The Road Wave TRW2 Guide

Questions, problems, missing parts?
Before returning to your retailer, call (1-866-235-5112)
or email ([e-mail]) our customer
service department. They are available from 8:00 a.m. -
5:00 p.m., CST, Monday - Friday. www.arblueclean.com
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model TRW2
READ CAREFULLY
IMPORTANT: RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO MANUAL FOR FUTURE
REFERENCE.
94330-CN
2050 PSI
Electric Pressure Washer

2
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
TABLE OF CONTENTS
SPECIFICATIONS
Model
Max PSI
(lbs/sq. in.)
Max GPM
(Gal/per min) Cold Water Volts Amps
Weight (lbs.)
TRW2 2050 1.4 ✔120 13 22
PRODUCT SPECIFICATIONS
Product Specications...................................................................................................... 2
Package Contents ............................................................................................................. 3
Hardware Contents ........................................................................................................... 3
Safety Information............................................................................................................. 4
Assembly Instructions....................................................................................................... 6
Operating Instructions .....................................................................................................11
Care and Maintenance ................................................................................................... 14
Pump Saver .....................................................................................................................15
Troubleshooting............................................................................................................... 16
Limited Warranty............................................................................................................. 17
Replacement Parts List .................................................................................................. 18

3
PACKAGE CONTENTSPACKAGE CONTENTSPACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
*I Extension Lance 1
J Spray Gun Trigger Lock 1
K Nozzle Cleaning Wire 1
L Detergent Tank 1
M Cord Hook 1
AA 2 1/2” Cabinet Mounting
Screws
4
BB 1 1/4” Wall Dog Screws 2
PART DESCRIPTION QUANTITY
A Hose Holder 1
B Wall Mount 1
*C Rotary Nozzle 1
D O-Ring Replacement Kit 1
*E Quick Connect Nozzles 4
F Power Washer Unit 1
G Soft PVC Hose 1
H Spray Gun 1
AA
BB
2 1/2" Cabinet Mounting Screws
Qty. 4
1 1/4" Wall Dog Screws
Qty. 2
A
G
H
*C
J
K
D
PW909383SS
AA
BB
*E
Soap – Black
0° – Red
15° – Yellow
25° – Green
*I
B
2050
MAX PSI
1.4
MAX GPM
M
L
F
*Packaged on the power washer unit.

