Introduction
1x10 4K HDMI Splitter
This 1x10 HDMI Splitter uses a single HDMI source, accessing to ten HDMI sinks. It allows one
HDMI device to be split easily to ten HDMI compatible monitors or projectors. In addition, it can be
placed at the end of a long HDMI cable to regenerate the HDMI signal. The resolution of this HDMI
splitter can be up to 3840x2160/60Hz.
This splitter supports EDID management function, comes with ten kinds of EDID mode, the users
can choose according to their own needs. In addition, this product is also built-in IR-TX extension
function, can work with our HDMI repeater which has IR-RX receiving the IR command to control
the source.

2021
Phone: [phone] Fax: [phone]
[email protected] www.telran.co.il
Features
◊Support HDMI 2.0 ,HDCP2.2
◊Support 3D video format
◊Supports HDR
◊Support CEC (only output1)
◊Support high resolution up to 3840X2160/60Hz
◊Support highest rate of 6G and TMDS clock can be up to 600 MHz
◊Support 8/10/12 bit deep color
◊Support AWG26 HDMI standard cable, input up to 5 meters ,output up to 10 meters.
◊Support one single HDMI source, accessing to multiple HDMI sinks, the source can be DVD
player, A/V receiver, set top box and etc.
◊Built-in IR extension function（via the IR-RX of HDMI repeater to control the HDMI sources)
◊Support serial port online upgrade
◊Support EDID management
◊12V/2A power adapter
Specifications
HDMI version …………………………………...…………………………………………. HDMI 2.0
HDCP version ……………………………...……….……………………………………. HDCP 2.2
HDMI resolution ………………………….….. ……….. ………..…………up to 3840x2160/60Hz
Support video format ……………………………..…………………………8/10/12bit Deep color
Support audio format………………..……. …….DTS-HD/Dolby-true HD/DTS/Dolby-AC3/DSD
Max bandwidth……………………………………………………………………………….600MHz
Max baud rate……………….…….………………….………………………………………..6Gbps
Input cable distance.……………………………..………….≤5m AWG26 HDMI standard cable
Output cable distance…………………………...…………≤10m AWG26 HDMI standard cable
Max working current……………..……………..……………………………………………....1.4 A
Power adapter format…………..….….input AC (50HZ, 60HZ) 100V-240V; output: DC12V/2A
Operating Temperature range….……………………..…………….……………(-15°C to +55°C)
Dimension (L x W x H)……………..............…………..………………………….375x89x22(mm)
Weight…….…..…………………….………………………………..…….……………………780g

2021
Phone: [phone] Fax: [phone]
[email protected] www.telran.co.il
U S E R M A N U A L
Product interface pictures
○1 Power adapter indicator
○2 12V Power Interface
○3 LED Output indicator
○4 HDMI output
○5 LED Input Indicator
○6 HDMI input
○7 DIP switch, using for EDID management
○8 IR TX Expansion Interface
○9 RS232 port
○10 Reset button
○11 Power switch

2021
Phone: [phone] Fax: [phone]
[email protected] www.telran.co.il
DIP EDID Switch Description:
DIP 1 234
x 000 copy edid
x 001 edid mix
x 010 4K_60Hz_2ch
x 011 4K_30Hz_2ch
x 100 4K_30Hz_5.1ch
x 101 1080P_3D_2ch
x 110 1080P_2D_2ch
x 111 1080P_2D_6ch
Working Mode Description:
There are two working modes for product, normal operating mode and upgrade mode, which is
decided by DIP EDID switch 1, 1 is upgrade mode，0 is normal operating mode.
IR extension description:
There is an IR TX Extension port, it can work with an optional HDMI repeater which works as IR-RX
and IR extended via HDMI cable.
Connection and Operation:
1: connect the HD source to the splitter input with one HDMI cable
2: connect the splitter output to the displays with 10 HDMI cables
3: connect 12V/2A power adapter to the splitter
4. Reset button: it’s a Reset key for system Reset.
Package include :
1. HDMI splitter x1pc
2. Power adapter x1pc
3. User manual x1pc
4. HDMI repeater (optional)
