone ...................................................................[phone]
Fax........................................................................[phone]
E-mail...........................................T[email protected]
Customer Service Repair:.................................................[phone]
Technical Support:
Phone ...................................................................[phone]
E-mail ........................ Tel[email protected]
Web ..................................................................................www.telex.com
CLAIMS
No liability be accepted for damages directly or indirectly arising from
the use of our materials or from any other causes. Our liability shall be
expressly limited to replacement or repair of defective materials.
WARNING
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.

Table
of
Contents
OVERVIEW..................................................... 13
Features ................................................................13
Operating Modes ..................................................14
IP-223 Accessories ...............................................15
IP-223 Specifications ............................................16
Front Panel ...........................................................17
TEST AND ADJUSTMENT POINTS ..................................17
HANDSET JACK ...........................................................18
IC BUTTON .................................................................18
LCD DISPLAY .............................................................18
LINE BUTTON .............................................................19
TX LED .....................................................................19
LNK LED ..................................................................19
Back Panel ............................................................20
10/100 ETHERNET CONNECTOR ..................................20
SERIAL CONNECTOR ...................................................21
RADIO 1 AND RADIO 2 CONNECTORS ..........................21
POWER CONNECTION ..................................................21
COMMUNICATIONS SYSTEM DESIGN.... 23
Communications Control .....................................23
TONE REMOTE CONTROL ............................................23
VOIP RADIO CONTROL ...............................................23
Network Requirements ..........................................24
IP OPERATION OVERVIEW ..........................................24
ETHERNET AS PHYSICAL LAYER ...................................24
BANDWIDTH ................................................................24
MULTICAST .................................................................24
INTERNET GROUP MANAGEMENT PROTOCOL ..............25
NETWORK PERFORMANCE ...........................................25
TCP/IP AND UDP/IP .................................................25
MULTICAST UDP/IP ...................................................25
INSTALLATION AND LEVEL SETTINGS . 27
Local Radio Connections .....................................27
JUMPER POSITIONS .....................................................27
TX AUDIO CONNECTION .............................................29
RX AUDIO CONNECTION .............................................29
COR I/O ....................................................................30
PTT CONNECTION ..................................................... 30
MONITOR CONNECTION ............................................. 31
R1 AND R2 RELAYS .................................................... 31
DIGITAL I/O ............................................................... 31
CTCSS CONNECTION ................................................. 31
Tone and Console Operation ................................32
2-/4-WIRE JUMPER SETTINGS ..................................... 32
TX SIDE SETTINGS ..................................................... 32
LOCAL PTT I/O ......................................................... 32
CROSS MUTE I/O ....................................................... 32
SUPERVISORY I/O ....................................................... 33
Level Adjustments .................................................33
GENERAL ALIGNMENT ................................................ 33
RADIO TX .................................................................. 33
RADIO RX .................................................................. 34
LINE TX MONITOR LEVEL - TONE AND CONSOLE
MODE ........................................................................ 34
CTCSS LEVEL ........................................................... 34
Frequency Decoding .............................................35
SETUP INFORMATION................................ 37
Setting the IP Address Information ......................37
USING HYPERTERMINAL ............................................. 38
Accessing IP-223 Web Browser Configuration
Windows ................................................................42
IP-223 Web Setup Windows Standards ................43
LINKS ......................................................................... 43
Welcome Window .................................................45
CONSOLE NAME FIELD .............................................. 45
FIRMWARE VERSION FIELD ........................................ 46
CHECKSUM FIELD ...................................................... 46
SUBMIT BUTTON ........................................................ 46
Basic Ethernet Setup Window ...............................47
SERIAL NUMBER FIELD .............................................. 47
MAC ADDRESS .......................................................... 47
USE DHCP SERVER CHECK BOX ............................... 48
UNIT IP ADDRESS FIELD ............................................ 48
SUBNET MASK FIELD ................................................. 48
GATEWAY ADDRESS FIELD ......................................... 48
DNS NUMBER 1–3 FIELDS ......................................... 48

