The Handy THMC-A User manual

OPERATOR’S MANUAL & PARTSLIST
MODEL –THMC-A
PETROL MULTICUTTER WITH LINE TRIMMER, PRUNER,
BRUSHCUTTER & HEDGECUTTER
Spares & Support: 01793 333212
Please read & understand this manual, paying particular attention to the safety
instructions, before use.
The manufacturer reserves the right to change the product specification and
livery according to continued product improvements.
THIS PRODUCT REQUIRES ASSEMBLY BEFORE USE.
193853001 02/03/2016

Assembly Is Required
This product requires assembly before use. See the “Assembly” section for instructions.
CONTENTS
SPECIFICATIONS
GENERAL SAFETY INSTRUCTIONS
FUELING
COMPONENTS
ASSEMBLY
OPERATION
GENERAL USE
MAINTENANCE
STORAGE
REPAIRS & SERVICING
NEED ASSISTANCE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
WARRANTY
EC DECLARATION OF CONFORMITY
NOTES
This symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment.
For more detailed information about recycling of this product, please contact your local council office, your
household waste disposal service or shop where you purchased the product.

SPECIFICATIONS
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
Model
THMC-A
Product Number
193853001
Engine Displacement
25.4cm³
Max Output Power
0.75Kw/7800 min¯¹
Fuel Tank Capacity
0.6L
Bore and Stroke
34 x 28mm
Fuel Type
Unleaded Petrol
Fuel Mixture Unleaded Petrol/2-Stroke Oil
25:1 Mineral Oil (see FUEL for synthetic)
Equivalent Spark Plug
Champion RCJ6Y or NGK BPMR7A
Max Engine Idling Speed
3200/min
Min Clutch Engagement Speed
4200/min
Max Engine Speed
9000/min
Fuel Consumption at Max Engine Speed
569g/kwh
Brushcutter
Line Trimmer
Pruner
Hedgecutter
Cutting Diameter
205mm
381mm
24mm
Cutting Length
250mm
370mm
Chain Bar Type
254mm (10”)
Shaft
Straight
Curve
Straight
Straight
Blades
3 (Double Sided)
2 (27 Individual)
Blade Diameter
205mm
Spool Type
Bump Feed, Twin
Line
Line Diameter
2mm Only
Line Length
3m Max
Net Weight
(Empty Tank)
5.7kg
4.7kg
5.8kg
5.8kg
Declared Sound
Pressure Level
96 dB(A)
96 dB(A)
98 dB(A)
98 dB(A)
Declared Sound
Power Level
106 dB(A)
106 dB(A)
108 dB(A)
108 dB(A)
Vibration
8 m/s²
8 m/s²
6.5 m/s²
6.5 m/s²
Gear Ratio
23:17
1:1
19:15
4.25:1
Max Cutting
Speed
6600rpm
7800/min
13.5m/s
2000rpm
Chain Pitch
3/8” 0.050
Chain Links
40
File Required
5/32”

GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine.
Learn its application and limitations as well as the specific potential hazards. Retain these
instructions for future reference. The operator is responsible for following the warnings &
instructions in this manual and on the product.
FOR MORE SPECIFIC INSTRUCTIONS AND SAFETY NOTICES, SEE THE INDIVIDUAL SECTIONS FOR
EACH ATTACHMENT, SUPPLIED WITH THE MULTICUTTER.
Read & understand operator’s manual
before using the machine. Failure to
follow instructions could result in
death or serious injury.
Do not smoke which using this machine
Wear gloves to protect your hands
Do not use near a flame, or sparks
Whenever the machine is in use, safety
glasses must be worn to safeguard
against flying objects.
Hearing protection must also be used
to protect the operators hearing.
If the operator is working in an area
where there is a risk of falling objects,
a safety helmet must also be worn.
POISONOUS GAS HAZARD
Engine exhaust contains carbon monoxide,
a poisonous gas that could kill in minutes.
You cannot see it, smell it or taste it. If you
start feeling sick, dizzy or weak whilst using
this product, shut it off and get to fresh air
IMMEDIATELY. See a doctor. You may have
carbon monoxide poisoning
Wear foot protection
Fire Risk
Fire and its vapors are extremely flammable
& explosive.
Fire or explosion can cause severe burns or
death.
Moving Parts
Rotating parts can contact or entangle
hands, feet, hair, clothing or
accessories.
Traumatic amputation or severe
laceration can result
Hot Surface.
Running engines produce heat. Engine
parts, especially the exhaust, become
extremely hot.
Severe thermal burns can occur on contact
15m
Keep all bystanders & animals at least
15 metres away from the machine
during operation.
If approached, stop the machine
immediately.
Acoustic power level LWA accordance with
directive 2000/14/EC + 2005/88/EC
(Please see machine for actual reading)
Safety alert symbol. Used to alert you to potential personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in serious injury
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION
Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.

STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect
your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand.
Be aware of what you are doing at all times. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluttered areas invite injuries.
Keep your work area clean with sufficient light. Keep the area around the machine clear of obstructions,
grease, oil, rubbish and other debris which could cause persons to fall onto moving parts.
SAFE TRANSPORTATION
Always carry the machine and attachments with the supplied safety guards. If transporting by vehicle, ensure
is it secured horizontally, with the fuel tank at the lowest point, to prevent turnover, fuel spillage or damage.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and drive
mechanisms. Vibration during use, may cause these to loosen.
Form a habit of checking to see that all other tools/equipment are removed from the working area before
turning it on.
Replace damaged, missing or failed parts before using it. Warning labels carry important information. Replace
any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckties or jewelry (rings, wrist watches), which can be caught in
moving parts. Protective electrically non-conductive gloves and non-skid heavy duty footwear are highly
recommended when working. Wear a face or dust mask if the operation is dusty. Always wear safety
glasses/goggles and/or face shields. Everyday eyeglasses have only impact resistant lenses; they are not safety
glasses/goggles. Wear protective hair covering to contain long hair, preventing it from getting caught in
machinery.
CAUTION HOT
Do not touch hot parts of the machine, burn injuries may occur.
DO NOT SMOKE
Do not smoke when using the tiller and ensure caution when handling fuel. We recommend you fuel the
machine at least 3 metres away from where you wish to work, in case any spilt fuel ignites when starting the
engine.
AVOID ELECTRICAL SHOCK
Do not operate near underground electrical cables, telephone lines, pipes or hoses.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons a minimum distance of 15 metres away from the machine. If approached, stop the
machine immediately. Do not allow children to handle, climb on or in the mixer.
USE THE SHOULDER HARNESS
Where possible make use of a shoulder harness when using the machine. Adjust the harness to a comfortable
operating position before using the machine. Maintain a firm grip on both handles during use. Keep your body
clear of the cutting area of the machine.
DO NOT OVERREACH
Keep proper footing and balance at all times when using the machine. Never stand on the machine. Serious
injury could occur if the machine is tipped or if the moving parts are unintentionally contacted. Do not store
anything above or near the machine, where anyone might stand on the machine to reach them.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands & feet out of the way of all moving parts. Do not place any part of your body or any tool e.g. in
the machine during operation. Do not place any moving parts on the ground during start up.
BLOCKAGES
Do not attempt to remove a blockage from a jammed machine before first switching the engine off.
KICKBACK
The Pruner is supplied with a low KICKBACK chain, however sometimes kick back can occur, so always hold the
unit firmly in two hands. The Kickback danger zone on your Pruner is the upper part of the nose of the guide
bar. Never saw using this part of the guide bar, which poses a significant risk for kickback.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use machine for a purpose for which it was not intended.
NEVER LEAVE MACHINE RUNNING UNATTENDED
Do not leave the machine unattended until it has come to a complete stop.

MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately after use. Keep the machine clean to ensure it operates to it’s full and safest
performance. When maintaining this machine, only the manufacturer’s original replacement parts should be
used. The use of non-original manufacturer parts may invalidate your warranty.
PROTECT THE ENVIRONMENT
Take left over materials to an authorised collection point or follow the stipulations in the country where the
mixer is used. Do not discharge into drains, soil or water.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry location. Keep the machine away from children and
others not qualified to use it.