4
SAFETY INFORMATIONSAFETY INFORMATIONSAFETY INFORMATION
Please read and understand this entire manual before
attempting to assemble and operate the product.
This manual contains information that relates to
PROTECTING PERSONAL SAFETY and PREVENTING
EQUIPMENT PROBLEMS. It is very important to read this
manual carefully and understand it thoroughly before
using the product. The symbols listed below are used to
indicate this information.
DANGER
Potential hazard that will result in serious injury or loss
of life.
WARNING
Hazard that could result in serious injury or loss of life.
CAUTION
Potential hazard that may result in moderate injury or
damage to equipment.
Note: The word “Note” is used to inform the reader of
something the operator needs to know about the tool.
WARNING
To reduce the risk of injury, the user must read
and understand the instructions before using
this product.
1. Prior to installation of this product, the installation
instructions should be read and completely
understood. The installation instructions must
be read to prevent personal injury and property
damage. Keep these installation instructions in an
easily accessible location for future reference.
2. This mount contains small parts which can act as a
choking hazard if swallowed.
3. CAUTION: The maximum load capacity is 30 lbs.
4. The wall structure must be capable of supporting
at least ve times the maximum load capacity as
indicated. If not, the wall must be reinforced.
5. Recommended mounting surfaces: wood stud
and solid-at concrete/brick. If the mount is to be
installed on any surface other than wood studs, solid
concrete or brick, use suitable hardware.
6. Make sure no water or natural gas lines are present
where the mount is to be installed. Cutting or drilling
into water or natural gas lines could cause personal
injury or property damage.
7. When mounting to wood studs, it is recommended
that a maximum 5/8” particle board be used.
8. Proper installation procedure by yourself or a
qualied service technician, as outlined in the
installation instructions, must be adhered to. Failure
to do so could result in serious personal injury.
9. When mounting to a wall that contains wood studs,
conrm the dead center of the wood stud prior to
installation, it is recommended that the wood studs
be a minimum of 16” apart (if applicable).
10. If you don’t understand these installation
instructions, please consult an installation
specialist.
11. Warning – When using this product basic,
precautions should always be followed, including
the following.
12. Read all the instructions before using the product.
13. Know how to stop the product and bleed pressures
quickly. Be thoroughly familiar with the controls.
14. Keep operating area clear of persons.
15. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
16. Follow the maintenance instructions as specied in
the manual.
17. To avoid personal injury and/or damage to property
and to maximize your power washing experience,
carefully follow all of the safety tips, instructions,
warnings and safeguards and become familiar with
all of the controls.
18. This power washer conforms to CSA and other safety
and consumer standards. DO NOT modify or rebuild
any part of your power washer.
19. DO NOT use your power washer when you are under
the inuence of alcohol or drugs. Use this power
tool carefully and only when you are alert.
20. Watch your balance and footing while using your
power washer. Surfaces become slippery when wet
and are extra slippery when using a detergent or
cleaner.
21. NEVER operate the power washer in bare feet,
sandals, or open-toed shoes.
22. When using the power washer near children, make
sure they are closely supervised by an adult to avoid
injury. NEVER let a child use the power washer.
23. Keep ngers, hands, feet and any part of your body
clear of the stream of high pressure water. The
powerful spray can cause blindness or blast holes in
the skin. It can break a window if you are too close
when you pull the trigger on the spray gun.
24. ALWAYS wear eye protection to prevent injury to
eyes when operating the power washer.
25. To avoid mishaps or injury, ALWAYS use the trigger

5
SAFETY INFORMATIONSAFETY INFORMATIONSAFETY INFORMATION
safety lock when not using the power washer even if
the spraying stops for a moment.
26. The power washer is equipped with a Ground Fault
Circuit Interrupter (GFCI) which greatly reduces the
chance of electric shock while the unit is in use. If
replacement of the plug or cord is needed, use only
identical replacement parts.
27. Point the spray gun in a safe direction when
beginning a power washing session.
28. Warning – NEVER spray directly at a person, animal,
electrical device or the unit itself.
29. When rst using the spray gun, hold the spray gun
and lance with two hands when pulling the trigger
(one hand to pull the trigger and the other to
stabilize the gun assembly) until you get used to the
“kickback” from the spray gun.
30. When you turn the power switch off, water pressure
may remain in the system. To discharge the
pressure, point the spray gun in a safe direction and
pull the trigger.
31. NEVER spray ammable liquids.
32. NEVER use the power washer in areas that contain
combustible dust, liquids or vapors.
33. Avoid contact of the pressure hose with sharp
objects and examine the hose regularly. Replace
if damaged. Due to the high pressure involved, it
cannot be repaired if cut or damaged.
34. Only use detergent specically formulated for power
washers and follow instructions on the detergent’s
label.
35. Protect eyes, lungs, and skin from exposure to
detergent. Dish or laundry soap is too thick and will
clog the nozzle of your detergent bottle.
36. Warning-If connection is made to a potable water
system, the system Should be protected against
backow.
CAUTION
Store the power washer indoors to prevent
the water in the unit from expanding under
freezing conditions. When the water freezes and
expands, your power washer will be damaged and
become inoperable. Or, if storing outdoors, it is
recommended you use pump saver (not included)
to protect pumps.
37. NEVER use hot water with your power washer. It will
overheat and damage the high pressure pump.
38. NEVER leave the power washer unattended while it
is powered “ON”.
39. ALWAYS turn the water supply “ON ” before turning
the power washer power to “ON”. Running the pump
dry will cause damage to the internal components.
40. NEVER use a water supply to your power washer
that exceeds 150 PSI maximum.
41. NEVER disconnect the high pressure hose from the
power washer while the system is pressurized.
42. NEVER permanently engage the trigger mechanism
on the spray gun.
43. NEVER operate the power washer unless all
components are properly and securely connected.
44. NEVER allow the power washer pump to run for
more than one minute after you have turned off the
water supply. This can cause the motor and pump to
overheat and fail.
45. NEVER use lances or other parts that are not
compatible for this specic AR Blue Clean unit.
46. NEVER USE AN EXTENSION POWER CORD since it
defeats the effectiveness of the GFCI and increases
the chance of electrocuting the operator.
47. NEVER spray any electrical outlet with your power
washer.
48. Inspect the power cord before using. DO NOT use it
if it is damaged.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Servicing of a Double-Insulated Appliance
Ground Fault Circuit Interrupter Protection:
This pressure washer is equipped with a ground-fault
circuit-interrupter (GFCI) built into the plugs of the
power-supply cord. This device provides additional
protection from the risk of electric shock. Should
replacement of the plug or cord become necessary,
use only identical replacement parts that include GFCI
protection.
In a double-insulated product, two systems of insulation
are provided instead of grounding. Grounding means
are not provided for a double insulated product, nor
should grounding means be added to the product.
Servicing a double-insulated product requires extreme
care and knowledge of the system, and should only be

