The handy Them1000 User manual

OPERATOR’S MANUAL & PARTSLIST

MODEL –THEM1000

1000W ELECTRIC LAWNMOWER

Spares & Support: 01793 333212

Please read & understand this manual, paying particular attention to the safety

instructions, before use.

The manufacturer reserves the right to change the product specification and

livery according to continued product improvements.

193886001 08/12/2015

CONTENTS

SPECIFICATIONS

GENERAL SAFETY INSTRUCTIONS

ELECTRICAL CONNECTION

MAINTENANCE & STORAGE

ASSEMBLY

OPERATION

TROUBLE SHOOTING

PARTS DIAGRAM & LIST

WARRANTY

DECLARATION OF CONFORMITY

SPECIFICATIONS

Model

THEM1000

Product Number

193886001

Motor Power

1000 watt

Motor Voltage & Frequency

230-240V/50HZ

No Load Speed

3450 r/min

Cutting Heights

20mm, 40mm &60mm

Max Cutting Diameter

320mm

Cable Length

10m

N.W

8.8 kg

IP Protection

IPX4

LpA

82.5dB(A) KpA=3dB(A)

LwA

90.7dB(A)

LwA Guaranteed

94dB(A)

The manufacturer reserves the right to change the product specification and livery according to

continued product improvements.

This symbol on the product or on its packaging indicates that this product may not be treated as household

waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and

electronic equipment.

For more detailed information about recycling of this product, please contact your local council office, your

household waste disposal service or shop where you purchased the product.

GENERAL SAFETY INSTRUCTIONS

Read and understand the owner’s manual and labels affixed to the machine. Learn its application

and limitations as well as the specific potential hazards. Retain these instructions for future

reference. The operator is responsible for following the warnings & instructions in this manual and

on the product.

Read & understand operator’s manual

before using the machine. Failure to

follow instructions could result in

death or serious injury.

Do not smoke which using this machine

Wear gloves to protect your hands

Do not use near a flame, or sparks

Whenever the machine is in use, safety

glasses/goggles must be worn to

safeguard against flying objects.

Hearing protection must also be used

to protect the operators hearing.

Wear shoes or boots with non- slip sole

Moving Parts

Rotating parts can contact or entangle

hands, feet, hair, clothing or

accessories.

Traumatic amputation or severe

laceration can result

15m

Keep all bystanders & animals at least 15

metres away from the machine during

operation.

If approached, stop the machine

immediately.

Double insulated or class 2 electrical

appliances are products that have been

designed in a way so as not to require a

safety connection to electrical earth

(These products must NOT have a

safety connection to Earth).

Acoustic power level LWA accordance

with directive 2000/14/EC + 2005/88/EC

(Please see machine for actual reading)

To reduce the risk of electric shock,

always unplug tool after use. Always

unplug tool before changing parts or

servicing. Failure to do so could result

in serious injury or death

Do not expose to rain or direct sunlight.

Safety alert symbol. Used to alert you to potential personal injury hazards. Obey all safety messages that

follow this symbol to avoid possible injury.

DANGER

Indicates an imminently hazardous situation which, if not avoided, will result in serious injury.

WARNING

Indicates a potentially hazardous situation which, if not avoided, could result in serious injury

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

CAUTION

Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may

result in property damage.

STAY ALERT

Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect

your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand.

Be aware of what you are doing at all times. Use common sense.

AVOID DANGEROUS CONDITIONS

Make sure there is adequate surrounding workspace. Cluttered areas invite injuries.

Keep your work area clean with sufficient light. Keep the area around the machine clear of obstructions,

grease, oil, rubbish and other debris which could cause persons to fall onto moving parts.

Do not use it in areas where fumes from paint, solvents or flammable liquids pose a potential hazard.

Do not operate the appliance on a slope that is too steep for safe operation.

When on slopes, slow down and make sure you have good footing.

INSPECT YOUR MACHINE

Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and drive

mechanisms. Vibration during use may cause these to loosen.

Form a habit of checking to see that all other tools/equipment are removed from the machines area before

turning it on.

Replace damaged, missing or failed parts before using it. Warning labels carry important information. Replace

any missing or damaged warning labels.

