ADC121S101EVM User's Guide
User's Guide
Literature Number: SNOU131
July 2014

Contents
1 ADC121S101 BoosterPack Components ................................................................................. 4
2 Software Installation............................................................................................................. 5
2.1 Graphical User Interface (GUI)............................................................................................. 5
2.2 Launchpad Firmware Upgrade............................................................................................. 6
2.3 Update USB Driver .......................................................................................................... 7
3 ADC121S101 BoosterPack Setup and Operation .................................................................... 10
3.1 Connections................................................................................................................. 10
3.2 Launching the Software ................................................................................................... 10
4 Board Layout..................................................................................................................... 14
5 Schematic ......................................................................................................................... 19
6 Bill Of Materials.................................................................................................................. 20
2Contents SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com
List of Figures
1-1. ADC121S101EVM Evaluation Board...................................................................................... 4
2-1. ADC12xS10x Installation Directory........................................................................................ 5
2-2. ADC12xS10x Installation Finish ........................................................................................... 6
2-3. USB Firmware Upgrade Window .......................................................................................... 7
2-4. Driver Not Installed .......................................................................................................... 8
2-5. Driver Authentication Warning ............................................................................................. 9
2-6. Driver Installed ............................................................................................................... 9
3-1. ADC121S101EVM Attached to MSP430................................................................................ 10
3-2. Part Select................................................................................................................... 11
3-3. Selectable Fields in GUI................................................................................................... 12
3-4. Testing the Part............................................................................................................. 13
4-1. Top Assembly Layer....................................................................................................... 14
4-2. Top Layer Routing ......................................................................................................... 15
4-3. Power Layer Routing ...................................................................................................... 16
4-4. Ground Layer Routing ..................................................................................................... 17
4-5. Bottom Layer Routing...................................................................................................... 18
5-1. ADC121S101EVM Schematic............................................................................................ 19
List of Tables
1-1. Device and Package Configurations ...................................................................................... 4
6-1. ADC121S101 Bill of Materials............................................................................................ 20
3
SNOU131–July 2014 List of Figures
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Chapter 1
SNOU131–July 2014
ADC121S101 BoosterPack Components
Figure 1-1. ADC121S101EVM Evaluation Board
Table 1-1. Device and Package Configurations
DEVICE IC PACKAGE
U1 LM4120IM5-3.3 SOT-23
U2 ADC121S101CIMF SOT-23
U3 LMT84DCK SC70
U4 LMV612MA SOIC-8
4ADC121S101 BoosterPack Components SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

