tell Adapter2 User guide

Adapter2
Adapter2 PRO
INSTALLATION AND APPLICATION MANUAL
for device version v7.03
Document version 7.0210.03.2022
Product models:
•Adapter2 2G.IN4.R1
•Adapter2 3G.IN4.R1
•Adapter2 3GA.IN4.R1
•Adapter2 4G.IN4.R1
•Adapter2 4GA.IN4.R1
•Adapter2 WiFi.IN4.R1
•Adapter2 PRO 2G.IN4.R1
•Adapter2 PRO 3G.IN4.R1
•Adapter2 PRO 3GA.IN4.R1
•Adapter2 PRO 4G.IN4.R1
•Adapter2 PRO 4GA.IN4.R1
•Adapter2 PRO WiFi.IN4.R1

2
Table of contents
1Adapter2 operation.................................................................................................................... 4
1.1 Key functions of the Adapter2 ............................................................................................ 4
1.2 Differences between the Adapter2 and the Adapter2 PRO models.................................... 4
1.3 Differences between the 2G, 3G, 3GA, 4G, 4GA and WiFi models.................................... 5
1.4 Under Voltage Lock Out (UVLO) function .......................................................................... 5
1.5 Remote monitoring application overview............................................................................ 5
1.5.1 General information about the notification process....................................................... 6
2Connecting the terminals and putting into operation ................................................................. 7
2.1 Connections and wiring...................................................................................................... 7
2.2 Input wiring......................................................................................................................... 8
2.3 Output wiring...................................................................................................................... 8
2.4 SIM card holder.................................................................................................................. 8
2.5 Connecting the antenna..................................................................................................... 9
2.6 Installation.......................................................................................................................... 9
2.7 Putting into operation ......................................................................................................... 9
2.8 Status LED signals........................................................................................................... 10
2.9 Technical specification..................................................................................................... 10
3Configuring the Adapter2 ........................................................................................................ 11
3.1 The user interface and configuration options of the software........................................... 11
3.2 Methods for connecting to the device............................................................................... 12
3.2.1 TELL servers and receivers........................................................................................ 12
3.2.2 Configuring directly via USB ....................................................................................... 13
3.2.3 Remote connecting to devices via cloud service......................................................... 14
3.2.4 Remote connecting to devices via peer-to-peer connection ....................................... 17
3.2.5 Remote connecting to devices which are using the TEX protocol .............................. 19
3.2.6 Remote connecting to devices which are using the TELLMon protocol...................... 20
4Adapter2 programming software usage and feature descriptions ........................................... 22
4.1 Connection menu............................................................................................................. 22
4.1.1 Viewing the settings options and configuring offline.................................................... 22
4.1.2 Connection type.......................................................................................................... 23
4.1.3 Device register............................................................................................................ 25
4.1.4 Server register ............................................................................................................ 28
4.2 Device settings menu....................................................................................................... 31
4.2.1 General device settings .............................................................................................. 32
4.2.2 Mobile devices (Adapter2 PRO only).......................................................................... 39
4.2.3 Reporting channels..................................................................................................... 41
4.2.4 Notification templates.................................................................................................. 45
4.2.5 Inputs.......................................................................................................................... 47
4.2.6 Input events ................................................................................................................ 48
4.2.7 Service events ............................................................................................................ 53
4.2.8 Custom events............................................................................................................ 59

3
4.2.9 IP cameras (Adapter2 PRO only)................................................................................ 64
4.2.10 Voice messages.......................................................................................................... 66
4.2.11 Admin access.............................................................................................................. 68
4.2.11 Advanced settings........................................................................................................ 69
4.3 Alarm system events menu.............................................................................................. 72
4.3.1 Alarm system events................................................................................................... 72
4.3.2 Custom event code names......................................................................................... 77
4.3.3 Custom user names.................................................................................................... 80
4.3.4 Custom partition names.............................................................................................. 83
4.3.5 Custom zone names................................................................................................... 86
4.4 Device status menu.......................................................................................................... 89
4.4.1 Status monitoring........................................................................................................ 89
4.4.2 Event monitoring......................................................................................................... 91
4.4.3 System event logs....................................................................................................... 93
4.5 Software settings menu.................................................................................................... 94
4.5.1 Settings....................................................................................................................... 94
4.5.2 About .......................................................................................................................... 95
5Transparent serial port ............................................................................................................ 96
5.1 Remote programming of alarm control panels ................................................................. 96
5.1.1 Paradox alarm systems .............................................................................................. 97
5.1.2 DSC alarm systems.................................................................................................. 101
5.1.3 Premier and Premier Elite alarm systems................................................................. 104
5.1.4 Bentel alarm systems................................................................................................ 107
5.1.5 Inim alarm systems................................................................................................... 110
6Arming and disarming the alarm control panel through the mobile application ..................... 114
7Updating the firmware ........................................................................................................... 115
7.1 Updating via USB........................................................................................................... 115
7.2 Updating remotely over the internet ............................................................................... 115
8Restoring the factory default settings.................................................................................... 116
9Contents of the package ....................................................................................................... 116
10 About the manufacturer......................................................................................................... 116