PACKET DELAY BEFORE PLAYBACK FIELD ..................48
QOS: PRECEDENCE BITS FIELD .................................48
QOS: D, T, AND R BITS FIELD ...................................49
LOCAL COMPUTER IP ADDRESS FIELDS .....................49
SUBMIT BUTTON .........................................................50
General Gain Setup Window ............................... 51
HANDSET MIC GAIN DROP DOWN MENU ....................52
HANDSET SIDETONE GAIN DROP DOWN MENU ...........52
RECEIVE GAIN DROP DOWN MENU ............................53
TRANSMIT GAIN DROP DOWN MENU ..........................53
CTCSS/RECORDER OUT GAIN DROP DOWN MENU ....54
TX VOICE GAIN FIELD ...............................................54
MSK TONE GAIN FIELD .............................................54
TDI RECEIVE GAIN DROP DOWN MENUS ...................55
TDI TRANSMIT GAIN DROP DOWN MENUS .................55
SUBMIT BUTTON .........................................................56
Multicast Address Setup Window ........................ 57
LINE NUMBER FIELD ..................................................57
ENABLE VIA ETHERNET CHECK BOX ...........................57
LINE TYPE DROP DOWN MENU ..................................58
LINE NAME FIELD ......................................................58
RX MCAST ADDRESS FIELD ........................................59
RX PORT FIELD ..........................................................59
TX GROUP PORT FIELD .............................................59
TTL FIELD .................................................................60
VOCODER TYPE DROP DOWN MENU ..........................61
ENABLE CHECK BOX ..................................................61
LINE NAME FIELD ......................................................61
MULTICAST ADDRESS FIELD .......................................61
OUTGOING PORT FIELD .............................................61
TTL FIELD .................................................................62
ENABLE CHECK BOX ..................................................62
NAME FIELD ...............................................................62
MULTICAST ADDRESS FIELD .......................................62
INCOMING PORT FIELD ..............................................62
OUTGOING PORT FIELD .............................................62
TTL FIELD .................................................................62
ENABLE CHECK BOX ..................................................63
VOCODER TYPE DROP DOWN MENU ..........................63
LINE NAME FIELD ......................................................63
MCAST ADDRESS FIELD ..............................................63
PORT FIELD ................................................................63
TTL FIELD .................................................................63
SUBMIT BUTTON .........................................................64
Per Line Setup Window ........................................ 65
Per Line Setup Window—Local, Tone, and
Console Mode ...................................................... 65
LINE SELECT 1 BUTTON ..............................................66
LINE SELECT 2 BUTTON ..............................................66
SUBMIT BUTTON .........................................................66
LINE TYPE FIELD ........................................................66
LINE ENABLED CHECK BOX ........................................66
LAM ENABLED CHECK BOX - LOCAL AND TONE
MODES .......................................................................66
COR ENABLED CHECK BOX - LOCAL AND TONE
MODES .......................................................................66
COR ACTIVE HIGH CHECK BOX - LOCAL AND TONE
MODES .......................................................................66
ALWAYS ONRADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................67
ONWITH PTT RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................67
TAPE OUTPUT RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................67
TX DELAY FIELD - LOCAL, TONE, AND CONSOLE,
MODES .......................................................................67
RX DELAY FIELD - LOCAL, TONE, AND CONSOLE
MODES .......................................................................67
SQUELCH TAIL DELAY FIELD - LOCAL, TONE, AND
CONSOLE MODES ........................................................67
MSK TONE DELAY FIELD - LOCAL AND TONE MODES 67
PTT DELAY FIELD - LOCAL MODE .............................68
JUMP TOENTRY DROP DOWN MENU ..........................68
GOBUTTON ................................................................68
UPDATE BUTTON ........................................................68
TONE ENABLE CHECK BOX .........................................68
RELAY DROP DOWN MENU - LOCAL, TONE, AND
CONSOLE MODES ........................................................69
RELAY GROUP DROP DOWN MENU - LOCAL, TONE,
AND CONSOLE MODES ................................................69
RELAY TIME (MS) FIELD - LOCAL, TONE, AND
CONSOLE MODES ........................................................69
DIGITAL OUTPUT FIELD - LOCAL MODE .....................70
CTCSS FREQ FIELD - LOCAL MODE ..........................70
CTCSS DEFAULT CHECK BOX - LOCAL MODE ...........70
SYSTEM FIELD - LOCAL MODE ....................................70
CHAN FIELD - LOCAL MODE .......................................71
LAM LEVEL FIELD - LOCAL, TONE, AND CONSOLE
MODES .......................................................................73
LAM TIME FIELD - LOCAL, TONE, AND CONSOLE
MODES .......................................................................73
SUPERVISOR CHECK BOX - TONE AND CONSOLE
MODES .......................................................................73
CROSS MUTE CHECK BOX - TONE AND CONSOLE
MODES .......................................................................73
FULL DUPLEX CHECK BOX - LOCAL, TONE, AND
CONSOLE MODES ........................................................73
RXAGC CHECK BOX - LOCAL, TONE, AND
CONSOLE MODES ........................................................73
HI-PASS RX CHECK BOX - LOCAL, TONE, AND
CONSOLE MODES ........................................................74
PRE-EMPHASIZE TX CHECK BOX - LOCAL MODE .......74
TX MONITOR CHECK BOX - TONE MODE ...................74
2-WIRE CHECK BOX - TONE MODE ............................74
F1 LAST CALL CHECK BOX - LOCAL, TONE, AND
CONSOLE MODES ........................................................74
PARALLEL TONE CONSOLE CHECK BOX - TONE AND
CONSOLE MODES ........................................................74

