Tharo Systems V Series User manual

V-Series Plus
User’s Manual
Revised November, 2023

1
FCC COMPLIANCE STATEMENT
FOR AMERICAN USERS
This equipment has been tested and found to comply with the limits for a CL SS digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at own expense.
EMS AND EMI COMPLIANCE STATEMENT
FOR EUROPEAN USERS
This equipment has been tested and passed with the requirements relating to electromagnetic
compatibility based on the standards EN 55022:1998+ 1:2000+ 2:2003, CISPR 22 , Class EN
55024:1998+ 1:2001+ 2:2003, IEC 61000- 4 Series EN 61000-3-2 / 2000 & EN 61000-3-3 / 1995.
The equipment also tested and passed in accordance with the European Standard EN55022 for the both
Radiated and Conducted emissions limits.
V-SERIES PLUS
TO WHICH THIS DECLARATION RELATES
IS IN CONFORMITY WITH THE FOLLOWING STANDARDS
EN55022 : 1998,CLSPR 22, Class / EN55024 : 1998IEC 61000-4 Serial / EN61000-3-2 : 2000 / EN
6100-3-3 : 1995 / CFR 47, Part 15/CISPR 22 3rd Edition : 1997, Class / NSI C63.4 : 2001 / CNS
13438 / IEC60950-1 : 2001 / GB4943 : 2001 / GB9254 : 1998 / GB17625.1 : 2003 /EN60950-1 : 2001
CAUTION
Danger of explosion if battery is replaced incorrectly.
Only replace battery with an equivalent type as recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Copyright and Trademark Notice
© 2009 by Tharo Systems, Inc.
I is illegal o pho ocopy or elec ronically ransmi a facsimile of his manual or any por ion of
i s con en s for any means or purpose wi hou he publisher’s permission. Fines of up o
$10,000.00 may be imposed for viola ion.
ll brand or product names are trademarks or registered trademarks of their respective companies.
Specifications are subject to change without notice.

2
Warranty Information .........................................................................................................................................3
1. Product Description ......................................................................................................................................4
General Information.....................................................................................................................................4
Printer Options ..............................................................................................................................................4
2. General Safety Tips......................................................................................................................................6
3. Unpacking the Printer and ccessories....................................................................................................6
4. Identifying Components..............................................................................................................................7
5. Printer Setup .................................................................................................................................................9
USB Installation ..........................................................................................................................................10
6. Control Panel ...............................................................................................................................................11
General Description and Operation.........................................................................................................11
Interpreting LED Messages.......................................................................................................................11
Printer Setup................................................................................................................................................11
uto Sensing................................................................................................................................................12
Turning the See-through Sensor on/off ................................................................................................12
7. Loading Media .............................................................................................................................................13
Ribbon Installation .....................................................................................................................................13
Label Installation ........................................................................................................................................15
Label Roll Core Installation Instructions................................................................................................16
Direct Thermal / Thermal Transfer Mode Switch.................................................................................17
Card / Hang tags Installation...................................................................................................................17
8. Installing the Printer’s Optional ccessories.........................................................................................18
V-Series Stripper Sensor Module Installation Instructions................................................................18
Cutter Module Installation Instructions .................................................................................................21
Compact FL SH Card Slot module with Real-Time Clock ..................................................................23
ppendix . Communication Interfaces .....................................................................................................24
Parallel Interface.........................................................................................................................................24
Serial Interface ...........................................................................................................................................24
USB Interface ..............................................................................................................................................24
ppendix B. Error Messages / Troubleshooting ........................................................................................25
Self Test........................................................................................................................................................25
Dump Mode..................................................................................................................................................25
LED Error Message Descriptions..............................................................................................................26
Problems and Recommended Solutions.................................................................................................27
ppendix C. Maintenance and djustment ................................................................................................28
Cleaning the Thermal Printhead..............................................................................................................28
Thermal Printhead Print Line djustment .............................................................................................29
Thermal Printhead Spring Box Pressure djustment..........................................................................29
Thermal Printhead Replacement .............................................................................................................30
Upgrading the Printer’s Firmware ...........................................................................................................31
Downloading True Type Fonts to the Printer’s Flash Memory ..........................................................32
Clearing Cutter Jams .................................................................................................................................33
Cleaning dhesive from the Cutter Blade .............................................................................................33