4
1 Adapter2 operation
1.1 Key functions of the Adapter2
The primary function of the Adapter2 is forwarding reports of alarm systems to remote monitoring
station over the Internet.
Main functions:
•Sends SMS, e-mail* and Push notification* with configurable message for each event.
•Reports events by SMS, e-mail* and Push notification*, by voice call with voice messages
uploadable as audio files, over IP to remote monitoring stations using different
communication protocols and by voice call using DTMF-based Contact ID protocol.
•Reporting options:
➢SMS with configurable message up to 4 phone numbers.
➢E-mail with configurable message up to 4 addresses*.
➢Push notification with configurable message up to 4 users (mobile applications)*.
➢Voice call up to 4 phone numbers with up to 15 uploadable messages of 10 seconds
each.
➢Reporting to CMS (Central monitoring station) over IP up to 4 IP addresses using SIA
IP DC-09, TELLMon and TEX protocol.
➢Reporting to CMS by voice call using DTMF-based (DC-05) Contact ID protocol.
•Up to 10 notification templates can be created and assigned to events to configure the
priorities of reporting channels used for reporting to CMS.
•Configurable Contact ID event codes for each input and service event, including partition
and zone options.
•Output control can be customized separately for each event using different operation modes,
which can also be used to arm or disarm the connected alarm control panel remotely, through
the mobile application.
•Available custom events: input events, service, and error events (new and restore as well)
•IP camera support: forwards the links of up to 4 IP cameras by e-mail and Push notification
along with the alarm messages.
* Available in the PRO model only
** SMS and call-based functions are not available in the WiFi product model.
1.2 Differences between the Adapter2 and the Adapter2 PRO models
There are differences in function between the Adapter2 and the Adapter2 PRO product models.
The Adapter2 PRO includes the following extra functions:
•E-mail notification
•Push notification
•TELL Control Center multiplatform mobile application (iOS and Android)
•IP camera support

5
1.3 Differences between the 2G, 3G, 3GA, 4G, 4GA and WiFi models
The only difference between the 2G, 3G and 4G models is the type of the modem used.
The 3G (UMTS) and the 4G (LTE) communication makes possible higher speed, thereby
increasing the speed of reporting. The 2G, 3G and the 4G models can be used in Europe, while
the 3GA model is equipped with a pentaband UMTS/HSPA modem that can be used worldwide.
The 4GA model is equipped with a multiband LTE modem which can be used in North America.
There is no difference between the mentioned models regarding the available functions or
configuration. For the 2G model, calls made through the GSM network will delay all other
communication, since 2G modems are unable to use multiple communication channels
simultaneously.
The WiFi model can only be used with a WiFi network. SMS and call-based functions are not
available in this model since it does not have a GSM modem. In turn, this model does not require
a SIM card.
1.4 Under Voltage Lock Out (UVLO) function
The Adapter2 is provided with built-in automatic power disconnection (Under Voltage
Lock Out) function. The device will turn off automatically when the supply voltage drops
below critical level, and turns back on when the voltage restores to operational level.
1.5 Remote monitoring application overview
The Adapter2 models equipped with a modem communicate with the TELLMon or SIA DC-09
receivers and MVP.next or TEX-MVP servers through the GSM service provider’s mobile
switching center using the GPRS/UMTS/LTE network, and then through the Internet. After
processing and conversion, the server forwards the received data packages through serial port
towards the monitoring PC that runs the alarm monitoring software. Alternative reporting channels:
voice call and SMS.
The WiFi product model connects to the Internet via a local WiFi router and does not support
alternative reporting via voice call or SMS.

