texet TR-3001 User manual

USER GUIDE
Руководство по эксплуатации
TR-3001
PORTABLE AUDIO SYSTEM
ПОРТАТИВНАЯ АУДИОСИСТЕМА

Device and controls
Устройство и органы управления
2
1 2 3 4
5
6 7 9 8 10
12
13
11

ENG
1 — ON/OFF Portable audio system on/off button
2 — Headphone output
3 — Mini USB DC (AUX) interface to charge portable
audio system and connect PC, line input to connect
external devices
4 — USB Host Interface for USB flash drives
5 — microSD slot for microSD memory cards
6 — Button to go to the previous subject
7 — Button to go to the next subject
8 — Playback/pause or on/off (by long press)
button
9 — MButton to select main functions of the
portable audio system
10 — V- Button to decrease the sound volume level
11 — V+ Button to increase the sound volume level
12 — Battery compartment
13 — Extendable antenna
3

1 — ON/OFF Кнопка включения/выключения
портативной аудиосистемы
2 — Выход для наушников
3 — Mini USB DC (AUX) интерфейс для заряда
портативной аудиосистемы и подключения
к ПК, линейный вход для подключения
внешних устройств
4 — USB хост Интерфейс для подключения
USB флеш накопителей
5 — microSD слот для microSD карт памяти
6 — Кнопка перехода к предыдущему файлу
7 — Кнопка перехода к следующему файлу
8 — Кнопка воспроизведения/паузы.
При долгом нажатии – включения/выключения.
9 — M Кнопка переключения режимов работы
портативной аудиосистемы
10 — V- Кнопка уменьшения уровня громкости звука
11 — V+ Кнопка увеличения уровня громкости звука
12 — Отсек для аккумуляторной батареи
13 — Выдвижная антенна
RUS
4

1. Portable audio system TR-3001
2. Battery teXet (analogue Nokia BL-5C) 1100 mAh
3. Universal cable for charging and connecting
external devices
4. User guide
5. Warranty certificate
1. Портативная аудиосистема TR-3001
2. Аккумуляторная батарея teXet
(аналог Nokia BL-5C) 1100 мАч
3. Универсальный кабель для заряда
и подключения внешних устройств
4. Руководство по эксплуатации
5. Гарантийный талон
Package contents
Комплектность
5
TBP-2214

Thank you for purchasing our portable audio system
teXet TR-3001. Before you start operating the unit,
please read this manual to take full advantage of the
audio system and extend its life. Save this manual to
refer to it in the future if the need arises.
This manual contains information on the technical
characteristics of the device, controls of the portable
audio system, all functions and modes of operation, as
well as a list of security measures.
Note: Due to continuous product improvement, the
manufacturer reserves the right to modify the software,
hardware, and specifications without prior notice to the
end user. Current information is always available on the
website www.texet.ru
Appearance of the menu screens shown in the
illustrations in the manual may differ slightly from the
existing products.
ENG
6

Technical specifications
1 Depending on the level of the sound
2 The charging device is not included and must be purchased
separately
Overall dimensions
142 x 63 x 47 mm
Weight 241 g
Display LED
Battery Li-Ion 3,7 V,
1100 mAh
(analogue
Nokia BL-5C)
Time of operation in playback
mode
6-12 hours 1
External power source USB 5 В, 0,5-1 А 2
Frontal speakers
2 x 40 mm, 4 Ohm
Rear speakers 2 x passive
subwoofers
Output power 2 x 3 W
Reproducible frequencies 85 Hz – 18 kHz
Line input response (L) and (R)
300 mV/channel
7

Signal-to-noise ratio 70 dB
Nonlinear-distortions
coefficient
< 0.55%
FM band range 87,5-108,0 MHz
MP3 player
Supported formats MP3
Bitrate 8 – 320 kBps
External media memory
capacity (USB and microSD)
up to 32Gb
External media file system
format
FAT32
Maximum MP3 files number
on external drive
2000
Number of levels tab folders up to 5
Number of libraries/folders 999
Working range -5 to + 40 °C
8

When turning on the portable
audio system, the display shows
the following information:
1. Start of operation
Setting the clock
Press and hold down the Mbutton to successively
adjust the time value and date: hours, minutes,
seconds, year, month, and day. Press Mbutton to
confirm the selected value:
Setting the value «Hours»
Setting the value «Minutes»
Setting the value «Year»
Setting the value «Month»
9

Setting the value «Day»
To change the display format of the time 12/24
press the button in normal operation mode of the
portable audio system:
12-hour time format
24-hour time format
Press the Mbutton to select
the MP3 player operation.
2. MP3 player operation
Insert the microSD memory card into the microSD
slot or the USB flash drive into the interface USB
host. Playback will start automatically. Use the
buttons / to select a required audio file.
10

Information on playing MP3 files from external
media:
• External media file system format: FAT32
• External media memory capacity: max. 32 Gb
• Up to 5 levels tab folders
• Number of libraries/folders: max. 999
• Number of recorded MP3 files: max. 2000
3. FM radio mode
Press the Mbutton to select
the FM radio mode.
Press quickly the buttons / to manually
adjust a needed radio frequency and press /
continuously to auto seek the radio stations.
Press and hold down the Mbutton to auto seek and
store radio stations ranging from 87,5 tо 108 MHz
in the portable audio system memory. There are 30
memory slots (P1-P30) available to store radio stations.
Press quickly the button to
select stored radio stations.
11

