TERK Technologies 143P005 User manual

Limited Warranty
TERK Technologies Corp. (TERK) warrants this product against defects in
materials or workmanship for one (1) year from the date of purchase.
During this warranty period, this product will be replaced without charge.
This warranty does not cover any damage due to acts of nature, commercial
use, accident, misuse, abuse or negligence. This warranty is only valid in
the USA. Replacement as provided under this warranty is the exclusive remedy
of the consumer. TERK shall not be liable for any incidental or consequential
damages for breach of any express or implied warranty on this product,
except to the extent that limitations of this sort are prohibited by applicable law.
THERE ARE NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURCHASE EXCEPT TO THE EXTENT THAT IMPLIED
WARRANTIES OF EITHER SORT ARE REQUIRED BY APPLICABLE LAW, AND
IN SUCH CASE, EACH WARRANTY IS LIMITED IN DURATION TO ONE YEAR.
Installing the Antenna::
Take your SIR-Mini (for SIRIUS Satellite Radio)
or XMicro (for XM Satellite Radio) and place the
antenna on the top of the bracket between the metal
tab and the cable pass-through hole (Fig.5).
Route the cable from the antenna through the top
of the bracket using the cable pass-through hole.
Determine the best route for the cable to reach the
satellite radio receiver.
Note: The cable has a very small diameter and should
be routed with care. Three feet of cable protector has
been included. Please install the cable protector around
the cable when going through areas that may cause
damage to the cable such as a door jamb or window. (Fig.4)
Once the cable has been routed to the satellite radio
receiver, plug the antenna connector into it.
Please refer to your satellite radio receiver owner’s
manual to activate your satellite radio service and
complete your receiver installation.
While holding the brackets together, install the lock
washers and the wing nuts (Fig.3). Before completely
tightening the wing nuts make sure that the ground
plane of the bracket where the antenna will be located
is parallel to the ground. Tighten both wing nuts so that
the bracket is secure.
14
2
1
2
3
3
Mounting the Bracket::
Select the top bar of either the driver’s side or
passenger side mirror mount (Fig.1). Place the
bracket on the front side of the bar (Fig.2).
Insert the two metal tabs of the small bracket
into the two slits near the top of the L-bracket
(Fig.2).
Lower the small bracket over the mirror bar until
the bolts in the L-bracket come through the
slots of the small bracket (Fig.2).
TRUCK MIRROR MOUNT BRACKET
Satellite Radio
SRB-MM
Works with Magnetic Mount Satellite Radio Antennas
Works with Magnetic Mount Satellite Radio Antennas
Shown below with the TERK XMicro & SIR-Mini
Fig.2
Fig.5
Fig.4
Fig.3
L-Bracket
Small Bracket
Fig.1
For more information, visit www.terk.com,
For technical support, call 1.800.942.TERK (8375)
Made in China
One year limited warranty
The SIRIUS name is a trademark of
SIRIUS Satellite Radio
The XM name is a trademark of
XM Satellite Radio
TERK and TERK Technologies are trademarks of
TERK Technologies Corp. Commack, NY
©2004 TERK Technologies Corp.
Installation instructions printed on the inside of this card::
143P005
XMicro SIR-Mini
Cable Protector
XMicro SIR-Mini