6
1.5.1 General information about the notification process
The device sends notifications based on own events available in the device, and based on the
configuration of the connected alarm system’s events.
There are 4 event categories available in the device: input events, service events, custom events,
and alarm system events.
•Input events: Input events are generated by triggering the contact inputs on the device.
•Service events: Service events are generated automatically by the device, such as error
events, own periodic test report, or events on reaching different configured limits.
•Custom events: Custom events are generated by freely configurable commands sent to the
device in a text message. Custom events and commands can be configured optionally in the
device.
•Alarm system events: Alarm system events are Contact ID messages received from the
connected alarm system via the device’s simulated phone line input.
When an event is generated, the device starts the notifications and controls configured for that
event. The order of notifications corresponds to the order in which the events occurred.
➢Reporting to a remote monitoring station
You can assign one from the notification templates configured in advance to each event.
In a notification template you can configure, which of the configured monitoring receivers should
be notified, and with what priority. Backup reporting by SMS can also be set for the case when
reporting fails to all the selected receivers. Reporting a given event will thereby be performed
according to the notification template associated with it. Regarding events received from the
connected alarm system, it is possible to filter events by event code, partition, and zone number.
Thereby, you can add a filter for a group of events or even a specific event, of which reporting can
be configured likewise, by assigning a notification template customized as needed. Furthermore,
depending on the device settings, as a backup option, the alarm system can also send reports via
DTMF based voice call to a landline receiver, by dialing a specific phone number.
➢Notification sending to users
Regardless of reporting to remote monitoring station, you can configure notifications for users
by call, SMS, Push message or e-mail (depending on the product model).
Reporting to remote monitoring station has priority against notification of users. The device sends
the events simultaneously to the configured IP addresses. It sends the ACK signal towards the
alarm control panel only when it receives the ACK from at least one of the configured receivers
(IP addresses). Regardless to this, event sending continues towards the other receivers. If the
device does not receive an ACK signal from any of the configured receivers, it tries to report the
event for up to 10 minutes. If reporting to the configured IP addresses fails for the mentioned
10 minutes, the device stops reporting the event and will no longer send notification on the given
event, but the event will be shown in the event logs.

7
2 Connecting the terminals and putting into operation
Attention! Do NOT connect the metallic parts of the GSM antenna connector or the
terminals of the device directly or indirectly to the protective ground, because this may
damage the device!
2.1 Connections and wiring
System terminal inputs and outputs:
V+ Supply voltage 12…24V DC (min. 500mA)
V- Supply voltage negative
LINE Simulated phone line output (connect to alarm system phone line input terminals)
IN1 Dry contact input 1
IN2 Dry contact input 2
IN3 Dry contact input 3
IN4 Dry contact input 4
COM Common negative for the contact inputs and the output (potential equivalent with V-)
OUT Relay output (switches the negative, max. 1A)
Attention!
Although the COM and V- terminals are equivalent, due to the design of internal circuit
protections, the COM terminal shall not be used as negative input for powering the device,
because this may damage the device! The COM terminal should only be used for
connecting the contact inputs and the relay output!
We would not advise powering the device directly from the power output of the alarm
control panel (AUX), as we can’t guarantee that the given output is able to fully operate the
device. Insufficient powering may lead to communication errors and frequent device
restarting, making it impossible for the device to operate normally as expected. To avoid
this, we suggest that you use a separate power supply for the device.

8
An uninterruptible power supply with adequate power is essential for the product to
operate properly. The power supply must provide a power that can serve the minimum
operating voltage and the maximum power consumption of the device. The power feed
must be continuous and transient-free even when there is a mains power failure, and the
power feed switches to backup battery operation.
An ideal solution for the above purposes is the power supply designed and manufactured
by TELL, which we expressly recommend using for our communicators.
•Recommended TELL power supply for use with an alarm control panel:
TT40VA-16VAC/24VDC, which provides power feed (16V AC) also for the alarm control
panel at the same time.
•Recommended TELL power supply for other use: TT25VA-12V5.
2.2 Input wiring
For the inputs, the normally closed or normally open dry contact should be connected between
the given input (IN1…IN4) and the negative of the power input (V-) or the COM terminal.
If a normally open dry contact is used to activate the input, choose the NO (normally open) option
in the given input’s settings. In this case, the input will become activated when the open contact
between the given input (IN1…IN4) and the V- terminal (or the COM terminal) becomes closed.
If a normally closed dry contact is used to activate the input, choose the NC (normally closed)
option in the given input’s settings. In this case, the input will become activated when the closed
contact between the given input (IN1…IN4) and the V- terminal (or the COM terminal) becomes
open.
2.3 Output wiring
The output provides normally open (N.O.) dry (potential free) relay contact by default and closed
contact upon control.
2.4 SIM card holder
The device requires a Mini (2FF) size SIM card.
The SIM card holder can be accessed by removing the cover of the aperture found on the device
enclosure.
Note: the WiFi device model does not require a SIM card, therefore it has no SIM card holder.
The cover can be removed by pressing it with your fingernail towards the LED at the end where
the gap is and then pulling it outwards. Insert the SIM card in the holder. The services to be
activated on the SIM card installed into the Adapter2 device should be chosen according to which
services of the device you wish to use. Basically, for communication with receivers and servers it
requires a SIM card with mobile Internet access that may use either public or private APN. The
functions that use SMS sending need SMS service and the ones that use calls require GSM voice
call service.