PTT NOTCH FILTER CHECK BOX - LOCAL, TONE,
AND CONSOLE MODES ................................................74
IR1600 MODEM CHECK BOX ......................................74
BUSY CHANNEL LOCKOUT CHECK BOX - LOCAL AND
TONE MODES ..............................................................74
PTT RELAY ONLY RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................74
PTT + R1 RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................75
PTT + R2 RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................75
PTT + BOTH RADIO BUTTON - LOCAL, TONE, AND
CONSOLE MODES ........................................................75
PTT TIMEOUT FIELD - LOCAL, TONE, AND CONSOLE
MODES .......................................................................75
SERIAL PORT MODE DROP DOWN MENU - LOCAL,
TONE, AND CONSOLE MODES .....................................75
SERIAL PORT PARAMS DROP DOWN MENU - LOCAL,
TONE, AND CONSOLE MODES .....................................76
FLEETSYNC DECODE CHECK BOX - LOCAL AND TONE
MODES .......................................................................77
FLEETSYNC ENCODE CHECK BOX - LOCAL AND TONE
MODES .......................................................................78
MDC DECODE CHECK BOX - LOCAL AND TONE
MODES .......................................................................78
MDC ENCODE CHECK BOX - LOCAL AND TONE
MODES .......................................................................78
TONE TYPE DROP DOWN MENU .................................78
ANI SUFFIX DROP DOWN MENU - LOCAL, TONE, AND
CONSOLE MODES ........................................................79
DIGIT DURATION FIELD - LOCAL AND TONE MODES ..79
INTERDIGIT DURATION FIELD - LOCAL AND TONE
MODES .......................................................................79
PAUSE DURATION FIELD - LOCAL AND TONE MODES .79
PREAMBLE DURATION FIELD - LOCAL AND TONE
MODES .......................................................................79
GROUP DIGIT FIELD - LOCAL AND TONE MODES .......80
REPEAT DIGIT FIELD - LOCAL AND TONE MODES .......80
ANI DECODER # FIELD ..............................................80
ANI CALL TYPE DROP DOWN MENU - LOCAL,
TONE, AND CONSOLE MODES .....................................80
ANI CALL FORMAT FIELD - LOCAL, TONE, AND
CONSOLE MODES ........................................................81
Per Line Setup Window—Phone Mode, View 1 ...81
AUTO ANSWER FIELD ..................................................82
AUTO DISCONNECT TIME FIELD .................................82
TX DELAY FIELD ........................................................82
RX DELAY FIELD ........................................................82
LAM LEVEL FIELD .....................................................82
LAM TIME FIELD .......................................................82
MIC CLICK CALL ENABLED CHECK BOX .....................83
NUMBER OF CLICKS FIELD .........................................83
TIME BETWEEN CLICKS FIELD ....................................83
CLICK DIAL STRING FIELD .........................................83
CLICK DIAL TIMEOUT FIELD ......................................83
RELAY CLOSURE ......................................................... 84
RXAGC ENABLED CHECK BOX ................................. 85
KEEP ALIVE DIGITS ENABLED CHECK BOX ................ 85
STAR/POUND KEYING ENABLED CHECK BOX ............. 85
DETECT TONES ENABLED CHECK BOX ....................... 85
HOOK FLASH TIME FIELD .......................................... 85
NETWORK CALL TIMEOUT FIELD ................................ 85
STATION ID FIELD ..................................................... 85
BUSY CHANNEL LOCKOUT CHECK BOX ...................... 85
C550 OPERATION ENABLED CHECK BOX ................... 86
RP251 OPERATION ENABLED CHECK BOX ................. 86
RP251 ACCESS DIGITS FIELD .................................... 86
RP251 CONNECT DIGITS FIELD ................................. 86
SERIAL PORT MODE DROP DOWN MENU ................... 86
SERIAL PORT PARAMETERS DROP DOWN MENU ......... 87
FLEETSYNC DECODE CHECK BOX .............................. 87
FLEETSYNC ENCODE CHECK BOX .............................. 87
MDC DECODE CHECK BOX ....................................... 87
MDC ENCODE CHECK BOX ....................................... 87
TONE TYPE DROP DOWN MENU ................................. 88
ANI SUFFIX DROP DOWN MENU ................................ 89
DIGIT DURATION FIELD ............................................. 89
INTERDIGIT DURATION FIELD .................................... 89
PAUSE DURATION FIELD ............................................ 89
PREAMBLE DURATION FIELD ..................................... 89
GROUP DIGIT FIELD .................................................. 90
REPEAT DIGIT FIELD ................................................. 90
ANI DECODER # FIELD .............................................. 90
ANI CALL TYPE DROP DOWN MENU .......................... 90
ANI CALL FORMAT FIELD .......................................... 91
Per Line Setup—iDEN Mode ............................... 92
TX DELAY FIELD ....................................................... 92
RX DELAY FIELD ....................................................... 92
SQUELCH TAIL DELAY FIELD ..................................... 93
JUMP TOENTRY DROP DOWN MENU ......................... 93
GOBUTTON ............................................................... 93
UPDATE BUTTON ....................................................... 93
FUNCTION TONE ENABLE CHECK BOX ....................... 93
RELAY DROP DOWN MENU ........................................ 94
RELAY GROUP DROP DOWN MENU ............................ 94
RELAY TIME (MS) FIELD ............................................. 94
CALL TYPE DROP DOWN MENU ................................. 95
IDEN NUMBER FIELD ................................................ 95
LAM LEVEL FIELD ..................................................... 96
LAM TIME FIELD ....................................................... 96
SUPERVISOR CHECK BOX ........................................... 97
CROSSMUTE CHECK BOX ........................................... 97
FULL DUPLEX CHECK BOX ........................................ 97
RXAGC CHECK BOX .................................................. 97
HI-PASS RX CHECK BOX ........................................... 97
PRE-EMPHASIZE TX CHECK BOX ............................... 97
TX MONITOR CHECK BOX .......................................... 97
2-WIRE CHECK BOX ................................................... 98
F1 LAST CALL CHECK BOX ........................................ 98
PARALLEL TONE CONSOLE CHECK BOX ..................... 98