Chapter 2
SNOU131–July 2014
Software Installation
2.1 Graphical User Interface (GUI)
To use the ADC121S101EVM, install the ADC12xS10x software:
1. If the ADC121S101EVM came from an FAE, the software GUI is in a .zip file. Otherwise, click on
http://www.ti.com/product/adc121s101, scroll down to the Software section, and download the latest
evaluation software.
2. Unzip the downloaded file into a known directory, and run the setup.exe file located in [Unzip
location]\ADC12xS10x\EVM_GUI\ADC12xS10x_Installer_v11.zip\ADC12xS10x_Installer
\Installer\Volume. Follow the pop-screen instructions by clicking the Next button to install the software.
Figure 2-1. ADC12xS10x Installation Directory
3. When the installation is finished, click the Finish button.
5
SNOU131–July 2014 Software Installation
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Launchpad Firmware Upgrade www.ti.com
Figure 2-2. ADC12xS10x Installation Finish
2.2 Launchpad Firmware Upgrade
This section is only necessary with a brand new Launchpad. If a Launchpad is shipped with an
ADC121S101EVM, skip this section.
MSP430 Firmware Upgrade Application Installation:
1. Navigate to http://www.ti.com/tool/msp430usbdevpack and click on Get Software.
2. Scroll down to the end of the page to find the USB Collateral Installers section.
3. Click on MSP430_USB_Firmware_Upgrade_Example-x-x-x-Setup.exe to download the tool; the page
redirects to a submission form.
4. Complete the information requested and submit the form; if approved, a download button appears.
5. Run the installation file and follow the on-screen instructions until completion. When asked about the
setup type, select Application Only. Click Finish when done.
Firmware upgrade:
1. If the ADC121S101EVM is from an FAE, the firmware is the text file adc12xs10x_fw-v0.92.txt.
2. Open the MSP430 USB Firmware Upgrade application. By default, the application is launched from
Start > Programs > Texas Instruments > MSP430 USB Firmware Upgrade Example.
3. Click Next to proceed on the first prompt; read and accept the license agreement and click Next to
continue.
6Software Installation SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Update USB Driver
Figure 2-3. USB Firmware Upgrade Window
4. Enable the Select Firmware button and browse to open the downloaded firmware adc12xs10x_fw-
v0.92.txt.
5. Press the BSL button on the MSP430 LaunchPad and connect to the PC with a USB cable; if detected,
the text on the Firmware Upgrade tool changes from No device connected to Found 1 device.
6. Click on the Upgrade Firmware button to program the LaunchPad. Close the application when done.
2.3 Update USB Driver
1. Before launching the ADC12xS10x software, connect the ADC121S101EVM board to a USB port of
the PC. Go to the Device Manager and find MSP43-USB Example. Right click and select Update
Driver Software.
7
SNOU131–July 2014 Software Installation
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Update USB Driver www.ti.com
Figure 2-4. Driver Not Installed
2. On the next screen, select the Browse my computer for driver software option and go to the directory
of the install files. Select the MSP430_CDC_PID0x094e_ADC_DAC_EVMs.inf file.
3. If prompted with a warning window, select Install this Driver Anyway. Close the installation window
when done. The device manager now displays a TI_ADC_DAC_EVMs item followed by a COM port
number.
8Software Installation SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Update USB Driver
Figure 2-5. Driver Authentication Warning
Figure 2-6. Driver Installed
9
SNOU131–July 2014 Software Installation
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Chapter 3
SNOU131–July 2014
ADC121S101 BoosterPack Setup and Operation
3.1 Connections
1. Attach the ADC121S101EVM BoosterPack onto the MSP430 LaunchPad using connectors JA, JB, JC,
JD. Align the Launchpad and ADC121S101EVM so that the text “LaunchPad” and “2013 TI” are in the
same direction.
Figure 3-1. ADC121S101EVM Attached to MSP430
2. Connect the USB cable from the LaunchPad to the PC.
3.2 Launching the Software
1. The ADC12xS10x GUI software runs by clicking on Start > All Program > ADC12xS10x. After running
the GUI, select ADC121S101.
10 ADC121S101 BoosterPack Setup and Operation SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Launching the Software
Figure 3-2. Part Select
2. GUI Descriptions:
• Ref. Voltage: User can define the reference voltage in volts.
• Channel #: Option to select channels 0-3
• Output Type:
– Decimal is the ADC code
– mV is millivolts
– Temperature is in Celsius and is only available on channel 3
• Single Read: Read a single conversion.
• Continuous Read: Read conversion results continuously.
• Zoom Out:
– Checked: Graph zooms out.
11
SNOU131–July 2014 ADC121S101 BoosterPack Setup and Operation
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Launching the Software www.ti.com
– Unchecked: Graph resolves to LabView default.
• Burst Mode:
– Checked: Graph updates with 1024 ADC conversions.
– Unchecked: Graph updates with one ADC conversion.
• Save Results to File:
– Checked: Save continuous read data to a text file.
– Unchecked: No data is saved.
Figure 3-3. Selectable Fields in GUI
3. Test the ADC121S101 by placing a finger on U3 to observe the temperature change.
12 ADC121S101 BoosterPack Setup and Operation SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Launching the Software
Figure 3-4. Testing the Part
13
SNOU131–July 2014 ADC121S101 BoosterPack Setup and Operation
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Chapter 4
SNOU131–July 2014
Board Layout
Figure 4-1. Top Assembly Layer
14 Board Layout SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com
Figure 4-2. Top Layer Routing
15
SNOU131–July 2014 Board Layout
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

www.ti.com
Figure 4-3. Power Layer Routing
16 Board Layout SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com
Figure 4-4. Ground Layer Routing
17
SNOU131–July 2014 Board Layout
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

www.ti.com
Figure 4-5. Bottom Layer Routing
18 Board Layout SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

