MC-1000WU-20A High-Resolution
B/W Camera
User’s Guide
Literature No. SOCU007
May 1998
Printed on Recycled Paper

IMPORTANT NOTICE
TexasInstrumentsanditssubsidiaries(TI)reservetherighttomakechangestotheirproductsortodiscontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TIdeemsnecessarytosupportthiswarranty.Specific testing ofallparametersofeach device isnotnecessarily
performed, except those mandated by government requirements.
CERTAIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICALAPPLICATIONS.INCLUSIONOFTIPRODUCTSINSUCHAPPLICATIONSISUNDERSTOODTO
BE FULLY AT THE CUSTOMER’S RISK.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TIassumesnoliabilityforapplicationsassistance or customer product design. TI does not warrantorrepresent
thatanylicense,eitherexpressorimplied,isgrantedunderanypatentright,copyright,maskworkright,orother
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.
Copyright 1998, Texas Instruments Incorporated

iii
Preface
Read This First
About This Manual
ThisUser’sGuideprovides installation, operation,and maintenanceinforma-
tion for the MC-1000WU-20A black and white video camera.
How to Use This Manual
This document contains the following chapters:
- Chapter 1 – Introduction
- Chapter 2 – Specifications
- Chapter 3 – Installation
- Chapter 4 – Operation
- Chapter 5 – CCD Circuit Description
- Chapter 6 – Cleaning Instructions
- Appendix A – Functional Block Diagram
- Appendix B – Timing Diagrams
Refer to the appropriate chapter for more information or for instructions con-
cerning procedures or practices.
Information About Cautions and Warnings
This book may contain cautions and warnings.
This is an example of a caution statement.
A caution statement describes a situation that could potentially
damage your software or equipment.

About This Manual
iv
This is an example of a warning statement.
A warning statement describes a situation that could potentially
cause harm to you.
The information in a caution or a warning is provided for your protection.
Please read each caution and warning carefully.
Trademarks
TI is a trademark of Texas Instruments Incorporated.

If You Need Assistance
v
Read This First
If You Need Assistance . . .
- World-Wide Web Sites
TI Online http://www.ti.com
Semiconductor Product Information Center (PIC) http://www.ti.com/sc/docs/pic/home.htm
- North America, South America, Central America
Product Information Center (PIC) [phone]
TI Literature Response Center U.S.A. [phone]
Software Registration/Upgrades [phone] Fax: [phone]
U.S.A. Factory Repair/Hardware Upgrades [phone]
U.S. Technical Training Organization [phone]
- Europe, Middle East, Africa
European Product Information Center (EPIC) Hotlines:
Multi-Language Support [phone] Fax: [phone]
Email: [email protected]
Deutsch [phone] or [phone]
English [phone]
Francais [phone]
Italiano [phone]
EPIC Modem BBS [phone]
European Factory Repair [phone]
Europe Customer Training Helpline Fax: [phone]
- Asia-Pacific
Literature Response Center [phone] Fax: [phone]
- Japan
Product Information Center +0120-81-0026 (in Japan) Fax: [phone] (in Japan)
+03-3457-0972 or (INTL) 813-3457-0972 Fax: [phone] or (INTL) 813-3457-1259
- Documentation
Whenmakingsuggestionsor reporting errorsindocumentation, please includethefollowing information thatison the title
page: the full title of the book, the publication date, and the literature number.
Mail: Texas Instruments Incorporated
Technical Documentation Services, MS 702
P.O. Box 1443
Houston, Texas 77251-1443
Note: When calling a Literature Response Center to order documentation, please specify the literature number of the
book.