3
Warran y Informa ion
The TH RO V-Series Plus Printers are warranted against defects in material or workmanship for 12 months (365
days) from the date of original shipment by TH RO SYSTEMS, INCORPOR TED. This warranty does not cover
normal wear and tear and shall be null and void if the equipment is modified, improperly installed or used, damaged
by accident or neglect, or in the event any parts are improperly installed or replaced by the user.
Since Printhead wear is part of normal operations, a Printhead warranty of 3 months (90 days) from the date of
original shipment by TH RO SYSTEMS, or 25,000 linear meters of use, whichever comes first. To qualify for this
warranty, the Printhead must be returned to TH RO or another authorized service center. lthough the user is not
required to purchase TH RO brand supplies (media and/or ribbons), to the extent it is determined that the use of
other supplies (media and/or ribbons) shall have caused any defect in the thermal Printhead for which a warranty
claim is made, the user shall be responsible for TH RO's customary charges for labor and materials to repair such
defect. To the extent that it is determined that failure to follow the preventive maintenance schedule and
procedures listed in the User Guide shall have caused any defect in the thermal Printhead for which a warranty claim
is made, this limited warranty shall be void. ny Printhead returned to TH RO with scratches or abrasions on the
Printhead at the point of failure will be deemed abused and no warranty replacement will be provided.
TH RO SYSTEMS' SOLE OBLIG TION UNDER THIS W RR NTY SH LL BE TO FURNISH P RTS ND L BOR FOR THE
REP IR OR REPL CEMENT OF PRODUCTS FOUND TO BE DEFECTIVE IN M TERI L OR WORKM NSHIP DURING THE
W RR NTY PERIOD.
s a condition of this warranty, the user must: (a) obtain a TH RO Return uthorization for the Printer, or
subassembly(s); (b) ship the Printer or subassembly(s), transportation prepaid to the authorized service location;
and (c) include with the Product or subassembly(s) a written description of the claimed defect. Unless TH RO
SYSTEMS authorizes return of the entire Product, the user shall return only the subassembly(s). Products returned
shall be packaged in the original packing and shipping container or comparable container. In the event equipment
is not so packaged or if shipping damage is evident, it will not be accepted for service under warranty. Surface
transportation charges for the return of the Printer to the customer shall be paid by TH RO SYSTEMS within the 48
contiguous states and the District of Columbia. Customer shall pay shipping costs, customs clearance, and other
related charges outside the designated area. If TH RO SYSTEMS determines that the Product returned to it for
warranty service or replacement is not defective as herein defined, BUYER shall be subject to a minimal labor charge
and all costs of handling and transportation.
Warran y Exclusions and Condi ions
The above warranties are in lieu of all other warranties, expressed or implied, oral or written, statutory or otherwise,
including any implied warran y of merchan -abili y or fi ness for a par icular purpose.
TH RO SYSTEMS shall not be responsible for the specific application to which any Products are applied, including
but not limited to compatibility with other equipment.
All statements, technical information and recommendations relating to THARO Products are based upon tests
believed to be reliable but do not constitute a guarantee or warranty.
TH RO SYSTEMS SH LL NOT, UNDER NY CIRCUMST NCES WH TSOEVER, BE LI BLE TO BUYER OR NY OTHER
P RTY FOR LOST PROFITS, DIMINUTION OF GOODWILL OR NY OTHER SPECI L OR CONSEQUENTI L D M GES
WH TSOEVER WITH RESPECT TO NY CL IM HEREUNDER. IN DDITION, TH RO SYSTEMS' LI BILITY FOR
W RR NTY CL IMS SH LL NOT, IN NY EVENT, EXCEED THE INVOICE PRICE OF THE PRODUCT CL IMED
DEFECTIVE, NOR SH LL TH RO SYSTEMS BE LI BLE FOR DEL YS IN REPL CEMENT OR REP IR OF PRODUCTS
No salesperson, representative or agent of TH RO SYSTEMS is authorized to make any guarantee, warranty, or
representation in addition to the foregoing warranty.
NO W IVER, LTER TION, DDITION, OR MODIFIC TION OF THE FOREGOING W RR NTIES SH LL BE V LID
UNLESS M DE IN WRITING ND SIGNED BY N EXECUTIVE OFFICER OF TH RO SYSTEMS.