Press the button Мto select
the mode Line-in (AUX).
4. Playback mode Line-in (AUX)
Connect an external device (MP3 player, tablet,
smartphone or mobile phone) to the mini USB DC
(AUX) socket via the universal cable.
To adjust the volume, use the buttons V+ and V-.
Press the button Мto select
the alarm mode. The mode
selected, the screen will display
the icon .
5. Alarm
Setting the alarm clock
Press and hold down the Mbutton to set the alarm
time. Use the buttons / to change the time value.
To activate the alarm, select «ON» in the alarm on/off
setup menu.
Press the Mbutton to move to the alarm tone
selection mode:
Built-in alarm
12

FM radio alarm
Selecting a preset
FM radio station
Alarm from microSD card
Alarm from USB flash drive
Attention: Before setting a file from microSD
memory card or USB flash card as an alarm it’s
necessary to create the folder named (\ALARM\) in the
root directory and put into it the MP3 file, which will
be used as an alarm.
13

This mode is available only for integrated alarm
clock.
When triggered the alarm, press the button to
interrupt the signal and activate the snooze alarm.
If you do not press any button at the alarm sounding
time for 1 minute in the snooze mode, the mode will
be automatically switched off.
If you press the button to interrupt the alarm, it
will be repeated in 5 minutes.
If you press any button except at the alarm time,
the snooze mode will be switched off.
6. Alarm repeat
7. Adjusting the volume of the sound
Press the button V- to decrease the volume. Press
and hold down the button V- to decrease the volume
quickly.
Press the button V+ to increase the volume. Press
and hold down the button V+ to increase the volume
quickly.
14

8. Troubleshooting guide
Doesn’t turn on 1. Check if the power button
is «ON»
2. Check the battery charge
degree
Not recharged 1. Check the charging cable
connection
No sound 1. Check the sound volume level
2. Check if there are MP3 files in
external media
3. Check the battery charge
degree
No reading
files from
external media
1. Check the USB flash drive file
system format
2. Check the external media for
availability of viruses
3. Check the number of sublevels
of the folders and MP3 files
stored in the external media
15

Poor radio
signal
reception
1. Adjust the position of the
extendable antenna, by which
the signal will be received
optimally
2. Best radio signal reception is
insured near the window
3. Make sure that the portable
audio system is removed from
possible interference sources,
such as TV set or mobile phone
16

Благодарим за приобретение портативной аудио-
системы teXet TR-3001. Прежде чем начать эксплу-
атацию устройства, внимательно прочтите данное
руководство, чтобы воспользоваться всеми возмож-
ностями аудиосистемы и продлить срок ее службы.
Сохраните это руководство, чтобы обратиться к нему,
если в будущем возникнет такая необходимость.
Данное руководство содержит информацию о
технических характеристиках устройства, органах
управления портативной аудиосистемой, полном
функционале и режимах работы, а так же перечень
мер безопасности.
Примечание: В целях непрерывного совершенство-
вания изделий, производитель сохраняет за собой
право изменять программное обеспечение, аппарат-
ную часть, и технические характеристики без пред-
варительного уведомления конечного пользователя.
Актуальная информация всегда доступна на сайте
www.texet.ru
Примечание: Внешний вид изображенных на рисун-
ках в руководстве экранов меню может незначитель-
но отличаться от вида существующих изделий.
RUS
17

Технические характеристики
1 В зависимости от уровня громкости звука
2 Не входит в комплект и приобретается отдельно
Габариты 142 x 63 x 47 мм
Масса 241 г
Дисплей LED
Аккумуляторная батарея Li-Ion 3,7 В,
1100 мАч
(аналог Nokia
BL-5C)
Время работы в режиме
воспроизведения 6-12 часов 1
Внешний источник питания USB 5 В, 0,5-1 А 2
Фронтальные динамики 2 x 40 мм, 4 Ом
Тыльные динамики 2 x пассивных
сабвуфера
Выходная мощность 2 x 3 Вт
Диапазон воспроизводимых
частот 85 Hz – 18 kHz
Чувствительность (Л) и (П)
300 мВ/канал
18

Сигнал/шум 70 dB
Коэффициент нелинейных
искажений < 0.55%
FM диапазон 87,5-108,0 MГц
MP3 плеер
Поддерживаемые форматы
файлов MP3
Битрейт 8 – 320 kBps
Максимальный поддерживае-
мый объем внешнего накопи-
теля (USB и microSD)
до 32Gb
Поддерживаемый формат
файловой системы внешнего
накопителя
FAT32
Максимальное поддержи-
ваемое количество чтения
записанных MP3 файлов
2000
Максимальное количество
уровней вложенных папок до 5
Максимальное количество
папок 999
Рабочий диапазон -5 to + 40 °C
19

При включении портативной
аудиосистемы на дисплее ото-
бражается следующая инфор-
мация:
1. Начало эксплуатации
Настройка часов
Нажмите и удерживайте кнопку М, чтобы по-
следовательно настроить значения времени и даты:
часов, минут, секунд, года, месяца и числа. Чтобы
подтвердить выбранное значение нажмите кнопку М
Настройка значения «Часы»
Настройка значения «Минуты»
Настройка значения «Год»
20
Table of contents
Languages:
Other texet Portable Stereo System manuals
Popular Portable Stereo System manuals by other brands

THOMSON
THOMSON RK250UDABCD operating instructions

Panasonic
Panasonic RX-D55 operating instructions

Sirius Satellite Radio
Sirius Satellite Radio Orbiter SB4000 user guide

Roberts
Roberts SRC985 user manual

Curtis
Curtis RCD668 owner's manual

Leaderwave Electronics
Leaderwave Electronics P-137L instruction manual