DRESS PROPERLY

Do not wear loose clothing, gloves, scarfs, neckties or jewelry (rings, wrist watches), which can be caught in

moving parts. Protective electrically non-conductive gloves and non-skid footwear are highly recommended

when working. Wear a face or dust mask if the operation is dusty. Always wear safety glasses/goggles and/or

face shields. Everyday eyeglasses have only impact resistant lenses; they are not safety glasses/goggles. Wear

protective hair covering to contain long hair, preventing it from getting caught in machinery.

DO NOT ABUSE THE CABLE

Never carry the machine by the electrical cable or yank it to disconnect the plug from the mains supply.

Keep the cable from heat, oil and sharp edges.

EXTENSION CABLES

Extension cables must be no longer than 50 metres in length. The cable section must be 1.5 mm2for cable

lengths up to 25 metres & 2.5 mm2for cable lengths over 25 metres & 230V to allow sufficient current flow to

the motor.

Improper use of extension cables may cause inefficient operation of the tiller, which can result in overheating

and motor damage.

Only extension cords to H07RN-F specification intended for outdoor purpose may be used. Avoid use of free

and inadequately insulated connections. Connections must be made with protected material suitable for

outdoor use. Make sure that any extension cable connections are dry and safe. Ensure that the extension cable

is carefully laid out avoiding liquids, sharp edges and places where vehicles might run over it. Avoid allowing

the extension cable to come into contact with the tiller tines. Ensure your extension cable is fully extended to

prevent overheating or the risk of fire.

AVOID ELECTRICAL SHOCK

Check the electric circuit is adequately protected and that it corresponds with the power, voltage and

frequency of the machines motor. Do not plug or unplug the motor while standing in or around damp or wet

ground. Do not use the machine in wet or damp areas or expose it to rain. Prevent body contact with

grounded surfaces: pipes, radiators, ranges, and refrigerator enclosures.

Make sure your fingers do not touch the plug’s metal prongs when plugging or unplugging the machine.

KEEP BYSTANDERS AND CHILDREN AWAY

Keep unauthorised persons a minimum distance of 15 metres away from the machine. Do not allow children to

handle, climb on the machine.

DO NOT OVERREACH

Keep proper footing and balance at all times when using the machine. Never stand on the machine. Serious

injury could occur if the moving parts are unintentionally contacted. Do not store anything above or near the

machine where anyone might stand on the machine to reach them.

AVOID INJURY FROM UNEXPECTED ACCIDENT

Keep hands out of the way of all moving parts. Do not place any part of your body or any tool during

operation.

DO NOT FORCE TOOL

Always work within the rated capacity. Do not use the machine for a purpose for which it was not

intended.

NEVER LEAVE MACHINE RUNNING UNATTENDED

Do not leave the machine unattended until it has come to a complete stop.

MAINTAIN YOUR MACHINE WITH CARE

Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full and safest

performance. When maintaining this machine, only the manufacturer’s original replacement parts should be

used. The use of non-original manufacturer parts may invalidate your warranty.

PROTECT THE ENVIRONMENT

Take left over materials to an authorised collection point or follow the stipulations in the country where the

mixer is used. Do not discharge into drains, soil or water.

STORE IDLE EQUIPMENT

When not in use, the machine should be stored in a dry location. Keep the machine away from children and

others not qualified to use it.

ELECTRICAL CONNECTION

Do not connect either core to the earth pin

The insulation on the grounded three metre electrical cord will only remain effective if the original

insulating parts are used for repairs and the spaces between the original insulation are maintained.

The use of a Residual Current Device (“RCD”) with a maximum tripping point of 30mA, on 230V

electrics is recommended. If using an extension cable, plug it directly into the RCD.

MAINTENANCE & STORAGE

WARNING

Improper maintenance & storage of the machine may void your warranty. Keep the machine clean

for better and safer performance.

MAINTENANCE

Before each use, check all nuts & bolts to be sure they are sufficiently tightened.

Keep all moving parts lightly greased, using Multi-purpose grease.

Ensure the breather openings on the motor casing are open and clean from debris. If they are

blocked, the motor could overheat and shut the machine down.