6
PREPARATION
ASSEMBLY INSTRUCTIONS
PREPARATION
Wall Mount Installation
After choosing an installation location, use a stud
nder to locate and mark wall stud.
Note: Wall mount screw holes are 16” on center.
Place wall mount (B) onto wall between marked studs.
After making sure wall mount is level, mark four screw
locations.
1
16” on center16” on center
StudStud
2
1
1
2
B
2050
MAXPSI
1.4
MAXGPM
Before beginning assembly of product, make sure all
parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or
damaged, DO NOT attempt to assemble the product.
Please call customer service at 1-866-235-5112.
Replacement parts will be sent no charge.
Estimated Assembly Time: 10 minutes.
Tools Required for Assembly (not included):
Phillips screwdriver, drill, 1.8" drill bit, 3/16" drill bit,
stud nder, pencil, level.
3/16"
1/8"
done by qualied service personnel.
Replacement parts for a double-insulated product must
be identical to the original parts.
A double-insulated product is marked with the words
“Double Insulation” or “Double Insulated”. Product may
also be marked with symbol shown here.
Double Insolated Product
SAFETY INFORMATION

7
ASSEMBLY INSTRUCTIONS
Hardware Used:
3
1/8"
Remove wall mount and drill four 1/8" pilot holes at
marked locations.
2050
MAXPSI
1.4
MAXGPM
4
2
AA
1
1
B
Install wall mount (B) on wall with four 2 1/2" cabinet
mounting screws (AA).
x 4
AA
AA BB
1 1/4"
Wall Dog Screw
Qty. 2
2 1/2" Cabinet
Mounting Screw
Qty. 4
2 1/2" Cabinet Mounting Screw
1
5
2
A
Hose Mount Installation
Place hose holder (A) on wall and mark screw
locations.
Install hose holder (A) with screws (BB).
Note: No anchor needed for sheet rock.
Note: If installing into brick or concrete pre-drill two pilot
holes using a 3/16" bit.
1
6
2
A
BB
1 1/4" Wall Dog Screws
BB
Hardware Used:
x 2
AA BB
1 1/4"
Wall Dog Screw
Qty. 2
2 1/2" Cabinet
Mounting Screw
Qty. 4

8
PREPARATIONASSEMBLY INSTRUCTIONS
7
G
Place Soft PVC hose (G) onto hose holder for storage.
Place power washer unit (F) in place on wall mount (B)
until secure. Unit will click into place. Pull forward on latches that are located on each side of
wall mount until latches snap in correct position, locking
power washer unit to wall mount.
Refer to power washer unit (F) owner’s manual for
operation instructions for the pressure washer.
10
9
F
B
Put spray gun (H) on power washer unit (F).
8
H
F

