TG Electronics HSY-S212W User manual

HSY-S212W Metal waterproof access control system
User Manual
Reading carefully before Install and use this manual
1. Product Profile
The product is Contact-less inductive card Metal Password Access Controller, According to the model,
respectively support 125Khz EM cards, It is one of the most advanced stand alone access controller.
It uses unique metal exterior design, Dexterity keyboard panel operation, Built-in high-grade
microprocessors, Strong anti-interference ability, Safety and reliability is extremely high, can provide
a powerful security for 2,000 users. It has strong functions, such as low power consumption,
Luminous keyboard, independent passwords, wiegand26 output, the output short circuit protection,
door magnetic alarm, prevent demolition alarm, exit button, the doorbell interface, level of security
Settings, etc. widely used in home, office, residential area and other public places.
2. Features
Low power consumption: less than 30mA standby current
Luminous keyboard: the night can also operate keyboard
User capacity: support 2,000 users

Independent password: can use password which irrelevant with the card to
open the door
User modification password: Users can revise the door password
Search speed: charge to open the door time less than 0.1 S.
Output short circuit protection: electric lock or alarm output circuit within 100
μS when shut down automatically output
Wiegand output: With Wiegand output interface，Wg26 card number or Wg4
buttons output
Usable keyboard delete card number: After card is lost, usable keyboard
delete card，Thoroughly eliminate safety lapses
The demolition alarm: Illegal dismantling machine, built-in alarm sound
buzzer
The bell button and interface: key and circuit segregation, external any the
doorbell.
3. Technical parameters
Work Voltage: DC9-28V
Static Current: ≤30mA
Reading Range: 3～8cm
Capacity: 2000 users
Ambient Temperature: -25～60 Degree
Ambient Humidity: 10%～90%
Electricity lock output: ≤3A
Alarm output: ≤20A
Output short circuit protection time; ≤100μS
Open time; 0 ~ 99 seconds (adjustable)
Size; 120 *56*18mm
4. Administrator operation
Restore factory settings:
Disconnect the power of the mechine,press “#” key ,at the same time conntect the
power for it,after the sound of “beep ”,then loosen” # “key. It means initialization of
machine successfully.
Note: restore factory Settings will not delete a user data
Enter administrator operation status:
Press * Administrator password # Administrator the default password: 999999
4.1 Modify administrator password:
Press 0 The new password # Repeat the new password #
Note: the administrator password for 6 ~ 8 random Numbers, please take
good care.
4.2 Add user:
4.2.1 Continuous increase card:
Press 1 Reading card ,Reading card , … #
4.2.2 Designated card No increase:

Press 1 Eight card number # , Eight card number # , … #
Automatically increase, the user ID automatically generated by this machine, the range
is 1 ~ 2000, and search from small to large.
4.2.3 Designated ID No swipe card increase:
Press 1 ID Number # Reading card ，ID Number # Reading
card , … #
4.2.4 Designated ID No and card No increase:
Press 1 ID Number # Eight card number # , ID Number # Eight card
number # , … #
Note: input ID digits for 1-4 digits, The range is 1 ~ 2000, such as 1,01,001,0001 ID
number all expressed 1.
Add card user will automatically generate a default password "1234", but this password
can't open the door, only for a user to change a new password.
4.2.5 Designated ID No and password increase:
Press 1 ID No # password # ID No # Password # … #
Note: applicable to no card users, password and card unrelated, input digits for four,
but not for "1234"
4.3 Delete user
4.3.1 Delete swipe card
Press 2 Reading card Reading card … #
4.3.2 Delete Designated card Number：
Press 2 Eight card number # ，Eight card number # ，… #
4.3.3 Delete Designated ID Number：
Press 2 ID No # ID No # … #
4.3.4 Delete all：
Press 20000 #
4.4 Door open method setting：
4.4.1 Card open：
Press 3 0 #
4.4.2 Card + Password open：
Press 3 1 #
4.4.3 Card or Password open：（Factory default）
Press 3 2 #
4.5 Unlock time setting：
Press 4 0～99 #
Note: The lock time range "0 to 99 seconds ", the factory default is 5 seconds
4.6 Alarm time setting：
Press 5 0～3 #
Note: The alarm time range "0 to 3 minutes ", the factory default is 1 minute
4.7 Magnetic Alarm Function setting：