4
1. Produc Descrip ion
General Informa ion
The TH RO V-424 Plus and V-434 Plus Printers are Thermal Transfer/Direct Thermal label Printers
designed for use on a desktop. The compact V-424 Plus and V-434 Plus feature a small footprint to fit
your work environment. The V-Series Plus Printers are constructed of a durable, impact-resistant
composite with a media window for easy viewing and monitoring of remaining supplies.
The TH RO V-424 Plus features a printhead density of 8 dots/mm (203 dots/in) and a maximum print
length of 1727mm (68”). The TH RO V-434 Plus features a printhead density of 12 dots/mm (300
dots/in) and a maximum print length of 762mm (30”).
The TH RO V-424 Plus and V-434 Plus Printers provide 125mm (4.92”) diameter label roll and 300
meter length ribbon capacities giving you the benefit of less downtime and increased production. Both
Printers come standard with built-in USB for high-speed data transfer from your PC.
ccessories available for the TH RO V-424 Plus and V-434 Plus Printers include a Cutter for ticket or
receipt printing applications, an internal Ethernet Card for network connectivity, a Compact FL SH Card
Slot module with a Real-Time Clock for time and date stamping of labels and a Stripper Sensor Module
so the Printers can be used in strip-and-peel applications.
Prin er Op ions
S ripper Sensor Module
The Stripper Sensor Module is used to sense printed labels in strip-and-peel applications. With the
Stripper Sensor Module installed, the printed labels are presented for removal and the used liner feeds
from the Printer and collects on the floor.
Cu er
The optional Cutter can be used to cut labels or tag stock up to a 10-mil (.254mm) thickness. Cutter
options include a choice of: cut after each label, cut after a specific quantity of labels, or cut at the end
of a print job.
Compac FLASH Card Slo module wi h Real-Time Clock
The Printer has the ability to use internal Flash memory for storing downloaded files including graphics
and fonts. This option provides a slot which allows you to install a Compact FL SH card to be used as
additional FL SH memory above and beyond the 4MB of FL SH that is standard in the Printer. This
increases the available space for the storage of these files. The Printer supports Compact FL SH Cards
from 128MB to 1GB. This module also includes a Real-Time Clock for the Time and Date stamping of
your labels.
In ernal E herne Adap er Card
The Internal Ethernet dapter Card provides networking capability to the V-424 Plus and V-434 Plus.
Ex ernal Label S and
The External Label Stand allows the use of label rolls with an outside diameter of 203.2 (8”).
EASYLABEL
®
- Label Design Sof ware for Windows
E SYL BEL
®
labeling software allows you to drive your Printer and create a full range of label formats
with a minimum of effort. E SYL BEL can be installed under Microsoft Windows® on IBM PCs and
compatibles. For further information about E SYL BEL, please contact your TH RO Reseller.

5
Technical Specifica ions - Specifications are subject to change without notice.
Model V-424 Plus V-434 Plus
Resolu ion 203 dpi (8 dot/mm) 300 dpi (12 dot/mm)
Prin Mode Thermal Transfer / Direct Thermal
CPU 32 Bit
Memory 4MB Flash, 8MB SDR M
Prin Speed 50.8mm (2”) ~ 101.6mm (4”)/sec
Prin Leng h 12mm (0.47”) ~ 1727mm (68”) 12mm (0.47”) ~ 762mm (30”)
Max Prin Wid h 108mm (4.25”) 105.7mm (4.16”)
Sensor Type Moveable Reflective sensor; Fixed transmissive; center aligned
Sensor De ec ion Type: Label gap and black mark sensing
Detection: Label length auto sensing and/or program command setting
Media
Label Roll: Max. 125mm (4.92”)
Core Diameter: 25.4mm (1”), 38.1mm (1.5”), 76.2mm (3”)
Width: 25.4mm (1”) ~ 118mm (4.64”)
Thickness: 0.06mm (0.002”) ~ 0.25mm (0.009”)
Ribbon
Length: 300m (981’)
Type: Ink outside thermal transfer ribbons (wax, resin and wax/resin) in
widths of 30 to 110mm (1.88” to 4.33”). Core inner diameter 25.4mm
(1”). Maximum ribbon roll diameter 68mm (2.67”).
Prin er Language TPL (Tharo Programming Language)
Sof ware
EASYLABEL
®
Start
Microsoft Windows Drivers, CUPS (Common UNIX Printing System)
Driver
Residen Fon s
11 resident alphanumeric fonts (including OCR & B), are expandable
eight times horizontally and vertically.
Scalable Font (Code Page 850 & 852)
Downloadable Fon s Windows Bit-map fonts, TrueType fonts and sian fonts
Image Handling BMP and PCX
Bar Codes
Code 39, Code 93, Code 128 (subsets , B, C), UCC/E N-128, UPC- ,
UPC-E, UPC and E N 2 or 5 digit extensions, I 2 of 5, E N-8, E N-13,
Codabar, Postnet, DUN 14, MaxiCode, Plessey, Telepen, FIM, China
Postal Code, RPS 128, PDF417, Data Matrix & QR Code
In erfaces
RS-232 Serial (Baud rate 4800 ~ 115200, XON/XOFF, DSR/DTR)
USB(2.0)
Parallel
Con rol Panel Two Bi-color LEDs: Ready and Status
Function Key: FEED
Power uto Switching 100/240V C, 50/60 Hz
Environmen Operation: 41° F to 104° F (5° C to 40° C)
Storage: -4° F to 122° F (-20° C to 50° C)
Humidi y Operation: 30-85%, non-condensing. Free air.
Storage: 10-90%, non-condensing. Free air.
Prin er Dimensions
Length: 285mm (11.2”)
Height: 171mm (6.8”)
Width: 226mm (8.9”)
Weight: 2.72Kg (6.0 lbs)
Op ions
Cutter
Stripper Sensor Module
Compact FL SH Card Slot module with Real-Time Clock
Internal Ethernet dapter
External Label Stand
EASYLABEL Silver, Gold, Platinum or Multi-User

