LEDPro™ Series
3 Pack Light Kits
4
Installation & Maintenance
For Models:
• LEDPro™ High Output, 3-Pack
(Item #120810)
• LEDPro™ 36, 3-Pack
(Item #120811)
3-YEAR WARRANTY
LEDPro™ 36
LEDPro™ High Output
065_12
TROUBLESHOOTING
SYMPTOM POSSIBLE SOLUTIONS
One or more lights fail to illuminate.
-Check connection from Light(C) to Splitter(B)
-Inspect Lens(D) for algae/debris accumulation
-Ensure bulb is properly seated in housing
-Replace failing bulb (LEDPro™ High Output only)
All lights fail to illuminate.
-Make sure Transformer(A) is properly seated in electrical outlet
-Make sure electrical outlet provides power
-Check Splitter(B) to Transformer(A) connection
-Check connections from Lights(C) to Splitter(B)
-Ensure bulbs are properly seated in housing
ACCESSORIES
DESCRIPTION ITEM NUMBER
LEDPro™ High Output Colored Bulb
(Choose from red, blue, green, yellow, warm white or cool white. Cool
white is standard)
#120812
WARRANTY
The Pond Guy® will repair or replace any LEDPro™ found to be defective within 3
years of the original purchase date. This limited warranty is extended exclusively to
the original purchaser beginning from the date of original receipt. Abuse or misuse
of this product voids all warranty. In case of warranty claims, the product must be
returned to place of purchase accompanied with the original receipt.
thePondguy®
we know ponds™
www.thepondguy.com
thePondguy®
we know ponds™
www.thepondguy.com

SAFETY
WARNING: FOR YOUR PROTECTION, ALWAYS UNPLUG THE UNIT FROM THE
POWER SOURCE BEFORE INSTALLING OR SERVICING. SHOULD THE UNIT
APPEAR TO BE NOT WORKING, DO NOT ATTEMPT TO REACH, REMOVE, OR
DISASSEMBLE BEFORE DISCONNECTING IT FROM THE POWER SOURCE.
1. ALWAYS use a properly grounded AC outlet. Do not immerse the LEDPro™ plug
in water or attempt to use a wet plug.
2. Provide a “drip loop” for the power cord. This is a loop in the cord below the level
of the receptacle or plug that prevents water from traveling along the cord in
the direction of the receptacle.
3. Be sure that a ground fault circuit interrupter (GFCI) is installed in the branch
circuit supplying the pond equipment.
4. NEVER remove the ground pin from the plug.
5. The LEDPro™ is not suitable for use in swimming pools, swimming ponds, or
other situations where humans may make bodily contact with the water. The
LEDPro™ may be used in or out of the water.
6. The power cable cannot be replaced. If the power cable becomes damaged, the
LEDPro™ should be discarded.
7. The LEDPro™ must be used with a transformer which is included.
IMPORTANT: The Pond Guy®, Inc. is not responsible for losses, injury
or death resulting from a failure to follow these safety precautions,
misuse or abuse of equipment.
TECHNICAL SPECS
MODEL # OF LIGHTS WATTAGE ITEM NUMBER
LED Pro™ 36, 3 Pack 3 3 x 3.6 Watts #120811
LEDPro™ High Output, 3 Pack 3 3 x 3 Watts #120810
INSTALLATION
DO NOT TAMPER WITH POWER CORD. LIGHTS MAY BE PLACED IN OR OUT OF WATER.
1) Plug the two-pin connector on the end of each Light(C) cord into the Splitter(B) and
tighten plastic retaining nut.
2) Plug the two-pin connector on the end of the Splitter(B) cord into the
Transformer(A) and tighten plastic retaining nut.
3) Place Lights(C) in desired locations.
4) Make sure Photocell(E) is located out of the water.
5) Plug the Transformer(A) into a standard 110 volt outlet with GFI.
MAINTENANCE
Clean lenses regularly, algae/debris may build up on the lenses and reduce light
intensity. Colored replacement bulbs are available for the LEDPro™ High Output
light kit (see “REPLACEMENT PARTS”).
32
LEDPro™ Series
3 Pack Light Kits
Installation & Maintenance Instructions
WARNING
!
• This unit may get warm when used in an open air
application, turn o power and allow unit to cool
before servicing.
• Operating the lights with missing or damaged covers
can result in risk of re or electrical shock.
• Do not exceed the voltage and wattage indicated on
the transformer.
• Keep away from ammable materials and/or children.
• This light assembly has not been tested or designed
for use in swimming pools and hot tubs.
(B)
(E)
(A)
|-------16’-------|
16’
16’
16’
(C)
(D)
LEDPro™ 36 & LEDPro™ High Output
•(A) Transformer
•(B) Splitter
•(C) Light
•(D) Lens
•(E) Photocell
