TerryLifts Lifestyle 4.3 Owner's manual

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 2 of 14
Contents
Circuit Diagram Section .........................................................................................................3
Wiring Diagram 1 – Lifestyle Lift Wiring to P/Pack Circ. Board CE966 (XH00203F).......4
Wiring Diagram 2 – Top Cap Connections......................................................................5
Wiring Diagram 3 – Trailing Cable Connectors.............................................................5
Wiring Diagram4 – Sling Main Wiring ...........................................................................7
Fault Finding ..........................................................................................................................9
Phone Support Fault Finding..............................................................................................9
Terry Lifestyle Fault Finding – Emergency Circuit ............................................................10
(Takes out all LED’s in Car User Display) ........................................................................10
Terry Lifestyle Fault Finding – Down Hold........................................................................11
(No Yellow LED’s in User Display) ...................................................................................11
Terry Lifestyle Fault Finding – Up Hold ............................................................................12
(No Green LED’s in User Display)....................................................................................12

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 3 of 14
Circuit Diagram Section
•Wiring Diagram 1– Lifestyle Lift Wiring to P/Pack Circuit Board
CE966 (XH00203E)
The Power-pack wiring loom contains logic for Emergency Dumping of the carriage.
The Emergency Dump Relay is controlled directly from the Emergency Dump Enable
Switch in the carriage along with the Down call button. The mains intrusion for the
Pump and Motor Unit can be found here.
•Wiring Diagram 2– Sling Top Connector, Door, Light and Underpan Wiring
This Top Connector is used to interface all cables that pass through the carriage roof on
the way to their final destinations.
•Wiring Diagram 3- Trailing Cable Wiring
•Wiring Diagram 4 –Sling Wiring
.

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 4 of 14
Wiring Diagram 1 – Lifestyle Lift Wiring to P/Pack Circ. Board CE966 (XH00203F)

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 5 of 14
Wiring Diagram 2 – Top Cap Connections

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 6 of 14
Wiring Diagram 3 – Trailing Cable Connectors
CE2123 Sling PCB

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 7 of 14
Wiring Diagram4– Sling Main Wiring

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 8 of 14

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 9 of 14
Fault Finding
Before undertaking any detailed Fault Finding, confirm that the basic fault finding in the user
instructions has been undertaken.
Notes on fault finding
1) Before commencing fault finding using the flow chart:-
a) Check the status of all LED’s and fuses – and take any necessary action
b) Check door is closed
c) Ideally the lift should be in mid position i.e. off its limit switches
d) Note that LED’s on the sling board are only illuminated during the “Light on” period
(initiated by up/down/door signal) and when the user LED panel is disconnected.
2) Voltage checks indicate 13.6V this will vary according to battery condition and where it is
being measured – but under no load conditions should never be below 11.5V
3) If the alarm sounds when lift ascending the float switch is closed – detecting a full fluid
catch tank.
Phone Support Fault Finding
User Display LED's.
Note: key fob to enable the lift is optional.
Up Underpan obstruction – Green out.
Underpan Down obstruction – Yellow Out.
Trapdoor Up/Down obstruction; Door Lock Error; Proving Switch Error – Blue, Green &
Yellow Out.
Note: Top Limit red plunger sticking down will cause the Green LED’s to extinguish.
THE PRIMARY EMERGENCY LOWERING PROCESS WILL OPERATE WHEN THE
SPRUNG EMERGENCY DUMP SWITCH ON THE CARRIAGE CONTROL STATION IS
TURNED AND HELD IN THE CLOCKWISE DIRECT AND THE DOWN SWITCH IS
SIMULTANEOUSLY PRESSED. THE LIFT WILL SAFELY TRAVEL DOWNWARDS.
BACK-UP EXTERNAL EMERGENCY LOWERING ON A TERRY LIFESTYLE LIFT IS
ONLY TO BE CARRIED OUT IF SOMEONE IS TRAPPED INSIDE THE LIFT – not as a
means of down operation until an engineer can attend.

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 10 of 14
Terry Lifestyle Fault Finding – Emergency Circuit
(Takes out all LED’s in Car User Display)
•Checks A,B,C,D,E,F – Done at Pwrpk PCB
•Checks 1,2,3,4,5,6,7,8 – Done at Sling PCB
A
CE966 – Powerpack PCB
240V In
B
CE966 – Powerpack PCB
Charger (13.6V)
i. Batteries (+13.6V)
ii. 5A Fuses on
Battery Negative
C
CE966 – Powerpack PCB
CB2 Resettable Fuse
D
CE966 – Powerpack PCB
TB4
STOP LINK
E
CE966 – Powerpack PCB
TB3 Pressure Switch
(Fitted on Ram)
1
CE2123 – Sling PCB
TB6
EMERGENCY
Trailing Cable
2/3
CE2123– Sling PCB
TB9
Final Limit Switch Emergency Link
(White & Red)
3/4
CE2123 – Sling PCB
TB24
DPS Switch (Orange)
5/6
CE2123 – Sling PCB
TB1
Lock Micro-switch & Handle
(Orange & Orange/Red)
6/7
CE2123 – Sling PCB
TB23
Ramp Switch Link
F
CE966 – Powerpack PCB
TB5 EMERGENCY
Trailing Cable
(Orange)
7/8
CE2123 – Sling PCB
TB13,TB18
Top Cap and Override

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 11 of 14
Terry Lifestyle Fault Finding – Down Hold
(No Yellow LED’s in User Display)
D1
CE2123 – Sling PCB
TB12 Down S/Edge
(Yellows)
D2*
CE2123– Sling PCB
TB11 Down S/Edge
(Yellows)
D3
CE2123 – Sling PCB
TB11 Final Down
(Blacks)
D5
CE2123 – Sling PCB
TB11 Final Down
(Blacks)
D6
CE2123 – Sling PCB
TB11 Down Hold
Trailing Cable
(Yellow)
D8
CE966 – Powerpack PCB
TB5 Trailing Cable
(Yellow)
DN Signal
Solenoid
+12V
D7
CE2123 – Sling PCB
TB6 Down Hold
Trailing Cable
(Yellow)
•Checks D1-D7 are done at Sling PCB
•Check D8, is done at Pwrpk PCB
*Check D2 includes
Emergency Dump Relay
D4
CE2123 – Sling PCB
TB11 Final Down
(Blacks)

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 12 of 14
Terry Lifestyle Fault Finding – Up Hold
(No Green LED’s in User Display)
U4
CE2123 – Sling PCB
TB15 Underpan UP
Separation Switch
(Brown)
U6
CE2123 – Sling PCB
TB8 Up Hold
Trailing Cable
(Brown)
U5
CE2123 – Sling PCB
TB15 Underpan Up
Separation O’ride
(Brown)
U7
CE966 – Powerpack PCB
TB5 Up Hold
Trailing Cable
(Brown)
Up Signal
Final Relays
Motor
U2
CE2123 – Sling PCB
TB11 Top Limit
Switch & Sling Top
Safety Edge
(Browns)
•Checks U1-U6 are done at Sling
PCB
•Check U7 is done at Powerpack
PCB
U3
CE2123 – Sling PCB
TB17 TOP CAP S/E & Links
(Brown)

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 13 of 14

Lifestyle Elecs & Fault Finding - XH00219
Issue: C
Page 14 of 14
XH00219C