6
2. General Safe y Tips
CAUTION!
During the print process the Printhead will become hot. Do NOT attempt to clean the Printhead
until it has had time to cool.
The Printhead is the Most Fragile part of your Printer. Do NOT use sharp or hard objects to clean
the Printhead. Do NOT touch the glass surface of the Printhead with your hand.
This Printer is built exclusively to print labels, tickets and tags, continuous paper, etc. Only use
media that is recommended for a direct thermal or thermal transfer Printer.
The Printer is configured for input voltages of 110 to 240 V. Connect only to a power outlet with
a grounded contact. lways ensure the Printer is switched OFF before connecting the power
cord to an electrical outlet.
Do not expose the Printer to moisture or operate it in wet or damp areas.
Remove the power cord from the rear of the Printer when disconnecting or attaching accessories
such as Stripper Sensors, Cutters, etc.
3. Unpacking he Prin er and Accessories
Check the condition of the packaging and contents for possible damage during transit.
NOTICE: Please re ain original boxes and all original packing ma erials in
case he Prin er mus be re urned.
In addition to this manual the following items should be included with your Printer:
Bar Code Printer
Power Cord (110V or 230V)
Switching Power dapter
Ribbon Shaft, Qty. 2
Label Roll Core
Empty Ribbon Roll
Quick Start Guide
ccessories CD: Includes Label Software, Manuals, Windows Drivers and CUPS Driver.
The following additional items are necessary for generating labels from your Printer:
Serial, Parallel, or USB cable
pplicable media (label stock/ribbon)

7
4. Iden ifying Componen s
2
1
3
4
5
6
7
8
1. Open Cover Button
2. Top Cover
3. Label Roll Core
4. Ribbon Rewind Wheel
5. Print Mechanism
6. Ribbon Rewind Shaft + Empty Take Up Core
7. Head Latches (left/right)
8. Front Cover Panel
2
1
3
4
5
1. LED (Ready)
2. LED (Status)
3. FEED Key
4. Compact FL SH Card Slot Module Cover
5. Printhead Pressure djustment Screw (left/right)

8
4
5
1
3
2
1. Ribbon Supply Shaft
2. Label Guide
3. Platen Roller
4.
Print Line djustment
5. Label Sensor
1
2
5
4
6
7
3
1. Fan-Fold Label Slot
2. Power Switch
3. Ethernet Socket (Option)
4. USB Port
5. Parallel Port
6. Serial Port (RS-232)
7. Power Socket

9
5. Prin er Se up
CAUTION!
When choosing a loca ion for he Prin er, ensure ha he Prin er and
opera or remain dry. If he Prin er or he opera or ge we , serious
injury o he opera or or damage o he Prin er may occur.
CAUTION!
Make sure ha he Prin er’s power swi ch is in he “O” or “Off” posi ion
before proceeding wi h he ins alla ion.
1. Plug the lead from the Switching Power dapter into the Printer’s power socket.
2. Plug the supplied power cord into the Switching Power dapter and then plug the other end of the
power cord into a grounded outlet.
3. Select the correct cable for the chosen interface. The Printer can be directly connected to the PC in
one of 3 ways: USB, parallel, or serial. For the connection to the USB port use a suitable USB
cable. For the connection to the PC’s parallel port use a suitable parallel interface cable. If the serial
interface is used make sure the proper serial cable is used. You can find pin assignments and
descriptions for all three interfaces connectors in ppendix .
NOTICE!
For Serial communica ions make sure ha he Serial Por Se ings in he
Prin er are configured he same as in he sof ware you will be using wi h he
Prin er.
4. Connect the Printer to the computer with the selected cable. Then secure the cable using any
screws or clips attached to the connectors. These prevent the connection from working loose.
5. Turn the Printer on, the Ready LED will glow green when the Printer is on.