4.7.1 Shielding of the function (factory default)：
Press 6 0 # 。
4.7.2 Open the function：
Press 6 1 #
Open the function, two possibilities:
4.7.2.1 If you open the door not closed properly, 1 minute, built-in buzzer alarm tone hair
tips, door or turn off automatically after 1 minute.
4.7.2.2 If normal unlock 20 seconds after the doors open, or door is forced open, external
alarm and built-in buzzer alarm at the same time
4.8 Security mode setting
4.8.1 Normal mode (factory default)
Press 7 0 #
4.8.2 Lock mode：
Press 7 1 #
That within ten minutes of continuous brush invalid card or enter the wrong password ten
times, external alarm and built-in buzzer alarm at the same time
5. User operations
5.1 User use card modify password:
Press * Reading card Old password # New password # Repeat the
new password #
5.2 User use ID No modify password
Press * ID No # Old password # New password # Repeat the
new password #
Note: applicable to a card or without card users, if the user password is "1234", must
use card to modify
5.3 Card open：
Reading card ，Effective namely open
5.4 Password open：
Press User password # ，Password right namely open
5.5 Card + Password open：
Reading card User password # ，Card and password right namely open
6 Remove alarm operation
6.1 External alarm and built-in buzzer alarm at the same time
SwipeValid card or press Administrator password# ，Can remove alarm。
6.2 Close door alarm tips
Close the door，or swipe card Valid card，or Input administrator password# ，Can
remove alarm
7. Acousto-optic instructions
Operation Red Green Buzzer Note

state Light Light
Standby Slow
flashing
Off
Buttons Di
Success Off On Di－
Failure DiDiDi
Into
programming
On Off Di－Indicator is
orange
Set condition On On
Exit
programming
Slow
flash
Off Di－
Unlock Off On Di－
Alarm Fast
flashing
Off Alarm
sound
8 Installation method, lead wire description and Cabling diagram
8.1 Installation method
8.1.1 On the wall of the aperture size machine on the pan is playing well with a hole, or
installed 2 exisiting junction box plus connecting.(Figure 1)
Figure1
8.1.2 Put the lead wire from Bottom shell of the outlet hole oout, he connection of cable
needed, Unused lines wrapped with insulating tape isolated to prevent short circuit
8.1.3 Finish line, Install the front cover to the back cover, Finally tighten the screws, Fixed
the front cover and back cover.
8.2 Lead wire description
Line
sequence
Marks Color Function description

1 BELL_A Pink Doorbell button one end
2 BELL_B Pale blue The doorbell button to the other end
3 D0 Green WG output line D0
4 D1 White WG output line D1
5 ALARM Grey Alarm negative (alarm positive
connected + 12 v
6 OPEN Yellow Exit button one end（Exit button the other
end connected GND）
7 D_IN Brown Magnetic switch one end (magnetic switch
another end connected GND)
8 DC+12V Red Power supply 9-28V input (DC input+)
9 GND Black GND
10 NO Blue Relay normally-on
end（Connected positive electric lock +）
11 COM Purple Relay Public end ，Connected GND
12 NC Orange Relay Closed end （connected negative
electric lock +）
8.3 Cabling diagram
8．3．1 Ordinary power supply Cabling diagram
Figure 2 Ordinary power supply Cabling diagram
8．3．2 Access Control Power Supply Cabling diagram

Figure3
Access Control Power Supply Cabling diagram
9 Packing list
Name Model/specification Quantity Note
Metal waterproof
access control
HSY-S212W access
control
1
User manual HSY-S212W access
control
1
Tapping screws Φ4mm×28 mm 4 Used for installation fixed
Stopper Φ6mm×30 mm 4 Used for installation fixed
Star screwdriver Φ20mm×60mm 1 Secial
Star screws
Φ3mm×6mm
1 Used between the front
cover and back cover for a
fixed
Warm Tip:
* Please don't secretly repair machine, if any problem, please return to factory
maintenance.
* Before the installation on the wall, if you want to punch, please check carefully wiring or
line tube, prevent drilling broken wiring etc unnecessary trouble, please use safe glasses
when drilling or fixed line clip.
* If product upgrades, specifications will likely differ, without prior notice.
