Themis GbE XMC User manual

GbE XMC
GbE XMC
Installation
Manual
Installation
Manual
XMC Module Ethernet card/
Intel 82571 Gigabit Ethernet
Controller based GbE XMC Module
Ethernet Card
Ethernet Card

Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card
Intel 82571 Gigabit Ethernet Controller based GbE XMC Module
GbE XMC Ethernet Card
GbE XMC Ethernet Card

Themis Computer—Rest of World
5 Rue Irene Joliot-Curie
38320 Eybens, France
Phone [phone]
Fax [phone]
Themis Computer—Americas and Pacific Rim
47200 Bayside Parkway
Fremont, CA 94538
Phone [phone]
Fax [phone]
http://www.themis.com
GbEXMCEthernetCard
InstallationManual
Version 1.0—November2011

Copyright © 2011 Themis Computer, Inc.
ALL RIGHTS RESERVED. No part of this publication may be reproduced in any form, by
photocopy, microfilm, retrieval system, or by any other means now known or hereafter invented without
the prior written permission of Themis Computer.
The information in this publication has been carefully checked and is believed to be accurate. However,
Themis Computer assumes no responsibility for inaccuracies. Themis Computer retains the right to
make changes to this publication at any time without prior notice. Themis Computer does not assume
any liability arising from the application or use of this publication or the product(s) described herein.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the United States Government
is subject to the restrictions set forth in DFARS 252.227-7013 (c)(1)(ii) and FAR 52.227-19.
TRADEMARKS
THEMIS®is a registered trademark of Themis Computer, Inc.
Intel®is a registered trademark of the Intel Corporation.
Samtec®is a registered trademark of Samtec, Inc.
All other trademarks or registered trademarks used in this publication are the property of their
respective owners.
Safety Precautions
Instructions regarding safety precautions during installation, operation, or maintenance of the equipment
are given in the section entitled “Safety Instructions” on page iv.
WARNINGS and CAUTIONS
The definitions of WARNINGS and CAUTIONS as used in this document are given in the Preface in
the section entitled “Notes, Cautions, Warnings, and Sidebars”.
GbE XMC Ethernet Card Installation Manual, Version 1.0
November 2011
Manual Part Number: 118470-024
Themis Customer Support
North America, South America, and Pacific Rim
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Web Site: http://www.themis.com

iii
Themis Computer
GbE XMC Ethernet Card Installation Manual
VersionRevisionHistory
Version 1.0.................................................................................... November 2011

iv Themis Computer
GbE XMC Ethernet Card Installation Manual Version 1.0
Safety Instructions
To maximize user safety and ensure correct device operation, all instructions con-
tained in this section should be read carefully.
• The device must be used in accordance with the instructions for use.
• Electrical installations in the room must correspond to the requirements of
respective regulations.
• Take care that there are no cables, particularly mains cables, in areas where
persons can trip over them.
• Do not use a mains connection in sockets shared by a number of other power
consumers. Do not use an extension cable.
• Only use the mains cable supplied.
• The unit is completely disconnected from the power source only when the
power cord is disconnected from the power source. Therefore the power cord
and its connectors must always remain easily accessible.
• Do not set up the device in the proximity of heat sources or in a damp location.
Make sure the device has adequate ventilation.
• All connection cables must be screwed or locked to the chassis housing.
• The device is no longer safe to operate when
— the device has visible damage or
— the device no longer functions.
• In these cases, the device must be shut down and secured against unintentional
operation.
• Repairs may only be carried out by a person authorized by Themis Computer.
• The device may only be opened for the installation and removal of extension
(PCI) cards, memory modules, storage drives, fan housings, power supplies,
and the lithium battery—all in accordance with the instructions given in this
and correlating manuals.
Caution: It is important that the user observe all warnings and instructions
that are on the device and contained in this manual.