10
USB Ins alla ion
1. USB is a Plug & Play
facility. Once the
USB cable is
connected from PC
to the Printer, the PC
will automatically
detect the new
device and begin the
installation process.
2. Select ‘Specify a
location’ and specify
the path of the
Printer driver.
3. Follow the
instructions in the
Wizard to complete
the installation.

11
6. Con rol Panel
General Descrip ion and Opera ion
FEED Key
Pressing the FEED key will cause the Printer to advance the media (according to media type) to a
specified stop position. If the Printer is loaded with continuous media the Printer will FEED the media
out a certain length. If the Printer is loaded with labels with gaps or black marks, the Printer will
advance one label at a time. If the label is not sent out in a correct position the sensor must be
calibrated. Follow the instructions for Sensor Calibration in the Maintenance and djustment section of
this manual.
In erpre ing LED Messages
LED Beep Description
Ready Status
Green 1 Normal
Red
(Flashing)
Orange 3
The Printer is printing a
Self-Test Label. Refer to
Appendix B for more
information.
Green
(Flashing)
Orange 3
The Printer is in Dump
Mode. Refer to Appendix B
for more information.
Orange
Or
Green*
Orange
Or
Green*
3
Printer is in Auto-Sensing
Mode.
Red
(Flashing)
The Printer is in firmware
download mode.
*If both of RE DY and ST TUS lights are green when doing uto-Sensing, then the See-through Sensor
is on. If both of RE DY and ST TUS lights are orange, then the See-through Sensor is off.
Prin er Se up
By holding down the FEED key and turning the power on, you will be able to change the Printer settings
depending on how many times the beeps before the FEED key is released. When the Printer is first
powered up, the Printer will beep 3 times quickly, and then will beep slowly after that.
Prin er Se ing Slow Beeps
Self Test 0 beeps
uto Sensing 1 beep
Dump Mode On 2 beeps
Direct Thermal 3 beeps
Thermal Transfer 4 beeps
See Through Sensor ON 5 beeps
Top of Form ON/OFF 6 beeps

12
Au o Sensing
Using uto Sensing the Printer automatically detects and records the label type and length (gap or black
mark paper). Then the Printer can accurately detect the label positions.
1. djust the Moveable Sensor so that it is located in a position to sense the label gaps or black marks.
2. Turn the Printer Off and press and hold the FEED key.
3. Turn the Printer On while holding down the FEED key.
4. The Printer will beep three times. Continue to hold the FEED key down; the Printer will beep again.
Then release the FEED key.
5. The Printer will now detect and record the label size/length.
NOTICE!
If bo h of READY and STATUS ligh s are green when doing Au o-Sensing,
hen he See- hrough Sensor is on. If bo h of READY and STATUS ligh s are
orange, hen he See- hrough Sensor is off.
Turning he See- hrough Sensor on/off
There are two types of Media Sensor in V-Series Plus Printers – a Reflective Sensor and a See-through
Sensor. By default, the Reflective Sensor is turned on and the See-through Sensor is turned off.
The Reflective Sensor may not be able to detect the label gap on labels with thick liner, colored liner, or
graphics. In these cases the See-through Sensor would need to be enabled.
To turn the See-through Sensor on:
1. Turn the Printer Off and press and hold the FEED key.
2. Turn the Printer On while holding down the FEED key.
3. The Printer will beep three times. Continue to hold the FEED key down; wait for the ST TUS light
turn red and RE DY light flash green, then release the FEED key.
4. The Printer will automatically print “SEE-THROUGH SENSOR IS ON”. This indicates that the
See-through Sensor is turned on (and the Reflective Sensor is turned off).
NOTICE!
To urn he See- hrough Sensor off, repea above-men ioned procedures.
Then he Prin er will prin “SEE-THROUGH SENSOR IS OFF” o indica e ha
he See- hrough Sensor is urned off and he Reflec ive Sensor is now on.
NOTICE!
If bo h of READY and STATUS ligh s are green when doing Au o-Sensing,
hen he See- hrough Sensor is on. If bo h of READY and STATUS ligh s are
orange, hen he See- hrough Sensor is off.

