The INA 5540-GA is an adapter to use a dual-ARB NSG 5500 +ARB to simulate
the pulses described in GMW 3172 section 9.2.5. This test requires two function
generators, one being modulated through a capacitor as shown below.
1 OVERVIEW
Figure 1 - The test circuit from GMW 3172

6
INA 5640-GA
For this reason, the INA 5540-GA is designed to use two inputs from two ARB
5500 channels output with the recommended capacitance built in directly to
the PA.
Figure 2 – The INA 5540-GA

7
Connect the CH1 and CH2 DSUB connectors to the respective ARB channel
output. Connect the Output to PA connector to the PA 5840 or PA 5740 input
using the cable supplied with the PA.
Finally, connect the INA 5540-GA to the supplied DC power supply and connect
that to mains.
2 SETUP

8
INA 5640-GA
Program a 0 V DC ramp for the master FG card and a square wave with 2 Vpp
and 1 Hz for the slave 1 FG card.
Measure the output voltage of PA and adjust the peak amplitude of the rectan-
gular wave to achieve the desired superimposed voltage. If the values seem
unusually, be sure that the appropriate source is selected in AutoStar.
3 ADJUSTMENT

9
Program a DC ramp for the master FG card with an amplitude corresponding to
Us required by the standard. Program a rectangular wave with an amplitude of
2 Vpp and logarithmic ramped frequency from 1 Hz to 4 kHz to 1 Hz, see pre-
programmed test in AutoStar.
5 TEST PROCEDURE

10
INA 5640-GA
Us=14 V, f=1 Hz
6 SAMPLE PLOTS
Us=14 V, f=100 Hz

11Us=14 V, f=4 kHz

12
INA 5640-GA
Inside the packaging, you will nd the following items:
1) INA 5540-GA
2) DC power supply
3) Users guide (this guide)
7 PACKAGE CONTENTS