FUELING
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while
smoking. Allow the engine to cool for more than 3 minutes, before re-fueling. Never fuel the
machine with the engine running. Fuel the engine at least 3 metres away from your work area.
Always fuel your machine outdoors.
Use good quality unleaded fuel.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel
system or essential carburetor components. This could result in starting issues which would not be
covered by your manufacturer’s warranty.
To keep fuel fresh, we recommend you use HANDY PARTS –SURE START FUEL ADDITIVE (HP-199)
which is available in 250ml bottles, for 25 litres of fuel.
SURE START
FUEL ADDITIVE
(HP-199)
Helps make machines easier to start
Extends shelf life of petrol up to 2 years
Keeps carburettor & engine clean
Reduces emissions & increases fuel
economy
Only use 2-stroke air cooled engine oil. DO NOT USE automotive or marine oil.
It is recommended that you use a Fuel Mixing Bottle, to ensure the correct fuel mixture is used with
your machine. We recommend HANDY PARTS –FUEL MIXING BOTTLE (HP-120).
The machine has been designed to use 25:1 unleaded petrol to 2-stroke mineral oil fuel ratio.
For semi-synthetic or synthetic oil’s, check the oil manufacturers guidelines to determine the correct
ratio. The fuel mixture should be shaken prior to entering the machine fuel tank.
25:1 Fuel Mixture Ratio
Unleaded
Petrol –litre
Two-Stroke
Mineral Oil - ml
1
40
2
80
3
120
4
160
5
200
Unscrew the fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80%
capacity. This will allow the fuel tank expansion.
Fasten the fuel cap tightly, being careful not to cross-thread. This will also prevent loosening through
vibration during use.
Wipe away any spillage, with an appropriate material.
If the machine has continued leaks, the product should not be started. Never use the machine with
damaged ignition cable or spark plug cap, as there is a risk of sparks.

IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a
maximum of 4-6 weeks.
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start
the engine and drain the carburetor of any remaining fuel. (See Maintenance for further instruction)
Dispose of any unwanted 2-stroke mixture at an authorised recycling point.

COMPONENTS

If you require any assistance with regards to the contents of your Multicutter, please contact us:
Tel: [phone] (Mon to Friday 8.30am to 5.30pm)
Email: [e-mail]
1
Power Unit
19
M5 Hex Bolt & Washer x4
2
Safety Trigger
20
M5 Hex Nut x4
3
Ignition Switch
21
Line Trimmer Shield
4
Shoulder Strap Hook
22
Brush cutter Metal Guard
5
Shoulder Strap
23
Line Trimmer Bump Feed Head
6
Coupler
24
Allen key
7
Hand-wheel
25
Spark Plug Spanner
8
Line Trimmer Shaft
26
Pruner Chain Tension Spanner
9
Hedge trimmer Blade Cover
27
Brush cutter Reversible 3 Tooth Blade
10
Brush cutter Shaft
28
Throttle Lock Button
11
Hedge cutter Attachment
29
Throttle Trigger
12
Pruner Shaft
30
Primer Bulb
13
Sprocket Cover
31
Fuel Tank Cap
14
M8 Hex Nut
32
Choke Lever
15
Pruner Bar
33
Recoil Starter
16
Pruner Chain
34
Exhaust
17
Pruner Chain/Bar Cover
35
Heat Insulation Protector
18
D-Handle
36
Ignition Cap & Spark Plug

