HalogenMini™
3 Pack Light Kit
4
Installation & Maintenance
For Models:
• HalogenMini™
(Item #120814)
1-YEAR WARRANTY
065_12
TROUBLESHOOTING
SYMPTOM POSSIBLE SOLUTIONS
One or more lights icker or fail to
illuminate.
-Inspect connection between Transformer(DFHD) and Lights(DFFD)
-Ensure bulb is properly seated in housing
-Replace failing bulb(s)
All lights fail to illuminate.
-Make sure Transformer(A) is properly seated in electrical outlet
-Make sure electrical outlet provides power
-Inspect connection between Transformer(DFHD) and Lights(DFFD)
-Ensure bulbs are properly seated in housing
Lights ll with water.
-Power o unit, unscrew light cover and inspect/reposition/replace
unseated or broken o-ring seals.
-Inspect light cover and housing for cracks or damage
REPLACEMENT PARTS
MODEL DESCRIPTION ITEM NUMBER
HalogenMini™ 10 Watt, MR11 Bulb #190115
HalogenMini™ 4 Pack Colored Filters #190135
WARRANTY
The Pond Guy® will repair or replace any HalogenMini™ found to be defective within 1 year
of the original purchase date. This limited warranty is extended exclusively to the original
purchaser beginning from the date of original receipt. The bulb is not covered by this
warranty. Abuse or misuse of this product voids all warranty. In case of warranty claims, the
product must be returned to place of purchase accompanied with the original receipt.
MR11 Bulb
Colored Filters
12V Transformer
thePondguy®
we know ponds™
www.thepondguy.com
thePondguy®
we know ponds™
www.thepondguy.com

SAFETY
WARNING: FOR YOUR PROTECTION, ALWAYS UNPLUG THE UNIT FROM THE
POWER SOURCE BEFORE INSTALLING OR SERVICING. SHOULD THE UNIT
APPEAR TO NOT BE WORKING, DO NOT ATTEMPT TO REACH, REMOVE, OR
DISASSEMBLE BEFORE DISCONNECTING IT FROM THE POWER SOURCE.
1. ALWAYS use a properly grounded AC outlet. Do not immerse the HalogenMini™ plug in
water or attempt to use a wet plug.
2. Provide a “drip loop” for the power cord. This is a loop in the cord below the level of the
receptacle or plug that prevents water from traveling along the cord in the direction of
the receptacle.
3. Be sure that a ground fault circuit interrupter (GFCI) is installed in the branch circuit
supplying the pond equipment.
4. NEVER remove the ground pin from the plug.
5. The HalogenMini™ is not suitable for use in swimming pools, swimming ponds, or other
situations where humans may make bodily contact with the water. The HalogenMini™
may be used in or out of the water.
6. The power cable cannot be replaced. If the power cable becomes damaged, the
HalogenMini™ should be discarded.
7. The HalogenMini™ must be used with a transformer which is included.
IMPORTANT: The Pond Guy®, Inc. is not responsible for losses, injury or death
resulting from a failure to follow these safety precautions, misuse or abuse of
equipment.
TECHNICAL SPECS
MODEL # OF LIGHTS WATTAGE ITEM NUMBER
HalogenMini™ 3 10 Watts #120814
INSTALLATION
DO NOT TAMPER WITH POWER CORD. LIGHTS MAY BE PLACED IN OR OUT OF WATER.
1) Plug the two-pin Connector(D) on the end of the Lights(B) cord into the
Transformer(A) and tighten plastic retaining nut.
2) Secure desired Lens(C) on each light.
3) Place Lights(B) in desired locations.
4) Plug the Transformer(A) into a standard 110 volt outlet with GFI.
MAINTENANCE
Clean lenses regularly, algae may build up on the lenses and reduce light intensity. Change
bulbs annually or when the lights stop working. To change bulbs unplug lights from the
power source, let them dry and remove the retainer from the HalogenMini™ by pushing
down and turning counter-clockwise. Remove the lens carefully and make sure the “O” ring
stays in place and is not lost. Gently pull out socket, remove the MR11 bulb and replace with
the new MR11 12 volt, 10 watt bulb by aligning the pins of the bulb into the socket. Gently
push the bulb down, DO NOT force it. Re-install the lens and lens retainer ensuring the
“O” ring remains in the correct groove of the HalogenMini™. To maintain a water tight seal,
make sure the lens is ush with the front lip of the rubber seal.
32
HalogenMini™
3 Pack Light Kit
Installation & Maintenance Instructions
WARNING
!
• This unit may get warm when used in an open air
application, turn o power and allow unit to cool before
servicing.
• Operating the lights with missing or damaged covers
can result in risk of re or electrical shock.
• Do not exceed the voltage and wattage indicated on
the transformer.
• Keep away from ammable materials and/or children.
• This light assembly has not been tested or designed for
use in swimming pools and hot tubs.
• Use ONLY recommended MR11
12 volt, 10 watt halogen bulbs.
3'
3'
3'
(A)
(D)
(B)
(C)
HalogenMini
•(A) Transformer
•(B) Light
•(C) Lens
•(D) Connector