9
ASSEMBLY INSTRUCTIONS
Locking Spray Gun (before Lance installation) To lock
trigger of spray gun (H), point gun away from you and
turn dial to lock (“3” and “9” position). Squeeze or pull
trigger to make sure it is locked. Always leave in locked
position when not in use. This ensures the gun is in
“safe” mode until it is ready for use. Turn dial to unlock
(“12” and “6” position) to release spray gun trigger.
Note: The trigger lock prevents trigger from being
accidentally engaged.
12
H
1
Locked
Unlocked
ASSEMBLY INSTRUCTIONS
13
*I
H
1
2
14
*I
*E
*C
Extension Lance Installation
While spray gun (H) is in the locked position, insert
lance (*I) into the end of spray gun by inserting and
turning clockwise until fully in place. To remove, turn
counterclockwise.
Attach nozzle (*E) and Rotary nozzle (*C) into end of
lance (*I) by pressing selected nozzle into place. It will
make a “click” sound when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
3
2
11
1
H
G
G
Pull back on collar at one end of soft PVC hose (G).Push
rmly to connect hose to spray gun (H). Twist collar to
secure. Conrm hose is locked into spray gun by slightly
pulling on them. The hose is now securely attached to
spray gun.

10
ASSEMBLY INSTRUCTIONS
3
16
1
2
G
F
G
Pull back on collar at the other end of soft PVC hose
(G). Push rmly to connect hose to power washer unit.
Twist collar to secure. Conrm hose is locked into power
washer unit by slightly pulling on hose. The hose is now
securely attached.
Attach a garden hose to built in garden hose
adapter. The water is now connected to your power
washer.
Note: Flush out garden hose before connecting to
garden hose adapter.
You have now completed the assembly and are ready
to begin using your electric power washer. Read and
observe all safety instructions.
1
2
15
*I
*E
*C
To remove nozzle (*E) and Rotary nozzle (*C), pull back
on collar of lance (*I) and pull out nozzle.
17
NF

11
OPERATING INSTRUCTIONS
• Push the power button to turn the unit on (green
power light will turn on). The unit will turn on for 1 - 2
seconds and shut off. This is a normal function of the
auto start feature.
• Squeeze the spray gun trigger to begin pressure wash-
ing.
• Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
• Release the spray gun trigger to stop the power
washer.
• Allow the motor to come to a complete stop before
squeezing the trigger again.
• Squeezing rapidly will cause the auto start feature to
miss an on/off cycle that may prevent it from turning
on while squeezing trigger after rapid squeezing. Use
slow, deliberate trigger pulls to avoid this.
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Make sure the power switch is off (light will be off).
• Unwind the power cord completely and plug
into a grounded 120 volt outlet.
• Turn on water supply at the faucet to completely
open.
• Turn the safety lock button on the spray gun to
unlocked. While pointing the spray gun in a safe
direction, squeeze the trigger on the spray gun until
there is a steady stream of water, letting the water
and air out of the hose.
OFF ON
K
lock

12
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
1
2
1
•Always test a small area to avoid chance of
damaging the surface.
• To remove the detergent tank, squeeze the clamp on
the tank cap small hose to remove the hose from the
cap. Pull the detergent tank straight out. To replace
the tank,push straight in and then reattach hose with
clamp.
• The power washer will
pull a ratio of water to
detergent of 10:1 or 10
parts water to 1 part
detergent. The detergent
concentration can be
adjusted by turning the
detergent knob on the
top of the machine. Turn
it left for more concentration or turn it right for less
concentration.
• When using the detergent tank, ll it with a properly
formulated detergent or cleaner with water ratio
according to instructions on the container. Close
detergent tank when done lling.
• When using detergent tank, use soap nozzle to draw
detergent from tank. Do NOT use with Foam Cannon.
• To remove detergent tank cap, rst rotate the
cord hook above it out of the way. Grasp the tank
cap by the lower black collar portion and turn
counterclockwise to release and raise it from tank
spout. Do not rotate cap by the upper red portion,it
will not release. To replace the cap, position it onto
spout, grasp cap by black collar and turn clockwise to
secure.

