Tews Technologies TVME8240A User manual

The Embedded I/O Company
TVME8240A
Single Board Computer
with IndustryPack® Interface
Version 2.0
User Manual
Issue 1.1
May 2008
TEWS TECHNOLOGIES GmbH TEWS TECHNOLOGIES LLC
Am Bahnhof 7
25469 Halstenbek, Germany
www.tews.com
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
9190 Double Diamond Parkway,
Suite 127, Reno, NV 89521, USA
www.tews.com
Phone: [phone]
Fax: [phone]
e-mail: [email protected]

TVME8240A User Manual Issue 1.1 Page 2 of 96
TVME8240A
Single Board Computer with IndustryPack
Interface
Available Board Options :
TMVE8240A-11
MPC8245 300 MHz, 64 MB SDRAM,
2 + 8 MB Flash, Fast Ethernet,
Front Panel I/O
TMVE8240A-12
MPC8245 300 MHz, 64 MB SDRAM,
2 + 8 MB Flash, Fast Ethernet, Ultra SCSI,
Front Panel I/O
TMVE8240A-21
MPC8245 300 MHz, 256 MB SDRAM,
2 + 32 MB Flash, Fast Ethernet,
Front Panel I/O
TMVE8240A-22
MPC8245 300 MHz, 256 MB SDRAM,
2 + 32 MB Flash, Fast Ethernet, Ultra SCSI,
Front Panel I/O
This document contains information, which is
proprietary to TEWS TECHNOLOGIES GmbH. Any
reproduction without written permission is forbidden.
TEWS TECHNOLOGIES GmbH has made any effort
to ensure that this manual is accurate and complete.
However TEWS TECHNOLOGIES GmbH reserves
the right to change the product described in this
document at any time without notice.
TEWS TECHNOLOGIES GmbH is not liable for any
damage arising out of the application or use of the
device described herein.
Style Conventions
Hexadecimal characters are specified with prefix 0x,
i.e. 0x029E (that means hexadecimal value 029E).
For signals on hardware products, an ‚Active Low’ is
represented by the signal name with # following, i.e.
IP_RESET#.
Access terms are described as:
W Write Only
R Read Only
R/W Read/Write
R/C Read/Clear
R/S Read/Set
©2008 by TEWS TECHNOLOGIES GmbH
All trademarks mentioned are property of their respective owners.

TVME8240A User Manual Issue 1.1 Page 3 of 96
Issue Description Date
-
Preliminary Issue for TVME8240A V2.0
Major board version change. Product ID changed to TVME820A.
MPC8245 CPU, 2x 82551 Ethernet Controller, 32 KB NVRAM, VME Bus Error
Interrupt, extended Boot Flash, readable switch, remote control & status, extended
SDRAM and Flash options
March 2007
1.0
Status Register 2 (Readable Switch Description),
Status Register 1 (Fuse Alarm Description),
Control Register 2 (RS422 Mode Description. Added note) ,
IP Control Register (Added control bit).
July 2007
1.1 Added new board options -21, -22 (extended SDRAM and Flash Memory).
Added LED output driver type note in the remote header section.
Supported Flash type 39VF64xx changed to 39VF64xxB. May 2008

TVME8240A User Manual Issue 1.1 Page 4 of 96