13
7. Loading Media
Ribbon Ins alla ion
1. Open the Printer’s Top Cover
by pressing the Open Cover
Buttons on both sides.
2. Release the Print Mechanism
by pushing in on the Head
Latches. The Print
Mechanism will now rotate up.
3. Remove the Ribbon Supply
and Ribbon Rewind Shafts.
4. Place the new Ribbon Roll onto
the Ribbon Supply Shaft and
reinstall the Shaft in the
Printer.

14
5. Feed the ribbon from the
Ribbon Supply Shaft under
the Printhead.
6. Place the empty ribbon core
onto the Ribbon Rewind Shaft
and reinstall the Shaft in the
Printer.
7. Secure the ribbon to the
empty ribbon roll core with
tape or part of a label and
wrap the ribbon around the
core.
8. Close the Print Mechanism by
firmly pressing down on it.
You will hear a click when the
Print Mechanism has been
secured.

15
Label Ins alla ion
1. Open the Printer’s Top Cover
by pressing the Open Cover
Buttons on both sides.
2. Place the roll of label stock
onto the Label Roll Core and
place it in the Printer.
3. Release the Print Mechanism
by pushing in on the Head
Latches. The Print
Mechanism will now rotate
up.
4. Feed the label through the
two Label Guides to the
Tear-off Bar.
5. lign the label guides to the
label edge.
6. Close the Print Mechanism by
firmly pressing down on it.
You will hear a click when the
Print Mechanism has been
secured.

16
Label Roll Core Ins alla ion Ins ruc ions
1” Roll Core Ins alla ion
1.5” roll core ins alla ion
3” roll core ins alla ion

17
Direc Thermal / Thermal Transfer Mode Swi ch
To switch into Direct Thermal (DT) Mode:
1. Turn the Printer Off and press and hold the FEED key.
2. Turn the Printer On while holding down the FEED key.
3. The Printer will beep three times. Continue to hold the FEED key down until the Printer beeps
three more times. Release the FEED key after the third beep.
4. The Printer will print, “NOW IS DIRECT THERM L (DT MODE)”. This indicates that Printer is now
in DT Mode.
To switch into Thermal Transfer (TT) Mode:
2. Turn the Printer Off and press and hold the FEED key.
3. Turn the Printer On while holding down the FEED key.
4. The Printer will beep three times. Continue to hold the FEED key down until the Printer beeps
four more times. Release the FEED Key after the fourth beep.
5. The Printer will print, "NOW IS THERM L TR NSFER (TT MODE)". This indicates that Printer is
now in TT Mode.
Card / Hang ags Ins alla ion
When ins alling card ags, he ag hole
mus align wi h he sensor arrow (as
indica ed), and hen use he Label Guide
o secure he ags.
Tag hole position
Sensor De ec ion Posi ion
Sensor

18
8. Ins alling he Prin er’s Op ional Accessories
The Optional Stripper Sensor Module, Cutter Module, or Compact FL SH Card Slot module with
Real-Time Clock can be easily installed and configured in the field. This section will provide a
component list and installation instructions for these optional accessories.
CAUTION!
Make sure ha he Prin er’s power swi ch is in he “O” or “Off” posi ion
before proceeding wi h he ins alla ion.
CAUTION!
Unplug he power cord from he Prin er before performing any service
on i . Failure o do so could resul in personal injury or damage o he
Prin er!
V-Series S ripper Sensor Module Ins alla ion Ins ruc ions
1 Stripper Sensor Module
2 Screws, Qty. 2
NOTE: The max wid h
when using he S ripper
Sensor Module is 110mm
NOTE: Recommended
Label liner hickness
when using he S ripper
Sensor Module is 0.06mm
± 10% wi h basic weigh
65g/ ㎡
㎡㎡
㎡ ± 6%.
2
1
1. Open the Printer’s top
cover by pressing the
Open Cover Buttons on
both sides.
2. Release the Print
Mechanism by pushing
in on the Head Latches.
The Print Mechanism
will now rotate up.

19
3. The Front Cover Panel
has two tabs, one on
each side. Push these
in to release them and
then remove the Front
Cover Panel as shown.
4. To the right you will see
two sockets. Choose
the socket that has the
same number of pins as
the connector on the
Stripper Sensor
Module. Plug the
connector into that
socket.
5. Position the Stripper
Sensor Module as
shown.
6. Hold the Stripper
Sensor Module while
tightening the screws.