13
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
2
1
2
Removing Power Washer Unit from Wall Mount for
Handheld Operation
• Unlock latches by pulling downward on the latches.
and then lift the power washer unit off the wall mount.
Operation Tips
• If you hear the motor run intermittently when the
trigger is not being squeezed, that is normal.
The pump is priming itself so it is ready to operate
when the trigger is squeezed. Turn off the power
washer if not being used after ve minutes.
• The o-rings on the bayonet end of the nozzle should
be cleaned regularly and lubricated with non-water
soluble grease such as petroleum jelly (not included).
• Keep the nozzle cleaning wire for use in unclogging
the nozzle. If you lose the cleaning wire, a
straightened paper clip also works.
How to Avoid Damaging Surfaces
• Damage to surfaces being cleaned occurs because
the impact force of the water pressure exceeds
the durability of the surface. Bare wood can be
penetrated, paint can be peeled off, etc. You can vary
the force of your power washer by controlling:
1. The angle of the surface being cleaned.
2. The distance of the nozzle from the surface being
cleaned.
• Never use a narrow high pressure stream of water on
soft surfaces susceptible to damage.
• Use the 25˚ angle quick connect nozzle when
cleaning windows. Be sure to place the nozzle
approximately 4 to 5 ft. away from the window with
the nozzle at 45° angle. Squeeze the trigger and vary
the spray pattern and angle until optimum cleaning
efciency is achieved.
Using Power Cord
• Remove the power cord from the unit by swiveling the
cord hook to the right or left. The power cord then can
be slid off to either side of the power washer unit.
• Swivel cord hook back to center when ready to wrap
the cord back into place for storage.

14
CARE AND MAINTENANCE
Detergents
• Use detergents designed for power washers.
Hardware stores or home centers also have power
washer detergents for different cleaning projects. The
cleaning solution should be the consistency of water
in order to prevent clogging your detergent bottle and
nozzle.
• This system applies detergent under low pressure.
The cleaning power of the detergents is enhanced
when applied with low pressure and enough
time is given to break down dirt and grime. The
combination of low pressure and chemical action
is very effective and can be better than scrubbing
if applied properly. Always spray detergent on a dry
surface. Do not pre-soak area. Wetting the surface
rst dilutes the detergent and reduces its cleaning
ability. Do not allow detergent to dry on surface. On
vertical surfaces being cleaned, apply detergent
to lower surfaces and work your way up to prevent
detergent from causing streaks in the dirt and
grime. Rinse detergent by pressure washing from
bottom up for same reason.
• If a stain is particularly tough, it may be necessary
to reapply the detergent and use a bristled brush to
scrub the stain. Subsequent power washing after
brushing should successfully complete your cleaning
job.
Cleaning Garden Hose Adapter
• The screen inside the adapter should be cleaned
periodically. Remove it by dragging a thumb over the
screen with enough pressure to pull the screen and
washer out. Rinse it with clean water and then place
it back in the adapter.
Cleaning Nozzles
• A clogged or partially clogged nozzle can cause
signicant reduction of water pressure coming out
of the nozzle and/or cause the unit to pulsate while
spraying.
• Turn off the unit.
• Turn off the water supply to the unit.
• Relieve any pressure trapped in the hose by
squeezing the trigger 2 - 3 times, then lock the spray
gun by turning the dial to lock (“3” and “9” position).
• Remove the nozzle from the spray gun.
• Using the nozzle cleaner wire provided (or an unfolded
paper clip), insert the wire into the nozzle hole and
move back and forth until debris is dislodged.
• Back ush water through the nozzles using garden
hose and highest pressure available (either standard
water nozzle or use your thumb over the nozzle to
create water pressure for back ush).