We recommend only manufacturer original parts are used when maintaining this machine.

Failure to do so could invalidate your manufacturer’s warranty.

CAUTION

Any maintenance and repairs carried out, to any electronic component must be undertaken by a

qualified technician.

CLEANING

Keep your machine clean.

Before cleaning, ensure it is unplugged from the mains.

Thoroughly clean the machine at the end of each day’s operation.

Clean the underside of the housing around the blade and deck with a stiff brush!

Clean the air vents, and remove any remaining grass or dirt.

CAUTION

Clean the tool after each use. Failure to carry out proper cleaning can result in damage to the

appliance or cause it to malfunction.

WARNING

Injury may occur when working on the tines. Wear protective gloves.

CAUTION

Wipe off any external material on the motor cover. Do not use petrol, turpentine, lacquer or paint

thinner, dry cleaning fluids or similar products. The use of chemical products or solvents may affect

the properties of the cover which has been produced using high density polyethylene PET.

STORAGE

For years of trouble free service, make sure the machine is clean and dry beforestoring.

Wipe all metal surfaces with an oil-impregnated cloth to protect them from corrosion (non-

resinous oil), or spray a fine coat of oil.

Before storing, clean the machine thoroughly as indicated above.

Store indoors or in a protected area during severe weather and winter months. Fold the Top

Handle over and store in a suitable place.

BLADE REPLACEMENT

CAUTION

Disconnect the mains and wear protective gloves when you attempt any kind of maintenance to

the blade.

WARNING

When the motor has been switched off, the blade will continue to rotate for several seconds, do

not touch the underside of the machine, until the cutting blade has come to a complete stop.

WARNING

Unbalanced blades will cause the lawnmower to vibrate violently - creating a risk of accident.

Check the blades’condition before each use. Sharpen or replace the blade with a new one when

necessary. It is recommended to have this done by an approved Handy dealer, using

recommended replacement parts.

At the end of the mowing season always re-sharpen the cutting blade or, if required, replace the

blade with a new one.

Always have the cutting blade re-sharpened or replaced by a specialist or one of our authorised

service dealers.

To remove and install the blade, follow the below instructions

1. Disconnect the lawnmower plug from the electrical mains plug socket.

2. Wear heavy duty safety gloves, when handling the blade.

3. Turn the mower over, to reveal the blade & blade housing.

4. With the other hand, remove the blade securing bolt & washer, using a suitable spanner.

5. Remove the blade, place the new blade over the central hub and make sure the two small holes

in the blade are located over the lugs on the blade housing.

NOTE: the blade side with stamped text should face outwards.

ASSEMBLY

Remove the machine and contents from the carton. Be sure the carton is empty before discarding.

If you require any assistance with regards to the contents of the machine, please contact us:

Tel: 01793 333212 - Mon –Fri 8.30am –5.30pm (excl. Bank Holidays)

Email: customerservice@handydistribution.co.uk

DESCRIPTION

1. Switch Box

2. Upper Handle

3. Cable Retainer

4. Lower Handle

5. Collection Box

6. Grass Collector Flap

7. Motor Cover

8. Wheel

9. Start Lever

10. Safety Lock Button

1

9

8

7

6

5

4

3

2

10

HANDLE ASSEMBLY

1. Assemble the upper handle (2) to the lower handle (4) with the knob (16), washer (15) and bolt

(14). (See Fig. 5).

2. Plug the two lower handle tubes in the main body holes. (See Fig. 4).

3. Install two lock screws and washers (18 & 19), ensure the handle tube is locked into the mower

body. (See Fig. 4).

COLLECTION BOX ASSEMBLY

1. First, attach the carry handle to the collection box top.

2. Insert the hook, into the box top.

3. Apply downward pressure to the other end of the handle, until a click is heard and the handle

fully located.

