Thenos PlayBox PB1-C User manual

Check Above Ceiling
Determine height & clearance
AREA ABOVE CEILING
Recommended 9in of height and 12in diameter
Actual unit size 7in of height and 97
/
8in diameter
SHEETROCK CEILINGSHEETROCK CEILING
9in
12in
Connectivity Options
NON-METALLIC
(ROMEX™)
ARMORED CABLE
(FLEX/MC)
EMT CONDUIT
(CONNECTOR NOT INCLUDED)
The PB1-C is versatile and may be
connected in the following ways:
Tools Needed
TAPE MEASURE
WIRE STRIPPER
3/16in
HEX BIT
3
/
16
DRILL
PENCIL
SHEETROCK
SAW
PHILLIPS
SCREW
DRIVER
What’s Included
ELEC. OUTLET
15A, 125V
SPEAKER ASSEMBLY
(TWO PARTS)
GRILL
OUTLET SCREWS (2)
6-32 x .75in
FLEX/MC
CABLE CLAMP
NM CABLE CLAMP
(ROMEX™) SADDLE CLAMPS (2)
TEMPLATE
PLAXBOX™
CEILING UNIT
Model PB1 - C
These instructions cover the In-Ceiling
Installation method for the PB1-C.
This version of the PlayBox™is suited
for installation within North America.
Consult a licensed professional and
observe all applicable codes.
1

Pair Sonos™
Using Sonos™app
pair & name speaker
prior to installing
your PlayBox™
Attach Outlet
D
A
Make sure all screws are tightened
to eliminate rattle
Secure PlayBox™
3/16in
HEX BIT
3
/
16
Wire Up
Choose the proper clamp for
your connectivity method
High-voltage component
Consult a licensed professional
observe all applicable codes
Cut Ceiling Hole
Cut the hole and
test fit the PlayBox™
Cut wider as needed
Use the template
to draw a circle
(97
/
8in or 25cm)
A
Proper Grounding
GREEN
GROUND STRAP
TO J-BOX
GROUND
SCREW
GROUND
WIRE
4
7
6
5
32

Lock Speaker
INSIDE OF
PLAYBOX™
DO NOT SKIP
THIS STEP
Attach Safety Cable
Hook Safety Cable from
Speaker Assembly to inside of PlayBox™
DO NOT SKIP
THIS STEP
Cord Store
Wrap Sonos™ power cord
clockwise 4 times around three points
Approx. 8in of cord
should remain
Tabs insert
in slots
Flange on
outside of base
Speaker Assembly
Separate Speaker Cage
by removing two screws (2)
8-32 x .25in
Screws in
Install Speaker
M
o
d
e
l
:
P
B
1
-
C
www.thenos.us/install
3
0
1
w
w
w
.
t
h
e
n
o
s
.
u
s
ceiling hole:
9
⁷
/
8
in or
25
cm
clearance:
9
in or
22
.86
cm
actual:
7
in or
17.78
cm
HEIGHT
In-Ceiling Solution for Sonos
A
U
•
C
M
•
J
D
•
K
S
T
•
L
T
T
H
E
N
O
S
P
B
1
-
C
/
B
6
.
6
/
0
6
1
8
Sonos™ logo should be near
PlayBox™ logo on outer blue flange
Sonos™Logo
exposed
10
8
9
1211

PENDANT
HOUSING
NAKED
HANG SUSPENDED
CEILING
Other Installation Options
Enjoy!
Attach Speaker Grill
Speaker grill attaches
via four Neo-Dymium magnets
Power-Up
Use the built-in
cord hook
to manage
power cord slack
Light verifies speaker has powered up
15
13 14