PTT NOTCH FILTER CHECK BOX ................................98
IR1600 MODEM CHECK BOX ......................................98
BUSY CHANNEL LOCKOUT CHECK BOX ......................98
PTT TIMEOUT FIELD ..................................................98
SERIAL PORT MODE DROP DOWN MENU ....................99
SERIAL PORT PARAMS DROP DOWN MENU .................99
Per Line Setup—Tetra Mode ............................... 99
TX DELAY FIELD ......................................................100
RX DELAY FIELD ......................................................100
SQUELCH TAIL DELAY ..............................................100
JUMP TOENTRY DROP DOWN MENU .......................100
UPDATE BUTTON ......................................................100
TONE ENABLE CHECK BOX .......................................101
RELAY DROP DOWN MENU .......................................101
RELAY GROUP DROP DOWN MENU ..........................101
RELAY TIME (MS) FIELD ...........................................101
TYPE DROP DOWN MENU .........................................102
ISSI/GSSI NUMBER FIELD .......................................102
LAM LEVEL FIELD ...................................................103
LAM TIME FIELD .....................................................103
SUPERVISOR CHECK BOX ..........................................104
CROSS MUTE CHECK BOX ........................................104
FULL DUPLEX CHECK BOX ......................................104
RXAGC CHECK BOX ................................................104
HI-PASS RX CHECK BOX ..........................................104
PRE-EMPHASIZE TX CHECK BOX ..............................104
TX MONITOR CHECK BOX ........................................104
2-WIRE CHECK BOX .................................................105
F1 LAST CALL CHECK BOX ......................................105
PARALLEL CONSOLE CHECK BOX .............................105
PTT NOTCH FILTER CHECK BOX ..............................105
IR1600 CHECK BOX .................................................105
PTT TIMEOUT FIELD ................................................105
SERIAL PORT MODE DROP DOWN MENU ..................106
SERIAL PORT PARAMS DROP DOWN MENU ...............106
Save to EEPROM Window ................................. 106
SAVE PARAMETERS BUTTON ......................................106
RESET IP-223 BUTTON .............................................107
Account Setup Window ...................................... 108
ENABLE CHECK BOX ................................................109
USERNAME COLUMN .................................................109
PASSWORD FIELD .....................................................109
NEW PASSWORD FIELD .............................................109
CONFIRM PASSWORD FIELD .....................................110
EDIT BUTTON ...........................................................110
SAVE BUTTON ...........................................................110
SUBMIT BUTTON .......................................................110
DELETE BUTTON ......................................................111
ADD NEW USER BUTTON ..........................................111
RESET SYSTEM PARAMETERS BUTTON .......................112
RESTORE FACTORY DEFAULTS RADIO BUTTON .........112
RESET CONFIRMATION CODE NUMBER .....................112
ENTER RESET CONFIRMATION CODE FIELD ..............112
RESET BUTTON .........................................................113
Edit User Accounts Window .............................. 114
SET NOPASSWORD CHECK BOX ...............................115
SAVE BUTTON ...........................................................116
CANCEL BUTTON ......................................................116
Add New User Window ...................................... 117
USERNAME FIELD .....................................................117
PASSWORD FIELD .....................................................117
CONFIRM PASSWORD FIELD ......................................117
ADDITIONAL FEATURE CHECK BOX ..........................117
SAVE TOEEPROM CHECK BOX ..............................118
WELCOME PAGE CHECK BOX ...................................118
ACCOUNT SETUP CHECK BOX ...................................118
BASIC ETHERNET & MULTICAST SETUP CHECK BOX .118
CLONE CONSOLE & PASS CHANGE CHECK BOX .......118
CRP SETUP & PIN TABLE CHECK BOX ....................118
GENERAL GAIN CHECK BOX .....................................118
PER LINE SETUP CHECK BOX ...................................118
TONE FREQ & DURATIONS CHECK BOX ...................118
CANCEL BUTTON ......................................................118
SUBMIT BUTTON .......................................................119
BACK TO ACCOUNT SETUP BUTTON ..........................119
ADD ANOTHER USER BUTTON ...................................119
Edit Created Accounts Window ......................... 120
NEW PASSWORD FIELD .............................................121
CONFIRM PASSWORD FIELD ......................................121
SAVE BUTTON ...........................................................121
Additional Feature Setup Window ..................... 122
ENTER ACCESS KEY FIELD ........................................122
Clone Console Window ...................................... 124
Crosspatch Setup Window ................................. 125
ENABLE LINE-LINE CHECK BOX ................................126
START PATCH FTONE DROP DOWN MENU ................126
STOP PATCH FTONE DROP DOWN MENU .................126
ENET PATCH TIMEOUT FIELD ...................................126
ENABLE RCP CHECK BOX ........................................126
DIALING DIGITS FIELD .............................................126
INTERDIGIT TIME FIELD ............................................126
BEEP DLY FIELD ......................................................127
PATCH TIMEOUT FIELD ............................................127
GLOBAL FIELD ..........................................................127
DROP ALL FIELD ......................................................127
RCP TABLES .............................................................127
JUMP TOENTRY DROP DOWN MENU ........................128
GOBUTTON ..............................................................128
ENTRY FIELD ............................................................128
ADD STRING FIELD ...................................................128
DELETE STRING FIELD ..............................................128
MODE DROP DOWN MENU .......................................129
PHONE FIELD (DIAL OPTION ONLY) .........................129
#1 OR #2 DROP DOWN MENU
(XPATCH OPTION ONLY) .........................................130
IP ADDRESS FIELD (XPATCH OPTION ONLY) ...........130
RXMULTICAST FIELD (DLVOIP OPTION ONLY) ........130
RXPORT FIELD (DLVOIP OPTION ONLY) .................130
TX MULTICAST FIELD (DLVOIP OPTION ONLY) .......130
TX PORT FIELD (DLVOIP OPTION ONLY) .................130