v
Themis Computer
GbE XMC Ethernet Card Installation Manual
• If extensions are made to the device, the legal stipulations and the device spec-
ifications must be observed.
• The device must be switched off when removing the top cover; for example,
before installing extension (PCI) cards.
Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices
or micro-circuitry. Proper packaging and grounding techniques are necessary pre-
cautions to prevent damage. Always take the following precautions:
1. Transport boards in static-safe containers such as boxes or bags.
2. Keep electrostatic-sensitive parts in their containers until they arrive at static-
free stations.
3. Always be properly grounded when touching a sensitive board, component, or
assembly.
4. Store electrostatic-sensitive boards in protective packaging or on conductive
foam.
Grounding Methods
Guard against electrostatic damage at workstations by following these steps:
1. Cover workstations with approved anti-static material. Provide a wrist strap
connected to a work surface and properly grounded tools and equipment.
2. Use anti-static mats, heel straps, or air ionizers to give added protection.
3. Handle electrostatic-sensitive components, boards, and assemblies by the case
or the PCB edge.
4. Avoid contact with pins, leads, or circuitry.
5. Turn off power and input signals before inserting and removing connectors or
test equipment.
6. Keep the work area free of non-conductive materials such as ordinary plastic as-
sembly aids and Styrofoam.
7. Use field service tools, such as cutters, and screwdrivers that are conductive.
8. Always place drives and boards PCB-assembly-side down on the foam.

vi Themis Computer
GbE XMC Ethernet Card Installation Manual Version 1.0

v
Themis Computer
Table of Contents
Version Revision History....................................................................................................... iii
Safety Instructions................................................................................................................. iv
Preface.................................................................................................................................. xvii
1. GbE XMC Overview and Specifications .................................................................... 1-1
1.1 Main Features ........................................................................................................ 1-3
1.2 Environmental ........................................................................................................ 1-4
1.3 Technical Support .................................................................................................. 1-4
2. Hardware Installation .................................................................................................. 2-1
2.1 Hardware Installation ............................................................................................. 2-1
A. Connector Pinouts and LEDs ..................................................................................... A-1
A.1 I/O Port Specifications .......................................................................................... A-1
A.2 GbE Card Front-Panel Connectors ....................................................................... A-2
A.2.1 Gigabit Ethernet (GbE) ............................................................................. A-2
A.3 XMC Connector .................................................................................................... A-3
A.4 Front-Panel LEDs ................................................................................................. A-6
A.4.1 PCB LEDs ................................................................................................. A-7
Appendix B. Solder Beads ................................................................................................B-1
B.1 Factory-Configurable Solder Beads .......................................................................B-1
B.1.1 GbE XMC Ethernet Card Solder Beads ....................................................B-1
Index .............................................................................................................................Index-1
Reader Comment Card

vi Themis Computer
GbE XMC Ethernet Card Installation Manual Version 1.0

vii
Themis Computer
Table of Contents
List of Figures
Figure 1 GbE XMC Ethernet Card................................................................................. xvii
Figure 2 Three-Quarter Front View of the XV1,XV2,LV1 .......................................... xviii
Figure 3 Three-Quarter Front View of the GbE Card..................................................... xix
Figure 4 Front View of the GbE Card............................................................................. xix
Figure 1-1 GbE XMC Ethernet Card................................................................................. 1-1
Figure 1-2 GbE XMC Ethernet Card Block Diagram....................................................... 1-2
Figure 1-3 Intel 82571EB Ethernet Controller.................................................................. 1-4
Figure 2-1 Host System Board for the GbE ...................................................................... 2-2
Figure 2-2 GbE XMC Ethernet Card................................................................................. 2-2
Figure A-1 GbE XMC Ethernet Card I/O Ports............................................................... A-1
Figure A-2 Gigabit Ethernet RJ45 Connector Pinout........................................................ A-2
Figure A-3 GbE XMC Connector Pinout......................................................................... A-3
Figure A-4 GbE Front-Panel LEDs.................................................................................. A-6
Figure A-5 GbE PCB LEDs (Bottom Side) ..................................................................... A-7
List of Tables
Table A-1 Gigabit Ethernet Connector-Pin Signals and LED Interpretation .................. A-2
Table A-2 GbE XMC Signal Descriptions....................................................................... A-3
Table A-3 GbE Front-Panel LED Behavior..................................................................... A-6
Table A-4 GbE Card PCB LED Descriptions (Bottom Side).......................................... A-8

viii Themis Computer
GbE XMC Ethernet Card Installation Manual Version 1.0

xvii
Themis Computer
Preface
This document, entitled GbE XMC Ethernet Card Installation Manual, provides a
hardware overview of the Themis GbE XMC Ethernet Card (see Figure 1 below),
which is based on the Intel 82571 Gigabit Ethernet Controller.
GbE XMC Ethernet Card is supported by XMC based platforms such as:
• Themis XV2 6RU VME64 Platform single board computer
• Themis XV1 6RU VME64 Platform single board computer
• Themis LV1 6RU VME64 Platform single board computer
(Each product mentioned above can be found in the following figure:
XV1;XV2;LV1, Figure 2 on page xviii).
.
Figure 1. GbE XMC Ethernet Card