4. Connect the first two hooks at the end of the collector: Align the hole in the top box with the

hook in the lower box. Insert the hook through the hole and press it until the hook clicks into

position. (fig. 14)

5. Assemble the other three hooks in the left side: Align the three hooks in this side on the lower

box (5) to the hook holes in the box cover (7), and keep it in the position. As you do this step,

you should make sure that the plastic piece on the lower box is under the cover box (7), and

then keep it in the position. (fig.15 and fig.16)

6. Assemble the other four hooks in the right side as above.

7. Assemble the last hook: Push the flat plate to the hook and make it click into position. (fig. 18)

8. Check the collection box to ensure the box is fitted well, when you do the next step.

9. Lift the grass collector flap of the lawnmower, put the collection box on the hook of mower.

OPERATION

Before operating the machine, please ensure you are fully aware of the below instructions, failure

to do so, could invalidate your manufacturer’s warranty. Completely unwind the electrical cable.

SWITCH ON YOUR LAWNMOWER

1. Before starting the machine, adjust the lawn mower to the cutting height you need. (Refer to the

Lawn Mower Height Adjustment section).

2. Your lawn mower is equipped with a safety switch. To operate the switch, press the lock button

then grasp the start lever to start running.

3. The power will be off when the start lever is released. To restart the mower, repeat step 2 above.

SWITCH OFF YOUR LAWNMOWER

1. Release the start lever. The start lever will return to the stop position automatically.

LAWNMOWER HEIGHT ADJUSTMENT

Prior to making any height adjustment to your machine, please ensure the motor is switch off, the

blade is stationary and the electrical plug removed from the wall socket. The blade will still rotate

for a short time, after the start lever has been released.

1. The lawnmower has three cutting heights, 20mm, 40mm & 60mm.

2. To adjust the front wheels, pull the front axle on either side of the cutter deck in turn and

relocate it in the require position & height.

3. For the rear wheel cutting height adjustment, turn over the unit and locate the rear axle.

4. One end is fixed by a pressure pad and the other end beside the slot is not fixed.

5. Pull the rear wheel axle end with the spring, along the slot and lift the wheel, then relocate it in

the required position.

TIPS DURING OPERATION

MOWING PROCEDURE

1. Always lay the cord on the ground near the outlet in neat, loose coils with the mower end of the

cord on top.

2. It is important to arrange the cord systematically to avoid annoying loops and knots.

3. Starting at the point nearest the electrical outlet, move back and forth across the lawn.

4. Each lawn with its trees, shrubs, and other obstructions requires a different mowing procedure.

A little experimenting will enable you to determine the easiest method of handling the cord on

your lawn.

EMPTYING THE GRASS BOX

1. When the grass box is full. Switch the mower off, disconnect the mower from the mains supply

and wait until the blade has come to a complete stop.

2. Hold the handle of the collection box.

3. Lift the collection box flap.

4. Tilt the collection box backwards, whilst removing it away from the lawnmower.

5. Empty the collection box.

TROUBLESHOOTING

PROBLEM

RESOLUTION

Motor does not run

1. Check the mains connection cable, plug fuse and circuit breaker.

2. Start on short grass or on an area which has already been mown.

3. Unplug the mower. Clean the discharge chute/housing, the blade

must rotate freely.

4. Correct the cuttingheight.

Reduced Motor Power

1. Correct the cuttingheight.

2. Clean the discharge chute/housing.

3. Have the blade re-sharpened or replaced by an authorised service

dealer.

The grass collector does

not fill completely

1. Correct the cuttingheight.

2. Allow the lawn to dry.

3. Have the blade re-sharpened or replaced by an authorised service

dealer.

4. Clean the grille on the grass catcher.

5. Clean the discharge chute/housing.

PARTS DIAGRAM

PARTS LIST

No.

Part No.

Description

Qty

No.

Part No.