vi

Running Title—Attribute Reference
vii
Chapter Title—Attribute Reference
Contents
1 General Description 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Introduction 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Physical Description 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Equipment Supplied 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Equipment Required But Not Supplied 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Specifications 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Specifications 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Interface Circuit 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Installation 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Interface Assignments 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Installation Procedure 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 Mounting the Camera 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.2 Connecting an Auto-Iris Lens 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.3 Connecting a Standard Lens 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.4 Connecting the AC/DC Power Supply 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.5 Connecting the Monitor 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Post-Installation Test 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Operation 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 General Operating Procedures 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.1 Turn-On Procedure 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.2 Turn-Off Procedure 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.3 Focusing 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.4 Adjusting Image Brightness 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 External Operation (See Appendix B) 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 CCD Circuit Description 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 The CCD Array 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Cleaning Instructions 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Cleaning 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A Functional Block Diagram A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1 Functional Block Diagram A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B Timing Diagrams B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.1 Timing Diagrams B-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables
viii
Figures
1–1 MC-1000WU-20A Interface Options and Mode Selection 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1 Input Interface Circuit of VD, HD, and MCK 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–2 Output Interface Circuit of Pixel and Shutter Monitor 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A–1 Functional Block Diagram A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–1 TV Internal Mode (see Note) B-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–2 TV External Mode B-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–3 The Relationship of Vertical Sync Out and Mechanical Shutter or Strobe Light B-3. . . . . . . .
B–4 The Relationship of Horizontal Drive Input and Video Output B-4. . . . . . . . . . . . . . . . . . . . . . . .
B–5 Shutter Internal Mode B-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–6 Shutter External Mode B-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–7 The Relationship of VD Input and HD Input B-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–8 HD Input Waveform B-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B–9 The Relationship of VD Input and C-Sync B-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tables
2–1 Specifications 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 Auto Iris Connector Pin Assignment 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 Power Connector Pin Assignment 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 Video Connector (BNC Connector) 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–4 AUX Connector Pin Assignment 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1
General Description
General Description
This User’s Guide describes installation, operation, and maintenance for the
MC-1000WU-20A video camera.
Topic Page
1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Introduction 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Physical Description 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Equipment Supplied 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Equipment Required But Not Supplied 1-6. . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Features
1-2
General Description
1.1 Features
The Texas Instruments MC-1000WU-20A camera features the Texas
Instruments TC215 solid-state monochrome charge-coupled-device (CCD)
image sensor. The camera is for vision system applications requiring high-
resolution and high-sensitivity operation. The camera features include:
- TV frame rate, 15 Hz
- High sensitivity, 0.35 lux typical
- 12 m m square pixel
- TI-Virtual Phase CCD technology
- High blue response
- High near-IR response
- Electron-hole recombination antiblooming
- 100% optical fill factor

Introduction
1-3
General Description
1.2 Introduction
TheMC-1000WU-20A isoneof aseriesof high-resolutionvideocameras that
employs TI’s mega-pixel CCD image sensors. The cameras are intended for
scientific and industrial imaging applications where image data processing is
required.
The MC-1000WU-20A camera employs the TI TC215 full-frame CCD image
sensor, which features 1,017,000 active photosites, resulting in a very-high-
resolution image. The TC215 sensor provides high sensitivity and good
spectral response as a result of the TI patented Virtual Phase technology.
TheTC215 sensor measures 17.2mm diagonally and features12- m msquare
pixels. The square pixels permit symmetrical image measurement in both the
X and Y axis. The photosite has a 100% fill factor and is responsive to wave-
lengths in the ultraviolet through the visible and into the near-infrared spectral
regions. The camera outputs composite analog video at a 20-mega-pixel per
second data rate. Two operating options can be selected - a normal operating
modeand a programmable shuttermode.In addition, the cameraprovidesfor
auto-iris control.
A mechanical shutter or strobe light is recommended for most
MC-1000WU-20Acameraapplications.Theshutteroperationissynchronized
to the camera by supplying an external shutter command signal. The shutter
may operate from a minimum integration time of 1/2500 second to 1/125
second or 10 frames/s maximum. Figure 1–1 shows the camera interface
options and mode selection.
Figure 1–1.MC-1000WU-20A Interface Options and Mode Selection
MCK (20 MHz)
HD
VD
SHT Command
SHT Monitor
Video
Camera Interface Signals
Digital
Multiplexer
Internal
X’TAL
20 MHz
EXT Pixel
MCK
20 MHz
I/E
80 MHz

Physical Description
1-4
General Description
1.3 Physical Description
TheMC-1000WU-20A cameraishoused inanaluminum case210.6mm long
(excluding lens) by 68.0 mm high by 68.0 mm wide. It is self-containedexcept
for power supply and monitor. The camera weighs 2.09 pounds.
The MC-1000WU-20A offers a standard TV C-mount lens attachment with an
adjustable lens locking ring to allow precise adjustment of the lens back focal
length. A variety of lenses or mechanical shutters may be used.
(??Page 3–4 says three ??)Two standard 1/4  20threaded tripod mounting
holes on the baseplate allow secure mounting.

Equipment Supplied
1-5
General Description
1.4 Equipment Supplied
After unpacking the camera and before discarding the packaging materials,
inventory the shipment for the following items:
- MC-1000WU-20A CCD camera
- Lens (optional) (not supplied)(??If not supplied, it won’t be in the in-
ventory??)
- MC-1000WU-20A CCD Camera User’s Guide
- Auto iris connector
- Power connector (optional power supply)
- I/O interface connector (not supplied)(??If not supplied, it won’t be in
the inventory??)