Chapter 5
SNOU131–July 2014
Schematic
Figure 5-1. ADC121S101EVM Schematic
19
SNOU131–July 2014 Schematic
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Chapter 6
SNOU131–July 2014
Bill Of Materials
Table 6-1. ADC121S101 Bill of Materials
Quanti
Designator Value Description Part Number Manufacturer
ty
!PCB 1 Printed circuit board SV601025 Any
CAP, CERM, 0.047 uF, 6.3 V, +/-10%, X7R, GRM188R70J473K
C1 1 0.047 uF Murata
0603 A01D
C2, C3, C6, C8, CAP, CERM, 0.1 uF, 10 V, +/-10%, X7R, C0603C104K8RACT
5 0.1 uF Kemet
C11 0603 U
CAP, CERM, 0.01 uF, 25 V, +/-10%, X7R, GRM188R71E103K
C4 1 0.01 uF Murata
0603 A01D
CAP, CERM, 1000 pF, 50 V, +/-5%,
C5 1 1000 pF C1608C0G1H102J TDK
C0G/NP0, 0603 TPSA106K010R090
C7 1 10 uF CAP, TA, 10 uF, 10 V, +/-10%, 0.9 ohm, SMD AVX
0
D1 1 20 V Diode, Schottky, 20 V, 0.2 A, SOD-523 SBR0220T5-7-F Diodes Inc.
FID1, FID2, Fiducial mark. There is nothing to buy or
3 N/A N/A
FID3 mount. Keystone
GND 1 Black Test point, TH, multipurpose, black 5011 Electronics
Header, TH, 100 mil, 4x2, gold plated, 230 mil
J1 1 TSW-104-07-G-D Samtec
above insulator
Header, TH, 100 mil, 3x2, gold plated, 230 mil
J2 1 TSW-103-07-G-D Samtec
above insulator Sullins Connector
J3, JVA 2 Header, 100 mil, 3x1, tin plated, TH PEC03SAAN Solutions
Connector, receptacle, 100 mil, 10x1, gold
JA, JB, JC, JD 4 SSW-110-23-F-S Samtec
plated, TH
Thermal transfer printable labels, 0.650" W x
LBL1 1 THT-14-423-10 Brady
0.200" H - 10,000 per roll RC0603FR-
R1, R3 2 100k RES, 100k ohm, 1%, 0.1W, 0603 Yageo America
07100KL
R2, R5, R8, R9 4 2.20k RES, 2.20k ohm, 1%, 0.1W, 0603 RC0603FR-072K2L Yageo America
CRCW0603200RFK
R4, R6, R7 3 200 RES, 200 ohm, 1%, 0.1W, 0603 Vishay-Dale
EA
SH-J2_5-6, SH-
J3_1-2, SH- 3 1x2 Shunt, 100 mil, gold plated, black 382811-6 AMP
JVA_2-3 Precision micropower low dropout voltage LM4120IM5-
U1 1 Texas Instruments
reference, 5-pin SOT-23, Pb-free 3.3/NOPB
Single channel, 0.5 to 1 MSPS, 12-bit A/D ADC121S101CIMF/
U2 1 Texas Instruments
converter, 6-pin SOT-23, Pb-free NOPB
Analog temperature sensors with Class-AB
U3 1 LMT84DCK Texas Instruments
output, DCK0005A
Dual 1.4 MHz, low power general purpose,
U4 1 LMV612MA/NOPB Texas Instruments
1.8 V, D0008A Keystone
VA-EXT 1 Red Test point, TH, multipurpose, red 5010 Electronics
20 Bill Of Materials SNOU131–July 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