15
OPERATING INSTRUCTIONS
Storage
• When your pressure washer session has been
completed, turn off the power switch. Unplug the
power cord from the outlet. Turn off the water supply.
Pull the trigger on the spray gun 2-3 seconds to drain
out the excess water and to release any remaining
water pressure. Do not allow the power washer to run
with no water owing through it.
• Remove high pressure hose from spray gun and
unscrew the other end of the high pressure hose from
the power washer.
• Remove lance from the gun. Place the gun in the
holster on the side.
• Make sure to discard any remaining detergent from
the tank. Residual chemical will stick to the container
which could become contaminated, and can cause
the detergent injector to clog and not function
properly. Flush the tank and nozzle head with clear
water to prevent clogging.
• Wind the power cord around the L-shaped hooks
located on the top of the machine.
• The pressure hose is stored on the hose hook located
on the back of the handle.
• DO NOT store the power washer where it is
exposed to freezing temperatures unless you use
an antifreeze designed for pumps. Store the power
washer indoors to prevent the water in the unit from
expanding under freezing conditions. When the
water freezes and expands, your power washer will
be damaged and become inoperable. Or, if storing
outdoors, it is recommended you use pump saver (not
included) to protect pumps.
CARE AND MAINTENANCE
OPERATING INSTRUCTIONSVERPUMP SAVER
Pump Saver is a product that protects and prolongs
the life of the pump. This will keep the internal parts
of the pump lubricated and protected from freezing
while being stored in ALL climates. It also assists with
protection from internal corrosion.
Pump Saver Instructions
Turn unit off and disconnect the hose and gun before
adding pump saver. Unscrew threaded top from bottle
to remove seal and reattach threaded top to bottle.
Remove black cap from bottle.
1) Place top of pump saver bottle onto the garden hose
adapter previously installed on the pressure washer
inlet.
2) Secure pump saver bottle by turning in a clockwise
direction.
3) Turn the power on.
4) Squeeze bottle to help it into the pump.
5) Turn power off when pump saver exits the
machine’s water outlet.
Note: Instructions on Pump Saver Bottle are generic and
not model specic
2
1

16
TROUBLESHOOTING
PROBLEM CORRECTIVE ACTION
Unit will not turn on. 1. Make sure the power washer is OFF. Plug in the electrical cord to a grounded 120 volt
outlet (no electrical extension cord should be used). If the electrical cord will not plug
into your outlet, your electrical outlet is not properly grounded and should not be used.
Use another electrical outlet.
2. If this did not correct the problem, try plugging into another electrical outlet and repeat
the above procedure. If it is still not working, call Customer Service. 1-866-235-5112
The high pressure
(HP) hose will
not connect/stay
connected to the
spray gun. Is this a
spray gun problem?
1. In most cases, the spray gun is not the problem. The problem is the rubber sleeve
covering the tting at the end of the high pressure hose. It has likely slipped up toward
the metal tip. To x: wiggle, twist and/or pull the rubber sleeve down until the entire tip
is visible plus an 1/8 in. of the metal tting below the tip. Now try to insert the hose tip
into the spray gun. It should “click” into place and will not come out until the hose is
released by pushing in the lever on the underside of the gun. You may cut away the end
of the sleeve with a sharp knife if unable to move the sleeve down. Be careful not to cut
or puncture the hose.
The unit is running
but there is no water
ow.
1. Power should NOT be turned on until water comes through the spray gun. Doing so will
damage the motor.
2. Check the water source.
3. Eject the nozzle from the lance to determine if clog is coming from the nozzle (If nozzle
is clogged, see nozzle cleaning instructions under “Cleaning nozzles”).
4. Take off the lance and just spray out of the spray gun. This will indicate if the problem is
with the lance.
5. Check garden hose adapter for loose connection and the lter for debris.
Why is water leaking
where the high
pressure hose
connects to the spray
gun?
1.
Make sure there is an o-ring at the end of the metal tip of the high pressure hose.
If no o-ring is present, the connection between the hose and spray gun will leak. A
Replacement O-Ring Kit is included in your parts. If you require additional O-rings,
O-Ring Kits are available online at www.arblueclean.com or call Customer Service at
1-866-235-5112 to place an order.
I can’t remove the
lance from the spray
gun. What should I
do?
1. All lances are attached and removed from the spray gun in the same manner. Insert
the end of the lance into the spray gun. Press the spray gun and lance together (about
a 1/8 in.) and turn the collar of the gun clockwise. The lance will lock in place. Remove
the lance by reversing this procedure. Press the spray gun and lance together and turn
counter clockwise. The lance will slide out.
2. Hold the spray gun and lance in an upright position with the nozzle end on the oor.
Push the whole assembly straight down to loosen the connection, and then follow the
removal process again. You may also spray soapy water or a lubricant in the area where
the lance connects to the spray gun
The power washer
turns on for
2 seconds, shuts
off, and will not turn
back on. Do I have a
defective unit?
1. When the water is connected, the accessories are assembled properly, and the power
is turned on, the power washer may turn on for 1 - 2 seconds to prime the pump. It
automatically shuts off and waits for the spray gun trigger to be pressed. When the
trigger is pressed, water starts owing through the pump. The water sensor in the pump
“senses” the moving water and automatically turns the power washer on.
2. Turn the power off, hold in the trigger on the spray gun so that you have a steady stream
of water. While you are holding the trigger open on the spray gun, at the same time, turn
the power on.
TROUBLESHOOTING
If you have any questions regarding the product, please call customer service at 1-866-235-5112