COMMAND BUTTONS .................................................131
PREV 10 BUTTON ......................................................131
NEXT 10 BUTTON ......................................................131
CRP PIN Table Window .....................................133
JUMP TOENTRY DROP DOWN MENU ........................134
GOBUTTON ..............................................................134
SUBMIT BUTTON .......................................................134
PIN ENABLE CHECK BOX .........................................135
ENTRY FIELD ............................................................135
PIN FIELD ................................................................135
SUBMIT BUTTON .......................................................135
PREV 30 ENTRIES BUTTON ........................................135
NEXT 30 ENTRIES BUTTON ........................................136
Pass Change Window .........................................137
Tone Frequency & Durations Window ...............138
MONITOR FREQUENCY FIELD ...................................138
PTT FREQUENCY DROP DOWN MENU ......................139
GUARD TONE DURATION FIELD ................................139
GUARD TONE MAGNITUDE FIELD .............................139
HOLD TONE MAGNITUDE FIELD ...............................139
HOLD TONE HANGTIME FIELD ..................................139
FUNCTION TONE DURATION FIELD ...........................140
FUNCTION TONE MAGNITUDE FIELD ........................140
FTONE 1-16 FREQUENCY FIELDS .............................140
UPDATE FIRMWARE................................. 143
Update Firmware ...............................................143
INSTALL TSM ............................................................143
DOWNLOAD TELEX FIRMWARE ..................................145
UPDATE FIRMWARE TOOL WINDOW ..........................146
UPLOAD VOIP HARDWARE FIRMWARE ......................147
CTCSS TONE FREQUENCY TABLE 149
CTCSS Tone Frequency Table ...........................149
DIGITAL OUTPUT TABLE 151
Digital Output Table ...........................................151
TONE FREQUENCY TABLE 153
Tone Frequency Table ........................................153
IP-223 SETTINGS - QUICK REFERENCE 155
I/O Connectors ...................................................155
Adjustments .........................................................155
Jumper Settings ...................................................156
PCB 750743 OR PCB 750630 REVISION F ...............156
PCB 750743 OR PCB 750630 REVISION C, D, E,
AND F ...................................................................... 156
PCB 750630 REVISION A ......................................... 156
Jumper Locations ...............................................157

List
of
Figures
FIGURE 1. Local and Tone Mode Connections .................................................................................................14
FIGURE 2. Console Mode Connection ...............................................................................................................14
FIGURE 3. IP-223 Front Panel ..........................................................................................................................17
FIGURE 4. IP-223 Case Top Test Points ...........................................................................................................17
FIGURE 5. IP-223 Back Panel ...........................................................................................................................20
FIGURE 6. DB25 Connector Pinout Configuration ...........................................................................................22
FIGURE 7. Jumper Positions ..............................................................................................................................27
FIGURE 8. IP-223 PCB Assembly ......................................................................................................................28
FIGURE 9. HyperTerminal Navigation ..............................................................................................................38
FIGURE 10. Com Terminal Setup Windows .......................................................................................................39
FIGURE 11. HyperTerminal Window Password ................................................................................................39
FIGURE 12. HyperTerminal Factory Setup Options – Serial Port Access Window ..........................................40
FIGURE 13. Connect to [IP Address] Window ..................................................................................................42
FIGURE 14. IP-223 Links ...................................................................................................................................43
FIGURE 15. Welcome Window ...........................................................................................................................45
FIGURE 16. Basic Ethernet Setup Window ........................................................................................................47
FIGURE 17. General Gain Setup Window ..........................................................................................................51
FIGURE 18. Handset Gain Setup Drop Down Menu .........................................................................................52
FIGURE 19. Handset Sidetone Gain Drop Down Menu ....................................................................................52
FIGURE 20. Receive Gain Drop Down Menu ....................................................................................................53
FIGURE 21. Transmit Gain Drop Down Menu ..................................................................................................53
FIGURE 22. CTCSS/Recorder Out Gain Drop Down Menu ..............................................................................54
FIGURE 23. TDI Receive Gain Drop Down Menu .............................................................................................55
FIGURE 24. TDI Transmit Gain Drop Down Menu ...........................................................................................55
FIGURE 25. Multicast Address Setup Window ...................................................................................................57
FIGURE 26. Line Type Drop Down Menu ..........................................................................................................58
FIGURE 27. Vocoder Type Drop Down Menu ...................................................................................................61
FIGURE 28. Vocoder Type Drop Down Menu ...................................................................................................63
FIGURE 29. Per Line Setup—Local, Tone, and Console Modes, View 1 ..........................................................65
FIGURE 30. Jump to Entry Drop Down Menu—Function Tone Setup ..............................................................68
FIGURE 31. Relay Drop Down Menu—Per Line Setup .....................................................................................69
FIGURE 32. Per Line Setup—Local, Tone, and Console Modes, View 2 ..........................................................72
FIGURE 33. Serial Port Drop Down Menu - Local Mode .................................................................................75
FIGURE 34. Serial Port Params Drop Down Menu - Normal Mode .................................................................76
FIGURE 35. Per Line Setup—Local, Tone, and Console Mode, View 3 ............................................................77
FIGURE 36. Tone Type Drop Down Menu .........................................................................................................78
FIGURE 37. ANI Type Drop Down Menu ..........................................................................................................79