ASSEMBLY
POWER UNIT
LOOP HANDLE
The Loop Handle is supplied in two sections, handle & clamp
Position the handle against the black foam grip. DO NOT position over the foam grip. The foam
grip is supplied to prevent vibration
The clamp is positioned on the underside of the shaft.
Line up the holes and enter the M5 Hex Bolts with the washers through the handle & clamp.
The M5 nut will fit within the clamp. Tighten the screws with the supplied Allen Key until secure.
SHOULDER HARNESS
Connect the latch of the Shoulder Strap to the metal harness loop, on the Power Unit shaft.
Adjust the Shoulder Strap to a comfortable position. Make sure any excess strap is secured away
from any moving parts of the machine.
FITTING THE ATTACHMENTS TO THE POWER UNIT
Each Attachment has a spring loaded locking button at the bottom of the shaft. This must be
engaged correctly into the Power Unit Coupler, before you should continue using the machine.
The attachments connect to the power unit by means of a coupler device.
Loosen the Hand-wheel on the Power Unit Coupler.
Push in the locking button on the Attachment shaft.
Align the button with the v-shaped guide recess on the Coupler and slide the two shafts
together to connect the Attachment and Power Unit.
Rotate the Attachment shaft until the locking button locks in the Coupler positioning hole.
Tighten the Hand-wheel securely.
WARNING
If the attachment locking button does not release completely into the positioning hole, the shafts
are not locked in place. Slightly rotate from side to side until the locking button locks.
D-Handle
Foam Grip
Metal Harness
Loop
Hand-wheel
Silver Locking
Button

BRUSH CUTTER
The Brush cutter Attachment, will require you to attach the 3 Toothed Blade & Metal Safety Guard. If
after assembly, you experience vibration through the machine during use, assembly has been
incorrectly completed by the user.
Remove the Blade Nut, this has a left hand thread, so turn clockwise to remove (Fig 1)
Remove the Cupped Washer, Clamp Washer & Flanged Washer (Fig 2)
Remove the three Metal Guard screws with the supplied Allen Key (Fig 3)
Position the Metal Safety Guard over the head of the shaft, aligning the holes and insert the
Metal Guard screws, until securely tightened. (Fig 4)
Fit the Flanged Washer securely. (Fig 5)
Fit the 3 Toothed Blade, over the raised section of the Flanged Washer. (Fig 6)
Fit the Clamp Washer, ensuring the blade is flat against the Flanged Washer. (Fig 7)
Fit the Cupped Washer (Fig 8)
Fit the Blade Nut, this Nut has a left hand thread & therefore to tighten, rotate clockwise. (Fig 9)
Align the locking hole within the Metal Guard and Flanged Washer. Insert the Allen Key to stop
the shaft rotating and firmly tighten the Blade Nut with the Spanner supplied. (Fig 10a & b)

HEDGE CUTTER
The Hedge cutter Attachment is supplied ready assembled.
PRUNER
The Pruner Attachment, will be supplied with the chain affixed to the bar, however you may need to
adjust the tension of the chain prior to first use. (See Maintenance Section For Instruction).
LINE TRIMMER
The Bump Feed Head will be fitted to the Line Trimmer Shaft on delivery. You will need to attach the
guard.
Remove the Locking Knob Bolt and Nut from the Guard
Slide the Shield onto the shaft and metal bracket, located above the Bump Feed Head.
Place the bolt through the guard & metal bracket and affix with the nut, until secured.
Remove the protective cover from the metal cutting knife, affixed to the guard.