Description

Qty

1

QG104‐01

Switch Box Assembly

1

25

QG104‐25

Motor Support

1

2

QG104‐02

Tapping Screw ST4.2*25 B

2

26

QG104‐26

Bearing 6002

1

3

QG104‐03

Upper Handle

1

27

QG104‐27

Big Pulley

1

4

QG104‐04

Hang Line Hook

1

28

QG104‐28

Belt 4PJ457

1

5

QG104‐05

Cable Hook

2

29

QG104‐29

Cord Clamp

2

6

QG104‐06

Flat Gasket Φ6xφ16x1.5

2

30

QG104‐30

Bearing 6902

1

7

QG104‐07

Handle Knob

2

31

QG104‐31

Gasket Φ5xφ12x0.8

4

8

QG104‐08

Nut M6

2

32

QG104‐32

Tapping Screw

ST4.8*19 B

4

9

QG104‐09

Round Head Square Neck

Bolts M6X35

2

33

QG104‐33

Tension Spring

Φ13xφ1.5x12

3

10

QG104‐10

Right Lower Handle

1

34

QG104‐34

Rear Axle

1

11

QG104‐11

Left Lower Handle

1

35

QG104‐35

Front Axle

1

12

QG104‐12

Pan‐Head Screw ST4*12.5

A

2

36

QG104‐36

Front Wheel

2

13

QG104‐13

Motor Cover Handle

1

37

QG104‐37

Main Housing

1

14

QG104‐14

Motor Cover

1

38

QG104‐38

Blade

1

15

QG104‐15

Motor Components

1

39

QG104‐39

Flat Gasket

Φ8xφ20x1.5

1

16

QG104‐16

Motor Fan Blade

1

40

QG104‐40

Hexagon Bolt M8X20

1

17

QG104‐17

Small Pulley

1

41

QG104‐41

Screw ST3*12 A

1

18

QG104‐18

Wheel Securing Clip

4

42

QG104‐42

Protective Cover

Twist Spring

Φ9xφ1.5x6

1

19

QG104‐19

Back Wheel

2

43

QG104‐43

Protective Cover

1

20

QG104‐20

Tapping Screw ST4.2*15 B

8

44

QG104‐44

Collection Box

(Lower)

1

21

QG104‐21

Motor Cover Handle

(Lower)

1

45

QG104‐45

Collection Box Cover

1

22

QG104‐22

Tapping Screw ST4.2*18 B

5

46

QG104‐46

Collection Box Handle

1

23

QG104‐23

Shaft With Retaining Ring

1

47

QG104‐47

Counterweight

1

24

QG104‐24

Bearing 609

1

48

QG104‐48

Tapping Screw

ST4.2*16 A

4

NOTES

_____________________________________________

NOTES

_____________________________________________

NOTES

____________________________________________

GJ HANDY & CO LTD USER WARRANTY POLICY

1. Users Statement of Warranty

Each new machine is warranted against defective material or assembly of material under normal

usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved

in replacing and repairing those parts, which are of original manufacture.

2. Period of Warranty

All Webb, Handy Pro (Brushcutter & Long Handle Hedgecutter only) and Sanli domestic products

2 years from the original date of sale to the first domestic user.

90 days from the original date of sale to the professional/commercial user.

90 days from the original date of sale when used for hire.

Engines as per the manufacturer’s warranty statement which will be supplied with the machine.

1 year from the original date of purchase for Replacement Spare Parts (unless normal wear & tear

component, which are covered for 90 days).

All machines’ must be serviced within the first 12 months from the original date of purchase to

comply with the warranty, failure to do so will invalidate the 2nd year of the warranty.

A reduced warranty period of ninety days applies to those items which are subject to normal wear

and tear (e.g. wheels, tyres, cutter bars, cylinders, bottom blades, belts, cables, grass bags, spark

plugs).

All Handy, Handy Pro (All others), Mowerland and Q-Garden domestic products

1 year from the original date of sale to the first domestic user.

90 days from the original date of sale to the professional/commercial user.

90 days from the original date of sale when used for hire.

Engines as per the manufacturer’s warranty statement which will be supplied with the machine.

1 year from the original date of purchase for Replacement Spare Parts (unless normal wear & tear

component, which are covered for 90 days).

A reduced warranty period of ninety days applies to those items which are subject to normal wear

and tear (e.g. wheels, tyres, cutter bars, cylinders, bottom blades, belts, cables, collection bags,

spark plugs).

All warranty repairs must be undertaken by an authorised service dealer.

These dealers have been accredited by GJ Handy & Co Ltd and agree to only use genuine parts and

follow our repair procedures.

Version 2 06-15

The Handy THEM1000 User manual

Popular Lawn Mower manuals by other brands