Equipment Required But Not Supplied
1-6
General Description
1.5 Equipment Required But Not Supplied
TheMC-1000WU-20A camerausesthe full-frameTC215CCD imagesensor.
This full-frame format sensor requires a mechanical shutter or an electronic
light strobe to prevent image smear. The shutter or strobe light allows scene
informationtobecapturedduringeithertheopentimeoftheshutteroron-time
of the strobe light. The transfer or read-out of the captured scene information
is performed during the closed time of the shutter or off-time of the strobe.
Once the shutter or strobe light is chosen, an appropriate lens may also be
selected.
The MC-1000WU-20A camera supplies analog video at either a 15-Hz frame
rate in the TV mode or a 10-Hz frame rate in the shutter mode and can be
displayed directly to a video monitor capable of those frame rates. However,
many applications require the addition of a custom or commercially available
frame-buffer or other video processing equipment. This hardware will enable
the user to capture and digitally process the scene information. The
MC-1000WU-20A is presently supported by several manufacturers of video
processing hardware and software systems. Most manufacturers have
application notes available describing the interface required.

2-1
Specifications
Specifications
This chapter lists specifications for the MC-1000WU-20A camera and
describes the interface circuit.
Topic Page
2.1 Specifications 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Interface Circuit 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

2-2
Specifications
2.1 Specifications
Table 2–1 lists the specifications for the MC-1000WU-20A camera.
Table 2–1.Specifications
Item Specification
Imager Texas Instruments TC215 Full-Frame CCD
Resolution 1024(H)  1024(V) (total imager)
1000(H)  1017(V) (active pixels)
Pixel size 12 m m  12 m m
Imager size H: 12.2 mm
V: 12.0 mm
Synchronization Internal/external (jumper selectable)
TV mode
Shutter mode
1050 lines/frame (33 blank lines)
15 frames/sec
non-interlace
1050 lines/frame (33 blank lines)
10 frames/sec (max)
Sensitivity 0.29 lux (max)
0.35 lux (typ)
0.41 lux (min)
1/30 integration
Video output: 100 IRE
S/N ratio: 48 dB
Light source: T=2870°K
S/N ratio 48 dB
MTF 10 MHz chart, 35% (typ), 500 nm
White clip 0.90 ±0.05 V
Setup level 50 ±10 mV
Output dc level 0.30 ±0.05 V
Sync level 0.30 ±0.015 V
Supply voltage +5 ±0.15 Vdc
–12 ±0.4 Vdc
+12 ±0.4 Vdc
Power consumption (typical) +5 V at 0.820 A
+12 V at 0.180 A
–12 V at 0.150 A
Non-uniformities Total black and white pixel non-uniformities, less than 20. Vertical line non-
uniformities, less than 5.
Shading (maximum)
Horizontal
Vertical
10% 100%
15 mV 50 mV
20 mV 70 mV
Vertical frequency 15.46 Hz
Horizontal frequency 16.234 kHz
Gamma 1.0

2-3
Specifications
Table 2–1.Specifications (Continued)
Item Specification
Operating temperature –10 _ C to +45 _ C
Storage temperature –30 _ C to +85 _ C
Dimensions 68 (W)  68 (H)  210.6 (D) mm
Weight 2.09 lbs

Interface Circuit
2-4
Specifications
2.2 Interface Circuit
The input interface circuit of VD, HD, and MCK shown in Figure 2–1, consists
of one SN75124 input gate pulled up through a 4.7-k W resistor to 5 Vdc and
pulled down to ground through an optional 100- W resistor. The optional pull
down is selected by jumpers JP1 (MCK), JP2 (HD), and JP3 (VD).
Figure 2–1.Input Interface Circuit of VD, HD, and MCK
5 V
VD
4.7 kΩ
75124
JP3
100 Ω
GND
5 V
HD
4.7 kΩ
75124
JP2
100 Ω
GND
5 V
MCK
4.7 kΩ
75124
JP1
100 Ω
GND
Figure 2–2.Output Interface Circuit of Pixel and Shutter Monitor
75123 470 Ω
Shutter
Monitor
Pixel Out
100 Ω
470 Ω
(see Note A)
NOTE A. For pixel clock receiving, pull domain resistor 100 Ωis recommended.

3-1
Installation
Installation
This chapter describes interface assignments and gives instructions for
installing and testing the camera.
Topic Page
3.1 Interface Assignments 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Installation Procedure 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Post-Installation Test 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3

Interface Assignments
3-2
Installation
3.1 Interface Assignments
Depending upon the application, it may be necessary to build a camera cable
that contains some combination of the signals listed below:
Table 3–1.Auto Iris Connector Pin Assignment
Pin Number Signal Name
AVideo signal
B GND
C +12 V
DNC
ENC
Note: Connectors
Camera side: PRC05-R5M (Tagimi)
Cable side: PRC05-P5F (Tagimi)
Table 3–2.Power Connector Pin Assignment
Pin Number Signal Name
A+12 V
B +12 V
C GND
D +5 V
E +5 V
F GND
G –12 V
HGND
Note: Connectors
Camera side: R03-R8F (Tagimi)
Cable side: R03-PB8M (Tagimi)
Table 3–3.Video Connector (BNC Connector)
Pin Signal Name
Center pin Composite video
Shell Video RTN