FIGURE 38. ANI Call Type Drop Down Menu—Per Line Setup ....................................................................... 80
FIGURE 39. Per Line Setup—Phone Mode, View 1 .......................................................................................... 81
FIGURE 40. Per Line Setup—Phone Mode, View 2 .......................................................................................... 84
FIGURE 41. Serial Port Drop Down Menu—Phone Mode ............................................................................... 86
FIGURE 42. Serial Port Params Drop Down Menu—Phone Mode .................................................................. 87
FIGURE 43. Tone Type Drop Down Menu ........................................................................................................ 88
FIGURE 44. ANI Type Drop Down Menu .......................................................................................................... 89
FIGURE 45. ANI Call Type Drop Down Menu—Per Line Setup ....................................................................... 90
FIGURE 46. Per Line Setup—iDEN Radio Mode, View 1 ................................................................................. 92
FIGURE 47. Jump to Entry—iDEN Function Tone Setup ................................................................................. 93
FIGURE 48. Relay Drop Down Menu—Per Line Setup ..................................................................................... 94
FIGURE 49. Call Type Drop Down Menu—iDEN Mode ...................................................................................95
FIGURE 50. Per Line Setup—iDEN Mode, View 2 ............................................................................................ 96
FIGURE 51. Per Line Setup—Tetra Mode, View 1 ............................................................................................ 99
FIGURE 52. Jump to Entry—Tetra Function Tone Setup ................................................................................ 100
FIGURE 53. Relay Drop Down Menu .............................................................................................................. 101
FIGURE 54. Type Drop Down Menu—Tetra Mode ......................................................................................... 102
FIGURE 55. Per Line Setup—Tetra Mode, View 2 .......................................................................................... 103
FIGURE 56. Save to EEPROM ........................................................................................................................ 106
FIGURE 57. Reset IP-223 ................................................................................................................................ 107
FIGURE 58. Account Setup .............................................................................................................................. 108
FIGURE 59. Account Setup Success Message .................................................................................................. 109
FIGURE 60. Edit User Account ........................................................................................................................ 114
FIGURE 61. Success Message .......................................................................................................................... 114
FIGURE 62. User Account Permission Change Success ................................................................................. 116
FIGURE 63. Add New User—Account Setup ................................................................................................... 117
FIGURE 64. Create New User Success Message ............................................................................................. 119
FIGURE 65. Edit Created Account .................................................................................................................. 120
FIGURE 66. Additional Feature Access ........................................................................................................... 122
FIGURE 67. Additional Feature List Example ................................................................................................. 123
FIGURE 68. Clone System Parameters ............................................................................................................ 124
FIGURE 69. Crosspatch Setup ......................................................................................................................... 125
FIGURE 70. Jump to Entry Drop Down Menu—Crosspatch Setup RCP Table .............................................. 128
FIGURE 71. Crosspatch Setup—Mode Drop Down Menu .............................................................................. 129
FIGURE 72. #1 or #2 Drop Down Menu—Crosspatch Setup .......................................................................... 130
FIGURE 73. Remote Crosspatch Pin ............................................................................................................... 133
FIGURE 74. Jump to Entry Drop Down Menu—Remote Crosspatch Setup .................................................... 134
FIGURE 75. Account Password Change .......................................................................................................... 137
FIGURE 76. Tone Frequency and Durations ................................................................................................... 138
FIGURE 77. PTT Frequency Drop Down Menu .............................................................................................. 139
FIGURE 78. Select Installation Folder ............................................................................................................ 144
FIGURE 79. Confirm Installation .................................................................................................................... 144
FIGURE 80. Telex Website Firmware Downloads. .......................................................................................... 145
FIGURE 81. Firmware Update Tool ................................................................................................................ 146
FIGURE 82. Firmware Update Tool— Success Messages .............................................................................. 148
FIGURE 83. Jumper Locations ........................................................................................................................ 157