9
•Installing the SIM card:
▪1. Pull the metal security lock of the SIM holder towards the LED until
you hear a click.
▪2. Reach under the metallic security lock with your fingernail and pull
to open the holder.
▪3. Slide the SIM card into the opened part with the contacts facing
down, as shown in the figure.
▪Fold back the opened part together with the SIM card.
▪Secure the SIM card by pressing down carefully the metallic security
lock and pulling it towards the side of the enclosure until you hear
a click.
2.5 Connecting the antenna
Connect the GSM antenna to the FME-M socket. The device comes with an antenna that provides
good transmission under normal reception circumstances. In case of experiencing signal strength
problems or/and wave interference (fading), use a directed antenna, or find a more advantageous
mounting place for the antenna. In case of installing the unit into a metal box, the antenna should
be mounted outside the box, in a place where the measured GSM signal is the highest available.
2.6 Installation
Please check the environment before installing:
•Verify the GSM signal with your mobile phone. It may happen that the signal strength is not
sufficient in the place where you planned to mount the device. If this is the case, you can
reconsider the place of installation before mounting the device.
•Do not mount the unit in places where it may be affected by strong electromagnetic
disturbances (e.g., close to electric motors, high voltage, etc.).
•Do not mount the unit in wet places, or places with a high degree of humidity.
2.7 Putting into operation
•Disable the voicemail service and SMS notification about missed calls on the
SIM card installed in the device.
•The device can handle the SIM card’s PIN code. If you want to use the
PIN code management, configure the SIM card’s PIN code in the programming
software in the “General” device settings menu. Otherwise disable PIN code request
on the SIM card.
•Enable caller identification service on the SIM card at the GSM service provider (this
service might not be enabled by default, please check). To enable this service, install the
SIM card into a mobile phone and call the customer service of the card’s GSM service
provider and enable the service in the menu, or visit one of the service provider’s personal
customer services and ask to enable this service on the SIM card.
•Check the SIM card to be installed correctly into the device.
•Check the GSM antenna to be connected correctly to the device.
•Check the wires to be connected as instructed in the wiring diagram.
•You can power up the device (12-24V DC). Make sure that the power source is sufficient for
the operation of the Adapter2 device. The nominal current consumption of the Adapter2
device is 120mA, however it may increase up to 500mA during communication and output
control. If the used power source is not sufficient for the operation of the device, this may
cause malfunctions.

10
2.8 Status LED signals
Slowly flashing green
Normal operation,
connected to the GSM or WiFi network
Flashing red
The GSM or WiFi service is unavailable,
or system startup/restart in progress
Permanent red
SIM card error
(only for models equipped with a modem)
2.9 Technical specification
Supply voltage range: 12…24V DC
Nominal current consumption: 120mA
Highest current consumption: 500mA @ 12V DC, 250mA @ 24V DC
Operating temperature: -20ºC - +70ºC
Transmission frequency:
2G model: 850/900/1800/1900 MHz
3G model: 900/2100 MHz @UMTS, 900/1800 MHz @GSM
3GA model: 800/850/900/1900/2100 MHz @UMTS
850/900/1800/1900 MHz @GSM
4G model: 900/1800 MHz@GSM/EDGE, B1/B8@WCDMA,
B1/B3/B7/B8/B20/B28A@LTE
4GA model: B2/B4/B5@WCDMA, B2/B4/B5/B12/B13@LTE
WiFi model: 2.4 GHz, 802.11 b/g/n
Highest load supported on output: 1A @ 24VDC
Modem type:
2G model: Quectel M95
3G model: Quectel UG95
3GA model: Quectel UG96
4G model: Quectel EG91-E
4GA model: Quectel EG91-NA
Dimensions: 84 x 72 x 32mm
Net weight: 200g
Gross weight (packed): 300g