OPERATION
POWER UNIT
STARTING A COLD ENGINE
Once you are happy that your Multicutter has been assembled & fuelled, you are now in a position
to start the machine. The attachments should not rotate with the engine idling and the throttle
trigger released. Check the idle screw.
During the first 10 hours of work, run the engine at moderate speed.
Place the Power Unit onto the floor, with the fuel tank at its lowest.
Move the Ignition Switch to the ‘ON’ position.
Move the Choke Lever upwards to the ‘Start’ position.
Push the clear rubber Primer Bulb, 10 times until the fuel mixture fills the bulb.
Squeeze the Safety Lever, the Throttle Lever and push in the Throttle Lock Button with your
thumb. This will assist you in starting the engine, without you needing to operate the throttle
assembly, due to it being locked at half throttle.
Place your left hand on the handle shaft to apply downward pressure.
Pull the Recoil Starter, with a smooth rapid pull for a strong spark, 3 times until the engine fires,
but immediately cuts out.
Move the Choke Lever downwards to the Run position
Pull the Recoil Starter again, with a smooth rapid pull. (Failure to move the Choke Lever to the
Run position could result in engine flooding)
The engine should now start and it is advisable to squeeze the Safety Lever & Throttle to release
the throttle lock.
Allow the engine to run for 10 seconds on normal tick over.
STARTING A WARM ENGINE
Place the Power Unit onto the floor, with the fuel tank at its lowest.
Move the Ignition Switch to the ‘ON’ position
Ensure the Choke Lever is downwards in the Run position.
Pull the Recoil Starter again, with a smooth rapid pull.
If you experience issues in starting the machine, please go to www.YouTube.com & search
‘Starting Your Multicutter’ for a step by step video of the starting procedure.
STOPPING THE ENGINE
Release the throttle trigger and allow the engine to idle for a few moments.
Move the ignition switch to the ‘OFF’ position.
WARNING
Attachments may continue to rotate for a few seconds after the engine has stopped.
Choke Closed
Cold Start
Position
Choke Open
Warm Start or
Run Position

ENGINE ADJUSTMENT
Your Multicutter Power Unit is fitted with a fuel mixture/idle screw. This can sometimes need
adjustment if the engine is running lumpy, cutting out or the attachments are rotating with the
throttle trigger released. Adjustment can assist with the running of the machine.
The screw is bronze, positioned below the Choke Lever and has a spring located behind the
screw head.
Using a small flat head screwdriver (not supplied), tighten the screw clock wise, finger tight.
Using the same flat head screwdriver, loosen the screw (anti-clockwise) 1¼ turns, to ensure the
machine is operating to its optimum level.
GENERAL USE
WARNING
Prior to using the Multicutter, ensure all hardware (bolts, screws & nuts) are securely tightened.
Always have a firm footing and use two hands.
Always position the Power Unit on your right side, with all attachments. Using it on the left
side will expose the user to the exhaust. The trigger handle should be positioned at waist
height. Hot surfaces can result in burns.
Operate the trigger with your right hand & hold the barrier handle with your left hand.
The trigger increases and decreases the power of the engine to the attachment, increasing the
revolution/reciprocation of the attachment.
BRUSH CUTTER
Always keep a firm grip with both hands during operation
The machine should be held at a comfortable position, with the trigger handle at hip height.
Adjust the harness to suit.
Maintain a firm footing in case the machine hits a solid object & kicks back.
Do not use the Brush cutter near fencing, posts, buildings or other immoveable objects
Best results are obtained if you cut from right to left, in a broad sweeping motion.
If a hard object is struck, immediately stop the machine and inspect for damage.
LINE TRIMMER
Always keep a firm grip with both hands during operation
The machine should be held at a comfortable position. Adjust the harness to suit.
Maintain a firm footing in case the machine hits a solid object & kicks back
Cut tall grass from the top down to prevent grass wrapping around the shaft housing & strong
head, which may cause overheating and damage. If grass becomes entangled, stop the engine
completely and remove the grass.

PRUNER
WARNING
The Pruner is supplied with a low KICKBACK chain, however sometimes kick back can occur, so
always hold the unit firmly in two hands. The Kickback danger zone on your Pruner is the upper
part of the nose of the guide bar. Never saw using this part of the guide bar, which poses a
significant risk for kickback.
Position the hook located on the bottom of the head against the branch, to reduce the risk of
the pruner jerking forward.
Ensure the chain is running in the correct direction.
Thin branches can be removed with a single cut, but if the branch is long, it is preferable to cut it
in several pieces, moving towards the main trunk of the tree.
Always check for any damage before each use and replace a damaged chain immediately, with
an approved replacement part.
Before every use, check the level of the chain oil in the reservoir.
During use, check the tension of the chain. (See Maintenance Section For Instruction)
Always fit the supplied blade guard when the Pruner Attachment is not in use.
For larger branches, the 3-point method should be used to prevent breakage.
Do not work at an angle, higher than 60 degree’s, there is a danger of being injured by branches
falling without warning. Also be careful not to trip over grounded branches.
Top
Cutting
Direction
3-point cutting method for larger branches
Do not work at an angle over 60 degree’s
Position cutting
hook against
branch