List
of
Tables
Table 84. IP-223 Specifications ...........................................................................................................................16
Table 85. Jumper Position ...................................................................................................................................21
Table 86. DB9 Pinout ..........................................................................................................................................21
Table 87. DB25 Connector Pinout Connections ..................................................................................................22
Table 88. PCB 750743 or PCB 750630 Revision C and Higher Jumper Positions ............................................29
Table 89. PCB 750743 or PCB 750630 Revision C and Higher Jumper Positions ............................................30
Table 90. RX Impedance Jumper Positions - 2-Wire ...........................................................................................30
Table 91. RX Impedance Jumper Positions - 4-Wire ...........................................................................................30
Table 92. 2- and 4-Wire Jumper Settings ............................................................................................................32
Table 93. PCB 750743 or PCB 750630 Revision C and Higher .........................................................................32
Table 94. Factory Set Frequencies ......................................................................................................................35
Table 95. IP-2002 Links .......................................................................................................................................43
Table 96. D, T, R Binary Reference .....................................................................................................................49
Table 97. Standard Function Tone Frequencies ................................................................................................140
Table 98. CTCSS Tone Frequencies ..................................................................................................................149
Table 99. Digital Output Values ........................................................................................................................151
Table 100. Supported Radio Dispatch Tone Frequencies .................................................................................153

13
CHAPTER 1
Overview
The IP-223 Remote Adapter Panel provides a reliable means of controlling two (2) audio devices remotely. The adapter has
multiple modes allowing it to connect to both digital and analog consoles, and performs a variety of other tasks related to using
radios on a digital network.
The IP-223 is interconnected to distant remote control console(s) by means of any available WAN (Wide Area Network) or
LAN (Local Area Network) connection.
Features
NOTE: The features listed below for the IP-223 do not comprise the full feature set. For more information on all the
features available, contact Radio Dispatch Sales listed on www.telex.com
.
NOTE: Transient protection is provided near all audio inputs and outputs. The IP-223 line transformers are not designed
to operate on lines carrying DC (direct current). If a voltage is on the line, isolate with external capacitors. If the
line termination must conduct direct current, install a 600:600 Ohm transformer designed for the current
involved.
•Ethernet TX and LINK LEDs
•PTT, Monitor, F1 and F2 relays (programmable to any
function tone or revert to F1)
•Four (4) PTT modes and three (3) monitor modes
•Nine (9) selectable PTT frequencies
•Seven (7) digital outputs for channel selection,
completely programmable per function tone
•CTCSS (Continuous Tone Coded Squelch System)
generation (64 frequencies)
•Hardware and software gain control
•Local handset port for monitoring activity and
transmission back to base or to radio
•RS-232C port on rear for initial configuration and
direct radio control
•Single function tone recognition (16 function tones)
•RX (Receive) audio squelch
•Crosspatch capability
•ANI (Automatic Number Identification) over-the-air-
protocol—decode and display
•Provides iDEN interface
•Supports Sepura SRM2000, TETRA radio
•E.F. Johnson RS5300 P25 radio interface
•Remote Crosspatch capabilities
•POTS line fail-over
•Phone line interface
•MDC and Fleetsync Encode/Decode
•5/6 Tone signalling encode/decode
•Kenwood radios interface

Overview
14
Operating Modes
The IP-223 is capable of operating each audio port in different modes:
Local Mode - Allows the radio to connect directly to the IP-223 allowing for simple migration and local control
of the radio.
Tone Mode - Allows the IP-223, based on Ethernet traffic, to generate required key tones required to control
industry standard tone-equipped radio circuits. This allows an existing tone decoder and radio to be
connected. This mode also supports a parallel analog console.
Console Mode - Allows the use of existing tone-based consoles. The IP-223 decodes industry standard tones,
converts it to Ethernet traffic to another IP-223 that can be in tone or local mode.
Phone Mode - Using a PIB (Phone Interface Box) or TDI (Telephone Dispatch Interface), a line on the IP-223 is
used to connect to an analog phone line.
FIGURE 1. Local and Tone Mode Connections
FIGURE 2. Console Mode Connection

15
IP-223 Accessories
iDEN Radio Mode - Using the NI-223, allows interface with a Falcon Class PTT (Push-To-Talk) mobile phone system.
TETRA Radio Mode - Used to interface to a TETRA digital trunked system using the IP-223 and the Sepura SRM2000
mobile radio. The IP-223 interfaces the radio through the PEI (Peripheral Equipment Interface)
allowing dispatch access to TETRA radio assets.
IP-223 Accessories
There are several optional accessories available for the IP-223:
Part Number Description
223RACK 1 unit high rack shelf to hold up to two (2) IP-223 units
2490248 Alignment Handset
730153 Power Supply
301611000 Fleetsync Over the Air Decode
301611004 FleetSync Encode/Decode
301611001 MDC Over the Air Decode
301611005 MDC 1200 Encode/Decode
301912000 NI-223
PRD000003000 IP223 to EFJohnson 5300 Mobile Radio Advanced Control Interface Box
301953000 IP223DB9Splitter - Serial Port splitter cable DB9
301956000 IP223CAB150/180 - IP223-Kenwood TK-150/180 cable
301957000 IP223CAB90 - IP223-Kenwood TK-90 cable
301969000 IP223CABCDM1250 - IP-223-Motorola CDM and GM cable
301961000 IP223CAB2000 - IP-223-Sepura SRM2000 cable
879794 IP223CAB Tone - IP-223-Dual DB25 Tone cable 24ft.