GbE XMC Ethernet Card Installation Manual Version 1.0
xviii Themis Computer
Figure 2. Three-Quarter Front View of the XV1,XV2,LV1

Preface
xix
Themis Computer
The GbE XMC Ethernet Card has been designed to fit on to a standard XMC carrier
board and is provided with installation hardware (not shown). The GbE Card is rug-
ged enough to meet the demands associated with such markets as the military, aero-
space, and telecommunications industries.
Figure 3. Three-Quarter Front View of the GbE Card
Figure 4. Front View of the GbE Card

GbE XMC Ethernet Card Installation Manual Version 1.0
xx Themis Computer
The GbE Card is based upon the Intel 82571 Gigabit Ethernet Controller which uti-
lizes PCI Express architecture v1.0a. The XMC connector also allows for a x4 PCIe
connection between the GbE Card and host board. The small form factor of the GbE
XMC Ethernet Card allows for tight space constraints yet powerfull enough for both
server and workstation network designs.
The GbE XMC Ethernet Card is based on the functionality and capability of the fol-
lowing Intel chip:
• Intel 82571EB Gigabit Ethernet Controller
An overview of GbE XMC Ethernet Card design and specifications is given in
Chapter 1, "GbE XMC Overview and Specifications", of this manual.
Connector pinout, LED, and solder bead descriptions are given in the Appendices of
this manual.
This manual is intended for an experienced system administrator with a knowledge
of networking, VME based platforms, high-speed single board computers, and cur-
rent OS software.
Website Information
Themis Computer corporate and product information may be accessed on the World
Wide Web by browsing the website http://www.themis.com.
Your Comments are Welcome
We are interested in improving our documentation and welcome your comments and
suggestions. You can email your comments to us at [email protected].
Please include the document part number (118470-024) in the subject line of your
email.

Preface
xxi
Themis Computer
Notes, Cautions, Warnings, and Sidebars
The following icons and formatted text are included in this document for the reasons
described:
Note: A note provides additional information concerning the procedure or action
being described.
Caution: A caution describes a procedure or action that may result in damage to
the equipment. This may involve—but is not restricted to—heavy equipment or
sharpobjects. To reduce the risk, follow theinstructionsaccompanyingthis symbol.
Warning: A warning describes a procedure or action that may cause injury or death
to the operator as a result of hazardous voltages. To reduce the risk, follow the in-
structions accompanying this symbol.
Sidebar: A “sidebar” adds detail to the section within which it is placed,
but is not absolutely vital to the description or procedure of the section.

GbE XMC Ethernet Card Installation Manual Version 1.0
xxii Themis Computer

1-1
Themis Computer
1
GbE XMC Overview and Specifications
The Themis GbE XMC Ethernet Card (see Figure 1-1) is a 10/100/1000 ethernet
solution that is installed and runs on XMC-based system platforms such as the The-
mis XV2 single-board computer. The GbE XMC utilizes PCIe v1.0a standard for
high speed and low latency.
SATA
(Not Used)
XMC Connector Intel Ethernet Controller
RJ-45
Ethernet Port
RJ-45
Ethernet Port
Figure 1-1. GbE XMC Ethernet Card
Introductory
Section Chapter

GbE XMC Ethernet Card Installation Manual Version 1.0
1-2 Themis Computer
Figure 1-2 below is a block diagram of the Themis GbE XMC Ethernet Card.
RJ-45
RJ-45
SATA
Connector
Cable
Intel
MUX
I2C FRU
64 kbit
SPI Flash
1 Mbit
SPI EEPROM
128 kbit
LTC3 412A
3.3V to 1.8V
LTC3 412A
3.3V to 1.8V
XMC
Connector
(SATA not used)
3.3V1.8V
1.1V
PCIe x4
LAN0_MDI
LAN1_MDI
SATA
PCIe x1
PCIe x3 / PCIe x4
XMC_GA0
SATA / PCIe x1
82571EB
Note: Not used in a typical configuration. This section is only used when the GbE Card is cabled to a 2PX2 Carrier Board
Figure 1-2. GbE XMC Ethernet Card Block Diagram