HEDGECUTTER
To adjust the angle of the Hedge cutter, depress levers A & B as shown below, to allow you to rotate
the Hedge cutter head to the desired angle & fix the locking lever to the gear ring, ensuring the teeth
are locked.
Always have a firm footing and use two hands to hold the machine
It is advisable to cut a hedge from the bottom up, sweeping the cutter head in an arc as you
move along the hedge. The double edged cutter blades allow cutting of your hedge in both
directions.
To cut the top of the hedge, adjust the cutter head to a horizontal position. Hold the cutter head
at an angle of 0-10 degrees as you sweep the head in an arc across the top of your hedge,
towards the outside to allow cuttings to fall to the ground.
Pay special attention to hedges which are positioned along wire fencing. If the cutting blades
make contact with the fence, damage may occur.
Do not use the Hedge Cutter Attachment for periods greater than 45 minutes. Take a break for
10-15 minutes or after using one tank of fuel.
If the blade comes into contact with a stone, wire or other foreign object, stop immediately and
check for any damage to the blades immediately.
Do not attempt to remove any twigs or branches jammed in the cutter blades, without first
turning the engine off.
Always check for any damage before each use and replace a damaged blade immediately, with
an approved replacement part.
Always fit the supplied blade guard when the Hedge Cutter Attachment is not in use.

MAINTENANCE
WARNING
Improper maintenance & storage of the Multicutter may void your warranty.
Keep the Multicutter clean for better and safer performance.
POWER UNIT
The engine of the Multicutter must be switched off, with the Spark Plug cap removed, before the
machine is unassembled, cleaned, serviced or maintained.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumption and allow
abrasive particles to pass in the engine. Remove & clean the air filter regularly to ensure optimum
performance.
Remove the air filter cover, by releasing the securing winged screw from the front of the cover.
Lift off the cover.
Remove the sponge air filter from the housing.
Tap the filter to remove light surface dust.
Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry
completely.
FUEL FILTER
Check the fuel filter periodically, but be careful not to allow dust to enter the fuel tank.
The fuel tank is fitted with a filter, which is situated at the free end of the fuel pipe and can be
extracted by using a piece of hooked wire.
If the filter is dirty on inspection, replace it immediately with an approved replacement part.
If the inside of the fuel tank is dirty, rinse out with petrol.
SPARK PLUG
Check the Spark Plug after every 10-15 hours of use.
Remove the Spark Plug cap
Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it anti-clockwise.
Clean & adjust the electrode gap to 0.6-0.7mm
If the Spark Plug is visibly damaged or worn, replace immediately (See Specification for details)
Install the new/cleaned Spark Plug to finger tightness, before fully tightening with the spanner.
Replace the spark plug with a similar make & model, every 100 hours or once a year (whichever
comes first)
SERVICING
We recommend your Multicutter power unit is serviced after 15 hours of use & thereafter, every 2
years.
Air Filter Cover Screw
Sponge Air Filter

BRUSHCUTTER
GEAR HEAD LUBRICATION
The gearhead is filled with multi-purpose grease. Regularly check the quantity and fill where
necessary. Remove the cross head bolt from the gearhead and fill appropriately. Refit the bolt,
when complete.
BLADE SHARPENING
Never attempt to sharpen the blade. It is reversible, so should be turned over when blunt. The blade
must remain balanced; an unbalanced blade will cause excessive vibration through the machine.
Always check for any damage before each use and replace a damaged blade immediately, with an
approved replacement part.
HEDGECUTTER
GEAR HEAD LUBRICATION
The gearhead is filled with multi-purpose grease. Regularly check the quantity and fill where
necessary. The Hedgecutter has two lubrication grease nipples, one for the angle bevel & one for the
transmission. Remove the grease nipple and fill appropriately. Refit the nipples when complete.
After each use, lubricate the blades with multipurpose spray. This prevents plant sap from fusing the
blades.
Grease Bolt
Grease Nipple