17
TROUBLESHOOTINGLIMITED WARRANTY
This product is under warranty to the original retail consumer against defects in material and workmanship for a
period of 1 (one) year and is a complete “bumper to bumper” warranty including the spray gun, the high pressure
hose and all accessories from the date of purchase. The warranty is not transferable or assignable. This warranty
covers replacement parts. This limited one year warranty applies only to products used in consumer applications
and is void in rental or any commercial application. Reasonable care must be used in conformity with operation and
maintenance instructions in the owner’s manual and quick start guide. Failure to follow these instructions will void
this warranty. This warranty gives you specic legal rights and you may also have other rights which vary from state
to state.
Warranty Process
Keep your original receipt of purchase in case of warranty claim.
If your power washer develops a problem, contact Customer Service:
• Call our toll-free number at 1-866-235-5112. Customer Service is available Monday - Friday 8:00 a.m. to 5:00
p.m. Central Standard Time (CST). A Customer Service Representative will work with you to x the problem.
If the power washer needs to be returned for repair, shipping costs to the company must be paid by the customer. A
Return Merchandise Authorization (RMA) Number will be issued for the return. Upon receiving the power washer,
the company will repair or replace the unit. We will send unit back to customer at no charge.
Please note: Power washers sent to the company without an RMA Number will NOT be accepted and will be
shipped back at the expense of the sender.

LIMITED WARRANTY
18
REPLACEMENT PARTS LIST
Printed in China
PART DESCRIPTION PART #
GSoap QC Nozzle PW4221470
H0° QC Nozzle PW4221430
I15° QC Nozzle PW4221440
J25° QC Nozzle PW4221450
K Garden Hose Adapter PW4221580
PART DESCRIPTION PART #
A Rotary Nozzle PW4220680
B O-Ring Replacement Kit PW909383SS
C Extension Lance PW3400960
D Wall Mount PW4620290
E Spray Gun PW4620420
F Soft PVC Hose PW4221550
Soap – Black
0° – Red
15° – Yellow
25° – Green
F
G
BPW909383SS A
E
C
K
H
I
J
D
2050
MAX PSI
1.4
MAX GPM
For replacement parts, call our customer service department at 1-866-235-5112, 8 a.m. - 5:00 p.m., CST,
Monday - Friday or order online at www.arblueclean.com