Overview
16
IP-223 Specifications
The specifications for the IP-223 are listed in Table 1. The specifications are subject to change without notice.
CAUTION: This device is not PoE (Power Over Ethernet) compatible.
TABLE 1. IP-223 Specifications
Operating Temperature Range 0 to 70°C for full specifications
Power Requirements +12 to +16Vdc, semi-regulated, ~700mA
Ethernet Speed 10 BaseT or 100 BaseTX
Lease Lines 2W and 4W supported
Radio Interface ±45VDC withstand rating
Relay Contact Ratings 1A at 125Vac
Non-Relay Outputs Open collector, active low, 200mA maximum, 40V collector to emitter voltage
Radio Input Level 10mVpp to 10Vpp, adjustable
Radio Output Level 10mVpp to 10Vpp for mic level or -40 to +10dBm into 600Ωload, adjustable
Radio Output Impedance 600Ωfor balanced mode, 200Ωfor single ended mode
Frequency Response ±1.5dB, 300 to 3000Hz
Audio Distortion 2% THD maximum
DTMF Detection Bandwidth ±25 Hz around center of frequency
MON timer 10ms to 9999ms, adjustable
Dimensions 8 ½” (215.9mm) Wide, 9 3/4” (247.65mm) Deep, by 1 5/8” (41.275mm) High
Actual Weight 3.75lb (1.701kg)
Shipping Weight and Dimensions 5lbs (2.267kg) ~ 12”(304.8mm) x 10”(254mm) x3”(76.2mm)

17
Front Panel
Front Panel
Test and Adjustment Points
Test and adjustment points for Radio 1 and Radio 2 are provided on the front panel. Newer versions of the IP-223 provide
access to additional test and adjustment points on the case top, as shown in Figure 4.
NOTE: Radio 1 and radio 2 are also referred to as line 1 and line 2 in this manual.
FIGURE 3. IP-223 Front Panel
FIGURE 4. IP-223 Case Top Test Points

Overview
18
Handset Jack
An optional handset is available for the IP-223. When the optional handset is plugged into the handset jack, the ability to
monitor and talk on either line is available. The handset jack is located on the front of the unit, see Figure 3. When the handset
PTT (Push to Talk) switch is pressed, the selected radio connected to the IP-223 is keyed up on the existing frequency and the
handset microphone audio is transmitted.
Ethernet audio is also generated on the TX multicast and port for the selected line. This functionality can be used to test both
the Ethernet network and the analog connection.
IC Button
The IC button, when pressed, sends audio from the handset microphone back through the IP Network on the selected TX
multicast and port. It also sends audio to the transmit lines of the IP-223 without keying up the radio. This means no PTT relay
in local mode and no EIA (Electronic Industries Association) tones in tone mode.
NOTE: A handset is required to use the IC button.
LCD Display
The LCD display provides panel status information, such as the IP and Subnet Addresses, line status, and handset line
selection.
•TX F# (# is the selected function tone) indicates a PTT is active.
•RX F# (# is the selected function tone) indicates the RX radio is active.
•ID # displays when a Fleetsync or MDC (Mobile Daughter Card) ANI ID is decoded. This does not include
serial decoding.
•When connected to a serially controlled radio, iDEN, Sepura, Kenwood or Johnson displays.
•INTCOM displays when the front panel IC button is pressed.
•EnetIC displays when the console generated intercom is received.
•CTX F# displays when the console mode IP-223 decodes tones from a tone console in Console mode.
•CRX F# displays when the IP-223 transmits wire-line audio to a legacy tone console in Console mode.
•PTX F# displays when the IP-223 decodes tones from a legacy tone console attached in parallel in Tone mode.
•CPT F# displays when the IP-223 transmits to a line if the line-to-line crosspatch is enabled.
•Ring displays when there is an incoming phone call in Phone mode.
•Offhook displays when the line is in use during a phone call.
•LLM displays when no phone line is connected to the PIB or TDI in Phone mode.
•NO LINE ENABLED displays after power-up if neither line is enabled.
•Scan List.... displays during power up while the IP-223 is communicating with serial controlled radios that
support the Scan List feature.

19
Front Panel
To toggle the LCD display, do the following:
1. Press and hold the line button and then momentarily press the IC button.
Three (3) different displays are available with each press of the IC button:
•While pressing the line button, press the IC button once.
The IP Address and Mask Address of the unit displays.
•Continue to hold the line button, then press the IC button a second time.
The TX alignment tones are turned ON.
•Continue to hold the line button, then press the IC button a third time.
The RX VU meter displays.
2. Press the IC button a fourth time to clear the display.
The LCD display returns to the normal.
3. Release the line button.
Line Button
The Line button is used to select which radio, or line, the handset audio is routed to and which line is being monitored. The
handset line selection is displayed as an asterisk (*) in the right most column of the LCD display. An asterisk (*) on the top
line of the display indicates a connection to line 1, and an asterisk (*) on the bottom line of the display indicates a connection
to line 2.
TX LED
The TX LED provides a visual indication the IP-223 is generating IP packets. When the LED is illuminated, packets are being
transmitted to the network.
LNK LED
The LNK LED provides a visual indication of the Ethernet connection. When the LED is illuminated, a valid network
connection is established.

Overview
20
Back Panel
10/100 Ethernet Connector
The 10/100 Ethernet connector provides the LAN or WAN connection for the IP-223.
FIGURE 5. IP-223 Back Panel
10/100
Ethernet
connector
Serial
connector
(DB9) Radio 1 and radio 2
connectors (DB25) Power
connection