11
3 Configuring the Adapter2
The Adapter2 can be configured the following ways:
•By computer via USB, using the programming software.
•By computer over the Internet, using the programming software.
The Adapter2 programming software is compatible with the following operating systems:
•Windows 10 (32/64 bit)
Earlier Windows operating systems are not supported by the software.
Installing the programming software: open the software setup application and follow the
instructions of the installation wizard to complete the installation. The latest version of the
programming software is available on the manufacturer’s website (http://www.tell.hu).
The Adapter2 programming software can be used to configure all Adapter2 device models.
3.1 The user interface and configuration options of the software
The user interface language can be selected during installation.
The user interface appearance can be changed using the “Theme” dropdown-menu found in the
“Software settings” / “Settings” menu, where you can choose from various appearance themes.
The software saves changes related to appearance upon closing and applies the saved settings
when reopened.
In the menus that contain a spreadsheet, an advanced filter is available in each column by clicking
on the filter icon , which appears on the right-hand edge of each column header by moving
the mouse pointer on the given header. You can use the filters to filter data in any column.
You can toggle between ascending and descending data sorting by clicking on a column’s header.
You can toggle between show/hide columns or change the order of the columns in the
spreadsheet by drag-and-drop, after clicking on the button marked with a star in the top left
corner of the spreadsheet. You can also change the order of the columns by moving the header
of the columns.

12
3.2 Methods for connecting to the device
For connecting to the device using the programming software, the options listed below are
available. For the “TEX protocol” and the “TELLMon protocol” connection options, the
communication protocol used by the device depends on how this has been configured in the
device by the installer, in accordance with the type of the server/receiver that it is connected to.
USB: connecting directly using a USB-A to USB-B cable.
TEX protocol: connecting remotely over the Internet to a device, which uses the TEX protocol.
Choose this option if the device is connected to any of the following servers/receivers via the TEX
protocol:
- MVP.next server;
- TELLMon receiver;
- TEX-MVP server;
- TEX BASE or TEX PRO server.
TELLMon protocol: connecting remotely over the Internet to a device, which uses the TELLMon
protocol. Choose this option if the device is connected to any of the following servers/receivers via
the TELLMon protocol:
- MVP.next server;
- TELLMon receiver.
Cloud: connecting remotely over the Internet, via the cloud server operated by the manufacturer.
You can use this option if the device is connected to the cloud.
Peer-to-peer: direct remote IP connection over the Internet. This option can be used if the
computer running the programming software, and the SIM card installed in the Adapter2 device
are in the same VPN or a private APN.
3.2.1 TELL servers and receivers
•TELLMon: standalone TELL remote monitoring receiver.
•MVP.next: cloud-based TELL remote monitoring server system.
•Cloud: cloud-based TELL server used for the mobile applications and remote access of
TELL devices.
•TEX-MVP: cloud-based TELL remote monitoring server system (discontinued).
•TEX BASE and TEX PRO: standalone TELL remote monitoring server (discontinued).

13
3.2.2 Configuring directly via USB
To start programming the device, follow the instructions below:
•Open the Adapter2 programming software.
•Select the USB option in the “Connection type” menu, power up the device and connect it
to the computer using a USB-A to USB-B cable.
•Enter the device password.
oSuper administrator permission: full access to all settings. (Default password: 1234).
oAdministrator permission: can only access settings enabled by the superadmin.
You can configure the admin password separately (see chapter “Connection type”).
oConnecting without a password: only restoring the factory default settings is available,
if the device has not been locked.
•Click on the “Connect” button.
•If the wrong password is entered, the software connects to the device, but the same functions
will be available as when connecting without a password. To try a different password, close
the connection using the “Disconnect” button, enter the new password, and then
connect again using the “Connect” button.
•The software connects to the device using standard HID driver, which is integrated in
Windows operating systems, thus there is no need to install special USB drivers. When the
device is connected to USB for the very first time, the Windows operating system installs the
drivers automatically.
•The connection status is indicated by the USB status icon placed in the upper left corner of
the program window:
USB disconnected (green)
connected via USB (grey)
•After connecting using the valid password, you can configure the device, change settings,
download event logs and monitor system status.
•To close the connection, click on “Disconnect” button.

14
3.2.3 Remote connecting to devices via cloud service
This connection type can be used if the Adapter2 device is connected to the cloud. For this,
the APN settings should be configured in the “General” settings menu, and a SIM card with
available mobile Internet service should be installed in the device, which may use either
a public or a private APN, but in the latter case, you must arrange with the mobile service
provider to open the given private APN for accessing the cloud server IP address at
54.75.242.103, port: 2020.
If the “Cloud usage” option is enabled in the “General” settings menu, the device will be
continuously online, so it can be accessed anytime over the cloud. If you don’t want to enable
permanent cloud usage due to the data use that it involves, it is possible to command the device
by SMS to connect temporarily to the cloud, about which you can read more in the below.
With this connection type, connection between the device and the Adapter2 programming
software will be established through the cloud server operated by the manufacturer.
The “System logs” option of the programming software cannot be used in case of remote
connection over the Internet.
Device name: from this drop-down menu, you can select the device you want to connect to, if you
have already added the contact details of the given device in the “Device register” menu.
Cloud: the name of the server where the device is connected. The server named “Cloud
(Adapter2, Pager4, DUALCOM SIA IP)” is the default. In case of using a proxy, for connecting
remotely to the device, it is possible to configure a server IP address and port number different
from the default server, by adding a new server in the “Server register” menu. If there are further
servers recorded, you can choose the appropriate server for the given device in this drop-down
menu from the recorded servers.
Device ID: the device identifier of the Adapter2 device to which you want to connect to.
The device identifier is unique, burned-in during production, and thereby it cannot be changed.
The device ID format is: FF:FF:FF:FF:FF:FF (6x2 hexadecimal characters).
You can read the device ID of the given device from the “Device ID” section in the “Status
monitoring” menu, via USB connection. The device will also send its device ID in the reply to your
request for connecting to the cloud, sent by SMS to the device, about which you can read more
below.
Device password: the security password of the device (default superadmin password: 1234).
Save the password: in case that you have provided the data necessary for connecting to the
device here in the “Connection parameters” section, and you enable this option, the program will
also save the entered password in the device register, when you initiate a connection to the device.

15
Connecting to the device through the cloud:
•Select the “Cloud” option in the “Connection type” menu.
•If you have already registered the device in the "Device register" menu, select the device
you want to connect to from the "Device Name" drop-down menu. Otherwise, you can
either enter the data needed for connecting, in the corresponding fields, which will be
recorded automatically in the device register using the entered device ID as the device
name, when you start connecting to the device. For this, select the server from the “Cloud”
drop-down menu, enter the identifier of the device in the “Device ID” field, and the device
password in the “Device password” field.
Entering the device password.
oSuper administrator permission: full access to all settings. (Default password: 1234).
oAdministrator permission: can only access settings enabled by the superadmin.
You can configure the admin password separately (see chapter “Connection type”).
oConnecting remotely without a password is not possible.
•If cloud usage is enabled in the settings of the given device, the device keeps continuous
connection with the cloud server. In this case skip the SMS sending process mentioned
below. Cloud usage can be enabled in the “General” settings menu. If cloud usage is
disabled, the device will not keep continuous connection with the cloud, it will only connect
upon request. Therefore, if this is the case, before trying to connect remotely to the device,
the request for connecting to the server should be sent by SMS to the phone number of the
SIM card installed into the device. The device accepts the request for connecting to the
cloud server from any phone number if the valid device password is specified in the
message. For this, the device password should be added in the message using the “PWD”
parameter, as specified below. Commands sent with a missing device password or a wrong
password, will be ignored by the device and it will not send any reply to these numbers.
The request command for connecting to the server is: CONNECT,PWD=device password#
PWD: the device password can be specified using this parameter. The superadmin and admin
passwords are both accepted (default superadmin password: 1234).
Example on the usage of the command mentioned above: CONNECT,PWD=1234#
Send the mentioned request command for connecting to the cloud by SMS to the phone number
of the SIM card installed in the device and wait for the device’s reply. As soon as the device
successfully connects to the cloud, it will send the following reply:
Connected to (IP address:port number)
ID=(device identifier)
If cloud usage is disabled in the device settings, the device remains connected to the cloud
for 10 minutes only and thereafter in case of inactivity it disconnects automatically. Therefore, you
have 10 minutes to connect to the device after it sends the reply message.
If you receive no message from the device within 1 or 2 minutes, please make sure that the
settings are correct and that the circumstances of sending the request for connecting satisfy the
conditions mentioned above.

16
Possible error messages:
Missing APN
The APN is not configured.
Network connection error
The device is unable to connect to the Internet due to an
error, faulty settings, or missing Internet service.
If the APN settings are not configured in the device, or if they are wrong, you can configure this
using the following SMS commands. It is also possible to configure the cloud settings, but normally
the factory default values are configured for this.
SMS command
Specification
APN=APN,PWD=device password#
Configuring the APN
APN=APN,username,password,PWD=device password#
Configuring the APN along
with the username and
password belonging to it
CONNECT=server address:port nr,PWD=device password#
Configuring the cloud server
address and port number,
then connecting to the server
Example on the usage of the commands mentioned above:
APN=internet,PWD=1234#
APN=net,guest,guest,PWD=1234#
CONNECT=54.75.242.103:2020,PWD=1234#
Wait for the device’s reply. After it has confirmed that it has connected to the cloud, continue with
the next step.
•Click on the “Connect” button and wait for the connection to establish. The process
of connecting may take a few seconds.
•The connection status is indicated by the status icon in the top left corner of the program
window:
disconnected (green)
connected (gray)
•After connecting using the valid password, you can configure the device, change settings,
download event logs, and monitor system status.
•To disconnect from the device, click on the “Disconnect” button.

17
3.2.4 Remote connecting to devices via peer-to-peer connection
This connection type can only be used ina private APN, or through a virtual private network
(VPN) connected to the given private APN. In case of using a private APN, sending and
receiving data between the SIM cards in the given APN should be enabled. The SIM card
installed in the Adapter2 device you wish to connect remotely to, should have a static IP
address and should be part of the given private APN, respectively VPN, just like the
computer from which you wish to connect to the device. If the computer is not part of the
given private APN through VPN, then you can connect to the device trough a mobile
Internet stick connected to the computer, in which you must use a SIM card that is part of
the given private APN. Also, the APN settings should be configured in the device you wish
to connect to. These settings are available in the “General” settings menu.
*For connecting directly to the WiFi product model from outside the local network,
configuring port forwarding is required in your router, and the static WAN IP address of the
router should be used in the software. The device uses port 6789 and UDP protocol.
Otherwise, you can only access the device in the local network using its local IP address.
With this connection type, a direct (peer-to-peer) connection will be established between the
device and the Adapter2 programming software.
The “System logs” option of the programming software cannot be used in case of remote
connection over the Internet.
Device name: from this drop-down menu, you can select the device you want to connect to, if you
have already added the contact details of the given device in the “Device register” menu.
Network: the name of the network used for connecting to the device. The program contains
a built-in network name “Peer-to-peer”, which can be used as the default. If needed, you can add
further network names in the “Server register” menu, which you can use to organize your devices
(e.g., you can configure a different network name for the local and the remote connections of your
WiFi devices).
Device IP address: the static IP address of the device you want to connect to. You can read the
device IP address of the given device from the “IP address” section in the “Status monitoring”
menu, via USB connection.
Device password: the security password of the device (default superadmin password: 1234).
Save the password: in case that you have provided the data necessary for connecting to the
device here in the “Connection parameters” section, and you enable this option, the program will
also save the entered password in the device register, when you initiate a connection to the device.

18
Connecting to the device through peer-to-peer connection:
•Select the “Peer-to-peer” option in the “Connection type” menu.
•If you have already registered the device in the "Device register" menu, select the device
you want to connect to from the "Device Name" drop-down menu. Otherwise, you can
either enter the data needed for connecting, in the corresponding fields, which will be
recorded automatically in the device register using the entered device ID as the device
name, when you start connecting to the device. For this, select the network from the
“Network” drop-down menu, enter the IP address of the device in the “Device IP address”
field, and the device password in the “Device password” field. *For the WiFi product
model, you must use the WAN IP address of the router to which the device is connected, if
you want to connect to the device from outside the local network.
Entering the device password.
oSuper administrator permission: full access to all settings. (Default password: 1234).
oAdministrator permission: can only access settings enabled by the superadmin.
You can configure the admin password separately (see chapter “Connection type”).
oConnecting remotely without a password is not possible.
•Click on the “Connect” button.
•The connection status is indicated by the status icon in the top left corner of the program
window:
disconnected (green)
connected (gray)
•After connecting using the valid password, you can configure the device, change settings,
download event logs, and monitor system status.
•To disconnect from the device, click on the “Disconnect” button.

19
3.2.5 Remote connecting to devices which are using the TEX protocol
This connection type can be used if the Adapter2 device you want to access remotely has
been configured to communicate with the given server using the TEX protocol. This is an
early custom TELL protocol which is supported by the Adapter2 device to be able to
communicate with the older TEX-MVP and TEX BASE/PRO servers. Therefore, this
connection type should be used basically to connect to the device via these servers.
However, for compatibility with the old TEX communicators, the TELLMon receiver and the
MVP.next server also support the TEX protocol. Therefore, still this connection type should
be used if the device is connected to a TELLMon receiver or an MVP.next server, and it has
been configured to communicate with the given server or receiver using the TEX protocol
for some reason.
Further details on the remote access of devices via the MVP.next server you can find in
chapter “Server register / Remote access of devices via the MVP.next server”.
With this connection type, connection between the device and the Adapter2 programming
software can be established through the server/receiver on which the device is online.
The “System logs” option of the programming software cannot be used in case of a remote
connection over the Internet.
Device name: from this drop-down menu, you can select the device you want to connect to, if you
have already added the contact details of the given device in the “Device register” menu.
Server/Receiver: the name of the server or receiver where the device is connected. The server
or receiver contact details should be recorded in advance in the “Server register” menu.
TEX group ID: the CMS identifier of the Adapter2 to which you want to connect to. The TEX
group ID can be configured in the device settings. Its format is: FFF (3 hexadecimal characters).
TEX device ID: the TEX identifier of the Adapter2 to which you want to connect to. The TEX
identifier can be configured in the device settings. Its format is: FFF (3 hexadecimal characters).
Device password: the security password of the device (default superadmin password: 1234).
Save the password: in case that you have provided the data necessary for connecting to the
device here in the “Connection parameters” section, and you enable this option, the program will
also save the entered password in the device register, when you initiate a connection to the device.
Connecting to the device through a server/receiver which uses the TEX protocol:
•Select the “TEX protocol” option in the “Connection type” menu.
•If you have already registered the device in the "Device register" menu, select the device
you want to connect to from the "Device Name" drop-down menu. Otherwise, you can
either enter the data needed for connecting, in the corresponding fields, which will be
recorded automatically in the device register using the entered device ID as the device
name, when you start connecting to the device. For this, select the server from the
“Server/Receiver” drop-down menu, where the device is connected, enter the
CMS identifier in the “TEX group ID” field, the TEX identifier of the device in the
“TEX device ID” field, and the device password in the “Device password” field. The server
or receiver contact details should be recorded in advance in the “Server register” menu.

20
Entering the device password.
oSuper administrator permission: full access to all settings. (Default password: 1234).
oAdministrator permission: can only access settings enabled by the superadmin.
You can configure the admin password separately (see chapter “Connection type”).
oConnecting remotely without a password is not possible.
•Click the “Connect” button.
•The connection status is indicated by the status icon in the top left corner of the program
window:
disconnected (green)
connected (grey)
•After connecting using the valid password, you can configure the device, change settings,
download event logs and monitor system status.
•To disconnect from the device, click on the “Disconnect” button.
3.2.6 Remote connecting to devices which are using the TELLMon protocol
This connection type can be used if the Adapter2 device you want to access remotely is
connected to a TELLMon receiver or an MVP.next server, and it has been configured to
communicate with the given server or receiver using the TELLMon protocol.
Further details on the remote access of devices via the MVP.next server you can find in
chapter “Server register / Remote access of devices via the MVP.next server”.
With this connection type, connection between the device and the Adapter2 programming
software can be established through the receiver on which the device is online.
The “System logs” option of the programming software cannot be used in case of remote
connection over the Internet.
Device name: from this drop-down menu, you can select the device you want to connect to, if you
have already added the contact details of the given device in the “Device register” menu.
Server/Receiver: the name of the server or receiver where the device is connected. The server
or receiver contact details should be recorded in advance in the “Server register” menu.
Device ID: the device identifier of the Adapter2 device to which you want to connect to.
The device identifier is unique, burned-in during production, and thereby it cannot be changed.
The device ID format is: FF:FF:FF:FF:FF:FF (6x2 hexadecimal characters).
You can read the device ID of the given device from the “Device ID” section in the “Status
monitoring” menu, via USB connection, or from the user interface of the server or receiver.
Device password: the security password of the device (default superadmin password: 1234).
Save the password: in case that you have provided the data necessary for connecting to the
device here in the “Connection parameters” section, and you enable this option, the program will
also save the entered password in the device register, when you initiate a connection to the device.
Other manuals for Adapter2
3
This manual suits for next models
13
Table of contents
Other tell Adapter manuals
